HDFS
HADOOP DISTRIBUTED FILE SYSTEM
What is HDFS
HDFS is a Filesystem designed for storing very large files running on
cluster of commodity hardware
It provides fault-tolerant storage layer for Hadoop and other sub-projects
It is a distributed file system that provides high-throughput access to
application data
It stores data reliably even in case of hardware faliure
HDFS Architecture
There are two types of nodes, works in master-slaves pattern
◦ Master (or called as Namenode) – It manages all the slave nodes and assign
work to slaves
◦ Slave (or called as Datanode) – Actual worker nodes, which does actual task
HDFS Architecture
Distributed storage
Data is distributed across the cluster of nodes
Data is splitted into smaller pieces and stored across multiple nodes of
the cluster
In this way it provides a way to Map-Reduce to process subset of large
data parallely on multiple nodes
Distributed storage also provides fault-tolerance capability
Namenode Datanode
Two Daemons Runs for HDFS (for storage)
◦ NameNode
◦ This daemon runs on Master
◦ Namenode stores all the metadata like filename, path, number of blocks, blockIds, block
locations, number of replicas, slave related config, etc.
◦ DataNode
◦ This daemon runs on all the slaves
◦ Datanodes stores the actual data
Namenode Datanode
Blocks
Files are splitted into number of blocks
Unlike 1 KB block size of OS filesystem, HDFS’s default block size is 64
MB (which can be increased according to the requirements)
It saves disk seek time, and other advantage is in the case of processing
(1 Mapper processes 1 block at a time)
Blocks
Replication
In HDFS all the data blocks are replicated across the cluster of nodes
Ideally one replica is present at one geographical location
The default replication factor is 3, which can be changed according to
the requirements.
We can change replication factor to desired value by editing
configuration files
High Availability
HDFS provides high availability of data by creating multiple replicas of
data blocks
If a network link or node or some hardware goes down data will be
available from some other path
If a hardware goes down data can be accessed from other nodes or
other paths as we have replicated data (default 3 replicas)
Reliable Data Storage
Data is stored quite reliably in HDFS, this feature is related to High
Availability.
Since data is highly available due to replication, hence if a node or few
nodes or some hardware crashes, the data will be stored reliably.
We can again balance the cluster by making the replication factor to
desirable value (by running few commands)
In other words we can say Hadoop (HDFS) is fault tolerant
Reliable Data Storage
Scalability
Two ways to scale the Filesystem
◦ Add more disks on the nodes of the cluster
◦ For this we need to edit the configuration files and add corresponding entries of newly added
disks
◦ Horizontal Scaling
◦ Another option is to add more nodes in the cluster
◦ We can add n number of nodes in the cluster on the fly (without any downtime)
File Access & other Operations
Programming
CLI (Command Line Interface)
We can perform almost all the operations which we can do on local
filesystem
HDFS provides different access rights rwx to ugo
We can also browse the filesystem by browser (http://Master-IP:50070)
Read a File
To read a file from HDFS, client needs to interact with Namenode, as
namenode is single place where all the the metadata is stored
Namenode provides the address of the slaves where file is stored
Client will interact with respective datanodes to read the file
Namenode also provide a token to the client which it shows to data
node for authentication
Read a File
Write a File
To write a file into HDFS, client needs to interact with namenode.
Namenode provides the address of the slave on which client will start
writing the data
As soon as client finishes writing the block, the slave starts copying the
block to another slave which in tern copy the block to another slave (3
replicas by default)
After required replicas are created then it will send the acknowledge to
the client
Authentication process (same as file read)
Write a File
Thank You
