1. SECURING
ANDROID
APPLICATIONS October 2014

2. http://www.linkedin.com/jmortega1
https://speakerdeck.com/jmortega/
@jmortegac

3. ARCHITECTURE / DALVIK VM / SANDBOX
ANDROID APPLICATIONS / PERMISSIONS
UTILS EXECUTION ENVIRONMENT
TOOLS ECLIPSE / ANDROID STUDIO
COMPONENTS SECURITY / STATIC ANALYSIS
ENCRYPTION / OBSFUSCATION
REVERSING APK TOOLS
APK ANALYZERS / PENTESTING / FORENSICS

4. Android Architecture

5. Dalvik VM
REGISTER-BASED VIRTUAL MACHINE
RUN ON A SLOW CPU WITH LITTLE RAM
OPTIMIZED FOR MOBILE DEVICES
DEX(Dalvik executable)

6. Dalvik vs ART(4.4)
DALVIK
ART
Just-In-Time (JIT) Compilation
Ahead-Of-Time (AOT) Compilation
Cache builds up over time
Boot times are faster
Cache is built at first boot Rebooting device takes significantly longer
Apps compiled when executed
Stores Compiled Apps
Consumes much more internal storage space
Settings>Developer options>Select runtime

7. Sandbox
Each app gets a unique linux ID(uid) and Groud ID(gid)
Gets own dedicated process and dedicated dalvik VM
Applications are "self-signed" with certificate signed by Developer
Apps can share the data with other apps using content providers
Permissions determine the capacity for communication components
The App Data gets stored in /data/data/<app process> accessible only by UID and GID
(root exceptional)

8. /data/data
Apps installed by user
Apps installed by google default : play store, play music , maps
Apps that are manufacturer specific : HTC sense, touchwiz
Apps that are shipped with stock rom : browsers
ROOT

9. Android Applications

10. APK Generating
ZIP + jarsigner+ zipalign for optimizing apk

11. Obtain APK
Google Play
Alternative markets (BlackMart, Fdroid, Aptoide)
Apk extractor
http://apps.evozi.com/apk-downloader

13. Permissions model
Android permissions protect
Access to sensitive APIs
Access to content providers
Inter- and intra-application communication
Protection mechanism to interact with other applications
Location (GPS), Camera, Bluetooth, Telephony, SMS/MMS, Network/data
AndroidManifest.xml

14. Permissions

15. Permissions
 Be carefull with install
applications
 Recommend install some
application to check permissions
 Disable automatic updates and
check application permissions
manually each time an application
wants to be installed or updated

16. Permissions in apps
Check permissions in runtime
PackageManager pm = context.getPackageManager();
int hasPerm = pm.checkPermission( android.Manifest.permission.WRITE_EXTERNAL_STORAGE, context.getPackageName());
if (hasPerm != PackageManager.PERMISSION_GRANTED) { // do stuff}
private boolean checkWriteExternalPermission(){
String permission = "android.permission.WRITE_EXTERNAL_STORAGE";
int res = getContext().checkCallingOrSelfPermission(permission);
return (res == PackageManager.PERMISSION_GRANTED);
}

17. Protection levels
normal: Default level for not application system, always granted
dangerous: Higher-Risk permission for access to private data. Requires user approval. SEND_SMS,ACCESS_FINE_LOCATION
signature Matching signature key. Two apps signed with the same certificate
system, signatureOrSystem:Same as signature, but also system apps pre- installed like Google Play Services

18. Permissions in apps
Minimize requested permissions
Users like apps that request few permissions
33% apps request more permissions that they need
Get Camera Pic need android.permission.CAMERA?
ContentValues contentValues = new ContentValues();
contentValues.put(MediaStore.Images.Media.DESCRIPTION, "Image capture");
contentValues.put(MediaStore.Images.Media.TITLE, "new image");
Uri uri = getContentResolver().insert(MediaStore.Images.Media.EXTERNAL_CONTENT_URI, contentValues);
Intent intent = new Intent(MediaStore.ACTION_IMAGE_CAPTURE);
intent.putExtra(MediaStore.EXTRA_OUTPUT, uri);
intent.putExtra(MediaStore.EXTRA_VIDEO_QUALITY, 1);
startActivityForResult(intent, 1);

19. Permissions in apps
Application don`t need permission to get a camera pic
<uses-permission android:name="android.permission.CAMERA" />
Where is the permission?
In the Google Camera Application
GoogleCamera.apk

20. Permissions in apps
Create custom permissions
<permission android:name="android.permission.CUSTOM_PERMISSION"
android:protectionLevel="normal" android:label="@string/custom_permission_label">
<permission android:name="android.permission.SEND_SMS"
android:permissionGroup=“android.permission-group.COST_MONEY"
android:protectionLevel="dangerous"
android:label="@string/permlab_sendSms"
android:description="@string/permdesc_sendSms" />

21. Permissions in apps
Group permissions
<permission-group android:name="android.permission-group.LOCATION"
android:description="@string/permgroupdesc_location" />
<!-- Allows an application to access fine (e.g., GPS) location -->
<permission android:name="android.permission.ACCESS_FINE_LOCATION"
android:permissionGroup="android.permission-group.LOCATION"
android:protectionLevel="dangerous"
android:description="@string/permdesc_accessFineLocation" />
<!-- Allows an application to access coarse (e.g., Cell-ID, WiFi) location -->
<permission android:name="android.permission.ACCESS_COARSE_LOCATION"
android:permissionGroup="android.permission-group.LOCATION"
android:protectionLevel="dangerous"
android:description="@string/permdesc_accessCoarseLocation" />

23. Install in SD CARD
<manifest xmlns:android="http://schemas.android.com/apk/res/android" package="com.example1" android:versionCode=“1" android:versionName="1.0" android:installLocation="auto|preferExternal"> <uses-sdk android:minSdkVersion="8" android:targetSdkVersion="19" /> </manifest>
$ adb shell
$ pm set-install-location 2
0 [auto]: Let system decide the best location1 [internal]: Install on internal device storage2 [external]: Install on external media

24. Check if Play Store is the installer
Check if Debuggable

25. Check Running emulator
Check Debugger certificate

26. Check signing key

27. Root detection
private boolean isDeviceRooted(){
try{
Runtime.getRuntime().exec("su");
return true;
}catch(IOExeception ex){
return false;
}
}
public static boolean() isDeviceRooted(){
File f= new File("/system/sbin/su");
return f.exits();
}

29. Malware
•Installing applications from known sites
•Check permissions during installation / upgrade
•Review comments from users
•Update the operating system and applications.
•Disable automatic connection to WiFi networks and avoid connecting to free WiFi
•Disable BlueTooth when not in use
Recommendations to avoid malware

30. Malware detection in Google play
Bluebox Security Scanner
SRT AppScanner
Lookout Mobile Security
Advanced Mobile Care
Malwarebytes Anti-Malware
CM Security

31. foresafe.com/scan
mobilesandbox.org
andrototal.org
copperdroid

33. Signing applications
Purpose of certificates in Android is to distinguish application authors
Android won't allow application to be upgraded unless signed with same certificate the applications are signed with the same key.
Android allows applications that are signed with the same certificate to run in the same processes
All applications must be signed with a digital certificate

34. Signing applications
Java keytool
$ keytool -genkey -v -keystore <keystore filename> -alias <alias for key> -keyalg RSA -keysize 2048 -validity 10000

35. Sign apk with private key
Check the apk signature
sm 236 Sun Feb 02 15:08:10 CET 2014 javamail.pop3.provider
X.509, CN=Android Debug, O=Android, C=US [certificate is valid from 3/04/13 18:13 to 27/03/43 17:13]
54226 Sun Feb 02 15:08:10 CET 2014 META-INF/MANIFEST.MF
54279 Sun Feb 02 15:08:10 CET 2014 META-INF/CERT.SF
1203 Sun Feb 02 15:08:10 CET 2014 META-INF/CERT.RSA
s = signature was verified
m = entry is listed in manifest
k = at least one certificate was found in keystore
i = at least one certificate was found in identity scope
jar verified.
Signing applications
$ jarsigner -verify -certs -verbose testing.apk
$ jarsigner -verbose -sigalg SHA1withRSA -digestalg SHA1 -keystore mykeystore testing.apk <alias_name>

36. Android Studio
Tool included in Android SDK for apk compress and optimizing
$ zipalign -f 4 app-signed.apk final-app.apk
Build > Generate Signed APK

37. Eclipse/Android Studio

40. Content Providers
A specialized type of complex data store in Android to standardize access and manipulation of stored data
Browser: bookmarks, browse history
CallLog: missed calls, call details
Contacts: Contact details
MediaStore: Media files

41. Content Providers
Offers a structured storage mechanism that can be limited to your own application or exported to allow access by other applications.
android:exported =“false"
android:exported ="true"
Versions >= 4.2 exported=“false” by default
<provider android:name=".data.DataProvider"
android:multiprocess="true"
android:authorities="myapp.data.DataProvider"
android:readPermission="myapp.permission.READ"
android:writePermission="myapp.permission.WRITE" />

42. Data Storage
Shared preferences
External storage
Requires permission android.permission.WRITE_EXTERNAL_STORAGE
Internal storage
Better than external since permissions not required
Sqlite3
File DataBase with extension *.db stored in /data/data/[package_name]/databases
Cloud Google Cloud Messaging(GCM)
ROOT

43. Shared preferences
An xml key-value pairs file stored in /data/data/com.your.package/shared_prefs/preferences.xml
Used by an application in order to save small sets of data for the application
Storing sensitive information in shared preferences is not recommended
Library for securing shared preferences
Encrypt the key-value pairs
AES symmetric key
https://github.com/scottyab/secure-preferences
ROOT

44. Secure Shared preferences
ROOT

45. Networking
Use HttpsURLConnection for secure web traffic
HTTPS + CA Certificate
import javax.net.ssl.HttpsURLConnection;
import javax.net.ssl.SSLContext;
import javax.net.ssl.TrustManagerFactory;
// build key store with ca certificate
KeyStore keyStore = buildKeyStore(context, certRawResId);
// Create a TrustManager that trusts the CAs in our KeyStore
String tmfAlgorithm = TrustManagerFactory.getDefaultAlgorithm();
TrustManagerFactory tmf = TrustManagerFactory.getInstance(tmfAlgorithm);
tmf.init(keyStore);
// Create an SSLContext that uses our TrustManager
SSLContext sslContext = SSLContext.getInstance("TLS");
sslContext.init(null, tmf.getTrustManagers(), null);
// Create a connection from url
RL url = new URL(urlString);
HttpsURLConnection urlConnection = (HttpsURLConnection) url.openConnection();
urlConnection.setSSLSocketFactory(sslContext.getSocketFactory());

46. Webview
class WebAppInterface {
private String sensitiveInformation;
public String toString() { return sensitiveInformation; }
}
WebView webview = new WebView(this);
setContentView(webview);
webView.loadUrl("http://website.com");
webView.addJavascriptInterface(new WebAppInterface(this), "injectedObject");
Vulnerability in version 4.1.2(API 16) Jelly Bean in Cross-site scripting (XSS), Cross-site Request Forgery (CSRF) attacks
With JavaScript and Java Reflection can access any of the public methods of the WebAppInterface
setJavascriptEnabled(true);

47. Webview
<script>
function execute(){
var sendSMS=Android.getClass.forName("android.telephony. SmsManager").
getMethod("getDefault",null).invoke(null,null);
sendSMS.sendTextMessage("+323232323",null,"message", null,null);
}
</script>

48. Webview best practices
Disable JavaScript and Plugin support if they are not needed.
Disable local file access. Restricts access to the app’s resource and asset directory.
Prevent loading content from 3rd party hosts.
Activate SSL in activity using HTTPS
In 4.2 @JavascriptInterface method annotation for limit access methods from javascript.
Avoid exposing protected data in javascript interface
@JavascriptInterface
public void method() { dostuff(); }

49. Webview best practices
Not save passwords
Not saving form data
Clear Cache
webSettings.setSavePassword(false);
webSettings.setSaveFormData(false);
@Override public void onPageFinished(WebView view, String url) {
super.onPageFinished(view, url);
view.clearCache(true); //delete local files in the browser
}

50. SQLite
SQLiteDatabase db = dbHelper.getWriteableDatabase();
String userQuery = "SELECT lastName FROM useraccounts WHERE userID = ?";
SQLiteStatement prepStatement =db.compileStatement(userQuery);
prepStatement.bindString(1, "userID");
prepStatement.simpleQueryForString();
Prepared statements to avoid sql injection
rawQuery
compileStatement

51. SQLite Cipher
https://github.com/sqlcipher/android-database-sqlcipher
public void initDB(Context context, String password) {
SQLiteDatabase database =
SQLiteDatabase.openOrCreateDatabase(DB_NAME,password, null);
database.execSQL("create table MyTable(a, b)");
}
import net.sqlcipher.database.*;
import android.database.sqlite.*;

52. Static analysis

53. Static analysis

54. LINT ECLIPSE /ANDROID STUDIO
Scans Android project sources for potential bugs
Comes with the SDK and detects common programming errors

55. Lint
$ lint --check Security --html security_report.html <project_home>
http://developer.android.com/tools/help/lint.html

56. ANDROID STUDIO

57. SONARQuBE
http://www.sonarqube.org/

60. Encryption in phone
 Supported since Android 3.0
 Encrypts the entire device with AES 128.
 Based on dm-crypt implementation
 PBKDF2 algorithm for password
 Takes at Least 1 h for Encryption of Data.
 Denoted to reduce in performance.

61. Encryption in applications
Android Crypto API
Based in javax.crypto from javaSE
 Obtain secretKey
public static SecretKey generateKey(char[] password, byte[] salt)
throws Exception {
int iterations = 1000;
int outputKeyLength = 256;
SecretKeyFactory secretKeyFactory
= SecretKeyFactory.getInstance(“PBKDF2WithHmacSHA1”);
KeySpec keySpec = new PBEKeySpec(password, salt,iterations, outputKeyLength);
byte[] keyBytes = secretKeyFactory.generateSecret(keySpec).getEncoded();
return new SecretKeySpec(keyBytes, “AES”);
}
import java.security.*;
import javax.crypto.*;

62. Encryption in applications
public static String encryptText(char[] password, String plainText)
throws Exception {
//Obtain secretkey
SecureRandom secureRandom = new SecureRandom();
int saltLength = 8;
byte[] salt = new byte[saltLength];
secureRandom.nextBytes(salt);
SecretKey secretKey = generateKey(password, salt);
Cipher cipher = Cipher.getInstance(“AES/CBC/PKCS5Padding”);
byte[] initVector = new byte[cipher.getBlockSize()];
secureRandom.nextBytes(initVector);
IvParameterSpec ivParameterSpec = new IvParameterSpec(initVector);
cipher.init(Cipher.ENCRYPT_MODE, secretKey, ivParameterSpec);
byte[] cipherData = cipher.doFinal(plainText.getBytes(“UTF-8”));
return Base64.encodeToString(cipherData,Base64.NO_WRAP | Base64.NO_PADDING)
+ “]” + Base64.encodeToString(initVector,Base64.NO_WRAP | Base64.NO_PADDING)
+ “]” + Base64.encodeToString(salt,Base64.NO_WRAP | Base64.NO_PADDING);
}

64. Obsfuscation
Renames classes, fields and methods using short names (a,b,c,..)

65. Obsfuscation in android projects
Proguard
Integrated in SDK
 http://developer.android.com/tools/help/proguard.html
 Enable Proguard in eclipse
proguard.config=${sdk.dir}/tools/proguard/proguard-android.txt:proguard-project.
txt

66. Obsfuscation in android projects
Enable Proguard in android STUDIO
In build.gradle
android { buildTypes { release { runProguard true proguardFile getDefaultProguardFile('proguard-android.txt') , 'proguard-rules.pro' } }

67. Proguard.config
-optimizationpasses 5 -dontusemixedcaseclassnames -dontskipnonpubliclibraryclasses -dontpreverify -verbose -optimizations !code/simplification/arithmetic,!field/*,!class/merging/* -keep public class * extends android.app.Activity -keep public class * extends android.app.Application -keep public class * extends android.app.Service -keep public class * extends android.content.BroadcastReceiver -keep public class * extends android.content.ContentProvider -keep public class * extends android.app.backup.BackupAgentHelper -keep public class * extends android.preference.Preference -keep public class com.android.vending.licensing.ILicensingService -keepclasseswithmembernames class * { native <methods>; } -keepclasseswithmembernames class * { public <init>(android.content.Context, android.util.AttributeSet); } -keepclasseswithmembernames class * { public <init>(android.content.Context, android.util.AttributeSet, int); } -keepclassmembers enum * { public static **[] values(); public static ** valueOf(java.lang.String); } -keep class * implements android.os.Parcelable { public static final android.os.Parcelable$Creator *; }

68. Proguard tool
http://proguard.sourceforge.net

71. Reverse Engineering Android Application

72. Rename Android app (.apk) to .zip
Extract zip
Run dex2jar on the extracted file
Open the .jar in a java decompiler
Reverse Engineering Android Application

73. Apk Tool
Reverses .apk file to an android project
$ apktool d target.apk output_directory

74. Apk Tool

75. Java vs Smali
Reverses .apk file to an android project
Learning smali through dalvik codes
http://pallergabor.uw.hu/androidblog/dalvik_opcodes.html

76. Dex2jar
http://code.google.com/p/dex2jar
Converts Android’s Dalvik executables into Java jar files.
$ unzip target.apk
$ d2jdex2jar.sh classes.dex -o target.jar

77. Dex2jar
activity_main.xml

78. Java Decompiler
 http://java.decompiler.free.fr

79. Dex to Java Decompiler
https://github.com/skylot/jadx
Decompile directly form apk or dex

81. Android Application Vulnerability Scanner
java –jar ScanAndroidApps.jar

82. Virtuous Ten Studio
http://virtuous-ten-studio.com/
Only for windows

83. Virtuous Ten Studio

84. Virtuous Ten Studio

85. Apk Analyser
https://github.com/maaaaz/androwarn
https://github.com/sonyxperiadev/ApkAnalyser
https://github.com/honeynet/apkinspector
https://code.google.com/p/droidbox

86. Apk Analyser
http://developer.sonymobile.com/knowledge-base/tools/analyse-your-apks-with-apkanalyser/
java -jar ApkAnalyser.jar

87. Androwarn
python androwarn.py -i my_apk.apk -r html -v 3

88. DroidBox
python apimonitor.py my_apk.apk

91. Dexter online
https://dexter.bluebox.com

92. Dexter online

93. TraceDroid
http://tracedroid.few.vu.nl
Records the behavior of the executed app, such as its network communication, the UI, but also its internal function calls and Java code that is executed.
Emulates a few actions, such as user interaction, incoming calls and SMS messages, etc. - this will reveal most malicious intents of an app.

94. Pentesting
Virtual Machine with tools for Reverse Engineering
https://redmine.honeynet.org/projects/are/wiki
https://appsec-labs.com/AppUse
Hacking distro dedicated to Mobile forensics and Security

95. https://github.com/viaforensics/android-forensics
http://andriller.com/
Forensics analisys

96. Intent Snifer
—Sees Activity’s startup Intents
—android.permission.GET_TASKS: Recent tasks Intents
ActivityManager am = (ActivityManager) getSystemService(ACTIVITY_SERVICE);
List<RecentTaskInfo> rti = am.getRecentTasks(1000,ActivityManager.RECENT_WITH_EXCLUDED);
for (RecentTaskInfo c : rti) {
log.append("received: " + rti.toString() + "n");
}

98. Books

99. References
http://code.google.com/p/dex2jar/
https://code.google.com/p/android-apktool
https://code.google.com/p/androguard/wiki/Installation
http://ashishb.net/security/android-security-related-tools
http://androidcracking.blogspot.com.es
http://developer.android.com/guide/topics/security/permissions.html
http://source.android.com/devices/tech/security/#android- application-security
http://siis.cse.psu.edu/android_sec_tutorial.html
