The exploration of oceans and sea beds is being made increasingly possible through the development of
Autonomous Underwater Vehicles (AUVs). This is an activity that concerns the marine community and it
must confront the existence of notable challenges. However, an automatic detecting and tracking system is
the first and foremost element for an AUV or an aqueous surveillance network. In this paper a method of
Kalman filter was presented to solve the problems of objects track in sonar images. Region of object was
extracted by threshold segment and morphology process, and the features of invariant moment and area
were analysed. Results show that the method presented has the advantages of good robustness, high
accuracy and real-time characteristic, and it is efficient in underwater target track based on sonar images
and also suited for the purpose of Obstacle avoidance for the AUV to operate in the constrained
underwater environment.
