RDF & OWL A simple overview of the b uilding blocks of the Semantic Web Presented by Rachel Lovinger   Semantic Web Affini...
RDF =  Resource Description Framework
<ul><li>Purpose: To provide a structure (aka framework) for describing identified things (aka resources) </li></ul>RDF
<ul><li>Identified ?  </li></ul><ul><li>In order to make meaningful statements in RDF, the thing you’re talking about has ...
<ul><li>Composed of three basic elements </li></ul><ul><li>Resources  – the things being described </li></ul><ul><li>Prope...
<ul><li>The elements are combined to make simple statements in the form of Triples </li></ul><ul><li><Subject> <Predicate>...
<ul><li>Information Expressed in Triples </li></ul><ul><li><http://www.w3.org/2001/sw/RDFCore/ntriples/> <dc:creator> &quo...
<ul><li>RDF Properties </li></ul><ul><li>type  </li></ul><ul><li>subClassOf </li></ul><ul><li>subPropertyOf </li></ul><ul>...
<ul><li>type  – a resource belongs to a certain class </li></ul><ul><li><WillSmith> <type> <Actor> </li></ul><ul><li>This ...
<ul><li>subClassOf  – a class belongs to a parent class </li></ul><ul><li><Actor> <subClassOf> <Person> </li></ul><ul><li>...
<ul><li>subPropertyOf  – a property has a parent property  </li></ul><ul><li><hasStar> <subPropertyOf> <hasActor> </li></u...
<ul><li>range  &  domain  – the types of resources that use a property </li></ul><ul><li><hasStar> <range> <Actor> </li></...
<ul><li>label  – a human-readable name for a resource </li></ul><ul><li><http://www.allmovie.com/Actor#WillSmith> <label> ...
<ul><li>comment  – a human-readable description </li></ul><ul><li><https://aarfwiki.main.corp/wiki/index.php/File:RDF_OWL....
RDF Blackberry Fruit typeOf BerryPie EdibleThing typeOf subClassOf ingredientOf Blackberry
<ul><li>Why is RDF uniquely suited to expressing data and data relationships? </li></ul><ul><li>More flexible  – data rela...
Namespaces
<ul><li>A method for qualifying names used in an XML document. Can be used to indicate usage of a standard, or to specify ...
OWL =  Web Ontology Language
OWL
<ul><li>Purpose: To develop ontologies that are compatible with the World Wide Web. </li></ul>OWL
<ul><li>Ontologies ?  </li></ul><ul><li>Definition and classification of concepts and entities, and the relationships betw...
<ul><li>Based on the basic elements of RDF; adds more vocabulary for describing properties and classes. </li></ul><ul><li>...
<ul><li>Relationships between Classes </li></ul><ul><li>disjointWith  – resources belonging to one class cannot belong to ...
<ul><li>Equality </li></ul><ul><li>sameAs  – indicates that two resources actually refer to the same real-world thing or c...
<ul><li>Richer Properties </li></ul><ul><li>Symmetric  – a relationship between A and B is also true between B and A </li>...
<ul><li>Richer Properties continued </li></ul><ul><li>inverseOf  – a relationship of type X between A and B implies a rela...
<ul><li>Class Property Restrictions – define the members of a class based on their properties </li></ul><ul><li>allValuesF...
<ul><li>This seems complicated. Why do it? </li></ul><ul><li>These capabilities allows systems to express and make sense o...
<ul><li>Inferences </li></ul><ul><li>Create new triples based on existing triples </li></ul><ul><li>Deduce new facts based...
<ul><li>Three Flavors of OWL </li></ul><ul><li>OWL Lite  – uses a subset of the capabilities </li></ul><ul><li>OWL DL  – u...
SKOS =  Simple Knowledge Organization System
<ul><li>Also based on RDF </li></ul><ul><li>Designed specifically to express information that’s more hierarchical – broade...
Need more?
<ul><li>SchemaWeb:  http://www.schemaweb.info/default.aspx   </li></ul><ul><li>RDF Primer:  http://www.w3.org/TR/REC-rdf-s...
