1. DDS
RPC over DDS
Gerardo Pardo-Castellote, Ph.D.
Chief Technology Officer, RTI
Sumant Tambe, Ph.D.
Senior Software Reseach Engineer, RTI
October 2014

2. © 2014 Real-Time Innovations, Inc.
Outline
• Goals
• Background
• Status
• Details
• More info

3. Goals
• Provide standard and interoperable way means to
support “RPC” communication patterns in DDS
• Support the Patters:
– Request/Reply
– Service Invocation
– Remote Procedure Call
– Remote Method Invocation
• Support invocation of IDL-specified interfaces over DDS
– Provide a simpler way to migrate CORBA applications to
DDS
– Support familiar “remote interface” programming style
equivalent to Java RMI and Apache Thrift
© 2014 Real-Time Innovations, Inc.

4. Advantages of RPC over DDS
• Client and Servers are decoupled
– No startup dependencies
• QoS enforcement to support service SLAs
– Ownership–Redundant pool of servers
– Lifespan–request is only valid for the next N sec
– Durability-request/replies will be eventually received and processed
– Cancellation– after a good quality response has arrived
© 2014 Real-Time Innovations, Inc.
• Data-Centricity
– Explicit trace-ability
– Interaction state can be Monitored, Logged, Audited, Stored,
Manipulated
• Watch by subscribing to requests and/or responses (wire-tap)
• One middleware – leverage DDS infrastructure
– Suited for real-time systems
– Multiplatform, Multilanguage, Interoperable

5. But I can already do it...
True:
• I can write my own RCP using request/reply Topics
• RTI Connext already supports a “Request/Reply”
equivalent to RPC
• Some other vendors do similar things
But…
• The mapping from service to Topics and Types is ad-hoc.
• These approaches are not portable/Interoperable
• Getting everything right is cumbersome at best
© 2014 Real-Time Innovations, Inc.

6. How can I do it myself?
• Map Interfaces to types & Topics…
– One Topic per interface, one per operation?
– What are the types. How to map exceptions, output
parameters, …
– What happens if the interfaces change, e.g. operation
is added or moved?
• Implement necessary
plumbing:
• Setup request topic and type
• Setup reply topic and type
• Filter unwanted requests
• Filter unwanted replies
© 2014 Real-Time Innovations, Inc.

7. But RPC is not a good/robust
idea/design pattern….
• RPC versus Desired State Pattern
– Insight: Often a request-reply can be modeled as
stateful data-centric interactions
Goal
State
© 2014 Real-Time Innovations, Inc.
write
Current
State
Affect
Service
Client
Service
Provider
Desired
State
read
write
read
read

8. RPC vs Desired State
• Desired state is good & more robust if the “request”
actually represents:
– a request to change of system state
– Take a long time to fulfill
– Needs to be observable by others
© 2014 Real-Time Innovations, Inc.
• However:
– Many requests that do not represent changes to state:
Database Query, Read a File…
– People familiar for “Service” or “Request/Reply” pattern
may find Directed State cumbersome –specially if extra
robustness is unwarranted
RPC over DDS provides best of both worlds!

9. Example: RobotControl
© 2014 Real-Time Innovations, Inc.
module robot {
@DDSService
interface RobotControl
{
void command(Command command);
float setSpeed(float speed) raises (TooFast);
float getSpeed();
void getStatus(out Status status);
};
}

10. RobotControl Client
© 2014 Real-Time Innovations, Inc.
import org.omg.dds.rpc.*;
public class TestRobot {
static void createRobotClient() {
RPCRuntime runtime = RPCRuntime.getInstance(TestRobot.class.getClassLoader());
ClientParams clientParams = runtime.createClientParams(); // optional
RobotControlSupport.Client robotClient =
RobotControlSupport.createClient(
clientParams.withServiceName(”TestRobot”)
.withInstanceName(“iRobot”)); // more configs available
robotClient.waitForService(); // optional
robotClient.getSpeed();
}
}

11. RobotControl Service (Java)
package robot;
import robot.RobotControl;
public class MyRobot implements RobotControl
{
public void command(Command command) { }
public float setSpeed(float speed) { return 1; }
public float getSpeed() { return 2; }
public void getStatus(/* out */ Status status) { }
© 2014 Real-Time Innovations, Inc.
}
import org.omg.dds.rpc.*;
public class TestRobot {
public static void createRobotServer()
{
RPCRuntime runtime = RPCRuntime.getInstance(TestRobot.class.getClassLoader());
MyRobot myRobot = new MyRobot();
Server server = runtime.createServer(); // Configurable using ServerParams
RobotControlSupport.Service service =
RobotControlSupport.createService(myRobot, server); // Configurable using ServiceParams
server.run(); // blocking
}
}

12. RobotControl Requester
© 2014 Real-Time Innovations, Inc.
public class TestRobot {
static void createRobotRequester() {
RPCRuntime runtime =
RPCRuntime.getInstance(TestRobot.class.getClassLoader());
RequesterParams reqParams = runtime.createRequesterParams();
// change params here if you like
Requester<RobotControlSupport.RequestType,
RobotControlSupport.ReplyType>
requester = runtime.createRequester(
RobotControlSupport.RequestType.class,
RobotControlSupport.ReplyType.class,
reqParams);
RobotControlSupport.RequestType request =
new RobotControlSupport.RequestType();
// populate request
requester.sendRequest(request);
}
}

13. RobotControl Replier
public class TestRobot {
static void createRobotReplier() {
RPCRuntime runtime =
RPCRuntime.getInstance(TestRobot.class.getClassLoader());
ReplierParams repParams = runtime.createReplierParams();
// change params here if you like
Replier<RobotControlSupport.RequestType,
RobotControlSupport.ReplyType>
replier = runtime.createReplier(
RobotControlSupport.RequestType.class,
RobotControlSupport.ReplyType.class,
repParams);
Sample<RobotControlSupport.RequestType>
request = replier.receiveRequest();
© 2014 Real-Time Innovations, Inc.
}
}

14. RobotControlSupport
public abstract class RobotControlSupport {
public final static class RequestType {
// omg.dds.rpc.RequestHeader header;
// robot.RobotControl_Call data;
© 2014 Real-Time Innovations, Inc.
}
public final static class ReplyType {
// omg.dds.rpc.ReplyHeader header;
// robot.RobotControl_Return data
}
public interface Client
extends RobotControl,
RobotControlAsync,
ClientEndpoint
{
}
public interface Service extends ServiceEndpoint
{
}
public static final RobotControlSupport.Client createClient();
public static final RobotControlSupport.Service createService(RobotControl impl);
// more client and service factory methods here
}

15. What needs to be specified
• Mapping to DDS Topics & Filters
– Each operation maps to a pair of topics?
• Simplicity, Flexibility vs Scalability
– Each interface to a pair of Topics?
• What are the types? Inheritance?
– Is publish-subscribe allowed? e.g. auditing, monitoring…
• Mapping to DDS Data-types
– How to model operations? Parameters (in, our) return, exceptions, …
– Fragility upon interfaces / operations changes?
– Describable using X-TYPES?
• DDS API and DDS-RTPS impact
– Are extensions required?
– Deployment on top of existing DDS
• Language Bindings (C, C++, Java, C#, …)
© 2014 Real-Time Innovations, Inc.

16. Architecture
Client Application Service
Data
Writer
Message-id1
© 2014 Real-Time Innovations, Inc.
Service
Implementation
Lang.
Bind.
GUID2
Client-side
Invoker
Data
Reader
Data
Reader
Data
Writer
GUID1 SN1 Foo
GUID2 SN2 GUID1 SN1 Bar
Message-id2
Correlation-id1
Content-based Filter for filtering
unwanted replies
Language Binding
Bar Svc.method(in Foo);
Foo
Bar
GUID1
Invoke
Return
Call Topic
Return Topic
Foo
Bar

17. Basic and Enhanced Service Mappings
• Basic
– Highest portability
– Enables RPC on top of existing (v1.3 or earlier) DDS Implementations
© 2014 Real-Time Innovations, Inc.
• Enhanced
– Elegant, Clean
– Leverages DDS-XTypes for type matching,
– Adds support for Robust service discovery, Implicit request/reply correlation
Mapping Aspect Basic Service Mapping Profile Enhanced Service Mapping
Profile
Correlation Information
(request-id)
Explicitly added to the data-type Implicit. They appear on the Sample
meta-data.
Topic Mapping One request topic and one reply topic
per interface. 2*N for a hierarchy of N
interfaces.
One request and one reply topic per
interface. Independent of interface
hierarchy.
Type Mapping Synthesized types compatible with
legacy (pre DDS-XTypes)
implementations.
Use facilities of DDS-XTypes for type
descriptions, annotations, and type-compatibility
checks.
Discovery No special extensions. Robust service discovery (no sample loss
due to transient states)

18. Language Bindings
• Two types of language bindings
– High-level binding that provide function-call semantics
– Low-level binding that are akin to send/receive (but still higher level than raw DDS
© 2014 Real-Time Innovations, Inc.
read/take/write)
• Strong separation between the data model and language binding
Client
Application
Function-call
language
binding
DDS API
Service
Specification
(IDL)
Client
Application
Request-Reply
language
binding
DDS API
Service
Implementation
Function call
language
binding
DDS API
Service
Implementation
Request-Reply
language
binding
DDS API
Service-specific Interoperable/Evolvable Data model (DDS/RTPS)

19. QoS Mapping
• Default strict reliable (request and reply)
– RELIABLE reliability
– KEEP_ALL history
– VOLATILE durability
• Can be changed by the user on a per-service level
© 2014 Real-Time Innovations, Inc.

20. struct RobotControl_setSpeed_In {
long s;
};
struct RobotControl_getSpeed_In {
boolean return_;
};
© 2014 Real-Time Innovations, Inc.
@DDSService
interface RobotControl
{
float setSpeed(float speed) raises (TooFast);
float getSpeed();
void start();
void stop();
};
@choice @autoid
struct RobotControl_Request {
RobotControl_setSpeed_In setSpeed;
RobotControl_getSpeed_In getSpeed;
RobotControl_start_In start;
RobotControl_stop_In stop;
};
@empty
struct start_In { octet dummy_;};
@empty
struct stop_In { octet dummy_;};

21. struct RobotControl_setSpeed_Out {
float return_;
// Also inout and out params
};
…
© 2014 Real-Time Innovations, Inc.
@DDSService
interface RobotControl
{
float setSpeed(float speed) raises (TooFast);
float getSpeed();
void start();
void stop();
};
@choice @autoid
struct RobotControl_setSpeed_Result {
RobotControl_setSpeed_Out out;
SystemExceptionCode sysx_;
TooFast toofast_ex;
};
…
@choice @autoid
struct RobotControl_Reply {
RobotControl_setSpeed_Result setSpeed;
RobotControl_getSpeed_Result getSpeed;
RobotControl_start_Result start;
RobotControl_stop_Result stop;
};

22. Status
• Ongoing standard at OMG
• RFP was issued in June 2012
• Initially 2 competing submissions:
1. Joint RTI + eProsima (later joined by TwinOaks)
2. PrismTech
• Very different approaches – not converging
– Evaluation team representing 5 companies formed to provide
feedback
• Recommendation was to simplify RTI/eProsima submission
• PrismTech dropped their submission and joined RTI/eProsimas’/TwinOaks
• Expected to be voted and adopted in Dec 2014
• Completed Function-Call and Request/Reply language binding
– Java (https://github.com/rticommunity/dds-rpc-java)
– C++* (https://github.com/rticommunity/dds-rpc-cxx)
– eProsima has POC implementation of “basic” profile working with several DDS
© 2014 Real-Time Innovations, Inc.
implementations

23. Questions?
© 2014 Real-Time Innovations, Inc.

24. Find out more…
www.rti.com
community.rti.com
demo.rti.com
www.youtube.com/realtimeinnovations
blogs.rti.com
www.twitter.com/RealTimeInnov
www.facebook.com/RTIsoftware
www.slideshare.net/GerardoPardo
www.slideshare.net/RealTimeInnovations
© 2014 Real-Time Innovations, Inc.
dds.omg.org
www.omg.org
© 2014 RTI
