PostgreSQL 9.4 JSON Types and Operators

PostgreSQL 9.4
JSON Types and Operators
Pittsburgh PostgreSQL Users Group
2015 December 16
Nicholas Kiraly
github.com/nkiraly
Twitter @NicholasKiraly
kiraly.nicholas@gmail.com

Introductions
github.com/nkiraly Twitter @NicholasKiraly
Systems Integration Engineer
Interface Systems to Produce New Value
Open Source Tools / PostgreSQL / FreeBSD Advocate
To play along with today’s examples, vagrant up with
https://github.com/nkiraly/koadstation/tree/master/dbdevf2

Why should I JSON with PostgreSQL ?
Misconception:
I need one system of record.
But I need to SQL, JSON, and XML so hard!
I have to do transforms, parsing, and derivative storage in my implementation to get
the job done with a single system of record.
Not so!
JSON operators allow for expressions in queries and indexes
Less round-trips for information querying and selection
Streamline and structure your data in one place in your system of record
Base your JSON documents on SQL normalized tables you get best of both worlds!

JSON vs JSONB
Stored as Text
Retains Whitespace
Retains Key Order
Retains Duplicate Keys
Index expressions only
Binary
Hierarchy of Key/Value pairs
Whitespace Discarded
Last Duplicate Key Wins
GIN Index support can be leveraged by contains
operators (@> <@ ? ?| ?&)

What about HSTORE?
PostgreSQL extension
For single-depth Key/Value pairs
JSON type objects can be nested to N
HSTORE only stores strings
JSONB uses full range of JSON numbers for
element values

JSON Operators
-> ->>
#> #>>
@> <@
? ?|
?&

->
Get Object Field
'[{"a":"foo"},{"b":"bar"},{"c":"baz"}]'::j
son->2
{"c":"baz"}
->>
Get Object Field As Text
'{"a":1,"b":2}'::json->>'b'
2
#>
Get Object At Specified Path
'{"a": {"b":{"c": "foo"}}}'::json#>'{a,b}'
{"c": "foo"}
#>>
Get Object At Specified Path As Text
'{"a":[1,2,3],"b":[4,5,6]}'::json#>>'{
a,2}'
3
JSON / JSONB Operators

@>
Does the left object contain the element on the right?
'{"a":1, "b":2}'::jsonb @> '{"b":2}'::jsonb
<@
Is the left element and value contained in the right?
'{"b":2}'::jsonb <@ '{"a":1, "b":2}'::jsonb
? Does the field key string exist within the JSON value?
'{"a":1, "b":2}'::jsonb ? 'b'
?| Do any of these key strings exist?
'{"a":1, "b":2, "c":3}'::jsonb ?| array['b', 'c']
JSONB Contains Operators
?& Do all these key strings exist?
'["a", "b"]'::jsonb ?& array['a', 'b']

JSON Queries
SELECT
doc
->’field’
->>’subfield’
FROM sometable

Insert JSON Data
suchjson=# INSERT INTO somejson VALUES ( 1,
'{
"name": "Nicholas Kiraly",
"address": {
"line1": "5400 City Blvd",
"line2": "Apt B",
"city": "Pittsburgh",
"state": "PA",
"zipcode": "15212"
}
}');
INSERT 0 1

Select JSON Data
suchjson=# SELECT * FROM somejson ;
id | doc
----+--------------------------------
1 | { +
| "name": "Nicholas Kiraly", +
| "address": { +
| "line1": "5400 City Blvd", +
| "line2": "Apt B", +
| "city": "Pittsburgh", +
| "state": "PA", +
| "zipcode": "15212" +
| } +
| }
(1 row)

Extract JSON Data
suchjson=# SELECT doc->>'address' FROM somejson ;
?column?
--------------------------------
{ +
"line1": "5400 City Blvd",+
"line2": "Apt B", +
"city": "Pittsburgh", +
"state": "PA", +
"zipcode": "15212" +
}
(1 row)

Navigate JSON Data
suchjson=# SELECT doc->'address'->>'zipcode' from somejson ;
?column?
----------
15212
(1 row)
suchjson=# SELECT doc->'address'->>'zipcode' = ‘15212’ from somejson ;
?column?
----------
t
(1 row)

JSONB Queries
SELECT
doc
->’field’
->>’subfield’
FROM sometable

Insert JSONB Data
suchjson=# INSERT INTO somejsonb ( doc ) VALUES ( '{
"name": "Nicholas Kiraly",
"address": {
"line1": "5400 City Blvd",
"line2": "Apt B",
"city": "Pittsburgh",
"state": "PA",
"zipcode": "15212"
}
}');
INSERT 0 1

Select JSONB Data
suchjson=# SELECT * FROM somejsonb ;
id | doc
----+-------------------------------------------------------------------------------
-
1 | {"name": "Nicholas Kiraly", "address": {"city": "Pittsburgh", "line1": "5400
City Blvd", "line2": "Apt B", "state": "PA", "zipcode": "15212"}}
(1 row)

Extract JSONB Data
suchjson=# SELECT doc->>'address' FROM somejsonb ;
?column?
------------------------------------------------------------------------------------
-
{"city": "Pittsburgh", "line1": "5400 City Blvd", "line2": "Apt B", "state": "PA",
"zipcode": "15212"}
(1 row)

How many rows have that JSON element?
suchjson=# SELECT COUNT(*) FROM somejsonb ;
count
--------
101104
suchjson=# SELECT COUNT(*) FROM somejsonb WHERE doc->'address'?'line2';
count
-------
56619

JSON Element arrays values
suchjson=# CREATE TABLE shopping_lists (
shopping_list_id BIGSERIAL,
shopping_list_doc JSONB
);
CREATE TABLE
suchjson=# INSERT INTO shopping_lists ( shopping_list_doc ) VALUES (
'{
"listName": "Needed supplies",
"items": [ "diet shasta", "cheese curls", "mousse" ]
}' );
INSERT 0 1

Element arrays as result rows
suchjson=# SELECT * FROM shopping_lists;
shopping_list_id | shopping_list_doc
------------------+-----------------------------------------------------------------
2 | {"items": ["diet shasta", "cheese curls", "mousse"], "listName":
"Needed supplies"}
(1 row)
suchjson=# SELECT jsonb_array_elements_text(shopping_list_doc->'items') AS item FROM
shopping_lists;
item
--------------
diet shasta
cheese curls
mousse
(3 rows)

Multiple rows, Element arrays as result rows
suchjson=# INSERT INTO shopping_lists ( shopping_list_doc ) VALUES (
'{
"listName": "Running low",
"items": [ "grid paper", "cheese curls", "guy fawkes masks" ]
}' );
INSERT 0 1
suchjson=# SELECT jsonb_array_elements_text(shopping_list_doc->'items') AS item FROM
shopping_lists;
item
------------------
diet shasta
cheese curls
mousse
grid paper
cheese curls
guy fawkes masks
(6 rows)

JSON Indexes
SELECT
jsondoc->>’element’
USING INDEX
->> text expression
@> contains

Cost of WHERE JSON ->> Expression
suchjson=# SELECT COUNT(*) FROM somejson;
100101
suchjson=# SELECT COUNT(*) FROM somejson WHERE (doc->'address'->>'zipcode'::text) =
'11100';
1001
suchjson=# EXPLAIN ANALYZE SELECT * FROM somejson WHERE (doc->'address'-
>>'zipcode'::text) = '11100';
QUERY PLAN
------------------------------------------------------------------------------------
Seq Scan on somejson (cost=0.00..4671.77 rows=501 width=36) (actual
time=0.039..316.502 rows=1001 loops=1)
Filter: (((doc -> 'address'::text) ->> 'zipcode'::text) = '11100'::text)
Rows Removed by Filter: 99100
Planning time: 0.093 ms
Execution time: 366.303 ms

Indexing for WHERE JSON ->> Expression
Expressionsuchjson=# CREATE INDEX somejson_zipcode ON somejson
((doc->'address'->>'zipcode'::text));
suchjson=# EXPLAIN ANALYZE SELECT * FROM somejson
WHERE (doc->'address'->>'zipcode'::text) = '11100';
QUERY PLAN
------------------------------------------------------------------------------------
Bitmap Heap Scan on somejson (cost=12.18..1317.64 rows=501 width=36) (actual
time=0.222..3.256 rows=1001 loops=1)
Recheck Cond: (((doc -> 'address'::text) ->> 'zipcode'::text) = '11100'::text)
Heap Blocks: exact=1001
-> Bitmap Index Scan on somejson_zipcode (cost=0.00..12.06 rows=501 width=0)
(actual time=0.210..0.210 rows=1001 loops=1)
Index Cond: (((doc -> 'address'::text) ->> 'zipcode'::text) =
'11100'::text)

Cost of WHERE ->Element->> Expression
suchjson=# SELECT COUNT(*) FROM somejsonb;
101104
suchjson=# EXPLAIN ANALYZE SELECT * FROM somejsonb WHERE (doc->'address'-
>>'zipcode'::text) = '11100';
QUERY PLAN
------------------------------------------------------------------------------------
Seq Scan on somejsonb (cost=0.00..4171.32 rows=506 width=159) (actual
time=0.033..58.670 rows=1011 loops=1)
Filter: (((doc -> 'address'::text) ->> 'zipcode'::text) = '11100'::text)

Indexing for WHERE ->Element->> Expression
CREATE INDEX somejsonb_zipcode ON somejsonb ((doc->'address'->>'zipcode'::text));
suchjson=# EXPLAIN ANALYZE SELECT * FROM somejsonb WHERE (doc->'address'-
>>'zipcode'::text) = '11100';
QUERY PLAN
-----------------------------------------------------------------------------------
Bitmap Heap Scan on somejsonb (cost=12.22..1253.10 rows=506 width=159) (actual
time=0.440..4.003 rows=1011 loops=1)
Recheck Cond: (((doc -> 'address'::text) ->> 'zipcode'::text) = '11100'::text)
-> Bitmap Index Scan on somejsonb_zipcode (cost=0.00..12.09 rows=506 width=0)
Index Cond: (((doc -> 'address'::text) ->> 'zipcode'::text) =
'11100'::text)

Cost of WHERE @> Contains Operator
suchjson=# EXPLAIN ANALYZE SELECT * FROM somejsonb WHERE doc @> '{ "address": {
"zipcode":"11100" } }';
QUERY PLAN
------------------------------------------------------------------------------------
-
Seq Scan on somejsonb (cost=0.00..3665.80 rows=101 width=159) (actual
time=0.019..59.580 rows=1011 loops=1)
Filter: (doc @> '{"address": {"zipcode": "11100"}}'::jsonb)

Indexing for WHERE @> Contains Operator
suchjson=# CREATE INDEX somejsonb_gin ON somejsonb USING gin ( doc jsonb_path_ops);
CREATE INDEX
suchjson=# EXPLAIN ANALYZE SELECT * FROM somejsonb WHERE doc @> '{ "address": {
"zipcode":"11100" } }';
QUERY PLAN
------------------------------------------------------------------------------------
-
Bitmap Heap Scan on somejsonb (cost=12.78..349.75 rows=101 width=159) (actual
time=0.376..4.644 rows=1011 loops=1)
Recheck Cond: (doc @> '{"address": {"zipcode": "11100"}}'::jsonb)
-> Bitmap Index Scan on somejsonb_gin (cost=0.00..12.76 rows=101 width=0)
Index Cond: (doc @> '{"address": {"zipcode": "11100"}}'::jsonb)

JSON Views
SELECT doc
FROM jsonview
WHERE things
-----------------------------
{ “formatted”: “data” }

Blog Site User Data Model
CREATE TABLE users (
user_id varchar(100) PRIMARY KEY,
user_name varchar(100) NOT NULL,
user_rank integer NOT NULL DEFAULT 10,
user_display_name varchar(200) NOT NULL
user_profile text
);

Blog Site Post Data Model
CREATE TABLE posts (
post_id varchar(100) PRIMARY KEY,
post_date timestamp with time zone,
post_summary varchar(200) NOT NULL,
post_content text NOT NULL,
post_tags varchar(100)[]
);
CREATE TABLE posts_read (
post_id varchar(100) REFERENCES posts(post_id),
user_id varchar(100) REFERENCES users(user_id),
read_date timestamp with time zone NOT NULL,
PRIMARY KEY (post_id, user_id)
);

User Detail JSON View
CREATE VIEW users_json AS
SELECT users.*, row_to_json(users, TRUE)
FROM users ;
SELECT * FROM users_json WHERE user_name = 'rsanchez';
-[ RECORD 1 ]-----+---------------------------------------------------
user_id | rick.sanchez@potp.com
user_name | rsanchez
user_rank | 10
user_display_name | Richard Sanchez
user_profile | Wubba lubba dub-dub!
row_to_json | {"user_id":"rick.sanchez@potp.com",
| "user_name":"rsanchez",
| "user_rank":10,
| "user_display_name":"Richard Sanchez",
| "user_profile":"Wubba lubba dub-dub!"}

Post JSON View
blogsite=#
CREATE VIEW posts_json AS
SELECT posts.*, row_to_json(posts, TRUE)
FROM posts ;

SELECT FROM Post JSON View
blogsite=# SELECT * FROM posts_json WHERE post_id = 'beths-new-bike';
-[ RECORD 1 ]+--------------------------------------------------------------------
post_id | beths-new-bike
post_date | 2015-12-15 04:04:37.985041+00
user_id | beth.smith@rr.com
post_summary | My New Bike
post_content | I got a new bike last night and it's better than a horse
post_tags | {bike,new,suchpedal}
row_to_json | {"post_id":"beths-new-bike",
| "post_date":"2015-12-15T04:04:37.985041+00:00",
| "user_id":"beth.smith@rr.com",
| "post_summary":"My New Bike",
| "post_content":"I got a new bike last night and it's better than a
horse",
| "post_tags":["bike","new","suchpedal"]}

Unread Posts JSON View
CREATE VIEW unread_posts_json AS
-- users that have not read posts
SELECT ur.*, row_to_json(ur, TRUE) AS json
FROM (
-- select u.user_id so view queries can limit to a specific user's unread
posts
SELECT u.user_id, p.post_id, p.post_summary, p.post_date
FROM users AS u CROSS JOIN posts AS p
WHERE NOT EXISTS (
SELECT 1 FROM posts_read
WHERE post_id = p.post_id AND user_id = u.user_id
)
) AS ur;

Posts Data
blogsite=# SELECT * FROM posts;
-[ RECORD 1 ]+---------------------------------------------------------
post_id | beths-new-bike
post_date | 2015-12-15 05:59:26.634021+00
user_id | beth.smith@rr.com
post_summary | My New Bike
post_content | I got a new bike last night and it's better than a horse
post_tags | {bike,new,suchpedal}
-[ RECORD 2 ]+---------------------------------------------------------
post_id | ricks-new-space-van
post_date | 2015-12-15 05:59:26.634021+00
user_id | rick.sanchez@potp.com
post_summary | New Spaceship
post_content | I got a new spaceship last night and -burp- its awesome
post_tags | {spaceship,new,interdimensional}

Select Morty Unread Posts JSON View
blogsite=# -- what posts hasn't Morty read yet?
blogsite=# SELECT json FROM unread_posts_json
WHERE user_id = 'morty.smith@gmail.com';
json
---------------------------------------------------------
{"user_id":"morty.smith@gmail.com", +
"post_id":"beths-new-bike", +
"post_user_id":"beth.smith@rr.com",+
"post_summary":"My New Bike", +
"post_date":"2015-12-15T02:55:59.461635+00:00"}
{"user_id":"morty.smith@gmail.com", +
"post_id":"ricks-new-space-van", +
"post_user_id":"rick.sanchez@potp.com",+
"post_summary":"I Got A New Space Van", +
"post_date":"2015-12-15T02:55:59.461635+00:00"}
(2 rows)

Select Rick Unread Posts JSON View
blogsite=# -- what posts hasn't Rick read yet?
blogsite=# SELECT json FROM unread_posts_json
WHERE user_id = 'rick.sanchez@potp.com';
json
------
(0 rows)

Select Beth Unread Posts JSON View
blogsite=# -- what posts hasn't Beth read yet?
blogsite=# SELECT json FROM unread_posts_json WHERE user_id = 'beth.smith@rr.com';
json
---------------------------------------------------------
{"user_id":"beth.smith@rr.com", +
"post_id":"ricks-new-space-van", +
"post_user_id":"rick.sanchez@potp.com",+
"post_summary":"I Got A New Space Van", +
"post_date":"2015-12-15T02:55:59.461635+00:00"}
(1 row)

Alternate Unread Posts View
CREATE VIEW unread_posts_v2_json AS
-- users that have not read posts
-- alternate version
SELECT ur.*, row_to_json(ur, TRUE) AS json
FROM (
SELECT posts.post_id, posts.post_date, posts.post_summary, users.user_id
-- take the cross product of users and posts
FROM users
INNER JOIN posts ON (
-- filter out the ones that exist in posts_read
(users.user_id, posts.post_id) NOT IN (SELECT user_id, post_id FROM
posts_read)
)
) AS ur;

Common Q&A Topic for PostgreSQL 9.4
No in-place element editing in 9.4
JSON structures must be rebuilt to update element values
jsonb_set() in 9.5 to replace entire sections
Append children elements by the same name to overwrite existing values in 9.4
Regenerate / reselect entire JSON structure

Questions?
Answers!
Feedbacks $#!7$%
SELECT
doc->knowledge
FROM jsonb
WHERE
applied_knowledge
IS NOT NULL

Questions ? Answers ! Feedbacks
PostgreSQL 9.4 JSON Types and Operators
http://www.meetup.com/Pittsburgh-PostgreSQL-Users-Group
Check Out @lfgpgh http://lfgpgh.com
Nicholas Kiraly
github.com/nkiraly
Twitter @NicholasKiraly
kiraly.nicholas@gmail.com

PostgreSQL 9.4 JSON Types and Operators

Recommended

Recommended

More Related Content

What's hot

What's hot (20)

Viewers also liked

Viewers also liked (8)

Similar to PostgreSQL 9.4 JSON Types and Operators

Similar to PostgreSQL 9.4 JSON Types and Operators (20)

Recently uploaded

Recently uploaded (20)

PostgreSQL 9.4 JSON Types and Operators

Editor's Notes
