Improving Manufacturing by Simulation: Processes, Microstructure & Tooling
- 1. improving manufacturing by simulation: Process, Microstructure & Tooling Dr Brian Miller Sales & Marketing Director WildeAnalysis.co.uk WildeAnalysis.co.uk
- 2. Overview • Formed in 1980 as Finite Elements Ltd • 1000+ clients • Member of Wilde Group of 70+ employees and £10m + turnover • Value Added Reseller for ANSYS, Autodesk Moldflow, DEFORM & ReliaSoft • ISO 9001:2008 Approved Quality Management System • On UK-steering committee for NAFEMS and involvement with many industry associations. WildeAnalysis.co.uk
- 3. Wilde Analysis CFD FEA Probability Reliability WildeAnalysis.co.uk 0 L S Value
- 4. Benefits of Simulation • In Design – Improved product performance – optimised – Less R&D lead time, costs and prototypes – Lighter – reduced material and energy costs – More reliable, less requirement for replacement – Enables ‘design for manufacture’ • In Manufacture – Less shop trials – Reduced scrap rates – Less material waste (flash, swarf, runners) – Improved quality & material performance WildeAnalysis.co.uk
- 5. Applications in all Engineering Fields WildeAnalysis.co.uk
- 6. Manufacturing Simulation Topics Blow Moulding, Extrusion & Other Polymer Processes Shape & tooling optimisation (POLYFLOW) + initial property determination for structural analysis Plastic Injection Moulding (Unfilled + Fibre Filled) Shape & tooling optimisation + initial property determination for structural analysis Metal Forming + Heat Treatment + Microstructure Shape & tooling optimisation + initial property determination for structural analysis + multiple process chain WildeAnalysis.co.uk
- 7. Process Modelling • Design for Manufacture • Example: Plastics Design – Assess design – Non-uniform thickness – Poor draft angles / undercuts – Complex and expensive – Assess manufacturability – Areas difficult/impractical to manufacture Courtesy: Autodesk WildeAnalysis.co.uk
- 8. Microstructural Modelling • Provides detailed information about the microstructure during thermo-mechanical processing . • Opportunities to improve process design through understanding impact on material Courtesy: SFTC WildeAnalysis.co.uk
- 9. Tooling Analysis • A carbide insert failed consistently in a high volume steel automotive part. • DEFORM was used in 1996 to isolate the root cause - an axial tensile stress at the fracture initiation point. • After redesign, the life was increased more that ten-fold for the first three stations in the progression. WildeAnalysis.co.uk
- 10. Virtual Prototyping of Blow Moulding Process Simulation / Part Testing (Implicit / Explicit CAD Design Manufacturing structural analysis) modify process modify CAD Fail PASS Courtesy: ANSYS WildeAnalysis.co.uk
- 11. Blow Moulding Process Simulation Courtesy: ANSYS WildeAnalysis.co.uk
- 12. Location of Minimum Thickness Identification of location with smallest thickness. Would this virtual product satisfyingly pass the tests and behave properly under services? Courtesy: ANSYS WildeAnalysis.co.uk
- 13. Effect of Variable Thickness uniform variable thickness thickness Top load - total deformation WildeAnalysis.co.uk
- 14. Moldflow to Structural Analysis • Primary stiffening cover, essential for the entire phone stiffness Courtesy: Autodesk WildeAnalysis.co.uk
- 15. Moldflow to Structural Analysis • Material PA, Zytel HTN53G50HSLR (DuPont) (50%Glass) restraints Vertical force Courtesy: Autodesk WildeAnalysis.co.uk
- 16. Moldflow to Structural Analysis • Gate Location: Top Gate location Fiber orientation Poor orientation in this area Courtesy: Autodesk WildeAnalysis.co.uk
- 17. Moldflow to Structural Analysis • Gate Location: Bottom Gate location Fiber orientation Good orientation in this area Courtesy: Autodesk WildeAnalysis.co.uk
- 18. Moldflow to Structural Analysis • Gate Location: Mid Gate location Fiber orientation Good orientation in this area Courtesy: Autodesk WildeAnalysis.co.uk
- 19. Deflection Comparison • Deflections predicted by Moldflow for different fibre orientations compared to isotropic material Gate location Fiber orientation Max. deflection Bottom Good 4.95mm Mid Good 4.27mm Top Poor 5.29mm Isotropic material 3.45mm Courtesy: Autodesk WildeAnalysis.co.uk
- 20. Stress Comparison –Fully integrated analysis: svonmises=35.9 MPa –Traditional stress analysis: svonmises=14.4 MPa –Fully integrated analysis: svonmises=80.1 MPa –Traditional stress analysis: svonmises=17.2 MPa Courtesy: Autodesk WildeAnalysis.co.uk
- 21. Typical Metal Forming Applications Hot forging Thread rolling Mechanical joining Cogging Machining Other applications Courtesy: SFTC WildeAnalysis.co.uk
- 22. Typical Metal Forming Applications Hot forging Thread rolling Mechanical joining Cogging Machining Other applications Courtesy: SFTC WildeAnalysis.co.uk
- 23. Typical Metal Forming Applications Hot forging Thread rolling Mechanical joining Cogging Machining Other applications Courtesy: SFTC WildeAnalysis.co.uk
- 24. Typical Metal Forming Applications Hot forging Thread rolling Mechanical joining Cogging Machining Other applications Courtesy: SFTC WildeAnalysis.co.uk
- 25. Typical Metal Forming Applications Hot forging Thread rolling Mechanical joining Cogging Machining Other applications Courtesy: SFTC WildeAnalysis.co.uk
- 26. Typical Metal Forming Applications Hot forging Thread rolling Mechanical joining Cogging Machining Other applications Courtesy: SFTC WildeAnalysis.co.uk
- 27. Typical Metal Forming Applications Hot forging Thread rolling Mechanical joining Cogging Machining Other applications Courtesy: SFTC WildeAnalysis.co.uk
- 28. Integrated Process Modeling System Geometry Microstructure Properties Residual Stress Anomalies Cogging Forging Heat Treat Machining Spin Lifing Cogging Shape Cooling Rate Machining Mission Sequence Ram Speed Sequences Cycles Alloy Composition DOE Design Optimization Courtesy: SFTC WildeAnalysis.co.uk
- 29. Machining Distortion • A number of leading aero engine OEMs and disk manufacturers are managing residual stress and machining distortion on a production basis. • Three dimensional capabilities are being developed as an ongoing effort. Courtesy: SFTC WildeAnalysis.co.uk
- 30. Machining Distortion s l o w co o l fa s t q u e n c h residual stress residual stress machining distortion (magnified after heat treatment after machining 20X) Courtesy: SFTC WildeAnalysis.co.uk
- 31. Machining Distortion • Heat treat & machining • 2D 3D conversion can distortion can be modeled in be used to sweep the 2D as an axisymmetric geometry and interpolate model. the residual stress to a • Broaching is simulated using three dimensional model. a 3D model. WildeAnalysis.co.uk
- 32. Metal Forming Simulation – Future Heat Treatment Mechanical Forging Machining Joining Cogging Pull Test Furnace Milling Cold Forming Heating Inertia Welding Casting Life Extrusion Machining Ring Rolling Induction Spot Welding Spin Heating Distortion Testing Rolling Sheet Forming Resistance Stir Welding Heating Courtesy: SFTC WildeAnalysis.co.uk
- 33. Summary • Engineering analysis increasingly applied to both product design and also manufacture. • In the most critical service applications, product optimisation spans multiple dissimilar processes. • Simulating geometry through the manufacturing cycle is inadequate to accurately predict in-service performance. • Prediction of internal properties (microstructure/ residual stress / fibre orientation) is required to simulate the part behaviour through a range of processes. WildeAnalysis.co.uk
Editor's Notes
