1. Modern Android Development
Computas
24.09.2015
Khiem-Kim Ho Xuan

2. Agenda
• Code behind
• Material Design
• Pattern recommended to use

3. Code behind
• Libraries:
• ButterKnife
• Square Otto Event Bus
• Google Play Services
• Support libraries
• Material design
• Retrofit
• Dagger2
• Picasso
24.09.20153

4. ButterKnife v7.0.1
• Annotate fields with @Bind
• ButterKnife will find the binded ID to the component, layout or resource ids.
• Why?
• Slow reflection. ButterKnife makes sure that the code is generated to perform the view
lookups. Bind delegates to the generated code.
• Resource Binding
• Bind resources. You need to specify the Bind. For example @BindString,
@BindDrawable, @BindColor, @BindDimen
• Non-Activity Binding
• Use @Bind to connect the component or Array. But need to specify @Bind({,….})
• Listener
• Bind listeners for example annotate @OnClick({….}) or @OnItemSelected({…})
• Reset Bind
• Need to clean the bindings when destroying an Activity
or a Fragment using @UnBind.
24.09.20154

5. Square Otto Event Bus v1.3.8
• Decouple parts of the application for communication.
• Acts as a pub-sub.
• Publish
• Tell Subscribers that an action has occured
• Subscribe
• Receive notification that an event has occured
• Annotate method with @Subscribe
• Register to a bus
• Need to call bus.register(this). In order to receive events
24.09.20155
bus.post(new AnswerAvailableEvent(42));
@Subscribe public void answerAvailable(AnswerAvailableEvent event) { //
TODO: React to the event somehow! }

6. Retrofit v2.0
• Turns HTTP API into a Java interface
• Uses Annotations to describe HTTP request:
• URL parameter replacement and query parameter support
• Object convertsion to request body (JSON, protocol buffer)
• Multipart request body and file upload
• Request Method
• Request Body
• Multipart
• Header
24.09.20156
@GET("/group/{id}/users") List<User> groupList(@Path("id") int groupId);
@POST("/users/new") Call<User> createUser(@Body User user);
@Multipart @PUT("/user/photo") Call<User> updateUser(@Part("photo")
RequestBody photo, @Part("description") RequestBody description);
@Headers({ "Accept: application/vnd.github.v3.full+json", "User-Agent:
Retrofit-Sample-App" }) @GET("/users/{username}") Call<User>
getUser(@Path("username") String username);

7. Dagger2
24.09.20157
• Dependency Injection making application loosely coupled.
• Annotations:
• @Module: classes whose methods provide dependencies
• @Provides: methods within module classes
• @Inject: request a dependency (a constructor, field or a method)
• @Component: bridge interface between modules and injection
@Module
public class VehicleModule {
@Provides @Singleton
Motor provideMotor(){
return new Motor();
}
@Provides @Singleton
Vehicle provideVehicle(){
return new Vehicle(new Motor());
}
}
@Inject
public Vehicle(Motor motor){
this.motor = motor;
}
@Singleton
@Component(modules = {VehicleModule.class})
public interface VehicleComponent {
Vehicle provideVehicle();
} // connect @modules with @inject

8. Dagger2
24.09.20158
• When everything is ready
• Obtain instance of the interface and invoke its method.
• Do it inside onCreate method!
• Why Dagger2?
• No reflection: graph validation, configuration and precondition done at compile time.
• Performance gain
public class MainActivity extends ActionBarActivity {
Vehicle mVehicle;
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_main);
VehicleComponent component = Dagger_VehicleComponent.builder().vehicleModule(new VehicleModule()).build();
mVehicle = component.provideVehicle();
Toast.makeText(this, String.valueOf(vehicle.getSpeed()), Toast.LENGTH_SHORT).show();
}
}

9. Picasso v2.5.2
24.09.20159
• Load image into a view based on url or from memory
• Picasso handles:
• ImageView recycling and download cancelation in an adapter
• Complex image transformations with minimal memory usage
• Automatic memory and disk caching.
• Has placeholders in case of loading or failed loading image.
Picasso.with(context) .load(url)
.placeholder(R.drawable.user_placeholder)
.error(R.drawable.user_placeholder_error) .into(imageView);

10. Material Design
• Make all apps flat as paper,
• responsive animations!
• Right color and shadow depths
• Get inspired!
• http://www.materialup.com/

11. Material Design
• Use Androids Design library:
• com.android.support.design
• Snackbar!
• Like Toast, but shows a message at the bottom of
the screen
Snackbar.make(mDrawerLayout, "Your message", Snackbar.LENGTH_SHORT)
.setAction(getString(R.string.text_undo), this)
.show();

12. Shared Element Transition
24.09.201512
• Animate different UI states in an application.
• Built on
• Scene: Defines UI states in an application
• Transition: Defines the animated change between two scenes
• Need to define transition in style.xml and also
<transitionSet
xmlns:android="http://schemas.android.com/apk/res/android">
<changeBounds>
<targets>
<target android:targetId="@id/ivPosterImage" />
<target android:targetId="@id/detailed_image" />
</targets>
</changeBounds>
<changeImageTransform>
<targets>
<target android:targetId="@id/ivPosterImage" />
<target android:targetId="@id/detailed_image" />
</targets>
</changeImageTransform>
</transitionSet>

13. Shared Element Transition
24.09.201513
<style name="AppTheme" parent="AppTheme.Base">
<item name="android:windowContentTransitions">true</item>
<item name="android:windowAllowEnterTransitionOverlap">true</item>
<item name="android:windowAllowReturnTransitionOverlap">true</item>
<item name="android:windowIsTranslucent">true</item>
<!-- specify enter and exit transitions -->
<item name="android:windowEnterTransition">@transition/fade</item>
<item name="android:windowExitTransition">@transition/fade</item>
<!-- specify shared element transitions -->
<item name="android:windowSharedElementEnterTransition">
@transition/change_image_transform
</item><transitionSet xmlns:android="http://schemas.android.com/apk/res/android">
<changeBounds>
<targets>
<target android:targetId="@id/ivPosterImage" />
<target android:targetId="@id/detailed_image" />
</targets>
</changeBounds>
<changeImageTransform>
<targets>
<target android:targetId="@id/ivPosterImage" />
<target android:targetId="@id/detailed_image" />
</targets>
</changeImageTransform>
</transitionSet>
<item name="android:windowSharedElementExitTransition">
@transition/change_image_transform
</item>
</style>

14. Floating Action Button
24.09.201514
• fabSize: set the size of the button
• Normal: 56dp
• Mini: 40dp
• backgroundTint: set the background color of this instance
• rippleColor set color of the ripple effect when pressed
• src: set the icon displayed within the FAB
<android.support.design.widget.FloatingActionButton
android:id=”@+id/fab_normal”
android:layout_width=”wrap_content”
android:layout_height=”wrap_content”
android:src=”@drawable/ic_plus”
app:fabSize=”normal” />

15. EditText Floating Labels
• Display floating labels above EditText fields.
• Gives focus or hint of float.
• Useful to use while data is being input
• You can also add Error message
24.09.201515
<android.support.design.widget.TextInputLayout
android:layout_width="match_parent"
android:layout_height="wrap_content">
<EditText
android:id="@+id/edit_text_email"
android:layout_width="match_parent"/>
</android.support.design.widget.TextInputLayout>
setErrorEnabled(true);
setError(getString(R.string.text_error_message));

16. Navigation View
• Placed within a DrawerLayout
24.09.201516
<android.support.v4.widget.DrawerLayout
xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:app="http://schemas.android.com/apk/res-auto"
android:id="@+id/drawer_layout"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:fitsSystemWindows="true">
<FrameLayout
android:id="@+id/main_content_frame"
android:layout_width="match_parent"
android:layout_height="match_parent" />
<android.support.design.widget.NavigationView
android:id="@+id/navigation_view"
android:layout_width="wrap_content"
android:layout_height="match_parent"
android:layout_gravity="start"
app:headerLayout="@layout/navigation_header"
app:menu="@menu/drawer" />
</android.support.v4.widget.DrawerLayout>

17. TabLayout
• tabMode: set the layout to fixed or scrollable
• tabGravity: set gravity of the tab, either filled (distributed to all available space
between individual tabs) or centre (position tabs in the center of the TabLayout)
• setText() and setIcon()
• Listeners:
• OnTabSelectedListener
• TabLayoutOnPageChangeListener
• ViewPagerOnTabSelectedListener
24.09.201517
<android.support.design.widget.TabLayout
android:id="@+id/sliding_tabs"
android:layout_width="match_parent"
android:layout_height="wrap_content"
app:tabMode="fixed"
app:tabGravity="fill" />
ViewPager pager = (ViewPager)
rootView.findViewById(R.id.viewPager);
pager.setAdapter(new MyPagerAdapter(getActivity().getSupportFragmentManager()));
TabLayout tabLayout = (TabLayout)
rootView.findViewById(R.id.sliding_tabs);tabLayout.addTab(tabLayout.newTab().setText("Tab One"));
tabLayout.addTab(tabLayout.newTab().setText("Tab Two"));
tabLayout.addTab(tabLayout.newTab().setText("Tab Three"));
tabLayout.setupWithViewPager(pager);

18. Coordinator Layout
• Super FrameLayout
• Adds transition view basedon motion of other components
• Lets us adapt layouts based on scroll events.
• Set the property layout_scrollFlags
• enterAlways – view will become visible when a downward scroll event occurs
• enterAlwaysCollapsed – if view has minHeight, it will only
enter at a that height and expand fully once the scrolling view
reached the top.
24.09.201518
<android.support.design.widget.CoordinatorLayout
xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:app="http://schemas.android.com/apk/res-auto"
android:layout_width="match_parent"
android:layout_height="match_parent">
<android.support.v7.widget.RecyclerView
android:layout_width="match_parent"
android:layout_height="match_parent"
app:layout_behavior=
"@string/appbar_scrolling_view_behavior" />
<android.support.design.widget.AppBarLayout
android:layout_width="match_parent"
android:layout_height="wrap_content">
<android.support.v7.widget.Toolbar
app:layout_scrollFlags="scroll|enterAlways" />
<android.support.design.widget.TabLayout
/> </android.support.design.widget.AppBarLayout>
</android.support.design.widget.CoordinatorLayout>

19. Support Toolbar
• Use
• com.android.support.appcompat-v7:<versionnumber>
• Remember to style the toolbar!
24.09.201519
<android.support.v7.widget.Toolbar
android:id=”@+id/my_awesome_toolbar”
android:layout_height=”wrap_content”
android:layout_width=”match_parent”
android:minHeight=”?attr/actionBarSize”
android:background=”?attr/colorPrimary” />
@Override
public void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.blah);
Toolbar toolbar = (Toolbar)
findViewById(R.id.my_awesome_toolbar);
setSupportActionBar(toolbar);
}
<style name="Theme.MyTheme"
parent="Theme.AppCompat.Light">
<!-- Set AppCompat’s actionBarStyle -->
<item name="actionBarStyle">@style/MyActionBarStyle</item>
<!-- Set AppCompat’s color theming attrs -->
<item name="colorPrimary">@color/my_awesome_red</item>
<item
name="colorPrimaryDark">@color/my_awesome_darker_red</item>
<!-- The rest of your attributes -->
</style>

20. Pattern recommended to use
• Model-View-Presenter (MVP)
• User interacts with the View.
• There is one-to-one relationship between View and Presenter means one View is mapped to
only one Presenter.
• View has a reference to Presenter but View has not reference to Model.
• Provides two way communication between View and Presenter.
24.09.201520

21. Firmu – The Cinema Locator App
• Google Play Store
• (Later on Windows Store and IOS).
• Highly inspired by Material Design and modern
mobile development.
• Feedback on the app please 
24.09.201521

22. Pitch (Beta version)
• Google Play Store
• (Later on Windows Store and IOS).
• Highly inspired by Material Design and modern
mobile development.
• Feedback on the app please 
24.09.201522

23. 23 © Computas AS 24.09.2015
Questions?
Computas AS Tel +47 67 83 10 00
Lysaker Torg 45, pb 482 Fax +47 67 83 10 01
1327 Lysaker Org.nr: NO 986 352 325 MVA
Norway www.computas.com
Khiem-Kim Ho Xuan
