1. SQL for Pattern Matching
LOGAN PALANISAMY

2. Agenda
 Introduction to regular expressions
 RegEx functions in Oracle
 SQL for Pattern Matching

3. Meeting Basics
 Put your phones/pagers on vibrate/mute
 Messenger: Change the status to offline or
in-meeting
 Remote attendees: Mute yourself (*6). Ask
questions via WebEx.

4. What are Regular Expressions?
 A way to express patterns
 credit cards, license plate numbers, vehicle identification
numbers, voter id, driving license, SSNs, phone numbers
 UNIX (grep, egrep), PHP, JAVA support Regular
Expressions
 PERL made it popular

5. Regular Expression Examples
Example Meaning
[0-9]{10,} 10 or more digits.
[0-9]{3}-[0-9]{2}-[0-9]{4} Social Security number
([0-9]{3})[1-9]{3}-[0-9]{4} Phone number (xxx)yyy-zzzz
d{1,3}.d{1,3}.d{1,3}.d{1,3} Very basic IPv4 address format using
Perl notation
(d{4}[- ]?){3}d{4} Credit Card (three occurrences of four
digits followed optionally by a space or
dash, and one 4-digit series)
[1-9][A-Z]{3}[0-9]{3} Car License Plate in California
[A-Z][a-z]+(s+[A-Z][a-z]*)?s+[A-Z][
a-z]+
First name, optional Middle
Initial/name, and Last name
([01]?[0-9][0-9]?|2[0-4][0-9]|25[0-
5].){3}([01]?[0-9][0-9]?|2[0-4][0-
9]|25[0-5])
IPv4 address format

6. Regular Expression Meta Characters
6
Meta
character
Meaning
. Matches any single "character" except newline.
* Matches zero or more of the character preceding it
e.g.: bugs*, table.*
^ Denotes the beginning of the line. ^A denotes lines starting
with A
$ Denotes the end of the line. :$ denotes lines ending with :
Escape character (., *, [, , etc)
[ ] matches one or more characters within the brackets. e.g.
[aeiou], [a-z], [a-zA-Z], [0-9], [[:alpha:]], [a-z?,!]
[^] negation - matches any characters other than the ones
inside brackets. eg. ^[^13579] denotes all lines not starting
with odd numbers, [^02468]$ denotes all lines not ending
with even numbers

7. Extended Regular Expressions Meta Characters
Meta character Meaning
| alternation. e.g.: the(y|m), (they|them)
+ one or more occurrences of previous character.
? zero or one occurrences of previous character.
{n} exactly n repetitions of the previous char or group
{n,} n or more repetitions of the previous char or
7
group
{n, m} n to m repetitions of previous char or group
(....) grouping or subexpression
n back referencing where n stands for the nth sub-expression.
e.g.: 1 is the back reference for first
sub-expression.

8. POSIX Character Classes
POSIX Description
[:alnum:] Alphanumeric characters
[:alpha:] Alphabetic characters
[:ascii:] ASCII characters
[:blank:] Space and tab
[:cntrl:] Control characters
[:digit:]
[:xdigit:] Digits, Hexadecimal digits
[:graph:] Visible characters (i.e. anything except spaces, control characters,
etc.)
[:lower:] Lowercase letters
[:print:] Visible characters and spaces (i.e. anything except control
characters)
[:punct:] Punctuation and symbols.
[:space:] All whitespace characters, including line breaks
[:upper:] Uppercase letters
[:word:] Word characters (letters, numbers and underscores)

9. Perl Character Classes
9
Perl POSIX Description
d [[:digit:]] [0-9]
D [^[:digit:]] [^0-9]
w [[:alnum:]_] [0-9a-zA-Z_]
W [^[:alnum:]_] [^0-9a-zA-Z_]
s [[:space:]]
S [^[:space:]]

10. Tools to learn Regular Expressions
 http://www.weitz.de/regex-coach/
 http://www.regexbuddy.com/

11. String operations before Regular Expression
support in Oracle
 Pull the data from DB and perform it in middle tier
or FE
 LIKE operator
 OWA_PATTERN in 9i and before

12. LIKE operator
 % matches zero or more of any character
 _ matches exactly one character
 Examples
 WHERE col1 LIKE 'abc%';
 WHERE col1 LIKE '%abc';
 WHERE col1 LIKE 'ab_d';
 WHERE col1 LIKE '_%' escape '';
 WHERE col1 NOT LIKE 'abc%';
 Very limited functionality
 Check whether first character is numeric: where c1 like '0%' OR c1
like '1%' OR .. .. c1 like '9%'
 Very trivial with Regular Exp: where regexp_like(c1, '^[0-9]')

13. REGEXP_* functions
 Available from 10g onwards.
 Powerful and flexible, but CPU-hungry.
 Easy and elegant, but sometimes less performant
 Usable on text literal, bind variable, or any column
that holds character data such as CHAR, NCHAR,
CLOB, NCLOB, NVARCHAR2, and VARCHAR2
(but not LONG).
 Useful as column constraint for data validation

14. REGEXP_LIKE
 Determines whether pattern matches.
 REGEXP_LIKE (source_str, pattern,
[,match_parameter])
 Returns TRUE or FALSE.
 Use in WHERE clause to return rows matching a pattern
 Use as a constraint
 alter table t add constraint alphanum check (regexp_like (x,
'[[:alnum:]]'));
 Use in PL/SQL to return a boolean.
 IF (REGEXP_LIKE(v_name, '[[:alnum:]]')) THEN ..
 Can't be used in SELECT clause
 regexp_like.sql

15. REGEXP_SUBSTR
 Extracts the matching pattern. Returns NULL when
nothing matches
 REGEXP_SUBSTR(source_str, pattern [, position [,
occurrence [, match_parameter]]])
 position: character at which to begin the search.
Default is 1
 occurrence: The occurrence of pattern you want to
extract
 regexp_substr.sql

16. REGEXP_INSTR
 Returns the location of match in a string
 REGEXP_INSTR(source_str, pattern, [, position [,
occurrence [, return_option [, match_parameter]]]])
 return_option:
 0, the default, returns the position of the first character.
 1 returns the position of the character following the occurence.
 regexp_instr.sql

17. REGEXP_REPLACE
 Search and Replace a pattern
 REGEXP_REPLACE(source_str, pattern [,
replace_str] [, position [, occurrence [,
match_parameter]]]])
 If replace_str is not specified, pattern/search_str is
replaced with empty string
 occurence:
 when 0, the default, replaces all occurrences of the match.
 when n, any positive integer, replaces the nth occurrence.
 regexp_replace.sql

18. REGEXP_COUNT
 New in 11g
 Returns the number of times a pattern appears in a
string.
 REGEXP_COUNT(source_str, pattern [,position
[,match_param]])
 For simple patterns it is same as
(LENGTH(source_str) –
LENGTH(REPLACE(source_str,
pattern)))/LENGTH(pattern)
 regexp_count.sql

19. Why “SQL for Pattern Matching”
 Deficiency of REGEXP_* functions
 Retrieving contiguous rows that are inter-related.
 Shortcoming of LEAD/LAG analytic functions

20. Example: Identify successive login failures
 Given a sequence of records, identify two or more
consecutive login failures showing all the details
SELECT user_id, login_time, result, mn, classifier
FROM logins MATCH_RECOGNIZE (
PARTITION BY user_id
ORDER BY login_time
MEASURES MATCH_NUMBER() as MN,
CLASSIFIER() as classifier
ALL ROWS PER MATCH
PATTERN (F{2,} S)
DEFINE
F AS result = 'FAILURE',
S AS result = 'SUCCESS’)
ORDER BY user_id, login_time;
 Logins_pm.sql

21. Components of SQL for pattern matching
 PARTITION BY: Logically divides the rows into groups
 ORDER BY: Orders the rows in a partition
 [ONE ROW | ALL ROWS] PER MATCH: Chooses
summaries or details for each match
 MEASURES: Defines calculations for use in the query
 PATTERN: Defines the row pattern to be matched
 DEFINE: Defines primary pattern variables
 AFTER MATCH SKIP: Defines where to restart the
matching process after a match is found
 SUBSET: Defines union row pattern variables

22. Operator Precedence
 Order of precedence
1. Quantifiers (*, +, {n, m}, etc)
2. Concatenation
3. Alternation (vertical bar “|” is the alternation operator)
 PATTERN (A B*)
 Is equivalent to PATTERN (A (B*))
 But not equivalent to PATTERN ((A B)*)
 PATTERN (A B | C D)
 Is equivalent to PATTERN ( (A B) | (C D))
 But not equivalent to PATTERN ( A (B | C) D)

23. Your Pals: MATCH_NUMBER & CLASSIFIER:
The two most useful functions
 MATCH_NUMBER ()
 Tells which rows are members of which match
 CLASSIFIER()
 Tells which pattern variable applies to which rows

24. Difference between an Empty Match and No
Match
 Empty-Match: A match with zero rows
 PATTERN (X*) could result in an empty match
 MATCH_NUMBER() increases for an empty-match
 CLASSIFIER() returns null value
 No match: No match at all
 PATTERN (X+) will never produce an empty-match. It either
matches something or doesn’t.
 empty_N_nomatch.sql

25. EMS Incident analysis
 Show worst incident periods (e.g. series of
Sev0/Sev1/Sev2s back to back)
 Show series of incidents that affected multiple
properties
 Explain how the following thing work
 PERMUTE (A, B, C)
 Not displaying certain matched rows with {- -}
 Incidents_pm.sql

26. Example: Sessionization of clickstream data
 Sessionize based on 30 or more minutes of inactivity
select *
from clicks MATCH_RECOGNIZE (
partition by user_id
order by click_time
MEASURES MATCH_NUMBER() as session_id
ALL ROWS PER MATCH
PATTERN (A B*)
DEFINE
B AS B.click_time < PREV(B.click_time) + 1/48
)
ORDER BY user_id, click_time;
 clicks_pm.sql

27. Defining Where to Restart the Matching Process
After a Match Is Found
 AFTER MATCH SKIP TO NEXT ROW: Resume pattern
matching at the row after the first row of the current
match.
 AFTER MATCH SKIP PAST LAST ROW: Resume pattern
matching at the next row after the last row of the current
match. The default
 AFTER MATCH SKIP TO FIRST pattern_variable:
Resume pattern matching at the first row that is mapped
to the pattern variable.
 AFTER MATCH SKIP TO LAST pattern_variable:
Resume pattern matching at the last row that is mapped
to the pattern variable.

28. AFTER MATCH SKIP .. : Things to watch out for
1. Resuming at non-existent row
AFTER MATCH SKIP TO B
PATTERN (A B* C)
2. Resuming at the same row (infinite loop)
AFTER MATCH SKIP TO A
PATTERN (A B+ C+)
3. Resuming at the same row or non-existent row
AFTER MATCH SKIP TO FIRST A
PATTERN (A* B)

29. Greedy Versus Reluctant quantifier
 By default, quantifiers are greedy. They try to match
as many instances of regular expression as possible.
 A* or A+ will try to match as many instances of A as possible
 Greedy behavior can be changed to reluctant by
suffixing the quantifiers with a question mark
 A*? Or A+? will match only as few instances of A as possible
 It is also called Lazy match
 greedy_vs_reluctant.sql

30. RUNNING vs FINAL Semantics
 RUNNING semantics
 Includes the rows from the beginning of the match to the
currently matched rows.
 This is the default
 Could be used in MEASURES and DEFINE sections
 FINAL semantics
 Includes all rows in a match
 Could be used only in MEASURES
 running_vs_final.sql

31. Detecting spikes/drops, and trends
 Simple V-Shape with 1 Row Output per Match (Ex.
18-1)
 Simple V-Shape with All Rows Output per Match
(Ex. 18-2)
 Pattern match for a W-Shape (Ex. 18-4)
 Pattern match V and U shapes (Ex. 18-11)
 Other detectable trends:
 Linearly increasing or Linearly decreasing
 Increasingly increasing or Increasingly decreasing
 Decreasingly increasing or Decreasingly decreasing

32. References
 Oracle Data Warehousing Guide (12c), Chapter 18

33. Q&A
