Embedded platforms are projected to integrate hundreds of cores in the near future, and expanding the
interconnection network remains a key challenge. We propose SNet, a new Scalable NETwork paradigm
that extends the NoCs area to include a software/hardware dynamic routing mechanism. To design routing
pathways among communicating processes, it uses a distributed, adaptive, non-supervised routing method
based on the ACO algorithm (Ant Colony Optimization). A small footprint hardware unit called DMC
speeds up data transfer (Direct Management of Communications). SNet has the benefit of being extremely
versatile, allowing for the creation of a broad range of routing topologies to meet the needs of various
applications. We provide the DMC module in this work and assess SNet performance by executing a large
number of test cases.
APPLYING GENETIC ALGORITHM TO SOLVE PARTITIONING AND MAPPING PROBLEM FOR MESH...ijcsit
This paper presents a genetic based approach to the partitioning and mapping of multicore SoC cores over a NoC system that uses mesh topology. The proposed algorithm performs the partitioning and mapping by reducing communication cost and minimizing power consumption by placing those intercommunicated cores as close as possible together. A program developed in C++ in which the provided specification of the multicore MPSoC system captures all data dependencies before any start of the design process. Experimental results of several multimedia benchmarks demonstrates that the genetic-based approach able to find different satisfied implementations to the problem of partitioning and mapping of MPSoC cores over mesh-based NoC system that satisfies design goals.
Simulation Issues in Wireless Sensor Networks: A SurveyM H
This paper presents a survey of simulation tools and systems for wireless sensor networks. Wireless sensor network modelling and simulation methodologies are presented for each system alongside judgments concerning their relative ease of use and accuracy. Finally, we propose a mixed-mode simulation methodology that integrates a simulated environment with real wireless sensor network testbed hardware in order to improve both the accuracy and scalability of results when evaluating different prototype designs and systems.
Algorithmic Construction of Optimal and Load Balanced Clusters in Wireless Se...M H
This paper proposes a clustering algorithm - Ba-lanced Minimum Radius Clustering (BMRC) - for use in large scale, distributed Wireless Sensor Networks (WSN). Cluster balancing is an intractable problem to solve in a distributed manner, and distribution is important, by reason of both avoiding specialised node vulnerability and minimising message overhead.The BMRC algorithm described here distributes several of the cluster balancing functions to the cluster-heads. In proposing this algorithm, several tentative claims have been made for it, namely that it is suitable for arbitrary number of cluster heads; that its pecifies a way to elect cluster heads and use them to create the local models; that it accomplishes optimal balanced clusters in distributed manner; that it is scalable and it uses the number-of-hops as a clustering parameter; that it is energy efficient. These claims were studied and verified by simulation.
The novel applications of sensor networks impose some requirements in wireless sensor network design. With the energy efficiency and lifetime awareness, the throughput and network delayalso required to support emerging applications of sensor networks. In this paper, we propose
throughput and network delay aware intra-cluster routing protocol. We introduce the back-up links in the intra-cluster communication path. The link throughput, communication delay, packet loss ratio, interference, residual energy and node distance are the considered factors in finding efficient path of data communication among the sensor nodes within the cluster. The
simulation result shows the higher throughput and lower average packet delay rate for the proposed routing protocol than the existing benchmarks. The proposed routing protocol also shows energy efficiency and lifetime awareness with better connectivity rate.
Adaptive Routing in Wireless Sensor Networks: QoS Optimisation for Enhanced A...M H
One of the key challenges for research in wireless sensor networks is the development of routing protocols that provide application-specific service guarantees. This paper presents a new cluster-based Route Optimisation and Load-balancing protocol, called ROL, that uses various quality of service (QoS) metrics to meet application requirements. ROL combines several application requirements, specifically it attempts to provide an inclusive solution to prolong network life, provide timely message delivery and improve network robustness. It uses a combination of routing metrics that can be configured according to the priorities of user-level applications to improve overall network performance. To this end, an optimisation tool for balancing the communication resources for the constraints and priorities of user applications has been developed and Nutrient-flow-based Distributed Clustering (NDC), an algorithm for load balancing is proposed. NDC works seamlessly with any clustering algorithm to equalise, as far as possible, the diameter and the membership of clusters. This paper presents simulation results to show that ROL/NDC gives a higher network lifetime than other similar schemes, such Mires++. In simulation, ROL/NDC maintains a maximum of 7\% variation from the optimal cluster population, reduces the total number of set-up messages by up to 60%, reduces the end-to-end delay by up to 56%, and enhances the data delivery ratio by up to 0.98% compared to Mires++.
APPLYING GENETIC ALGORITHM TO SOLVE PARTITIONING AND MAPPING PROBLEM FOR MESH...ijcsit
This paper presents a genetic based approach to the partitioning and mapping of multicore SoC cores over a NoC system that uses mesh topology. The proposed algorithm performs the partitioning and mapping by reducing communication cost and minimizing power consumption by placing those intercommunicated cores as close as possible together. A program developed in C++ in which the provided specification of the multicore MPSoC system captures all data dependencies before any start of the design process. Experimental results of several multimedia benchmarks demonstrates that the genetic-based approach able to find different satisfied implementations to the problem of partitioning and mapping of MPSoC cores over mesh-based NoC system that satisfies design goals.
Simulation Issues in Wireless Sensor Networks: A SurveyM H
This paper presents a survey of simulation tools and systems for wireless sensor networks. Wireless sensor network modelling and simulation methodologies are presented for each system alongside judgments concerning their relative ease of use and accuracy. Finally, we propose a mixed-mode simulation methodology that integrates a simulated environment with real wireless sensor network testbed hardware in order to improve both the accuracy and scalability of results when evaluating different prototype designs and systems.
Algorithmic Construction of Optimal and Load Balanced Clusters in Wireless Se...M H
This paper proposes a clustering algorithm - Ba-lanced Minimum Radius Clustering (BMRC) - for use in large scale, distributed Wireless Sensor Networks (WSN). Cluster balancing is an intractable problem to solve in a distributed manner, and distribution is important, by reason of both avoiding specialised node vulnerability and minimising message overhead.The BMRC algorithm described here distributes several of the cluster balancing functions to the cluster-heads. In proposing this algorithm, several tentative claims have been made for it, namely that it is suitable for arbitrary number of cluster heads; that its pecifies a way to elect cluster heads and use them to create the local models; that it accomplishes optimal balanced clusters in distributed manner; that it is scalable and it uses the number-of-hops as a clustering parameter; that it is energy efficient. These claims were studied and verified by simulation.
The novel applications of sensor networks impose some requirements in wireless sensor network design. With the energy efficiency and lifetime awareness, the throughput and network delayalso required to support emerging applications of sensor networks. In this paper, we propose
throughput and network delay aware intra-cluster routing protocol. We introduce the back-up links in the intra-cluster communication path. The link throughput, communication delay, packet loss ratio, interference, residual energy and node distance are the considered factors in finding efficient path of data communication among the sensor nodes within the cluster. The
simulation result shows the higher throughput and lower average packet delay rate for the proposed routing protocol than the existing benchmarks. The proposed routing protocol also shows energy efficiency and lifetime awareness with better connectivity rate.
Adaptive Routing in Wireless Sensor Networks: QoS Optimisation for Enhanced A...M H
One of the key challenges for research in wireless sensor networks is the development of routing protocols that provide application-specific service guarantees. This paper presents a new cluster-based Route Optimisation and Load-balancing protocol, called ROL, that uses various quality of service (QoS) metrics to meet application requirements. ROL combines several application requirements, specifically it attempts to provide an inclusive solution to prolong network life, provide timely message delivery and improve network robustness. It uses a combination of routing metrics that can be configured according to the priorities of user-level applications to improve overall network performance. To this end, an optimisation tool for balancing the communication resources for the constraints and priorities of user applications has been developed and Nutrient-flow-based Distributed Clustering (NDC), an algorithm for load balancing is proposed. NDC works seamlessly with any clustering algorithm to equalise, as far as possible, the diameter and the membership of clusters. This paper presents simulation results to show that ROL/NDC gives a higher network lifetime than other similar schemes, such Mires++. In simulation, ROL/NDC maintains a maximum of 7\% variation from the optimal cluster population, reduces the total number of set-up messages by up to 60%, reduces the end-to-end delay by up to 56%, and enhances the data delivery ratio by up to 0.98% compared to Mires++.
A NEW APPROACH TO STOCHASTIC SCHEDULING IN DATA CENTER NETWORKSIJCNCJournal
The Quality of Service (QoS) of scheduling between latency-sensitive small data flows (a.k.a. mice) and throughput-oriented large ones (a.k.a. elephants) has become ever challenging with the proliferation of cloud-based applications. In light of this mounting problem, this work proposes a novel flow control scheme, HOLMES (HOListic Mice-Elephants Stochastic), which offers a holistic view of global congestion awareness as well as a stochastic scheduler of mixed mice-elephants data flows in Data Center Networks (DCNs). Firstly, we theoretically prove the necessity for partitioning DCN paths into sub-networks using a stochastic model. Secondly, the HOLMES architecture is proposed, which adaptively partitions the available DCN paths into low-latency and high-throughput sub-networks via a global congestion-aware scheduling mechanism. Based on the stochastic power-of-two-choices policy, the HOLMES scheduling mechanism acquires only a subset of the global congestion information, while achieves close to optimal load balance on each end-to-end DCN path. We also formally prove the stability of HOLMES flow scheduling algorithm. Thirdly, extensive simulation validates the effectiveness and dependability of HOLMES with select DCN topologies. The proposal has been in test in an industrial production environment. An extensive survey of related work is also presented.
SECTOR TREE-BASED CLUSTERING FOR ENERGY EFFICIENT ROUTING PROTOCOL IN HETEROG...IJCNCJournal
One of the main challenges for researchers to build routing protocols is how to use energy efficiently to extend the lifespan of the whole wireless sensor networks (WSN) because sensor nodes have limited battery power resources. In this work, we propose a Sector Tree-Based clustering routing protocol (STB-EE) for Energy Efficiency to cope with this problem, where the entire network area is partitioned into dynamic sectors (clusters), which balance the number of alive nodes. The nodes in each sector only communicate with their nearest neighbour by constructing a minimum tree based on the Kruskal algorithm and using mixed distance from candidate node to base station (BS) and remaining energy of candidate nodes to determine which node will become the cluster head (CH) in each cluster? By calculating the duration of time in each round for suitability, STB-EE increases the number of data packets sent to the BS. Our simulation results show that the network lifespan using STB-EE can be improved by about 16% and 10% in comparison to power-efficient gathering in sensor information system (PEGASIS) and energy-efficient PEGASIS-based protocol (IEEPB), respectively.
ADAPTIVE RANDOM SPATIAL BASED CHANNEL ESTIMATION (ARSCE) FOR MILLIMETER WAVE ...IJCNCJournal
Millimeter-wave and mMIMO communications are the most essential success systems for next-generation wireless sensor networks to have enormous amounts of accessible throughput and spectrum. Through installing huge antenna arrays at the base station and performing coherent transceiver processing, mMIMO is a potential technology for enhancing the bandwidth efficiency of wireless sensor networks. The use of mmWave frequencies for mMIMO systems solves the problem of high path-loss through offering greater antenna gains. In this work, we provide a design with a random spatial sample structure that incorporates a totally random step before the analogue is received. It contains a totally random step before the analogue received signals are sent into the digital component of the HBF receiver. Adaptive random spatial based channel estimation (ARSCE) is proposed for channel session measurement collection, and an analogue combiner with valves has been used to estimate the signals at each receiving antenna. The proposed optimization problem formulation attempts to discover the orientations and gains of wideband channel routes. In addition, our proposed model has compared to various state-of-art techniques while considering error minimization.
Information Extraction from Wireless Sensor Networks: System and ApproachesM H
Recent advances in wireless communication have made it possible to develop low-cost, and low power Wireless Sensor Networks (WSN). The WSN can be used for several application areas (e.g., habitat monitoring, forest fire detection, and health care). WSN Information Extraction (IE) techniques can be classified into four categories depending on the factors that drive data acquisition: event-driven, time-driven, query-based, and hybrid. This paper presents a survey of the state-of-the-art IE techniques in WSNs. The benefits and shortcomings of different IE approaches are presented as motivation for future work into automatic hybridization and adaptation of IE mechanisms.
ADAPTIVE SENSOR SENSING RANGE TO MAXIMISE LIFETIME OF WIRELESS SENSOR NETWORK IJCNCJournal
Wireless Sensor Network (WSN) is commonly used to collect information from a remote area and one of the most important challenges associated with WSN is to monitor all targets in a given area while maximizing network lifetime. In wireless communication, energy consumption is proportional to the breadth of sensing range and path loss exponent. Hence, the energy consumption of communication can be minimized by varying the sensing range and decreasing the number of messages being sent. Sensing energy can be optimized by reducing the repeated coverage target. In this paper, an Adaptive Sensor Sensing Range (ASSR) technique is proposed to maximize the WSN Lifetime. This work considers a sensor network with an adaptive sensing range that are randomly deployed in the monitoring area. The sensor is adaptive in nature and can be modified in order to save power while achieving maximum time of monitoring to increase the lifetime of WSN network. The objective of ASSR is to find the best sensing range for each sensor to cover all targets in the network, which yields maximize the time of monitoring of all targets and eliminating double sensing for the same target. Experiments were conducted using an NS3 simulator to verify our proposed technique. Results show that ASSR is capable to improve the network lifetime by 20% as compared to other recent techniques in the case of a small network while achieving an 8% improvement for the case of a large networks.
Wireless mesh networks offer high bandwidth Internet access for mobile users anywhere and at any time.
It is an emerging technology that uses wireless multi-hop networking to provide a cost-efficient way for
community or enterprise users to have broadband Internet access and share network resource. In this paper,
we have tried to give a comparative analysis of various Gateway Placement approaches which can be
helpful in understanding which approach will be useful in which situation.
Load aware self organising user-centric dynamic co mp clustering for 5g networksredpel dot com
Load aware self organising user-centric dynamic co mp clustering for 5g networks
for more ieee paper / full abstract / implementation , just visit www.redpel.com
ON THE PERFORMANCE OF INTRUSION DETECTION SYSTEMS WITH HIDDEN MULTILAYER NEUR...IJCNCJournal
Deep learning applications, especially multilayer neural network models, result in network intrusion detection with high accuracy. This study proposes a model that combines a multilayer neural network with Dense Sparse Dense (DSD) multi-stage training to simultaneously improve the criteria related to the performance of intrusion detection systems on a comprehensive dataset UNSW-NB15. We conduct experiments on many neural network models such as Recurrent Neural Network (RNN), Long-Short Term Memory (LSTM), Gated Recurrent Unit (GRU), etc. to evaluate the combined efficiency with each model through many criteria such as accuracy, detection rate, false alarm rate, precision, and F1-Score.
Simulator for Energy Efficient Clustering in Mobile Ad Hoc Networkscscpconf
The research on various issues in Mobile ad hoc networks is getting popular because of its
challenging nature and all time connectivity to communicate. Network simulators provide the
platform to analyse and imitate the working of the nodes in the networks along with the traffic
and other entities. The current work proposes the design of a simulator for the mobile ad hoc
networks that provides a test bed for the energy efficient clustering in the dynamic network.
Node parameters like degree of connectivity and average transmission power are considered for
calculating the energy consumption of the mobile devices. Nodes that consume minimum energy among their 1-hop neighbours are selected as the cluster heads.
Information extraction from sensor networks using the Watershed transform alg...M H
Wireless sensor networks are an effective tool to provide fine resolution monitoring of the physical environment. Sensors generate continuous streams of data, which leads to several computational challenges. As sensor nodes become increasingly active devices, with more processing and communication resources, various methods of distributed data processing and sharing become feasible. The challenge is to extract information from the gathered sensory data with a specified level of accuracy in a timely and power-efficient approach. This paper presents a new solution to distributed information extraction that makes use of the morphological Watershed algorithm. The Watershed algorithm dynamically groups sensor nodes into homogeneous network segments with respect to their topological relationships and their sensing-states. This setting allows network programmers to manipulate groups of spatially distributed data streams instead of individual nodes. This is achieved by using network segments as programming abstractions on which various query processes can be executed. Aiming at this purpose, we present a reformulation of the global Watershed algorithm. The modified Watershed algorithm is fully asynchronous, where sensor nodes can autonomously process their local data in parallel and in collaboration with neighbouring nodes. Experimental evaluation shows that the presented solution is able to considerably reduce query resolution cost without scarifying the quality of the returned results. When compared to similar purpose schemes, such as “Logical Neighborhood”, the proposed approach reduces the total query resolution overhead by up to 57.5%, reduces the number of nodes involved in query resolution by up to 59%, and reduces the setup convergence time by up to 65.1%.
A new paradigm that accommodates and exploits SDN, Network Analytics (NA) and AI, and provides use cases that illustrate its applicability and benefits
An Overview of Information Extraction from Mobile Wireless Sensor NetworksM H
Information Extraction (IE) is a key research area within the field of Wireless Sensor Networks (WSNs). It has been characterised in a variety of ways, ranging from the description of its purposes, to reasonably abstract models of its processes and components. There has been only a handful of papers addressing IE over mobile WSNs directly, these dealt with individual mobility related problems as the need arises. This paper is presented as a tutorial that takes the reader from the point of identifying data about a dynamic (mobile) real world problem, relating the data back to the world from which it was collected, and finally discovering what is in the data. It covers the entire process with special emphasis on how to exploit mobility in maximising information return from a mobile WSN. We present some challenges introduced by mobility on the IE process as well as its effects on the quality of the extracted information. Finally, we identify future research directions facing the development of efficient IE approaches for WSNs in the presence of mobility.
DESIGNING AN ENERGY EFFICIENT CLUSTERING IN HETEROGENEOUS WIRELESS SENSOR NET...IJCNCJournal
Designing an energy-efficient scheme in a Heterogeneous Wireless Sensor Network (HWSN) is a critical
issue that degrades the network performance. Recharging and providing security to the sensor devices is
very difficult in an unattended environment once the energy is drained off. A Clustering scheme is an
important and suitable approach to increase energy efficiency and transmitting secured data which in turn
enhances the performance in the network. The proposed algorithm Energy Efficient Clustering (EEC)
works for optimum energy utilization in sensor nodes. The algorithm is proposed by combining the
rotation-based clustering and energy-saving mechanism for avoiding the node failure and prolonging the
network lifetime. This shows MAC layer scheduling is based on optimum energy utilization depending on
the residual energy. In the proposed work, a densely populated network is partitioned into clusters and all
the cluster heads are formed at a time and selected on rotation based on considering the highest energy of
the sensor nodes. Other cluster members are accommodated in a cluster based on Basic Cost Maximum
flow (BCMF) to allow the cluster head for transmitting the secured data. Carrier Sense Multiple Access
(CSMA), a contention window based protocol is used at the MAC layer for collision detection and to
provide channel access prioritization to HWSN of different traffic classes with reduction in End to End
delay, energy consumption, and improved throughput and Packet delivery ratio(PDR) and allowing the
cluster head for transmission without depleting the energy. Simulation parameters of the proposed system
such as Throughput, Energy, and Packet Delivery Ratio are obtained and compared with the existing
system.
There are number of cluster based routing algorithms in mobile ad hoc networks. Since ad hoc networks are not accompanied by fixed access points, efficient routing is a must for such networks. Clustering approach is applied in mobile ad hoc network because clusters are more easily manageable and are more viable. It consists of segregating the given network into several reasonable clusters by using a clustering algorithm. By performing clustering we elect a worthy node from the cluster as the cluster head in such a way that we strive to reduce the management overheads and thus increasing the efficiency of routing. As for the fact that nodes in mobile ad hoc network have frequent host change and frequent topology change routing plays an important role for maintenance and backup mechanism to stabilize network performance. This paper aims to review the previous research papers and provide a survey on the various cluster based routing protocols in mobile ad hoc network. This paper presents analytical study of cluster based routing algorithms from literature. Index Terms— Ad- hoc networks, Cluster head, Clustering, Protocol, Route selection.
Mobile elements scheduling for periodic sensor applicationsijwmn
In this paper, we investigate the problem of designing the mobile elements tours such that the length of each tour is below a per-determined length and the depth of the multi-hop routing trees bounded by k. The path of the mobile element is designed to visit subset of the nodes (cache points). These cache points store other nodes data. To address this problem, we propose two heuristic-based solutions. Our solutions take into consideration the distribution of the nodes during the establishment of the tour. The results of our experiments indicate that our schemes significantly outperforms the best comparable scheme in the literature.
International Journal of Engineering Research and Applications (IJERA) is an open access online peer reviewed international journal that publishes research and review articles in the fields of Computer Science, Neural Networks, Electrical Engineering, Software Engineering, Information Technology, Mechanical Engineering, Chemical Engineering, Plastic Engineering, Food Technology, Textile Engineering, Nano Technology & science, Power Electronics, Electronics & Communication Engineering, Computational mathematics, Image processing, Civil Engineering, Structural Engineering, Environmental Engineering, VLSI Testing & Low Power VLSI Design etc.
Network on Chip Architecture and Routing Techniques: A surveyIJRES Journal
The processor designing and development was designed to perform various complex logical information exchange and processing operations in a variety of resolutions. They mainly rely on concurrent and sync, both that of the software and hardware to enhance the productivity and performance. With the high speed growth approaching multi-billion transistor integration era, some of the main problems which are symbolized by all gate lengths in the range of 60-90 nm, will be from non-scalable delays generated by wire. All similar problems may be solved by using Network on Chip (NOC) systems. In the presented paper, we have summarized research papers and contributions in NOC area. With advancement in the technology in the on chip communication, faster interaction between devices is becoming vital. Network on Chip (NOC) can be one of the solutions for faster on chip communication. For efficient link between devices of NOC, routers are needed. This paper also reviews implementation of routing techniques. The use of routing gives higher throughput as required for dealing with complexity of modern systems. It is mainly focused on the routing design parameters on both system level including traffic pattern, network topology and routing algorithm, and architecture level including arbitration algorithm.
This paper presents a genetic based approach to the partitioning and mapping of multicore SoC cores over a NoC system that uses mesh topology. The proposed algorithm performs the partitioning and mapping by reducing communication cost and minimizing power consumption by placing those intercommunicated cores as close as possible together. A program developed in C++ in which the provided specification of the multicore MPSoC system captures all data dependencies before any start of the design process. Experimental results of several multimedia benchmarks demonstrates that the genetic-based approach able to find different satisfied implementations to the problem of partitioning and mapping of MPSoC cores over mesh-based NoC system that satisfies design goals.
Many intellectual property (IP) modules are present in contemporary system on chips (SoCs). This could provide an issue with interconnection among different IP modules, which would limit the system's ability to scale. Traditional bus-based SoC architectures have a connectivity bottleneck, and network on chip (NoC) has evolved as an embedded switching network to address this issue. The interconnections between various cores or IP modules on a chip have a significant impact on communication and chip performance in terms of power, area latency and throughput. Also, designing a reliable fault tolerant NoC became a significant concern. In fault tolerant NoC it becomes critical to identify faulty node and dynamically reroute the packets keeping minimum latency. This study provides an insight into a domain of NoC, with intention of understanding fault tolerant approach based on the XY routing algorithm for 4×4 mesh architecture. The fault tolerant NoC design is synthesized on field programmable gate array (FPGA).
A NEW APPROACH TO STOCHASTIC SCHEDULING IN DATA CENTER NETWORKSIJCNCJournal
The Quality of Service (QoS) of scheduling between latency-sensitive small data flows (a.k.a. mice) and throughput-oriented large ones (a.k.a. elephants) has become ever challenging with the proliferation of cloud-based applications. In light of this mounting problem, this work proposes a novel flow control scheme, HOLMES (HOListic Mice-Elephants Stochastic), which offers a holistic view of global congestion awareness as well as a stochastic scheduler of mixed mice-elephants data flows in Data Center Networks (DCNs). Firstly, we theoretically prove the necessity for partitioning DCN paths into sub-networks using a stochastic model. Secondly, the HOLMES architecture is proposed, which adaptively partitions the available DCN paths into low-latency and high-throughput sub-networks via a global congestion-aware scheduling mechanism. Based on the stochastic power-of-two-choices policy, the HOLMES scheduling mechanism acquires only a subset of the global congestion information, while achieves close to optimal load balance on each end-to-end DCN path. We also formally prove the stability of HOLMES flow scheduling algorithm. Thirdly, extensive simulation validates the effectiveness and dependability of HOLMES with select DCN topologies. The proposal has been in test in an industrial production environment. An extensive survey of related work is also presented.
SECTOR TREE-BASED CLUSTERING FOR ENERGY EFFICIENT ROUTING PROTOCOL IN HETEROG...IJCNCJournal
One of the main challenges for researchers to build routing protocols is how to use energy efficiently to extend the lifespan of the whole wireless sensor networks (WSN) because sensor nodes have limited battery power resources. In this work, we propose a Sector Tree-Based clustering routing protocol (STB-EE) for Energy Efficiency to cope with this problem, where the entire network area is partitioned into dynamic sectors (clusters), which balance the number of alive nodes. The nodes in each sector only communicate with their nearest neighbour by constructing a minimum tree based on the Kruskal algorithm and using mixed distance from candidate node to base station (BS) and remaining energy of candidate nodes to determine which node will become the cluster head (CH) in each cluster? By calculating the duration of time in each round for suitability, STB-EE increases the number of data packets sent to the BS. Our simulation results show that the network lifespan using STB-EE can be improved by about 16% and 10% in comparison to power-efficient gathering in sensor information system (PEGASIS) and energy-efficient PEGASIS-based protocol (IEEPB), respectively.
ADAPTIVE RANDOM SPATIAL BASED CHANNEL ESTIMATION (ARSCE) FOR MILLIMETER WAVE ...IJCNCJournal
Millimeter-wave and mMIMO communications are the most essential success systems for next-generation wireless sensor networks to have enormous amounts of accessible throughput and spectrum. Through installing huge antenna arrays at the base station and performing coherent transceiver processing, mMIMO is a potential technology for enhancing the bandwidth efficiency of wireless sensor networks. The use of mmWave frequencies for mMIMO systems solves the problem of high path-loss through offering greater antenna gains. In this work, we provide a design with a random spatial sample structure that incorporates a totally random step before the analogue is received. It contains a totally random step before the analogue received signals are sent into the digital component of the HBF receiver. Adaptive random spatial based channel estimation (ARSCE) is proposed for channel session measurement collection, and an analogue combiner with valves has been used to estimate the signals at each receiving antenna. The proposed optimization problem formulation attempts to discover the orientations and gains of wideband channel routes. In addition, our proposed model has compared to various state-of-art techniques while considering error minimization.
Information Extraction from Wireless Sensor Networks: System and ApproachesM H
Recent advances in wireless communication have made it possible to develop low-cost, and low power Wireless Sensor Networks (WSN). The WSN can be used for several application areas (e.g., habitat monitoring, forest fire detection, and health care). WSN Information Extraction (IE) techniques can be classified into four categories depending on the factors that drive data acquisition: event-driven, time-driven, query-based, and hybrid. This paper presents a survey of the state-of-the-art IE techniques in WSNs. The benefits and shortcomings of different IE approaches are presented as motivation for future work into automatic hybridization and adaptation of IE mechanisms.
ADAPTIVE SENSOR SENSING RANGE TO MAXIMISE LIFETIME OF WIRELESS SENSOR NETWORK IJCNCJournal
Wireless Sensor Network (WSN) is commonly used to collect information from a remote area and one of the most important challenges associated with WSN is to monitor all targets in a given area while maximizing network lifetime. In wireless communication, energy consumption is proportional to the breadth of sensing range and path loss exponent. Hence, the energy consumption of communication can be minimized by varying the sensing range and decreasing the number of messages being sent. Sensing energy can be optimized by reducing the repeated coverage target. In this paper, an Adaptive Sensor Sensing Range (ASSR) technique is proposed to maximize the WSN Lifetime. This work considers a sensor network with an adaptive sensing range that are randomly deployed in the monitoring area. The sensor is adaptive in nature and can be modified in order to save power while achieving maximum time of monitoring to increase the lifetime of WSN network. The objective of ASSR is to find the best sensing range for each sensor to cover all targets in the network, which yields maximize the time of monitoring of all targets and eliminating double sensing for the same target. Experiments were conducted using an NS3 simulator to verify our proposed technique. Results show that ASSR is capable to improve the network lifetime by 20% as compared to other recent techniques in the case of a small network while achieving an 8% improvement for the case of a large networks.
Wireless mesh networks offer high bandwidth Internet access for mobile users anywhere and at any time.
It is an emerging technology that uses wireless multi-hop networking to provide a cost-efficient way for
community or enterprise users to have broadband Internet access and share network resource. In this paper,
we have tried to give a comparative analysis of various Gateway Placement approaches which can be
helpful in understanding which approach will be useful in which situation.
Load aware self organising user-centric dynamic co mp clustering for 5g networksredpel dot com
Load aware self organising user-centric dynamic co mp clustering for 5g networks
for more ieee paper / full abstract / implementation , just visit www.redpel.com
ON THE PERFORMANCE OF INTRUSION DETECTION SYSTEMS WITH HIDDEN MULTILAYER NEUR...IJCNCJournal
Deep learning applications, especially multilayer neural network models, result in network intrusion detection with high accuracy. This study proposes a model that combines a multilayer neural network with Dense Sparse Dense (DSD) multi-stage training to simultaneously improve the criteria related to the performance of intrusion detection systems on a comprehensive dataset UNSW-NB15. We conduct experiments on many neural network models such as Recurrent Neural Network (RNN), Long-Short Term Memory (LSTM), Gated Recurrent Unit (GRU), etc. to evaluate the combined efficiency with each model through many criteria such as accuracy, detection rate, false alarm rate, precision, and F1-Score.
Simulator for Energy Efficient Clustering in Mobile Ad Hoc Networkscscpconf
The research on various issues in Mobile ad hoc networks is getting popular because of its
challenging nature and all time connectivity to communicate. Network simulators provide the
platform to analyse and imitate the working of the nodes in the networks along with the traffic
and other entities. The current work proposes the design of a simulator for the mobile ad hoc
networks that provides a test bed for the energy efficient clustering in the dynamic network.
Node parameters like degree of connectivity and average transmission power are considered for
calculating the energy consumption of the mobile devices. Nodes that consume minimum energy among their 1-hop neighbours are selected as the cluster heads.
Information extraction from sensor networks using the Watershed transform alg...M H
Wireless sensor networks are an effective tool to provide fine resolution monitoring of the physical environment. Sensors generate continuous streams of data, which leads to several computational challenges. As sensor nodes become increasingly active devices, with more processing and communication resources, various methods of distributed data processing and sharing become feasible. The challenge is to extract information from the gathered sensory data with a specified level of accuracy in a timely and power-efficient approach. This paper presents a new solution to distributed information extraction that makes use of the morphological Watershed algorithm. The Watershed algorithm dynamically groups sensor nodes into homogeneous network segments with respect to their topological relationships and their sensing-states. This setting allows network programmers to manipulate groups of spatially distributed data streams instead of individual nodes. This is achieved by using network segments as programming abstractions on which various query processes can be executed. Aiming at this purpose, we present a reformulation of the global Watershed algorithm. The modified Watershed algorithm is fully asynchronous, where sensor nodes can autonomously process their local data in parallel and in collaboration with neighbouring nodes. Experimental evaluation shows that the presented solution is able to considerably reduce query resolution cost without scarifying the quality of the returned results. When compared to similar purpose schemes, such as “Logical Neighborhood”, the proposed approach reduces the total query resolution overhead by up to 57.5%, reduces the number of nodes involved in query resolution by up to 59%, and reduces the setup convergence time by up to 65.1%.
A new paradigm that accommodates and exploits SDN, Network Analytics (NA) and AI, and provides use cases that illustrate its applicability and benefits
An Overview of Information Extraction from Mobile Wireless Sensor NetworksM H
Information Extraction (IE) is a key research area within the field of Wireless Sensor Networks (WSNs). It has been characterised in a variety of ways, ranging from the description of its purposes, to reasonably abstract models of its processes and components. There has been only a handful of papers addressing IE over mobile WSNs directly, these dealt with individual mobility related problems as the need arises. This paper is presented as a tutorial that takes the reader from the point of identifying data about a dynamic (mobile) real world problem, relating the data back to the world from which it was collected, and finally discovering what is in the data. It covers the entire process with special emphasis on how to exploit mobility in maximising information return from a mobile WSN. We present some challenges introduced by mobility on the IE process as well as its effects on the quality of the extracted information. Finally, we identify future research directions facing the development of efficient IE approaches for WSNs in the presence of mobility.
DESIGNING AN ENERGY EFFICIENT CLUSTERING IN HETEROGENEOUS WIRELESS SENSOR NET...IJCNCJournal
Designing an energy-efficient scheme in a Heterogeneous Wireless Sensor Network (HWSN) is a critical
issue that degrades the network performance. Recharging and providing security to the sensor devices is
very difficult in an unattended environment once the energy is drained off. A Clustering scheme is an
important and suitable approach to increase energy efficiency and transmitting secured data which in turn
enhances the performance in the network. The proposed algorithm Energy Efficient Clustering (EEC)
works for optimum energy utilization in sensor nodes. The algorithm is proposed by combining the
rotation-based clustering and energy-saving mechanism for avoiding the node failure and prolonging the
network lifetime. This shows MAC layer scheduling is based on optimum energy utilization depending on
the residual energy. In the proposed work, a densely populated network is partitioned into clusters and all
the cluster heads are formed at a time and selected on rotation based on considering the highest energy of
the sensor nodes. Other cluster members are accommodated in a cluster based on Basic Cost Maximum
flow (BCMF) to allow the cluster head for transmitting the secured data. Carrier Sense Multiple Access
(CSMA), a contention window based protocol is used at the MAC layer for collision detection and to
provide channel access prioritization to HWSN of different traffic classes with reduction in End to End
delay, energy consumption, and improved throughput and Packet delivery ratio(PDR) and allowing the
cluster head for transmission without depleting the energy. Simulation parameters of the proposed system
such as Throughput, Energy, and Packet Delivery Ratio are obtained and compared with the existing
system.
There are number of cluster based routing algorithms in mobile ad hoc networks. Since ad hoc networks are not accompanied by fixed access points, efficient routing is a must for such networks. Clustering approach is applied in mobile ad hoc network because clusters are more easily manageable and are more viable. It consists of segregating the given network into several reasonable clusters by using a clustering algorithm. By performing clustering we elect a worthy node from the cluster as the cluster head in such a way that we strive to reduce the management overheads and thus increasing the efficiency of routing. As for the fact that nodes in mobile ad hoc network have frequent host change and frequent topology change routing plays an important role for maintenance and backup mechanism to stabilize network performance. This paper aims to review the previous research papers and provide a survey on the various cluster based routing protocols in mobile ad hoc network. This paper presents analytical study of cluster based routing algorithms from literature. Index Terms— Ad- hoc networks, Cluster head, Clustering, Protocol, Route selection.
Mobile elements scheduling for periodic sensor applicationsijwmn
In this paper, we investigate the problem of designing the mobile elements tours such that the length of each tour is below a per-determined length and the depth of the multi-hop routing trees bounded by k. The path of the mobile element is designed to visit subset of the nodes (cache points). These cache points store other nodes data. To address this problem, we propose two heuristic-based solutions. Our solutions take into consideration the distribution of the nodes during the establishment of the tour. The results of our experiments indicate that our schemes significantly outperforms the best comparable scheme in the literature.
International Journal of Engineering Research and Applications (IJERA) is an open access online peer reviewed international journal that publishes research and review articles in the fields of Computer Science, Neural Networks, Electrical Engineering, Software Engineering, Information Technology, Mechanical Engineering, Chemical Engineering, Plastic Engineering, Food Technology, Textile Engineering, Nano Technology & science, Power Electronics, Electronics & Communication Engineering, Computational mathematics, Image processing, Civil Engineering, Structural Engineering, Environmental Engineering, VLSI Testing & Low Power VLSI Design etc.
Network on Chip Architecture and Routing Techniques: A surveyIJRES Journal
The processor designing and development was designed to perform various complex logical information exchange and processing operations in a variety of resolutions. They mainly rely on concurrent and sync, both that of the software and hardware to enhance the productivity and performance. With the high speed growth approaching multi-billion transistor integration era, some of the main problems which are symbolized by all gate lengths in the range of 60-90 nm, will be from non-scalable delays generated by wire. All similar problems may be solved by using Network on Chip (NOC) systems. In the presented paper, we have summarized research papers and contributions in NOC area. With advancement in the technology in the on chip communication, faster interaction between devices is becoming vital. Network on Chip (NOC) can be one of the solutions for faster on chip communication. For efficient link between devices of NOC, routers are needed. This paper also reviews implementation of routing techniques. The use of routing gives higher throughput as required for dealing with complexity of modern systems. It is mainly focused on the routing design parameters on both system level including traffic pattern, network topology and routing algorithm, and architecture level including arbitration algorithm.
This paper presents a genetic based approach to the partitioning and mapping of multicore SoC cores over a NoC system that uses mesh topology. The proposed algorithm performs the partitioning and mapping by reducing communication cost and minimizing power consumption by placing those intercommunicated cores as close as possible together. A program developed in C++ in which the provided specification of the multicore MPSoC system captures all data dependencies before any start of the design process. Experimental results of several multimedia benchmarks demonstrates that the genetic-based approach able to find different satisfied implementations to the problem of partitioning and mapping of MPSoC cores over mesh-based NoC system that satisfies design goals.
Many intellectual property (IP) modules are present in contemporary system on chips (SoCs). This could provide an issue with interconnection among different IP modules, which would limit the system's ability to scale. Traditional bus-based SoC architectures have a connectivity bottleneck, and network on chip (NoC) has evolved as an embedded switching network to address this issue. The interconnections between various cores or IP modules on a chip have a significant impact on communication and chip performance in terms of power, area latency and throughput. Also, designing a reliable fault tolerant NoC became a significant concern. In fault tolerant NoC it becomes critical to identify faulty node and dynamically reroute the packets keeping minimum latency. This study provides an insight into a domain of NoC, with intention of understanding fault tolerant approach based on the XY routing algorithm for 4×4 mesh architecture. The fault tolerant NoC design is synthesized on field programmable gate array (FPGA).
Noise Tolerant and Faster On Chip Communication Using Binoc ModelIJMER
International Journal of Modern Engineering Research (IJMER) is Peer reviewed, online Journal. It serves as an international archival forum of scholarly research related to engineering and science education.
Performance Analysis of Mesh-based NoC’s on Routing Algorithms IJECEIAES
The advent of System-on-Chip (SoCs), has brought about a need to increase the scale of multi-core chip networks. Bus Based communications have proved to be limited in terms of performance and ease of scalability, the solution to both bus – based and Point-to-Point (P2P) communication systems is to use a communication infrastructure called Network-on-Chip (NoC). Performance of NoC depends on various factors such as network topology, routing strategy and switching technique and traffic patterns. In this paper, we have taken the initiative to compile together a comparative analysis of different Network on Chip infrastructures based on the classification of routing algorithm, switching technique, and traffic patterns. The goal is to show how varied combinations of the three factors perform differently based on the size of the mesh network, using NOXIM, an open source SystemC Simulator of mesh-based NoC. The analysis has shown tenable evidence highlighting the novelty of XY routing algorithm.
The router is a network device that is used to connect subnetwork and packet-switched networking by directing the data packets to the intended IP addresses. It succeeds the traffic between different systems and allows several devices to share the internet connection. The router is applicable for the effective commutation in system on chip (SoC) modules for network on chip (NoC) communication. The research paper emphasizes the design of the two dimensional (2D) router hardware chip in the Xilinx integrated system environment (ISE) 14.7 software and further logic verification using the data packets transmitted from all input/output ports. The design evaluation is done based on the pre-synthesis device utilization summary relating to different field programmable gate array (FPGA) boards such as Spartan-3E (XC3S500E), Spartan-6 (XC6SLX45), Virtex-4 (XC4VFX12), Virtex-5 (XC5VSX50T), and Virtex-7 (XC7VX550T). The 64-bit data logic is verified on the different ports of the router configuration in the Xilinx and Modelsim waveform simulator. The Virtex-7 has proven the fast-switching speed and optimal hardware parameters in comparison to other FPGAs.
Design of an Efficient Communication Protocol for 3d Interconnection NetworkIJMTST Journal
Three-dimensional integrated circuits (3D ICs) provide better device integration, reduced signal delay and reduced interconnect power. They additionally give better layout flexibility by permitting heterogeneous integration, by taking the advantage of intrinsic capability of reducing the wire length in 3D ICs, 3D NOC Bus Hybrid mesh layout was suggested. This layout provides an apparently significant stage to implement economical multicast routings for 3D networks-on-chip. A unique multicast partitioning and routing strategy for the 3D NOC-Bus Hybrid mesh architectures to improve the system performance and to decrease the power consumption is being proposed. The planned design exploits the useful attribute of a single-hop (bus-based) interlayer communication of the 3D stacked mesh design to supply superior hardware multicast support. Finally customized partitioning approach and an effective routing method is given to decrease the average hop count and network latency. Compared to the recently designed 3D NOC architectures being capable of supporting hardware multicasting, huge simulations with traffic profiles reveals design exploitation, which is the planned multicast routing strategy will facilitate significant performance enhancements.
Low power network on chip architectures: A surveyCSITiaesprime
Mostly communication now days is done through system on chip (SoC) models so, network on chip (NoC) architecture is most appropriate solution for better performance. However, one of major flaws in this architecture is power consumption. To gain high performance through this type of architecture it is necessary to confirm power consumption while designing this. Use of power should be diminished in every region of network chip architecture. Lasting power consumption can be lessened by reaching alterations in network routers and other devices used to form that network. This research mainly focusses on state-of-the-art methods for designing NoC architecture and techniques to reduce power consumption in those architectures like, network architecture, network links between nodes, network design, and routers.
RIVERBED-BASED NETWORK MODELING FOR MULTI-BEAM CONCURRENT TRANSMISSIONSijwmn
The paper presents a Riverbed simulator implementation with both routing and medium access control
(MAC) protocols for mobile ad-hoc network wireless networks with multi-beam smart antennas (MBSAs).
As one of the latest promising antenna techniques, MBSAs can achieve concurrent transmissions /
receptions in multiple directions/beams. Thus it can significantly improve the network throughput.
However, so far there is still no accurate network simulator that can measure the MBSA-based
routing/MAC protocol performance. In this paper, we describe the simulation models with the
implementation of MBSA antenna model in physical layer, MAC layer, and routing layer protocols, all in
Riverbed Modeler. We will compare two routing scenarios, i.e., multi-hop diamond routing scenario and
multi-path pipe routing. We will analyze the network performance for those two scenarios and illustrate the
advantages of using MBSAs in wireless networks.
RIVERBED-BASED NETWORK MODELING FOR MULTI-BEAM CONCURRENT TRANSMISSIONSijwmn
The paper presents a Riverbed simulator implementation with both routing and medium access control
(MAC) protocols for mobile ad-hoc network wireless networks with multi-beam smart antennas (MBSAs).
As one of the latest promising antenna techniques, MBSAs can achieve concurrent transmissions /
receptions in multiple directions/beams. Thus it can significantly improve the network throughput.
However, so far there is still no accurate network simulator that can measure the MBSA-based
routing/MAC protocol performance. In this paper, we describe the simulation models with the
implementation of MBSA antenna model in physical layer, MAC layer, and routing layer protocols, all in
Riverbed Modeler. We will compare two routing scenarios, i.e., multi-hop diamond routing scenario and
multi-path pipe routing. We will analyze the network performance for those two scenarios and illustrate the
advantages of using MBSAs in wireless networks.
RIVERBED-BASED NETWORK MODELING FOR MULTI-BEAM CONCURRENT TRANSMISSIONSijwmn
The paper presents a Riverbed simulator implementation with both routing and medium access control (MAC) protocols for mobile ad-hoc network wireless networks with multi-beam smart antennas (MBSAs). As one of the latest promising antenna techniques, MBSAs can achieve concurrent transmissions /
receptions in multiple directions/beams. Thus it can significantly improve the network throughput. However, so far there is still no accurate network simulator that can measure the MBSA-based
routing/MAC protocol performance. In this paper, we describe the simulation models with the implementation of MBSA antenna model in physical layer, MAC layer, and routing layer protocols, all in Riverbed Modeler. We will compare two routing scenarios, i.e., multi-hop diamond routing scenario and
multi-path pipe routing. We will analyze the network performance for those two scenarios and illustrate the advantages of using MBSAs in wireless networks.
Enhancenig OLSR routing protocol using K-means clustering in MANETs IJECEIAES
The design of robust routing protocol schemes for MANETs is quite complex, due to the characteristics and structural constraints of this network. A numerous variety of protocol schemes have been proposed in literature. Most of them are based on traditional method of routing, which doesn’t guarantee basic levels of Qos, when the network becomes larger, denser and dynamic. To solve this problem we use one of the most popular methods named clustering. In this work we try to improve the Qos in MANETs. We propose an algorithm of clustering based in the new mobility metric and K-Means method to distribute the nodes into several clusters; it is implemented to standard OLSR protocol giving birth a new protocol named OLSR Kmeans-SDE. The simulations showed that the results obtained by OLSR Kmeans-SDE exceed those obtained by standard OLSR Kmeans and OLSR Kmed+ in terms of, traffic Control, delay and packet delivery ratio.
Evaluating feasibility of using wireless sensor networks in a coffee crop thr...IJCNCJournal
A Wireless Sensor Networks is a network formed with sensors that have characteristics to sensor an area to
extract a specific metric, depending of the application.
We would like to analyse the feasibility to use sensors in a coffee crop.In this work we are evaluating routing protocolsusing real dimensions and characteristics of a coffee crop. We evaluate, through simulation, AODV, DSDV and AOMDV and two variants known in this work as AODVMOD and AOMDVMOD with 802.15.4 MAC Protocol
.For this comparison, we defined three performance metrics: Packet Delivery Ratio (PDR), End-to-End Delay
and Average Energy Consumption. Simulation results show that AOMDVMOD overall, outperforms others
routing protocols evaluated, showing that is possible to use WSN in a real coffee crop environment.
6th International Conference on Machine Learning & Applications (CMLA 2024)ClaraZara1
6th International Conference on Machine Learning & Applications (CMLA 2024) will provide an excellent international forum for sharing knowledge and results in theory, methodology and applications of on Machine Learning & Applications.
HEAP SORT ILLUSTRATED WITH HEAPIFY, BUILD HEAP FOR DYNAMIC ARRAYS.
Heap sort is a comparison-based sorting technique based on Binary Heap data structure. It is similar to the selection sort where we first find the minimum element and place the minimum element at the beginning. Repeat the same process for the remaining elements.
KuberTENes Birthday Bash Guadalajara - K8sGPT first impressionsVictor Morales
K8sGPT is a tool that analyzes and diagnoses Kubernetes clusters. This presentation was used to share the requirements and dependencies to deploy K8sGPT in a local environment.
TOP 10 B TECH COLLEGES IN JAIPUR 2024.pptxnikitacareer3
Looking for the best engineering colleges in Jaipur for 2024?
Check out our list of the top 10 B.Tech colleges to help you make the right choice for your future career!
1) MNIT
2) MANIPAL UNIV
3) LNMIIT
4) NIMS UNIV
5) JECRC
6) VIVEKANANDA GLOBAL UNIV
7) BIT JAIPUR
8) APEX UNIV
9) AMITY UNIV.
10) JNU
TO KNOW MORE ABOUT COLLEGES, FEES AND PLACEMENT, WATCH THE FULL VIDEO GIVEN BELOW ON "TOP 10 B TECH COLLEGES IN JAIPUR"
https://www.youtube.com/watch?v=vSNje0MBh7g
VISIT CAREER MANTRA PORTAL TO KNOW MORE ABOUT COLLEGES/UNIVERSITITES in Jaipur:
https://careermantra.net/colleges/3378/Jaipur/b-tech
Get all the information you need to plan your next steps in your medical career with Career Mantra!
https://careermantra.net/
NO1 Uk best vashikaran specialist in delhi vashikaran baba near me online vas...Amil Baba Dawood bangali
Contact with Dawood Bhai Just call on +92322-6382012 and we'll help you. We'll solve all your problems within 12 to 24 hours and with 101% guarantee and with astrology systematic. If you want to take any personal or professional advice then also you can call us on +92322-6382012 , ONLINE LOVE PROBLEM & Other all types of Daily Life Problem's.Then CALL or WHATSAPP us on +92322-6382012 and Get all these problems solutions here by Amil Baba DAWOOD BANGALI
#vashikaranspecialist #astrologer #palmistry #amliyaat #taweez #manpasandshadi #horoscope #spiritual #lovelife #lovespell #marriagespell#aamilbabainpakistan #amilbabainkarachi #powerfullblackmagicspell #kalajadumantarspecialist #realamilbaba #AmilbabainPakistan #astrologerincanada #astrologerindubai #lovespellsmaster #kalajaduspecialist #lovespellsthatwork #aamilbabainlahore#blackmagicformarriage #aamilbaba #kalajadu #kalailam #taweez #wazifaexpert #jadumantar #vashikaranspecialist #astrologer #palmistry #amliyaat #taweez #manpasandshadi #horoscope #spiritual #lovelife #lovespell #marriagespell#aamilbabainpakistan #amilbabainkarachi #powerfullblackmagicspell #kalajadumantarspecialist #realamilbaba #AmilbabainPakistan #astrologerincanada #astrologerindubai #lovespellsmaster #kalajaduspecialist #lovespellsthatwork #aamilbabainlahore #blackmagicforlove #blackmagicformarriage #aamilbaba #kalajadu #kalailam #taweez #wazifaexpert #jadumantar #vashikaranspecialist #astrologer #palmistry #amliyaat #taweez #manpasandshadi #horoscope #spiritual #lovelife #lovespell #marriagespell#aamilbabainpakistan #amilbabainkarachi #powerfullblackmagicspell #kalajadumantarspecialist #realamilbaba #AmilbabainPakistan #astrologerincanada #astrologerindubai #lovespellsmaster #kalajaduspecialist #lovespellsthatwork #aamilbabainlahore #Amilbabainuk #amilbabainspain #amilbabaindubai #Amilbabainnorway #amilbabainkrachi #amilbabainlahore #amilbabaingujranwalan #amilbabainislamabad
A FLEXIBLE SOFTWARE/HARDWARE ADAPTIVE NETWORK FOR EMBEDDED DISTRIBUTED ARCHITECTURES
1. Circuits and Systems: An International Journal (CSIJ), Vol.8, No.1/2/3, July 2021
DOI: 10.5121/csij.2021.8301 1
A FLEXIBLE SOFTWARE/HARDWARE ADAPTIVE
NETWORK FOR EMBEDDED DISTRIBUTED
ARCHITECTURES
Celine Azar
Department of Physics and Electronics, Faculty of Sciences,
Lebanese University, Beirut, Lebanon
ABSTRACT
Embedded platforms are projected to integrate hundreds of cores in the near future, and expanding the
interconnection network remains a key challenge. We propose SNet, a new Scalable NETwork paradigm
that extends the NoCs area to include a software/hardware dynamic routing mechanism. To design routing
pathways among communicating processes, it uses a distributed, adaptive, non-supervised routing method
based on the ACO algorithm (Ant Colony Optimization). A small footprint hardware unit called DMC
speeds up data transfer (Direct Management of Communications). SNet has the benefit of being extremely
versatile, allowing for the creation of a broad range of routing topologies to meet the needs of various
applications. We provide the DMC module in this work and assess SNet performance by executing a large
number of test cases.
KEYWORDS
Distributed manycore architectures, scalable network, hardware/software network paradigm.
1. INTRODUCTION
The age of giga transistor devices is approaching [1], with 10 nm technology predicted soon, thus
allowing to integrate a whole system, including thousands of IPs, onto a single die. The ability of
these gigascale SoCs (System-On-Chip) to efficiently link pre-designed functional blocks and
satisfy their communication needs will be one of its limitations [2].
Computation has always been expensive, whereas communication has been cheaper, however this
has changed with scaling systems [3]. With the advancement of technology, computation is
getting more affordable, allowing for the integration of thousands of processors on a single chip.
Given their quantity and therefore their capacity to implement a large number of running
programs, future processors may be viewed as real transistors. Communication, on the other
hand, presents significant problems, which may be summarized in three areas: technology,
performance, and design productivity issues [2]. Technology issues arise from non-scalable
global wire delays, though gate delays decrease as technology improves. Due to submicron
effects (clock skew, power associated with clock distribution trees, etc. ), core synchronization
will be impossible, and another solution will consist of self-synchronous cores communicating
through a network-centric architecture [4]. Interconnection systems based on shared buses are
causing performance difficulties and will not satisfy the connectivity needs of future SoCs [5]. In
terms of design productivity, because synthesis and compiler technology are not keeping up with
IC production [6], and because time-to-market is critical, modular reusable on-chip networks are
the solution for dedicated bus-based designs.
2. Circuits and Systems: An International Journal (CSIJ), Vol.8, No.1/2/3, July 2021
2
While many experts predict gigascale manycores in the near future, with scalability as the
ultimate objective, one potential design approach is distributed homogeneous architectures,
which prioritize local communication exchanges and links between neighbour cores. However,
we have reservations about the capacity to manage communications in platforms with thousands
of processors while maintaining strict local routing rules. Designers have developed a network-
centric strategy based on Network-On-Chips (NoCs) to solve technological difficulties,
integrating techniques established for macro-scale, multi-hop networks into a die. The NoC
paradigm's main objective is to increase design productivity and performance by dealing with
growing parallelism [7]. Despite the fact that the NoCs area has been extensively explored, we
believe there is a need to develop a new technique that provides greater flexibility and dynamicity
in order to meet future requirements. In reality, future manycore systems are expected to run
sophisticated and dynamic applications with variable computational and communication
requirements. In addition, component failures may occur in the system, which must be handled
by dynamically modifying the routing pathways without user intervention.
While NoCs are a good answer for today's network topologies, we expect that in future manycore
designs with thousands of cores on chip, more efficient interconnection techniques would be
provided. We suggest allocating a core to a routing process to add "intelligence" to the routing
mechanism. Future manycores will include thousands of cores, as previously stated, and the
computing resource will be inexpensive given its abundance. As a result of the large number of
cores integrated on the same chip, some will be left idle, and routing processes may be allocated
to these unoccupied processors. They will establish a routing network with a completely flexible
topology, referred to as routing topology. Routing cores are responsible for creating routing
pathways amongst communicating processes in a distributed dynamic manner without any
centralized control. Data is transmitted using a network of dedicated modules known as DMC,
which minimize the transmission latency once routing pathways have been established. Because
it allocates a unique and predetermined routing task to the chosen routing PEs, this technique
enhances design productivity and simplifies the programmability issue. As a result, we move
away from NoCs' communication-centric strategy and toward a PE-centric approach, with the PE
(Processing Element) handling communication management.
The SNet [8] scalable dynamic communication paradigm is discussed in this article. The goal of
this proposal is to improve future manycores' flexibility, scalability, and programmability. To
design routing pathways, SNet uses an adaptive, bio-inspired routing approach that implements
the ACO metaheuristic [9]. After that, we will go through the DMC's hardware design. Data
transmission is handled by a network of DMCs. The state of the art on existing NoCs is presented
in the next section. We offer an overview of the SNet principle and the DMC architecture in
section 3. We compare the SNet routing characteristics to those of existing NoCs in section 4.
Section 5 concludes with a summary of future projects.
2. NOCS: A STATE OF THE ART
The NoCs area has been extensively studied, and we will focus in this paper on two features of
NoCs: interconnection topology and routing strategy. The arrangement and connections between
cores are defined by the interconnection topology. As a result, NoCs can have a fixed
interconnection topology or an adjustable topology that can be modified to meet the needs of the
applications. Furthermore, the routing strategy uses either deterministic protocols, such as the XY
approach, or adaptive rules, which establish routing pathways dynamically based on network
demand. Figure 1 illustrates instances of NoCs for various types of routing interconnections and
strategies.
3. Circuits and Systems: An International Journal (CSIJ), Vol.8, No.1/2/3, July 2021
3
Figure 1. Examples of NoCs for various routing interconnections and strategies.
Fixed NoC topologies (such as mesh networks and fat trees) are differentiated by their tile-based
connections, whereas adaptive NoCs have no pre-designed interconnections and instead build a
flexible network to map numerous topologies, each fitting the demands of unique application
requirements (such as latency or throughput). Figure 1 shows examples of all the above-
mentioned categories of NoCs.
Regular NoCs include Æthereal [10], aSoC [11], DyNoC [12], DyXY [13], HERMES [5],
MANGO [14], Proteo [15], SDN-SS [18], SoCBus [16], and SPIN [17]. aSoC and Hermes are
mesh networks that use 𝑛-port switches with (𝑛 − 1) ports for connecting to neighbor switches
and one port for connecting to the local IP block interface, where 𝑛 = 4 and 5 respectively.
SoCBus and aSoC implement circuit switched deterministic routing and assign one virtual
channel. SoCBus uses a minimal path-length routing method to establish the routes statically. In
the case of aSoC, communication is pre-established in a reconfigurable statically-scheduled
system aimed at data-intensive applications. Hermes uses packet switching instead of circuit
switching, employing the XY deterministic approach and assigning one virtual channel. SDN-SS
makes a step towards an adaptive routing strategy while implementing a 2D mesh topology. It
uses a centralized controller which collects the requests from the system manager and searches
for the shortest path between source and target tasks, while avoiding contentions. MANGO not
only implements the mesh topology, but it also provides numerous virtual channels to accomplish
QoS without affecting bandwidth, and it supports both guaranteed services (GS) and best effort
(BE) routing. BE routing covers communications when just accuracy and completeness are
ensured, while GS routing adds timing obligations such minimum throughput or maximum delay.
The Æthereal channel allows point-to-point communication between two network interfaces and
supports both GS and BE services. Offline determined configurations, each corresponding to a
needed user feature, are loaded to the network. To deal with network congestion, DyNoC and
DyXY construct a mesh topology and develop an adaptive variant of the XY deterministic
routing system. Routing in DyNoC includes three modes: N-XY (Normal XY), which acts as a
standard XY router, SH-XY (Surrounding Horizontal XY), which is used when the right or left
routers are congested, and SV-XY (Surrounding Vertical XY), which is used when the upper and
lower routers are overloaded. When it comes to routing, DyXY uses an XY scheme until a
4. Circuits and Systems: An International Journal (CSIJ), Vol.8, No.1/2/3, July 2021
4
network congestion arises. To get past the overloaded zone, it then transfers the packet to the
least loaded neighbor.
SoCBus, aSoC, HERMES, MANGO, Æthereal, DyNoC, and DyXY use 2D mesh topologies,
whereas Proteo [15] and SPIN [17] use hierarchical networks. Proteo is a hierarchical packet-
switching network based on a deterministic hop-by-hop routing algorithm with numerous virtual
channels and built from tiny rings. SPIN, on the other hand, features a fat-tree architecture with
one virtual channel and adaptive routing. The routers are free to use any of the fat tree's
redundant paths, which reduces congestion and improves speed.
Kilo-NoC [19] chooses a MECS (Multidrop Express Channels) topology which uses point-to-
multipoint channels connecting each source node to multiple destinations. It uses elastic buffers
to optimize QoS while reducing the buffering cost. A customed routing strategy is proposed to
exploit the underlying architecture and prevent contentions.
CHAIN [20], OAA [21], µSpider [22], and Xpipes [2], on the other hand, are designs for
adaptive networks, each built at a different system level. CHAIN is a deterministic routing
system that uses fine grain components to target heterogeneous low-power devices. The µSpider
network may be customized using a CAD tool that creates NoC VHDL code at the RTL level,
allowing designers to create ad hoc NoCs based on application requirements. The interconnection
topology and routing protocol, for example, are design-time adjustable µSpider features. The
OAA network may also have its interconnection topology configured at design time. Xpipes, on
the other hand, offers a high-level NoC design and implements a library of design-time
composable soft macros (switches, network interfaces, and links) that can be used to instantiate
and synthesize domain- specific heterogeneous architectures.
When it comes to routing strategies, CHAIN, Xpipes, and µSpider don't provide dynamicity at
the protocol level. SPIN, DyNoC, and DyXY all promise this functionality, but they all have a
defined interconnection architecture. As a result, we introduce SNet, a unique network that
blends flexible connectivity topology with dynamic routing strategy to provide a design that is
suited for future applications and system needs. The DMC accelerator decreases the space needed
while improving performance. SNet was developed to operate with any interconnection topology.
3. THE SNET PARADIGM
3.1. Description of SNet
Scalability and flexibility are improved using the SNet approach. Local communications between
neighboring processors are prioritized, and they can be organized in any regular pattern. After the
layout has been established, the neighborhood, or the number of neighbors for each processor, is
decided to define the interconnection network. As a result, the mesh topology is a 4-neighbor
square arrangement.
Communication requests are routed across shared buffers, with each buffer connecting the two
CPUs on either side. The distributed ACO algorithm, which may fit any layout/neighboring
setup, is being used as SNet's routing strategy. Furthermore, SNet allows users to assign
processing and routing tasks to any of the available cores. As a result, routing PEs create a
completely configurable routing architecture. One of the major motivations for using RISC cores
in processors is to duplicate small-footprint simple cores.
5. Circuits and Systems: An International Journal (CSIJ), Vol.8, No.1/2/3, July 2021
5
We chose a manycore platform, called CEDAR [9], to verify the SNet idea, which consists of an
array of homogenous RISC cores coupled in a mesh manner via shared buffers. The selected
cores have a minimal footprint of 16 𝐾𝐺𝑎𝑡𝑒𝑠 and contain a 4 𝐾𝐵 instruction memory and a 4 𝐾𝐵
local data memory in the platform's actual implementation. [9] has further information about the
CEDAR platform and the ACO algorithm. The following are the features of SNet:
Communication is done by running the ACO algorithm on an arbitrary number of cores
using a routing process. As a result, processors are split between routing and calculating
PEs. The user has the option of defining any routing topology.
The ACO algorithm creates dynamic routes between remote communication tasks
without the need for human intervention. As a result, the user is free of programming
responsibilities. To decrease congestion, paths are spread evenly across routing nodes.
Data transfers are handled by the DMC module, which is a co-processor linked to each
core to speed transmission once routing pathways are dynamically constructed. The
DMCs are linked in a mesh manner on the specified platform.
Multitasking is not handled in the current implementation of SNet, but it will be in future works.
The goal of multitasking is to enhance the core usage rate. After the routes are created by the
routing PEs, the execution moves on to other activities, which might be computation or control
tasks. We can also opt to turn off the routing PEs in order to save power consumption. As a
result, the SNet concept's routes generation phase may be thought of as an initialization operation
that can be revisited during runtime to adjust the routing paths to the current system state and
application requirements.
Figure 2. The CEDAR-H platform featuring a network of DMCs.
6. Circuits and Systems: An International Journal (CSIJ), Vol.8, No.1/2/3, July 2021
6
3.2. The DMC unit
The DMC (Direct Management of Communication) is a brand-new element that has been added
to the CEDAR platform [9]. It is tied to each CPU in order to speed up data transfers between
distant tasks. As a result, the PEs handle the path construction step in software, while the DMCs
handle the data transfers. As illustrated in Figure 2, the DMCs are connected in a point-to-point
way, and packets are routed in a wormhole form. To distinguish between the two platforms, we
will designate CEDAR-S (as for CEDAR-Software) the original one described in [9].
Furthermore, the platform, which includes the DMCs network, will be known as CEDAR-H (as
for CEDAR-Hardware) (cf. Figure 2).
Figure 3 shows the DMC block diagram. It has a link table that is dynamically updated during
path construction by the ACO algorithm. As a result, the link table is a local routing table that
includes compact data for data routing locally. A Finite State Machine (FSM) is included in the
DMC module to manage many requests arriving at the same time while using a round robin
checking technique. A switch is added to this to reroute data in the next valid direction. In
addition to registers and multiplexers for control, one shifter and five AND gates are added for
data processing. Figure 4 shows a closer view of the DMC co-processor.
Figure 3. The DMC unit’s block diagram.
The DMC unit works like this: It starts by looking for requests arriving from one of four
directions: South, East, North, or West. Each request consists of two parts: a 32-bit data to
forward and a 6-bit table index that allows the link table to retain 64 simultaneous interactions.
The number of communications is parameterizable at compile time and can be changed. When a
request is identified, the index is utilized to obtain the next transfer index and direction from the
link table. As a result, the tuple {𝑑𝑎𝑡𝑎/𝑛𝑒𝑤 𝑖𝑛𝑑𝑒𝑥} is routed in the following direction.
The DMC module is extremely efficient, just using one cycle for each data transmission. The
network has a bandwidth of 9.6 𝐺𝑏𝑝𝑠 in its current format. The routing paths established at
runtime determine the minimal message delay. It is possible that the selected route is not the
shortest. The ACO routing protocol considers two criteria while creating these paths: the distance
between the source and destination tasks, and the total of the loads of all crossed routing PEs. The
latter option aids in distributing routes equitably across available resources. We compare the
SNet approach to state-of-the-art NoCs to assess its flexibility, area, and performance. The
overhead incurred by devoting a core to perform routing is discussed in the next section. The
7. Circuits and Systems: An International Journal (CSIJ), Vol.8, No.1/2/3, July 2021
7
average message latencies vs the injection rates are shown to evaluate performance. We also
compare the DMC module's performance to that of [8], following data optimization.
Figure 4. A detailed version of the DMC components.
4. PERFORMANCE COMPARISONS
4.1. Area Comparisons
The primary characteristics of NoC designs are their parametrizability and granularity [3]. The
ease with which a system-level NoC attribute can be modified at instantiation time is referred to
as parametrizability. Thus, it is the NoC's degree of flexibility at the system level, i.e., the number
of malleable factors such as the number of virtual channels in the switch, pipeline stages in the
connections, and so on. Granularity refers to the level of description of the NoC, which is
provided as a single IP at the coarse level and as a series of constructed blocks at the fine level.
Figure 5 depicts a diverse set of NoCs that fill the design space defined by these criteria. To this
figure from [3], the SNet network has been added.
CHAIN [20], for example, provides a library of fine-grained NoC components that the designer
may utilize to construct the appropriate NoC. While the CHAIN NoC is design-flexible, it offers
limited system-level flexibility. The network is described as a rather coarse grain system-level
module by Æthereal [10], SoCBus [16], and aSoC [11], each with its own set of features.
Æthereal has a lot of flexibility when it comes to changing the available slots, whereas aSoC and
SoCBus may not provide a lot of options. However, aSoC allows for flexible connection
programming after instantiation, making it more versatile than SoCBus. HERMES [5], which has
a parameterizable input queue, operates at the same degree of flexibility. With its fixed
architecture and protocol, SPIN [17], built as a single IP core, is the least parameterizable. Xpipes
[2] offers a collection of fine-grain soft macros of switches and pipelined connections that the
Xpipes compiler uses to create an application-specific network automatically. As a result, the
granularity and parametrizability levels are in the midrange. Similarly, the Proteo NoC [15] falls
into the same category since it has adjustable control and data sizes and is made up of tiny ring
8. Circuits and Systems: An International Journal (CSIJ), Vol.8, No.1/2/3, July 2021
8
networks. In the case of the MANGO NoC [14], its router allows for the assumption of GS and
BE service quality, even though the NoC is specified at a very coarse granularity level.
Figure 5. Positioning a collection of NoCs and the SNet paradigm according to the granularity and
parametrizability requirements in the NoCs design space [3].
Table 1 [7] lists the router overhead of the previously stated NoCs. Due to FPGA synthesis or
lack of information, calculations for the DyNoC, DyXY, Kilo-NoC, OAA and µSpider are not
provided. Synthesis methods are performed using various technologies, and we compare them by
scaling the dimensions of the specified NoCs to 40 𝑛𝑚 TSMC.
Table 1. Routers areas for the studied NoCs.
NoCs Tech.
(𝑛𝑚)
Router area
(𝑚𝑚2)
Router area
(𝐾𝐺𝑎𝑡𝑒𝑠)
Est. Router Area,
40 𝑛𝑚, (𝑚𝑚2)
Æthereal 120 0.26 – 0.0234
aSoC 180 0.07 – 0.0018
CHAIN 350 – 4.75 0.0029
HERMES 350 – 10 – 49 0.006 – 0.03
MANGO 130 0.19 – 0.0105
Proteo 180 0.20 – 0.0052
SDN-SS 28 0.0085 – 0.0105
SNet 40 0.012 – 0.014 16 0.012 – 0.014
SoCBus 180 0.04 – 0.08 – 0.001 – 0.002
SPIN 130 0.24 – 0.0132
Xpipes 100 0.1 – 0.0104
We first calculate the total number of gates and then evaluate the area at 40 𝑛𝑚 TSMC. Buffers
are included in the routers zones, and their implementation varies per NoC. The number of virtual
channels (VC), the number of ports, the buffer depth, and the flit width are all listed in Table 2
[7]. By multiplying the four buffer parameters, the total buffer size may be computed. The buffer
sizes for the selected NoCs range from 12 𝑏𝑦𝑡𝑒𝑠 to 600 𝑏𝑦𝑡𝑒𝑠. SNet's router area is computed by
adding one core area to the area of the DMC co-processor (0.162 𝜇𝑚2
at 40 𝑛𝑚 TSMC) and the
9. Circuits and Systems: An International Journal (CSIJ), Vol.8, No.1/2/3, July 2021
9
overhead of the four shared buffers that connect each core to its four closest neighbours. In line
with the computed range of buffer sizes, we evaluate two typical memory sizes, 128 𝑏𝑦𝑡𝑒𝑠 and
512 𝑏𝑦𝑡𝑒𝑠, and the two results are shown in Table 1.
Table 2. Organization of buffers for the evaluated NoCs [7].
NoCs VC Ports Buffer Depth
(𝑓𝑙𝑖t𝑠)
Flit Width (𝑏𝑖𝑡𝑠) Buffer Size
(𝑏𝑦𝑡𝑒𝑠)
Æthereal 1 5 8 3 ∗ 32 480
aSoC 1 4 2 32 32
CHAIN 𝑛/𝑎 𝑛/𝑎 𝑛/𝑎 𝑛/𝑎 𝑛/𝑎
HERMES 1 5 5 – 30 32 100 – 600
MANGO 8 5 1 32 160
Proteo 1 3 7 8 21
SoCBus 1 3 1 16 6
SPIN 1 8 4 ? 32 128 ?
Xpipes 1 4 ? 32 𝑛/𝑎
We can conclude that the least flexible NoCs, such as CHAIN and SoCBus, have the most
reduced areas. While being part of a very flexible network, the SNet router's area takes a middle
range value between Xpipes, SDN-SS and MANGO from one part and SPIN, HERMES, and
Æthereal from the other:
The interconnection architecture is completely configurable, allowing SNet to be
designed in a multitude of contexts.
The number of virtual channels can be increased or decreased as needed. In the actual
implementation, it is set to 64 channels, which is the length of the DMC module's link
table. This table length is parameterizable and may be adjusted at compile time to meet
the needs of the application.
Pathways between communicating tasks are established at runtime and may alter based
on the load at each run.
Users may configure some PEs as routers to map any routing topology on the platform at
instantiation time, allowing them to map any routing topology on the platform. By
replacing the common router with a core, the network gains more programmability and
data control and synchronization is handed to the network level.
Thus, the benefit of SNet is that it provides a programmable, highly flexible communication
network design while still offering a tiny footprint router with a significant memory space.
4.2. Performance comparisons
4.2.1. Simulation Approach
The comparison of performance with state-of-the-art NoCs is a sensitive operation, since
different simulation configurations provide a wide range of observed results. As Salminen et al
[23] point out, measurement setups in NoC publications are frequently imprecise, resulting in
biased comparisons. These can be resumed by the following questions:
How often are bursts of packets injected at a router, and how large are these bursts?
10. Circuits and Systems: An International Journal (CSIJ), Vol.8, No.1/2/3, July 2021
10
How far do packets travel in the network from a source node towards their destination
node?
What proportion of total traffic does each router inject into the network?
By using defined simulation settings and realistic traffic models, we choose an evaluation
technique proposed in [24] to extract the features of various routing topologies applied to SNet.
As a result, we provide a theoretical study aimed at characterizing the SNet paradigm. 16
computational nodes are assigned to the platform, which size varies between 6 × 6 and 8 × 8
processors array, depending on the routing topology. We do handle huge systems in this study,
with thousands of cores, but we focus here on constrained dimensions in order to define SNet in a
reasonable time frame. Each platform node sends 640 messages with 𝑛 flits to the network, with a
flit width of 32 𝑏𝑖𝑡𝑠. 𝑛 is changed between 10 and 1000 𝑓𝑙𝑖𝑡𝑠, which is equivalent to 25 𝐾𝐵 and
2.44 𝑀𝐵 respectively, to evaluate the network saturation limits. In order to mimic realistic traffic,
such as in application runnings, injection is conducted by source processes rather than by a traffic
generator. The simulations are run on the ISS simulator platform, which is based on an ISS array
of RISC processors and simulates one instruction every cycle. The Poisson injection distribution
is used to simulate traffic, and the tested routing topologies, which consist of different task
mappings, are illustrated in Figure 6. Routing PEs are represented with dark grey nodes,
computational PEs are in light grey, and unassigned PEs are white nodes. We emphasize the
benefit of having invariable source codes regardless of the mapping. Because the ACO algorithm
is completely decoupled from the actual location of processes, changing the arrangement of
computing/routing nodes has no effect on the executed programs. The number of PEs allocated to
execute a routing task is what differ between different topologies, while the number of computing
PEs remains the same.
Figure 6. Routing topologies evaluated on the manycore platform.
4.2.2. Conducted Measurements
The injection rate and average message delay parameters are used to evaluate performance.
Equation (1) calculates the injection rate:
where 𝑡ℎ𝑒𝑜𝑟𝑒𝑡𝑖𝑐𝑎𝑙𝐷𝑎𝑡𝑎𝐹𝑙𝑜𝑤 is the bandwidth, which is determined by the number of routers in
the topology under study, and 𝑚𝑒𝑎𝑠𝑢𝑟𝑒𝑑𝐷𝑎𝑡𝑎𝐹𝑙𝑜𝑤 is calculated using simulation. We look at
three possible task distributions across the cores and how they affect latency [24]:
11. Circuits and Systems: An International Journal (CSIJ), Vol.8, No.1/2/3, July 2021
11
(1)
Spaced mapping is the worst case scenario, and it is based on a spatially uniform traffic
distribution.
Localized mapping at a rate of 0.5 is an intermediate scenario.
Best mapping puts the communicating tasks as near as possible, aiming 𝐿𝐹 = 1 if the
topology permits it.
The ratio of local traffic to overall traffic is referred to as the localization factor (𝐿𝐹). As per a
0.5 localization factor, 50% of the traffic generated by source PEs is transmitted to destination
PEs that are one hop away, while the remaining traffic is divided among destination PEs that are
two hops apart.
4.2.3. Results
[8] shows measured latencies for the examined routing topologies under spatially uniform traffic
distribution and best mapping, whereas Figure 7 (a) and (b) show values for localized mapping
with 𝐿𝐹 = 0.5 for the CEDAR-S and CEDAR-H platforms, respectively. Figure 7 (a) shows that
the square topology has the best performance, with a maximum injection rate of 0.67. This is due
to a 50% reduction in the number of remote communications requiring more than two hops to
reach destinations. The square and bridge topologies may both be observed in this way. The
column topology outperforms both L and U topologies. When localized mapping is used, network
traffic is decreased, and the relatively large number of routers manages contentions more
efficiently than in the L and U topologies, where the number of routers is halved when compared
to the column topology. This in no way diminishes the significance of the L and U topologies. It
is a decision the user must take based on the application's requirements, a trade-off between
performance, area efficiency, and topology which best represents task mapping and
communication requirements.
We notice in Figure 7 (b) a shift to the right for the collection of curves when we change to the
CEDAR-H platform. There are three distinct groups in the figure. The L, U, W, Cross, and
Column topologies are present in the first. These have the lowest injection rates, with the Cross
topology reaching a maximum of 0.4. The second set includes the Square and H topologies,
which, because of their larger number of routing PEs, are able to better handle network
congestions. They yield nearly identical results, with a maximum injection rate of 0.47. The third
category is reserved for the bridge topology, which has the highest injection rate equal to 0.8.
12. Circuits and Systems: An International Journal (CSIJ), Vol.8, No.1/2/3, July 2021
12
(a) Simulations conducted on the CEDAR-S platform.
(b) Simulations conducted on the CEDAR-H platform.
Figure 7. Latency variation with Poisson injection distribution for Localized Mapping (𝐿𝐹 = 0.5).
We find that the examined routing topologies span a wide range of injection rate and delay
values. Choosing one of these topologies, or any of the many others, is a matter of the
implemented application. The CEDAR-H platform outperforms CEDAR-S while only occupying
a tiny amount of space overhead. The results indicate that we can get excellent performance even
when striving for flexibility and scalability.
4.2.4. DMC performances
The same simulation experiments are conducted on the CEDAR-S and CEDAR-H platforms to
quantify the DMC performance. To compare the two systems, a fixed injection rate is used, and
average message latencies for all routing topologies are displayed (cf. Figure 8). An injection rate
equal to 0.2 is chosen for spaced mapping, and 0.3 for localized and best mappings. This decision
was made in order to calculate an average message delay value for all topologies. On the
CEDAR- H platform, for example, the maximum injection rate for the L Topology under spaced
mapping is equal to 0.2, hence raising the injection rate will result in no latency for that routing
topology.
13. Circuits and Systems: An International Journal (CSIJ), Vol.8, No.1/2/3, July 2021
13
(a) Spaced Mapping
(b) Localized mapping
(c) Best mapping
Figure 8. Average message latency for CEDAR-S and CEDAR-H platforms under: (a) Spaced mapping,
(b) Localized mapping and (c) Best mapping.
14. Circuits and Systems: An International Journal (CSIJ), Vol.8, No.1/2/3, July 2021
14
As seen in Figure 8 (a), under spaced mapping, the latency values range between 790 and 1200
cycles for CEDAR-S, and between 30 and 120 cycles for CEDAR-H. A performance gain of 94%
is achieved by CEDAR-H compared to the CEDAR-S platform. For the localized mapping (cf.
Figure 8 (b)), the latency values range between 590 and 790 cycles for the CEDAR-S platform,
and between 50 and 195 cycles for the CEDAR-H platform. The latter scores a gain of 82%
compared to the CEDAR-S platform. As for the best mapping (cf. Figure 8 (c)), the latency
values range between 420 and 795 cycles for CEDAR-S, and between 50 and 210 cycles for
CEDAR-H, resulting in an overall gain of 86%. A higher gain percentage is scored for spaced
mapping, compared to localized and best mappings, since the DMC manages to reduce drastically
the network contentions.
We conclude that the studied routing topologies cover a large scale of injection rate and latency
values. CEDAR-S vs. CEDAR-H is a choice between area efficiency and performance.
5. CONCLUSION AND FUTURE WORK
This article introduces SNet, a new routing architecture, and its DMC accelerator. Scalability,
flexibility, and programmability are all features of this paradigm. SNet may be used to design any
interconnection topology and can be applied to any routing topology. It has a hardware module
called DMC that speeds up data transmissions. SNet's router offers a medium range area value
when compared to state-of-the-art NoCs, while being totally configurable and customizable. This
study uses SNet to run over 100 simulations. While performance was not the primary motivation
for this work, the results demonstrated that, despite its high flexibility and scalability, SNet is
able to achieve high injection rates of up to 0.9 and low message latencies. We plan to apply the
multitasking technique to SNet in the future. To maximize space usage, all cores will be able to
dynamically switch between routing and computational tasks. This full dynamic method will be
used in the development of an application.
REFERENCES
[1] Itrs report of the year 2010. [Online]. Available:
http://www.itrs.net/links/2010ITRS/Home2010.htm
[2] D. Bertozzi and L. Benini, “Xpipes: a network-on-chip architecture for gigascale systems-on- chip,”
Circuits and Systems Magazine, IEEE, no. 2, 2004, doi: 10.1109/MCAS.2004.1330747.
[3] T. Bjerregaard and S. Mahadevan, “A survey of research and practices of network-on-chip,” ACM
Comput. Surv., vol. 38, no. 1, p. 1, 2006, doi: 10.1145/1132952.1132953.
[4] Itrs report of the year 2001. [Online]. Available: http://www.itrs.net/Links/2001ITRS/Home.htm
[5] F. Moraes, N. Calazans, A. Mello, L. Moller and L. Ost, “Hermes: an infrastructure for low area
overhead packet-switching networks on chip,” Integration, the VLSI Journal, vol. 38, no. 1, pp. 69 –
93, 2004, doi: 10.1016/j.vlsi.2004.03.003.
[6] Itrs report of the year 1999. [Online]. Available: http://www.itrs.net/links/1999Winter
[7] E. Salminen, “Survey of network-on-chip proposals,” white paper, OCP-IP, pp. 1 – 13, 2008.
[8] C. Azar, S. Chevobbe, Y. Lhuillier and J. Diguet, “SNet, a flexible, Scalable NETwork paradigm for
manycore architectures,” in 2013Seventh IEEE/ACM International Symposium On Networks- On-
Chip (NOCS), Tempe, USA, 2013, pp. 1-2, doi: 10.1109/NoCS.2013.6558414.
[9] C. Azar, S. Chevobbe, Y. Lhuillier and J. Diguet, “Dynamic Routing Strategy for Embedded
Distributed Architectures,” in 2011 18th IEEE International Conference on Electronics, Circuits, and
Systems, 2011, pp. 653-656, doi: 10.1109/ICECS.2011.6122359.
[10] K. Goossens, J. van Meebergen, A. Peeters and R. Wielage, “Networks on silicon: combining best-
effort and guaranteed services,” Proceedings 2002 Design, Automation, and Test in Europe
Conference and Exhibition, 2002, pp. 423 – 425, doi: 10.1109/DATE.2002.998309.
15. Circuits and Systems: An International Journal (CSIJ), Vol.8, No.1/2/3, July 2021
15
[11] J. Liang, S. Swaminathan and R. Tessier, “ASOC: a scalable, single-chip communications
architecture,” Proceedings 2000 International Conference on Parallel Architectures and Compilation
Techniques, 2000, pp. 37 – 46, doi: 10.1109/PACT.2000.888329.
[12] C. Bobda, A. Ahmadinia, M. Majer, J. Teich, S. Fekete and J. van der Veen, “DyNoC: A dynamic
infrastructure for communication in dynamically reconfigurable devices,” International Conference
on Field Programmable Logic and Applications, 2005, 2005, pp. 153 – 158, doi:
10.1109/FPL.2005.1515715.
[13] M. Li, Q. Zeng and W. Jone, “DyXY - a proximity congestion-aware deadlock-free dynamic routing
method for network on chip,” 2006 43rd ACM/IEEE Design Automation Conference, 2006, pp. 849
– 852, doi: 10.1109/DAC.2006.229242.
[14] T. Bjerregaard and J. Sparso, “A router architecture for connection-oriented service guarantees in the
mango clockless network-on-chip,” Design, Automation and Test in Europe, 2005, pp. 1226 – 1261
Vol. 2, doi: 10.1109/DATE.2005.36.
[15] D. Siguenza-Tortosa, T. Ahonen and J. Nurmi, “Issues in the development of a practical NoC: the
proteo concept,” the VLSI Journal, vol. 38, no. 1, pp. 95 – 105, 2004, doi: 10.1016/j.vlsi.2004.07.015.
[16] S. Sathe, D. Wiklund and D. Liu, “Design of a switching node (router) for on-chip networks,” ASIC,
2003. Proceedings. 5th International Conference on, 2003, pp. 75 – 78 Vol. 1, doi:
10.1109/ICASIC.2003.1277494.
[17] P. Guerrier and A. Greiner, “A generic architecture for on-chip packet-switched interconnections,”
Proceedings Design, Automation and Test in Europe Conference and Exhibition 2000, 2000, pp. 250
– 256, doi: 10.1109/DATE.2000.840047.
[18] M. Ruaro, L. L. Caimi and F. G. Moraes, “A Systematic and Secure SDN Framework for NoC-
Based Many-Cores,” IEEE Access, vol. 8, pp. 105997 – 106008, 2020, doi:
10.1109/ACCESS.2020.3000457.
[19] B. Grot, J. Hestness, S. Keckler and O. Mutlu, “A QoS-Enabled On-Die Interconnect Fabric for Kilo-
Node Chips,” IEEE Micro, vol. 32, no. 3, pp. 17 – 35, May-June 2012, doi: 10.1109/MM.2012.18.
[20] J. Bainbridge and S. Furber, “Chain: a delay-insensitive chip area interconnect,” in IEEE Micro, vol.
22, no. 5, pp. 16 – 23, Sept. – Oct. 2002, doi: 10.1109/MM.2002.1044296.
[21] S. Salibekyan and P. Panfilov, “A new approach for distributed computing in embedded systems,”
Procedia Engineering, vol. 100, no. 3, pp. 977 – 986, 2015, doi: 10.1016/j.proeng.2015.01.457.
[22] S. Evain, J. Diguet and D. Houzet, “NoC design flow for TDMA and QoS management in a GALS
context,” EURASIP Journal on Embedded Systems, vol. 2006, no. 1, pp. 63653, 2006, doi:
10.1155/ES/2006/63656.
[23] E. Salminen, A. Kulmala and T.D. Hamalainen, “On the credibility of load-latency measurement of
network-on-chips,” 2008 International Symposium on System-on-Chip, 2008, pp. 1 – 7, doi:
10.1109/ISSOC.2008.4694860.
[24] P. Pande, C. Grecu, M. Jones, A Ivanov and R. Saleh, “Performance evaluation and design trade- offs
for network-on-chip interconnect architectures,” in IEEE Transactions on Computes, vol. 54, no. 8,
pp. 1025 – 1040, Aug. 2005, doi: 10.1109/TC.2005.134.
