1. UI Testing in Xcode 7
Dominique Stranz

3. UI TESTING IN XCODE 7
Example Test: Successful user login
1) tap my account button
2) tap log in button
3) tap & type e-mail
4) tap & type password
5) tap log in button

4. UI TESTING IN XCODE 7
Example Test: Successful user login
@interface Account : XCTestCase
@property (strong) TestUser *user;
@end
@implementation Account
- (void)setUp {
[super setUp];
[self createUser]; //we are creating test user account here, it will be used in all test cases
self.continueAfterFailure = NO;
}
- (void)tearDown {
[super tearDown];
}
- (void)testLogin_CredentialsAreValid_ShouldLogin {
}

5. RECORDING…

6. UI TESTING IN XCODE 7
Recording…
Problem with non-ascii characters
Not so useful with localised appsComplicated and not
universal queries

7. Testability
Quality of Accessibility Data
source: WWDC, Session 406

8. UI TESTING IN XCODE 7
UIAccessibility identifiers
Unique identifiers allow recorder to use simpler queries
‣ Locale independent
‣ Ignored by Voice Over

9. UI TESTING IN XCODE 7
How to set UIAccessibility identifiers?
@protocol UIAccessibilityIdentification <NSObject>
@required
/*
A string that identifies the user interface element.
default == nil
*/
@property(nullable, nonatomic, copy) NSString *accessibilityIdentifier
NS_AVAILABLE_IOS(5_0);
@end

10. UI TESTING IN XCODE 7
We can choose from several options to find element
We should use more precise query, if our accessibility
identifier or label isn’t unique:

11. UI TESTING IN XCODE 7
Why not share our identifiers between app & test targets?
…and finally use user credentials created in setUp method.

12. EXPLANATION

13. UI TESTING IN XCODE 7
XCUIElement - proxy for all application UI elements
XCUIElement UIButton
UITextField
UITableViewCell
and others…
‣ currentTitle
‣ currentAttributedTitle
‣ text
‣ placeholder
‣ textLabel.text
‣ detailTextLabel.text
‣ title
‣ label
‣ value
‣ placeholderValue
‣ identifier
‣ selected
‣ frame
‣ …

14. UI TESTING IN XCODE 7
Interactions
XCUIElement
‣ title
‣ label
‣ value
‣ placeholderValue
‣ identifier
‣ selected
‣ frame
‣ …
- (void)typeText:(NSString *)text;
- (void)tap;
- (void)doubleTap;
- (void)twoFingerTap;
- (void)tapWithNumberOfTaps:(NSUInteger)numberOfTaps
numberOfTouches:(NSUInteger)numberOfTouches;
- (void)pressForDuration:(NSTimeInterval)duration;
- (void)pressForDuration:(NSTimeInterval)duration
thenDragToElement:(XCUIElement *)otherElement;
- (void)swipeUp;
- (void)swipeDown;
- (void)swipeLeft;
- (void)swipeRight;
- (void)pinchWithScale:(CGFloat)scale velocity:(CGFloat)velocity;
- (void)rotate:(CGFloat)rotation withVelocity:(CGFloat)velocity;

15. UI TESTING IN XCODE 7
Element queries
XCUIElement
‣ title
‣ label
‣ value
‣ placeholderValue
‣ identifier
‣ selected
‣ frame
‣ …
/*! Returns a query for all descendants of the element matching the
specified type. */
- (XCUIElementQuery *)descendantsMatchingType:(XCUIElementType)type;
/*! Returns a query for direct children of the element matching the
specified type. */
- (XCUIElementQuery *)childrenMatchingType:(XCUIElementType)type;

16. UI TESTING IN XCODE 7
Element queries
XCUIElement
‣ title
‣ label
‣ value
‣ placeholderValue
‣ identifier
‣ selected
‣ frame
‣ …
/*! Returns a query for all descendants of the element matching the
specified type. */
- (XCUIElementQuery *)descendantsMatchingType:(XCUIElementType)type;
@property (readonly, copy) XCUIElementQuery *tables;
@property (readonly, copy) XCUIElementQuery *buttons;
@property (readonly, copy) XCUIElementQuery *staticTexts;
@property (readonly, copy) XCUIElementQuery *textFields;
@property (readonly, copy) XCUIElementQuery *secureTextFields;
@property (readonly, copy) XCUIElementQuery *textViews;

17. UI TESTING IN XCODE 7
Element queries
XCUIElement
‣ title
‣ label
‣ value
‣ placeholderValue
‣ identifier
‣ selected
‣ frame
‣ …
[element descendantsMatchingType:XCUIElementTypeButton];
element.buttons

18. UI TESTING IN XCODE 7
Root element - XCUIApplication
@interface XCUIApplication : XCUIElement
- (void)launch;
- (void)terminate;
@property (nonatomic, copy) NSArray <NSString *> *launchArguments;
@property (nonatomic, copy) NSDictionary <NSString *, NSString *> *launchEnvironment;
@end

19. UI TESTING IN XCODE 7
XCUIElementQuery
@interface XCUIElementQuery : NSObject <XCUIElementTypeQueryProvider>
@property (readonly) NSUInteger count;
- (XCUIElement *)elementBoundByIndex:(NSUInteger)index;
- (XCUIElement *)elementMatchingPredicate:(NSPredicate *)predicate;
- (XCUIElement *)elementMatchingType:(XCUIElementType)elementType
identifier:(nullable NSString *)identifier;
- (XCUIElement *)objectForKeyedSubscript:(NSString *)key;
@end

20. UI TESTING IN XCODE 7
XCUIElementQuery
@interface XCUIElementQuery : NSObject <XCUIElementTypeQueryProvider>
@property (readonly) NSUInteger count;
- (XCUIElement *)elementBoundByIndex:(NSUInteger)index;
- (XCUIElement *)elementMatchingPredicate:(NSPredicate *)predicate;
- (XCUIElement *)elementMatchingType:(XCUIElementType)elementType
identifier:(nullable NSString *)identifier;
- (XCUIElement *)objectForKeyedSubscript:(NSString *)key;
@end
▸ Evaluates the query
▸ Return the number of matches found

21. UI TESTING IN XCODE 7
XCUIElementQuery
@interface XCUIElementQuery : NSObject <XCUIElementTypeQueryProvider>
@property (readonly) NSUInteger count;
- (XCUIElement *)elementBoundByIndex:(NSUInteger)index;
- (XCUIElement *)elementMatchingPredicate:(NSPredicate *)predicate;
- (XCUIElement *)elementMatchingType:(XCUIElementType)elementType
identifier:(nullable NSString *)identifier;
- (XCUIElement *)objectForKeyedSubscript:(NSString *)key;
@end
▸ Return nth element in query results
▸ Example:
XCUIElement *firstCell = [app.tables.cells elementBoundByIndex:0];

22. UI TESTING IN XCODE 7
XCUIElementQuery
@interface XCUIElementQuery : NSObject <XCUIElementTypeQueryProvider>
@property (readonly) NSUInteger count;
- (XCUIElement *)elementBoundByIndex:(NSUInteger)index;
- (XCUIElement *)elementMatchingPredicate:(NSPredicate *)predicate;
- (XCUIElement *)elementMatchingType:(XCUIElementType)elementType
identifier:(nullable NSString *)identifier;
- (XCUIElement *)objectForKeyedSubscript:(NSString *)key;
@end
▸ Example:
NSPredicate *labelPrefixPredicate = [NSPredicate predicateWithFormat:
@"label BEGINSWITH %@", prefix];
XCUIElement *label = [app.staticTexts
elementMatchingPredicate:labelPrefixPredicate];

23. UI TESTING IN XCODE 7
XCUIElementQuery
@interface XCUIElementQuery : NSObject <XCUIElementTypeQueryProvider>
@property (readonly) NSUInteger count;
- (XCUIElement *)elementBoundByIndex:(NSUInteger)index;
- (XCUIElement *)elementMatchingPredicate:(NSPredicate *)predicate;
- (XCUIElement *)elementMatchingType:(XCUIElementType)elementType
identifier:(nullable NSString *)identifier;
- (XCUIElement *)objectForKeyedSubscript:(NSString *)key;
@end
▸ Example:
XCUIElement *button = [app elementMatchingType:XCUIElementTypeButton
identifier:@"login"];

24. UI TESTING IN XCODE 7
XCUIElementQuery
@interface XCUIElementQuery : NSObject <XCUIElementTypeQueryProvider>
@property (readonly) NSUInteger count;
- (XCUIElement *)elementBoundByIndex:(NSUInteger)index;
- (XCUIElement *)elementMatchingPredicate:(NSPredicate *)predicate;
- (XCUIElement *)elementMatchingType:(XCUIElementType)elementType
identifier:(nullable NSString *)identifier;
- (XCUIElement *)objectForKeyedSubscript:(NSString *)key;
@end
▸ Example:
XCUIElement *button = app.buttons[@"login"];

25. DEMO

26. UI TESTING IN XCODE 7
How to asset test results?
▸ We can use all variants of XCTAssert macro
▸ But more accurate for asynchronous UI are expectations
XCUIElement *loggedInLabel = app.tables.staticTexts[Identifier_Account_LoggedInLabel];
NSPredicate *exists = [NSPredicate predicateWithFormat:@"exists == 1"];
[self expectationForPredicate:exists evaluatedWithObject:loggedInLabel handler:nil];
[self waitForExpectationsWithTimeout:15 handler:nil];

27. UI TESTING IN XCODE 7
Performance test
- (void)testLogin_CredentialsAreValid_ShouldLogin {
[self measureBlock:^{
//UITest code
}];
}
▸ Xcode executes each test 10 times and compare average execution
time with baseline (selected from previous results)
▸ Test will fail if new average has increased from baseline by 10% or
more, but it will ignore regressions of less than a tenth of a second

28. TIPS & TRICKS

29. UI TESTING IN XCODE 7
Handle UI interruptions
▸ Setup interruptions monitor
[self addUIInterruptionMonitorWithDescription:@"Location Permission"
handler:^BOOL(XCUIElement *element) {
XCUIElement *button = alert.buttons[@"Allow"];
if (button.exists) {
[button tap];
return true;
}
return false;
}];
▸ Handlers are invoked in reverse order
until one of them return true
1 2

30. UI TESTING IN XCODE 7
Handle UI interruptions
▸ By default, XCode 7.2 will try to find &
tap elements matching predicate:
userTestingAttributes CONTAINS "cancel-button"
userTestingAttributes CONTAINS "default-button"
1 2

31. UI TESTING IN XCODE 7
Handle UI interruptions
▸ By default, XCode 7.2 will try to find &
tap elements matching predicate:
userTestingAttributes CONTAINS "cancel-button"
userTestingAttributes CONTAINS "default-button"
2▸ Do you prefer confirm button as first
choice? Add your own monitor:
NSPredicate *predicate = [NSPredicate predicateWithFormat:
@"userTestingAttributes CONTAINS "default-button""];
XCUIElement *button = [alert.buttons elementMatchingPredicate:predicate];
if (button.exists) {
[button tap];
return true;
}

32. UI TESTING IN XCODE 7
Typing in secure text field doesn’t work
▸ Workaround: Disconnect Hardware Keyboard in Simulator
▸ „Neither element or any descendant has keyboard focus”
error occurs when you are trying to type in secure UITextField

33. ▸ Instead, we should check if element is hittable:
UI TESTING IN XCODE 7
Why your test is not waiting for hidden elements?
▸ Hidden elements fulfil exists predicate:
[NSPredicate predicateWithFormat:@"exists == 1"]
[NSPredicate predicateWithFormat:@"hittable == 1"]

34. UI TESTING IN XCODE 7
How to detect that app is in test mode?
XCUIApplication * app = [[XCUIApplication alloc] init];
[app setLaunchArguments:@[@"UITESTS"]];
[app launch];
NSArray *arguments = [[NSProcessInfo processInfo] arguments];
if ([arguments containsObject:@"UITESTS"]) {
//Customize app for tests
}
▸ In test file:
▸ In application:

35. UI TESTING IN XCODE 7
How to speed up tests?
▸ Disable animations in AppDelegate:
NSArray *arguments = [[NSProcessInfo processInfo] arguments];
if ([arguments containsObject:@"UITESTS"]) {
[UIView setAnimationsEnabled:NO];
}

36. ▸ Waiting for element is one of the most cases in UI tests,
why not use convenient helper?
UI TESTING IN XCODE 7
Waiting for elements shortcuts
NSPredicate *exists = [NSPredicate predicateWithFormat:@"exists == 1"];
[self expectationForPredicate:exists evaluatedWithObject:element handler:nil];
[self waitForExpectationsWithTimeout:15 handler:nil];
[self waitForElement:element];
[self waitForElement:button withTimeout:60];

37. ▸ Waiting for element is one of the most cases in UI tests,
why not use convenient helper?
UI TESTING IN XCODE 7
Waiting for elements shortcuts
NSPredicate *exists = [NSPredicate predicateWithFormat:@"hittable == 1"];
[self expectationForPredicate:exists evaluatedWithObject:element handler:nil];
[self waitForExpectationsWithTimeout:15 handler:nil];
[self waitForElementHittable:element];
[self waitForElementHittable:button withTimeout:60];

38. ▸ Waiting for element is one of the most cases in UI tests,
why not use convenient helper?
UI TESTING IN XCODE 7
Waiting for elements shortcuts
NSPredicate *exists = [NSPredicate predicateWithFormat:@"hittable == 1"];
[self expectationForPredicate:exists evaluatedWithObject:element handler:nil];
[self waitForExpectationsWithTimeout:15 handler:nil];
[self waitForElementHittable:element];
[self waitForElementHittable:button withTimeout:60];
https://github.com/dstranz/XCUITestsAdditions
pod "XCUITestsAdditions"

39. UI TESTING IN XCODE 7
Change device orientation
[[XCUIDevice sharedDevice] setOrientation:UIDeviceOrientationLandscapeRight];
[[XCUIDevice sharedDevice] setOrientation:UIDeviceOrientationLandscapeLeft];
▸ Landscape
[[XCUIDevice sharedDevice] setOrientation:UIDeviceOrientationPortraitFaceUp];
[[XCUIDevice sharedDevice] setOrientation:UIDeviceOrientationPortraitFaceDown];
▸ Portait

40. UI TESTING IN XCODE 7
Simulates the user pressing a physical button
[[XCUIDevice sharedDevice] pressButton:XCUIDeviceButtonHome];
[[XCUIDevice sharedDevice] pressButton:XCUIDeviceButtonVolumeUp];
[[XCUIDevice sharedDevice] pressButton:XCUIDeviceButtonVolumeDown];
▸ Home button
▸ Volume up
▸ Volume down
▸ Volume up & down doesn’t work on simulator

41. UI TESTING IN XCODE 7
Test coverage

42. UI TESTING IN XCODE 7
How to reset simulator state before each test?
It’s not possible to force launching app on clean simulator
(rdar://22455111).
What are workarounds?

43. UI TESTING IN XCODE 7
How to reset simulator state before each test?
▸ If you are using CI, you can run xcrun simctl erase all
between each test cases
▸ You can clean NSUserDefaults and Keychain in
AppDelegate, when app is in UITests mode
▸ …or rollback changes in tearDown method
(for example logout user after login test)

44. THANK YOU
