The document outlines the implementation of a serverless analytics system using Google Cloud's BigQuery and App Engine, managing significant event volumes that range from 20 million to 70 million events per day. It discusses various data types supported by BigQuery and includes details on data loading formats, querying functions, and user-defined functions. Additionally, it covers limits on Data Manipulation Language (DML) operations and presents several example queries related to public datasets.

1. Gabriel PREDA
@eRadical
(Almost) Serverless Analytics System
with BigQuery & AppEngine

2. Agenda
Going Serverless with
AppEngine & Tasks
Pub/Sub, DataStore
BigQuery
Load
Batch
Streaming Inserts
Query
UDF
Export
...some BigQueries...

3. AeonsSome years ago...
~ 500,000 - 2,000,000 events / day
(on average)

4. Some time ago...
~2,000,000 - 22,000,000 events / day
Dec 2014: 57,430,000 events / day
1 day to recompute » 12 hours

5. NOW()
22,000,000 - 70,000,000 events / day
AVG » 40,000,000 events / day
Processing ~30GB-70GB / day
Recompute 1 day » 10-20 minutes

6. serverless?
Desired for: https://www.innertrends.com

7. other... (almost) serverless products
Cloud Functions (alpha - Node.JS)
Cloud DataFlow (Java, Python - beta)

8. BigQuery
https://cloud.google.com/bigquery/docs/

9. BigQuery - data types
● STRING - UTF-8 (2 bytes + encoded string size)
● BYTES - base64 encoded (except in Avro)
● INTEGER - 64-bit signed (8 bytes)
● FLOAT (8 bytes)
● BOOLEAN - true/false, 1/0 only in CSV (1 byte)
● TIMESTAMP ex:”2014-08-19 12:41:35.220 UTC” (8 bytes)
● DATE, TIME, DATETIME - limited support in Legacy SQL
● RECORD - a collection of fields (size of fields)
https://cloud.google.com/bigquery/data-types

10. BigQuery -> loadData()
Formats: CSV, JSON (newline delimited), Avro, Parquet (experimental)
Tools: Web UI, bq, API
Source:
local files,
Cloud Storage, [demo]
Cloud Datastore (backup files),
POST requests,
SQL DML*
Google Sheets
- Federated Data Sources
- Streaming Inserts

11. BigQuery -> loadData()
bq load ...

12. BigQuery -> loadData()
Got some rows?

13. BigQuery -> SELECT … FROM surprise…
query:
SELECT { * | field_path.* | expression } [ [ AS ] alias ] [ , ... ]
[ FROM from_body
[ WHERE bool_expression ]
[ OMIT RECORD IF bool_expression]
[ GROUP [ EACH ] BY [ ROLLUP ] { field_name_or_alias } [ , ... ] ]
[ HAVING bool_expression ]
[ ORDER BY field_name_or_alias [ { DESC | ASC } ] [, ... ] ]
[ LIMIT n ]
];
from_body:
from_item [, ...] | # Warning: Comma means UNION ALL here
from_item [ join_type ] JOIN [ EACH ] from_item [ ON join_predicate ] |
(FLATTEN({ table_name | (query) }, field_name_or_alias)) |
table_wildcard_function
from_item:
{ table_name | (query) } [ [ AS ] alias ]
join_type:
{ INNER | [ FULL ] [ OUTER ] | RIGHT [ OUTER ] | LEFT [ OUTER ] | CROSS }

14. BigQuery -> SELECT … FROM surprise…
Date-Partitioned Tables [demo]
Table Decorators - See the past w/ @
Table Wildcard Functions - TABLE_DATE_RANGE() & TABLE_QUERY()
Interesting functions
- DateTime » UTC_USEC_TO_DAY/HOUR/MONTH/WEEK/YEAR()
» Shifts a UNIX timestamp in microseconds to the beginning of the period it occurs in.
- JSON_EXTRACT[_SCALAR]()
- URL functions » HOST(), DOMAIN(), TLD()
- REGEXP_MATCH(), REGEXP_EXTRACT()

15. bigquery.defineFunction(
'expandAssetLibrary', // Name of the function exported to SQL
['user_id', 'video_id', 'stage_settings'], // Names of input columns
[ {'name': 'user_id', 'type': 'integer'}, // Output schema
{'name': 'video_id', 'type': 'string'},
{'name': 'asset', 'type': 'string'} ],
expandAssetLibrary // Reference to JavaScript UDF
);
function expandAssetLibrary(row, emit) { …………………………
emit({ user_id: row.user_id, video_id: row.video_id, asset: ss.url.replace('http://', ''));
}
BigQuery -> User Defined Functions

16. BigQuery -> DML
Standard SQL only
Maximum UPDATE/DELETE statements per day per table: 48
Maximum UPDATE/DELETE statements per day per project: 500
Maximum INSERT statements per day per table: 1,000
Maximum INSERT statements per day per project: 10,000

17. BigQuery -> export()
To: Google Cloud Storage
Format: CSV, JSON [.gz], Avro
…1G files

18. BigQuery -> some (Big)Queries
SELECT year, count(1)
FROM [bigquery-public-data:samples.natality]
WHERE father_age < 18
GROUP BY year
ORDER BY year
SELECT year, count(1)
FROM [bigquery-public-data:samples.natality]
WHERE mother_age < 18
GROUP BY year
ORDER BY year
SELECT table_id, row_count, CEIL(size_bytes/POW(1024, 3)) AS gb
FROM [bigquery-public-data:ghcn_m.__TABLES__] ORDER BY gb DESC

19. BigQuery -> some (Big)Queries
SELECT REGEXP_EXTRACT(path, r'.*.(.*)$') AS file_extension,
COUNT(1) AS k
FROM [bigquery-public-data:github_repos.files]
GROUP BY file_extension
ORDER BY k DESC
LIMIT 20
SELECT table_id, row_count,
CEIL(size_bytes/POW(1024, 3)) AS gb
FROM [bigquery-public-data:github_repos.__TABLES__]
ORDER BY gb DESC
