If you are looking formore detail in iProcess Server’s architecture we can see that its engines are
organized into nodes, where a node is formed by 1 or N iProcess Engine servers sharing a database
instance. If there is more than one engine for load balancing or fault tolerance, it’s called a node
cluster. Engines use Remote Procedure Calls (RPC) to communicate with the clients and can be
split into four parts:
• Process Sentinels
• Foreground Processes
• Background Processes
• MBox Set

3. www.adlearnings.com
Process Sentinels: which are responsible for making sure that the rest of the processes are
running.
Foreground Processes: processes dealing with user interaction.
Background Processes: processes performing the “internal” tasks.
MBox Set: communication link between background and foreground processes
The Server comes with a client interface called Objects Server which provides an API to interact
with the engine. It is available in two “flavors”:
Process Objects (TPO): a thick client implementation API for COM/C++/Java.
Server Objects (TSO): a thin client implementation API for EJB and .NET.
Business Processes executed by the iProcess Server can interact with external systems as well
using EAI plugins. There are plug-ins for different systems, including BusinessWorks, Oracle, Java,
SQL Server and scripts.

4. www.adlearnings.com
Unlock a locked iProcess Procedure:
When you don’t properly close your iProcess procedure you have a chance of locking the object
for further use.For some strange cosmic reason, this happens to me a lot. To fix this quickly in a
DEV environment connect to the iProcess database and search for the following tables, find the
record and delete it.
List cases in a Procedure in TIBCO iProcess:
Commands to do: 1) To List cases in a process
In the command prompt on the server run
2) To List all outstanding cases per process plist –o PROC >outfilePROC.txt
3) To Check outstanding steps plist -D PROC >outfilePROC.txt
4) Check WIS and system setup plist -w PROC >outfilePROC.txt
5) Check contents of a queue plist -mWv PROC >outfilePROC.txt
