AIM:
          TRIGGER AND CURSOR PROGRAM USING SQL


                             INTRODUCTION:
In SQL procedures, a cursor make it possible to define a result set (a set of data
     rows) and perform complex logic on a row by row basis. By using the same
mechanics, an SQL procedure can also define a result set and return it directly to
            the caller of the SQL procedure or to a client application.



A cursor can be viewed as a pointer to one row in a set of rows. The cursor can only
   reference one row at a time, but can move to other rows of the result set as
                                      needed.



         To use cursors in SQL procedures, you need to do the following:

                   1)Declare a cursor that defines a result set.

                  2)Open the cursor to establish the result set.

3)Fetch the data into local variables as needed from the cursor, one row at a time.

                          4)Close the cursor when done.



     The SQL CREATE TRIGGER statement provides a way for the database
  management system to actively control, monitor, and manage a group of tables
whenever an insert, update, or delete operation is performed. The statements
  specified in the SQL trigger are executed each time an SQL insert, update, or
delete operation is performed. An SQL trigger may call stored procedures or user-
 defined functions to perform additional processing when the trigger is executed.




                                  CURSOR PROGRAM:

 The following PROGRAM uses a cursor to select the five highest paid employees
                                  from the emp table.



                                        Input Table

                   SQL> SELECT ename, empno, sal FROM emp ORDER BY sal DESC;




                                  ENAME          EMPNO        SAL

                                    ---------- --------- --------

                                   KING           7839     5000

                                   SCOTT          7788      3000

                                   FORD           7902      3000

                                   JONES           7566     2975

                                   BLAKE          7698      2850

                                   CLARK          7782      2450

                                   ALLEN          7499      1600

                                   TURNER          7844      1500

                                   MILLER          7934     1300

                                   WARD            7521     1250

                                  MARTIN           7654      1250

                                   ADAMS           7876      1100
JAMES           7900      950

               SMITH           7369      800

                      PL/SQL Block




            -- available online in file 'sample2'

                         DECLARE

                        CURSOR c1 is

            SELECT ename, empno, sal FROM emp

    ORDER BY sal DESC; -- start with highest paid employee

                my_ename VARCHAR2(10);

                  my_empno NUMBER(4);

                  my_sal NUMBER(7,2);

                          BEGIN

                          OPEN c1;

                     FOR i IN 1..5 LOOP

        FETCH c1 INTO my_ename, my_empno, my_sal;

EXIT WHEN c1%NOTFOUND; /* in case the number requested */

                       /* is more than the total    */

                       /* number of employees       */

 INSERT INTO temp VALUES (my_sal, my_empno, my_ename);

                           COMMIT;

                         END LOOP;

                         CLOSE c1;

                           END;


                   Output Table



     SQL> SELECT * FROM temp ORDER BY col1 DESC;
NUM_COL1 NUM_COL2 CHAR_COL

                                    -------- -------- --------

                                      5000      7839 KING

                                      3000      7902 FORD

                                      3000     7788 SCOTT

                                     2975      7566 JONES

                                      2850     7698 BLAKE




                                 TRIGGER PROGRAM

This trigger will insert a record into the table 'product_check' before a sql
             update statement is executed, at the statement level.

               CREATE or REPLACE TRIGGER After_Update_Row_product

                                            AFTER

                                     insert On product

                                     FOR EACH ROW

                                             BEGIN

                              INSERT INTO product_check

                        Values('After update, Row level',sysdate);

                                             END;

                                                /

                  Now lets execute a update statement on table product.




                        UPDATE PRODUCT SET unit_price = 800

                             WHERE product_id in (100,101);

Lets check the data in 'product_check' table to see the order in which the trigger is fired.
SELECT * FROM product_check;

                             Output:




     Mesage                                    Current_Date




    ------------------------------------------------------------




     Before update, statement level            26-Nov-2008

  Before update, row level                        26-Nov-2008

After update, Row level                             26-Nov-2008

Before update, row level                            26-Nov-2008

After update, Row level                              26-Nov-2008

     After update, statement level              26-Nov-2008
