The document discusses the benefits of engineered systems over traditional puzzle piece integration. Specifically, it notes that engineered systems allow for cross-domain expertise to work together better by integrating components. It also provides examples of how Exadata storage servers function as smart storage to offload processing from database servers. The document contrasts row and column database formats and how engineered systems allow both formats to coexist and remove tradeoffs.

1. Copyright © 2012, Oracle and/or its affiliates. All rights reserved.1

2. Copyright © 2012, Oracle and/or its affiliates. All rights reserved.2
Why Engineered Systems
Oracle Database 12c
Cary Millsap and Thomas Kyte
http://.....
http://asktom.oracle.com/

3. Copyright © 2012, Oracle and/or its affiliates. All rights reserved.3
In a Warehouse
environment – how many
DBA’s can tell you how
many GB’s/sec they can
transfer from disk to
server?

4. Copyright © 2012, Oracle and/or its affiliates. All rights reserved.4
In an OLTP environment,
what would happen if log
writes on a busy system
went from an average of 3-
5ms to 7-10ms (or longer)?

5. Copyright © 2012, Oracle and/or its affiliates. All rights reserved.5
In a Warehouse
environment – how do you
“size” your storage? By
gigabytes or
gigabytes/second?

6. Copyright © 2012, Oracle and/or its affiliates. All rights reserved.6
In an OLTP environment,
what do you probably wait
on more than anything?

7. Copyright © 2012, Oracle and/or its affiliates. All rights reserved.7
Puzzle Pieces to be integrated, vs Engineered System

8. Copyright © 2012, Oracle and/or its affiliates. All rights reserved.8
Getting cross domain expertise to work together…

9. Copyright © 2012, Oracle and/or its affiliates. All rights reserved.9
Exadata is Smart Storage
 Database Servers
– Perform complex database processing such as
joins, aggregation, etc.
 Exadata Storage Servers
– Storage Server is smart storage, not a DB node
– Search tables and indexes filtering out data that is
not relevant to a query
– Cells serve data to multiple databases enabling
OLTP and consolidation
– Simplicity, and robustness of storage appliance
Compute and Memory
Intensive Processing
Data Intensive
Processing

10. Copyright © 2012, Oracle and/or its affiliates. All rights reserved.10
Until Now Must Choose One Format and Suffer Tradeoffs
Row Format Databases vs. Column Format
Databases
Row
 Transactions run faster on row format
– Example: Insert or query a sales order
– Fast processing few rows, many columns
Column
 Analytics run faster on column format
– Example : Report on sales totals by region
– Fast accessing few columns, many rows
SALES
SALES

11. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. |
Oracle Multitenant
New architecture for consolidating databases and simplifying operations
11
db1 db2
db3 Self-contained PDB for each application
• Applications run unchanged
• Rapid provisioning (via clones)
• Portability (via pluggability)
Shared memory and background
processes
• More applications per server
Common operations performed at CDB
level
• Manage many as one (upgrade, HA, backup)
• Granular control when appropriate
