1. 101
Streaming Reliability Engineering
Yusuke Goto @ AbemaTV, Inc.

2. Yusuke Goto
五藤 佑典
https://ygoto3.com/
@ygoto3_
● Majored in Graphic Design at California State University, San Bernardino
● Software engineer @ CyberAgent, Inc. and AbemaTV, Inc.
● CyberAgent, Inc.
○ A Developer Expert in video technology and product design
● AbemaTV, Inc.
○ Lead Video Streaming Client Engineering team
○ Lead Cross Device Engineering team

3. in Video Technology and Product Design

4. Internet media
● Blogging platform
● Music streaming
● Game
● Curation
● Ad product
Development
● Ad agency
Broadcasting
● News
● Documentary
● Drama
● Anime
● Sports
● Music
● Movies
- Internet TV station -

6. 20+ channels * 24/7 + 30,000 Episodes Always Available
20+ Channels 24/7 EPG
* Japan’s biggest content library

7. 2.3 Tbps (via Akamai’s Adaptive Media Delivery)
updated Japan’s highest traffic on July 9th, 2019.

8. We’re Reinventing the TV, Making it Extremely Convenient
Professional news
Live streaming
Simultaneity
Anywhere
● Phones
● TVs
● Desktops
● Tablets
● Smart Speakers
● Smart Displays
Anytime
● Timeshift playback
● Catchup playback
● Double-speed
playback

9. https://abema.tv/

10. Why Reliability Engineering is Important
● Keep creating new service values by challenging technical edges
● Keep our service reliable all the time
Our limited resource
Development
? %
Operation
? %

11. Why Reliability Engineering is Important
● Keep creating new values by challenging technical edges
● Keep our system available all the time
Our limited resource
Development
? %
Operation
? %
Reliability engineering gives us a way to decide
the balance between development and operation

12. W/o Reliability Engineering
● Quality improvement depends on an individual’s ownership
● Confusion by subjective reviews from app stores and SNS
● Gradually degraded service quality can be ignored

13. W/o Reliability Engineering
● Quality improvement depends on an individual’s ownership
● Confusion by subjective reviews from app stores and SNS
● Gradually degraded service quality can be ignored
As a result,
reliability will be lost

14. Google’s SRE Practice
The ideas of Google’s SRE practice can be applied to video streaming
https://sre.google/books/

15. Streaming Reliability Engineering
Not Site Reliability Engineering
● We consider it to be a part of Site Reliability Engineering
● A reliability engineering part which requires domain knowledge in video
streaming

16. Defining the Video Streaming Level
When can you say your video streaming service is reliable enough?
Service Level Terminologies
● Service Level Indicators a.k.a. SLI
○ a carefully defined quantitative measure of some aspect of the level of service that is provided
● Service Level Objectives a.k.a. SLO
○ a target value or range of values for a service level that is measured by an SLI
● Service Level Agreements a.k.a. SLA
○ an explicit or implicit contract with your users that includes consequences of meeting (or
missing) the SLOs they contain

17. This is an example of how
a video streaming service tries
Reliability Engineering

18. Defining Video Streaming SLOs
Based on which playback behaviors really matter to a user
Key questions: Does a viewer
● Succeed to start watching the content?
● Smoothly watch the whole content with no interruption?
● Watch the content in a good video quality?
● Not wait long for the content to start playing?

19. Defining Video Streaming SLOs
Does a viewer succeed to start watching the content?
● The most critical question
● It matters regardless of usecase type
● If a viewer fails, it means we fail to provide no value as a video streaming
service

20. Defining Video Streaming SLOs
Does a viewer smoothly watch the whole content with no interruption?
● The second most critical question
● It matters regardless of usecase type
● If a viewer doesn’t, it means we give him or her a stressful experience

21. Defining Video Streaming SLOs
Does a viewer watch the content in a good video quality?
● The question differentiates ABEMA from others
● 2 types of video quality
○ Resolution
■ Matters most when watching it on a big screen
○ Encoding
■ Matters regardless of usecase type
● If its quality is not satisfactory, it means we possibly get him or her away from
our service

22. We’re Reinventing the TV, but Extremely Convenient
Professional news
Live streaming
Simultaneity
Anywhere
● Phones
● TVs
● Desktops
● Tablets
● Smart Speakers
● Smart Displays
Anytime
● Timeshift playback
● Chasing playback
● Double-speed
playback

23. Various Types of Usecases
● Phones
● Tablets
● TVs
● Web on Desktops
● Web on Phones
● Smart Speakers
● Smart Displays

24. Defining Video Streaming SLOs
Does a viewer not wait long for the content to start playing?
● It matters most when a viewer zaps channels
○ Essential experience of TV
● If a viewer waits long, it means we fail to provide value equivalent to the TV
broadcasting

25. Converting Key Questions into Indicators
Does a viewer succeed to start watching the content?
Startup Success Rate

26. Converting Key Questions into Indicators
Does a viewer succeed to start watching the content?
Startup Success Rate

27. Converting Key Questions into Indicators
Does a viewer smoothly watch the whole content with no interruption?
Successful Playback Rate

28. Converting Key Questions into Indicators
Does a viewer smoothly watch the whole content with no interruption?
Successful Playback Rate

29. Converting Key Questions into Indicators
Does a viewer watch the content in a good video quality?
Rendition Distribution Success Rate
Video Quality MOS Success Rate

30. Converting Key Questions into Indicators
Does a viewer watch the content in a good video quality?
Rendition Distribution Success Rate
Video Quality MOS Success Rate
The indicator is about the
video resolution

31. Converting Key Questions into Indicators
We used to value other indicators :
● Round-Trip Time
● Bandwidth
● Bitrate
● Throughput

32. Converting Key Questions into Indicators
We used to value other indicators :
● Round-Trip Time
● Bandwidth
● Bitrate
● Throughput
A user doesn’t care even if these are bad

33. Converting Key Questions into Indicators
We used to value other indicators :
● Round-Trip Time
● Bandwidth
● Bitrate
● Throughput
A user doesn’t care even if these are bad
A user cares the video’s resolution !

34. Converting Key Questions into Indicators
Rendition Distribution Success Rate A more user-centric indicator

35. Converting Key Questions into Indicators
Rendition Distribution Success Rate A more user-centric indicator
How often we provide the preferable rendition matters
regarding the video quality

36. Converting Key Questions into Indicators
Rendition Distribution Success Rate A more user-centric indicator

37. Converting Key Questions into Indicators
Does a viewer not wait long for the content to start playing?
Join Time Success Rate

38. Categorizing the SLIs
Indicators for QoS
(Quality of Service)
● Startup Success Rate
● Successful Playback Rate
Indicators for QoE
(Quality of Experience)
● Rendition Distribution
Success Rate
● Video Quality MOS
Success Rate
● Join Time Success Rate

39. Video Streaming SLIs Video Streaming SLOs

40. What do SLOs mean?
When an SLO is not met:
● Our service loses users’ trust
● An SLO should trigger an action to reachieve it
● The priority of taking back reliability should be higher than that of developing
a new feature

41. Defining Video Streaming SLOs
1. Collect the current facts
2. Decide a threshold for each SLI in order to keep the current service level
3. Decide your ideal objectives which we should aim in a longer period

43. Creating SLO Document
Category SLI SLO
QoS Startup Success Rate 99%
QoS Smooth Playback Success Rate 99%
QoE Rendition Distribution Success (>= 1080p 60%) Rate
for TV
90%
QoE Video Quality MOS Success (>= 3.0) Rate 90%
QoE Join Time Success (<= 3 secs) Rate
for Linear
75%

44. Updating SLO Document towards Your Ideal Objectives
Category SLI SLO
QoS Startup Success Rate 99.99%
QoS Smooth Playback Success Rate 99%
QoE Rendition Distribution Success (>= 1080p 80%) Rate
for TV / Desktop
90%
QoE Video Quality MOS Success (>= 4.0) Rate 90%
QoE Join Time Success (<= 2 secs) Rate
for Linear
90%

45. Deciding an Internal SLAs
More like agreements between developers and business owners

46. Collecting Indicators from Monitoring Metrics
● # of Startup Errors
● # of In-Stream Errors
● Rendition Distribution
● Join Time
● Video Quality MOS

47. It’s time to challenge the new technical experiments
while your SLOs are met ...

48. Now we need to prevent SLIs from being degraded
as time passes

49. Practices to Keep Achieving SLOs
● Alerting on SLOs
○ Respond to problems before you consume too much of your error budget
● Change Management
○ Take a good care of uncontrollable changes on your users’ environments
● Fallback Strategies
○ Make an aggressive stream less risky

50. Alerting on SLOs
The simplest way to set an alert is simply too fragile.
Target Error Rate ≥ SLO Threshold

51. Target Error Rate ≥ SLO Threshold
has too many false positive alerts

52. https://sre.google/workbook/alerting-on-slos/

53. We better focus only on significant alerts,

54. We better focus only on significant alerts,
or we will be exhausted very soon..

55. A Significant Event
An event that consumes a large fraction of the error budge
Not this Not this

56. A Significant Event
An unsiginificant event could blind
responders with visibly loud noise

57. A Significant Event
Of course paging is worse
under such situation...

58. Introducing Burn Rate Strategy
It alerts only when a error budget spend is significant enough
https://sre.google/workbook/alerting-on-slos/

59. Change Management
Staged Rollout + Experimentation
Alpha / Beta
(internal developers
/ opt-in users)
Staged rollout
Production
(100% of users)
1% 50%
10%
50%
A/B Testing

60. Ephemeral Change Management
Take a good care of uncontrollable changes on your users’ environments
● App version updates
● OS version updates
● Firmware updates
● Brand-new hardware releases
● Automatic SDK updates
● Combinations of updates

61. App version updates
Product Engineering Team Video Engineering Team

62. App version updates
Product Engineering Team Video Engineering Team
Releases a new version

63. App version updates
Product Engineering Team Video Engineering Team
Releases a new version Could affect video playback

64. App version updates
Product Engineering Team Video Engineering Team
Releases a new version

65. App version updates
Product Engineering Team Video Engineering Team
Releases a new version Sets alerts on the latest version

66. App version updates
Product Engineering Team Video Engineering Team
Releases a new version Sets alerts on the latest version
Segmented alert

67. Automatic SDK updates
IMA SDK
Uses
Native Bridge
JavaScript
Refers

68. Automatic SDK updates
IMA SDK
Uses
Native Bridge
JavaScript
Native Bridge
JavaScript
New !
Refers

69. Automatic SDK updates
IMA SDK
Uses
Native Bridge
JavaScript
Native Bridge
JavaScript
Native Bridge
JavaScript
New !
Refers

70. Automatic SDK updates
Once it happens, patch the uncovered pitfall
to make sure at least the same problem won’t
happen again.

71. Combinations of updates
Uses
Latest
Firmware
Old
Firmware
CAF
Receiver SDK
CAF
Receiver SDK
Automatic update Automatic update

72. Combinations of updates
Uses
Old
Firmware
Latest
Firmware
Old
Firmware
CAF
Receiver SDK
CAF
Receiver SDK
Automatic update Automatic update
Stop
Updating

73. Combinations of updates
CAF
Receiver SDK
CAF
Receiver SDK
CAF
Receiver SDK
Automatic update
Old
Firmware
Latest
Firmware
Old
Firmware
Automatic update
Stop
Updating

74. Fallback Strategy: Aggressive stream to Safe Stream
Modifying clients so that aggressive failures are less likely to cause user harm

75. Aggressive video stream - Low-latency news
Pros:
● A viewer watches news contents close to the real time
● Knowing what happens right now can save people’s lives during a disaster
Cons:
● Shorter segment length => Less buffering length => More rebuffering events

76. Aggressive video stream - Ad-personalized linear
Pros:
● A viewer watches potentially more interesting ads
○ Viewers and advertisers are both happy
Cons:
● High load on deciding personalized ads => Streams could be unstable

77. Fallback Strategy: Aggressive stream to Safe Stream
Modifying clients so that aggressive failures are less likely to cause user harm

78. Fallback Strategy: Aggressive stream to Safe Stream
Modifying clients so that aggressive failures are less likely to cause user harm
If a viewer watching an aggressive stream experiences
● Rebuffer Events
● Startup Errors
● In-Stream Errors
x times in y seconds,
then the player automatically switches to a safe stream

79. Fallback Strategy: Aggressive stream to Safe Stream
Modifying clients so that aggressive failures are less likely to cause user harm
If a viewer watching an aggressive stream experiences
● Rebuffer Events
● Startup Errors
● In-Stream Errors
x times in y seconds,
then the player automatically switches to a safe stream
A fallback strategy makes
aggressive video streams safer
in a user’s environment

80. Conclusion
● Reliability engineering is an essential strategy for service innovation
● Applying reliability engineering to a video streaming service is hard
● Some practices work fine and others don’t for your service
○ Find your own practice
○ The example here is far from perfect - we keep exploring further
● No option but more practices

81. Yusuke Goto
五藤 佑典
https://ygoto3.com/
@ygoto3_
Thank you !
