RbCUDA and ArrayFire gem has an outstanding performance and can handle real world problems by crunching huge datasets. Deep learning libraries for Ruby with GPU acceleration are on their way. In this talk I would like to show how RbCUDA and ArrayFire help you easily accelerate your code.

1. GPU Accelerated
Libraries for
Ruby
Prasun Anand

2. About me
● SciRuby Contributor
● Google Summer of Code 2016, 2017
● Genenetwork project
● Ruby Grant 2017
● Projects:
○ JRuby port of NMatrix
○ ArrayFire gem
○ RbCUDA

3. Scientific Computing

4. Why should Python
programmers have all the
fun ?

5. Arrays / Matrices

6. BLAS and LAPACK

7. GPU Computing is not easy !

8. CUDA and OpenCL

10. Af_Array
[1] pry(main)> a = ArrayFire::Af_Array.new 2, [2,2],[1,2,3,4]
No Name Array
[2 2 1 1]
Offsets: [0 0 0 0]
Strides: [1 2 4 4]
1.0000 3.0000
2.0000 4.0000
=> #<ArrayFire::Af_Array:0x000000020aeab8>

11. Af_Array
[1] pry(main)> a = ArrayFire::Af_Array.new 2, [2,2],[1,2,3,4]
No Name Array
[2 2 1 1]
Offsets: [0 0 0 0]
Strides: [1 2 4 4]
1.0000 3.0000
2.0000 4.0000
=> #<ArrayFire::Af_Array:0x000000020aeab8>

12. Af_Array
[1] pry(main)> a = ArrayFire::Af_Array.new 2, [2,2],[1,2,3,4]
No Name Array
[2 2 1 1]
Offsets: [0 0 0 0]
Strides: [1 2 4 4]
1.0000 3.0000
2.0000 4.0000
=> #<ArrayFire::Af_Array:0x000000020aeab8>

13. Af_Array
[1] pry(main)> a = ArrayFire::Af_Array.new 2, [2,2],[1,2,3,4]
No Name Array
[2 2 1 1]
Offsets: [0 0 0 0]
Strides: [1 2 4 4]
1.0000 3.0000
2.0000 4.0000
=> #<ArrayFire::Af_Array:0x000000020aeab8>

14. [2] pry(main)> b = a + a
No Name Array
[2 2 1 1]
Offsets: [0 0 0 0]
Strides: [1 2 4 4]
2.0000 6.0000
4.0000 8.0000
=> #<ArrayFire::Af_Array:0x000000020625c8>

15. [1] pry(main)> left = ArrayFire::Af_Array.new 2 , [3,3] , [1, 4, 6, 4, 11 , 2 ,-5, 8, 10]
No Name Array
[3 3 1 1]
1.0000 4.0000 -5.0000
4.0000 11.0000 8.0000
6.0000 2.0000 10.0000
=> #<ArrayFire::Af_Array:0x000000014e56c8>
[2] pry(main)> right = ArrayFire::Af_Array.new 2 , [3,2] , [1, 0, 8, 10, -11, 8]
No Name Array
[3 2 1 1]
1.0000 10.0000
0.0000 -11.0000
8.0000 8.0000
=> #<ArrayFire::Af_Array:0x00000001591db0>

16. [3] pry(main)> result = ArrayFire::BLAS.matmul(left, right, :AF_MAT_NONE, :AF_MAT_NONE)
No Name Array
[3 2 1 1]
-39.0000 -74.0000
68.0000 -17.0000
86.0000 118.0000
=> #<ArrayFire::Af_Array:0x000000016136f8>

17. VALUE arf_init(int argc, VALUE* argv, VALUE self)
{
afstruct* afarray;
Data_Get_Struct(self, afstruct, afarray);
dim_t ndims = (dim_t)NUM2LONG(argv[0]);
dim_t* dimensions = (dim_t*)malloc(ndims * sizeof(dim_t));
dim_t count = 1;
for (size_t index = 0; index < ndims; index++) {
dimensions[index] = (dim_t)NUM2LONG(RARRAY_AREF(argv[1], index));
count *= dimensions[index];
}
double* host_array = (double*)malloc(count * sizeof(double));
for (size_t index = 0; index < count; index++) {
host_array[index] = (double)NUM2DBL(RARRAY_AREF(argv[2], index));
}
af_create_array(&afarray->carray, host_array, ndims, dimensions, f64);
return self;
}

18. static VALUE arf_matmul(VALUE self, VALUE left_val, VALUE right_val, VALUE left_prop_val, VALUE
right_prop_val){
afstruct* left;
afstruct* right;
afstruct* result = ALLOC(afstruct);
Data_Get_Struct(left_val, afstruct, left);
Data_Get_Struct(right_val, afstruct, right);
af_mat_prop left_mat_prop = arf_mat_type_from_rbsymbol(left_prop_val);
af_mat_prop right_mat_prop = arf_mat_type_from_rbsymbol(right_prop_val);
af_matmul(&result->carray, left->carray, right->carray, left_mat_prop, right_mat_prop);
return Data_Wrap_Struct(CLASS_OF(left_val), NULL, arf_free, result);
}

19. BLAS functionalities
● Matmult
● Transpose
LAPACK functionalities
● Det
● Inverse
● Norm
● Qr
● Cholesky
● Svd
● lu

20. Statistics
● Mean
● Median
● Variance

21. Benchmarks
● AMD FX 8350 octacore processor
● Nvidia GTX 750Ti GPU
● Double dtype

23. 10 X
Faster than NMatrix-Ruby-Lapack

27. 10,000 X
Faster than NMatrix-Ruby

31. 100,000 X
Faster than NMatrix-Ruby-BLAS

34. RbCUDA

35. GPU Array
● Generic pointer used to handle an array of elements on the GPU.
● Memory copying from CPU to GPU and vice-versa.
● Interfaced with NMatrix and NArray

36. vadd_kernel_src = <<-EOS
extern "C" {
__global__ void matSum(int *a, int *b, int *c)
{
int tid = blockIdx.x;
if (tid < 100)
c[tid] = a[tid] + b[tid];
}
}
EOS
f = compile(vadd_kernel_src)
RbCUDA::Driver.run_kernel(f.path)

37. ● CuBLAS
● CuSolver
● CuRand

38. Benchmarks
● AMD FX 8350 octacore processor
● Nvidia GTX 750Ti GPU
● Double dtype

40. 1,000,000 X
Faster than NMatrix-Ruby-BLAS

43. Future Work
● Image Processing APIs and Indexers
● Multiple dtypes
● RbCUDA is under active development.
● Project RbCUDA is being funded by Ruby Association
(Ruby Grant 2017)

44. Hobby Projects
1. Synapse : A Ruby first Deep Learning Library
2. Ninjaplot : A plotting library

45. ● https://github.com/arrayfire/arrayfire-rb
● https://github.com/prasunanand/rbcuda
● https://github.com/prasunanand/synapse
● https://github.com/prasunanand/ninjaplot
Contributions are Welcome!

46. Acknowledgements
1. Pjotr Prins
2. Pradeep Garigipati
3. Kenta Murata

47. Thanks!
Github: prasunanand
Twitter: @prasun_anand
Blog: prasunanand.com

48. Questions
