Idoton Media provides a video streaming solution that allows users to view live video from cameras on mobile devices and computers remotely. The software compresses video on site to minimize bandwidth usage. It streams to over 25 frames per second to almost all mobile phones and internet-connected computers. Key features include live streaming to 20 viewers, motion detection alerts, remote camera control, and password protected access. The system architecture involves network cameras connected to a local computer running the Idoton software, which streams video to authorized remote users over the internet.

1. &

2. Anytime Anywhere
Monitoring
Right where you are.
©2006 New Edge

7. What we do
Idoton Media is a software services business.
We provide tailored video streaming solutions that enable users to
remotely view people, locations, facilities and events live via ordinary cell
phones, mobile smart devices and personal computers.
No additional software is required on any mobile device or remote
computer ie. only the native capabilities of the device are required.
The idoton Media video streaming experience is similar to watching live
broadcast Television with up to 25 frames per second live video.
Our software is loaded on local computer and compresses video footage
at the point of capture to send data using negligible bandwidth and ensure
mobile/satellite data plan friendliness:
5 minutes live viewing = 1 MegaByte (approximately)

8. What we do
We optimize video for the user’s preferred access medium, cell
phone or computer, and deliver password protected video to:
Almost all mobile devices independent of particular mobile operator on
2G (GPRS) or better (3G) networks including Symbian operated cell
phones (Nokia, Sony-Ericsson, Motorola, Samsung, etc), Blackberry,
Windows Mobile smart phones and iPhone.
All Internet enabled computers with broadband Internet connection
independent of preferred Browser (Internet Explorer, Safari, Firefox,
etc)

9. Solution Features
Live, real time video transmission supporting 20+ simultaneous viewers
on any remote computer and cell phones, subject to uplink bandwidth of
satellite Internet connection
Configurable SMS/Email alerts complement existing security systems to
warn of local motion activity within individual camera zones
Video can be recorded according to predefined schedules plus
automatic recording of any local activity, which includes
preceding 30 seconds as lead-in to the activity
As with live video, all recorded video can also be retrieved and played
on any remote computer or cell phone
All video, both live and recorded, includes Date and Time digital
watermarking

10. Solution Features
Live transmission from all cameras on an outlet can be displayed
simultaneously on one full screen on any remote computer without special
software.
Cameras are independently Pan/Tilt/Zoom controllable from any remote
computer or cell phone
Individually configurable access rights by administrators for all Users allows
access to some or all cameras and outlet
Day to day administration of the individual LOOK@LERT EYECommand
applications at each site is via Internet web
portal and is password accessible from any remote computer including:
- Add/Moves/Changes of Users and individual camera and outlet access rights
- Recording Schedules
- Arm/Disarm of alerts

11. High-Level Architecture
IP network cameras on each outlet are powered by a local ToughBook computer and
iDotOn Media’s LOOK@LERT EYECOMMAND software.
Upon request for video access by a remote viewer on computer or cell phone, the
LOOK@LERT EYE Command server is contacted to ensure valid license subscription
and password authorization.
LOOK@LERT EYECOMMAND then sends video company existing satellite connection
directly from the outlet to the remote viewer over the Internet from a public IP address.
No video data is ever sent to any third party including us.

12. Live Demo
www.lalert.net
login : mirage
pass : mirage
choose camera group for 4 grid cctv
click red square button for fullscreen
location : Cilandak, South Jakarta
www.lookatmybaby.net
login : test
pass : test
this demo focusing on comparing webcam
with IP camera (wireless-Linksys and
wired-Axis)

13. Webcam switch
Analog camera
Modem
Router
Speedy
Capture Card PC IP camera
IP Streaming Server
Customer registration
Check valid license on each access
(no video ever sent)
iDotOn server Users

14. Hardware Specification
Streaming Server
- Core2Duo, 2GB RAM, HD 80 GB/4 cameras/month
- support Windows XP or Vista
- support NetFramework 3.5
Modem/Router Speedy
- support DMZ or other feature for publishing IP Address server
Client Network
- streaming TCP Port 554
- streaming UDP Range 10400 - 10900
- minimum 50 kbps/camera for realtime streaming
Client Cellphone
- iPhone, BB, Symbian 60, and WinMobile support
- support streaming flv and mjpeg (Real Player / WMP standard)
- apn cellular provider support streaming
- minimum 40 kbps/camera for realtime streaming
