In this knolx, I'll be discussing about the components involved in setting up an EC2 instance and how we can achieve it via Terraform

1. Presented By: Yatharth Sharma
Understanding AWS
with Terraform

2. Lack of etiquette and manners is a huge turn off.
KnolX Etiquettes
Punctuality
Respect Knolx session timings, you
are requested not to join sessions
after a 5 minutes threshold post
the session start time.
Feedback
Make sure to submit a constructive
feedback for all sessions as it is
very helpful for the presenter.
Silent Mode
Keep your mobile devices in silent
mode, feel free to move out of
session in case you need to attend
an urgent call.
Avoid Disturbance
Avoid unwanted chit chat during
the session.

3. Agenda
01 Introduction to Cloud Providers - AWS
02 Benefits
03 AWS Infrastructure
04 Setting up Infrastructure - From Scratch
05 Infrastructure as Code - Terraform
04 Demo

4. Introduction to Cloud Providers - AWS
General Client-Server Architecture
Server Components
● Compute (CPU)
● Memory (RAM)
● Storage
Database (Structured Storage)
Network Devices
● Routers
● Switches
● DNS server

5. Benefits
● On Demand service
● Pay as you go
● Access resources instantly
● Easy to access/use

6. AWS Infrastructure
● AWS is global
○ Regions
■ Availability Zones
● Data Centers
○ Edge Locations (Point of Presence)
AWS Infrastructure

7. Setting up Infrastructure -
From Scratch
LucidChart

8. Setting up Infrastructure -
From Scratch
● VPC - Logically Isolated sections where AWS Resources are launched.
● Subnet - Logical subdivision of an IP network.
● Internet Gateway - Highly available VPC component that allows communication between your
VPC and the internet.
● Elastic IP - An Elastic IP address is a static IPv4 address.
● NAT Gateway - Enable instances in a private subnet to connect to the internet or other AWS
services, but prevent the internet from initiating a connection with those instances.
● Route Tables - Contains a set of rules, called routes, that are used to determine where network
traffic from your subnet or gateway is directed.
● Instance - Server holding compute, storage and memory

9. Infrastructure as Code
Provisioning Infrastructure via s/w to achieve consistent and predictable
environments.
Benefits of IaC
● Automate deployment
● Consistent environments
● Reusable components
● Documented Architecture

10. IaC - Terraform
Features of Terraform
● Defined in code
● Stored in source control
● Declarative Syntax
● Idempotent
● Follows Push mechanism

11. IaC - Terraform
Terraform Concepts
● Provider
○ AWS, Azure, GCP
terraform {
required_providers {
aws = {
source = "hashicorp/aws"
version = "3.23.0"
}
}
}
provider "aws" {
# Configuration options
}

12. IaC - Terraform
Terraform Concepts
● Resources
○ VPC, Subnet, Instance, RDS
resource "aws_vpc" "main" {
cidr_block = "10.0.0.0/16"
instance_tenancy = "default"
tags = {
Name = "main"
}
}

13. IaC - Terraform
Terraform Concepts
● Variables
○ Image id, AZs etc
variable "user_information" {
type = object({
name = string
address = string
})
sensitive = true
}
resource "some_resource" "a" {
name = var.user_information.name
address = var.user_information.address
}

14. IaC - Terraform
Terraform Concepts
● Data
data "aws_ami" "web" {
filter {
name = "state"
values = ["available"]
}
filter {
name = "tag:Component"
values = ["web"]
}
most_recent = true
}
resource "aws_instance" "web" {
ami = data.aws_ami.web.id
instance_type = "t1.micro"
}

15. IaC - Terraform
Terraform Concepts
● Output
output "instance_ip_addr" {
value = aws_instance.server.private_ip
description = "The private IP address of the main server instance."
}

16. Terraform
Benefits out of the box
● Inspect state file
● Dependency graph: Tf knows the order in which resources needs to be created first
● Calculates Additions, updations and deletions
● Parallel Execution
● Allow saving the plan

17. Demo

18. Thank You !
Get in touch with me:
yatharth.sharma@knoldus.com
