Muninmax produces pineapple processing equipment for the global market. Muninmax’s core pineapple in can and aseptic pineapple capabilities include sterilization systems, deaeration systems, bag-in-drum fillers, juice blending and flavor addition, and tanker loading systems. Contact us at candy@muninmax.co.th for further information or visit us our website www.muninmax.co.th

1. Pineapple Processing Line – The
best solution for Pineapple Industry
1
www.Muninmax.co.th

2. 2
Munimax ‘s technology to meet the demands
of today’s pineapple processing requirements.
Our total commitment had led to the
development of innovative equipment to
improve overall operating efficiently, minimize
downtime for maintenance, and most
important, reduce capital investments.
www.Muninmax.co.th

3. 3
With more than 25 years of experience,
fully understand the development of
Pineapple Industry, we can supply
complete pineapple
processing lines on turnkey basis for the
production of natural or concentrated
puree as well as single machines to
meet specific requirements
www.Muninmax.co.th

4. 4
1 2
3 4
5
1. Dumper
2. Raw Material Inspection Conveyor
3. Washing Conveyor
4. Inspection Conveyor
5. Ginaca
After washing and sorting,
the pineapple arrives at the
“Ginaca”, machine where it
is mechanically broken
down into three
components: cylindrical
flesh (the cylinder are then
sliced as typically done for
canned fruit), peel and
“juice material”. This
consists of the pineapple
core, and the flesh
obtained from between the
skin and the cylinder.
State-of-the art equipment...
www.Muninmax.co.th

5. 5
… get high yield recovery
www.Muninmax.co.th
The pineapple cylindrical flesh comes to the
slicing machine and segmentor to finish the
preparation processing line.
2
1
3
1. Product after peeling from Ginaca
2. Slicing machine
3. Segmentoir

6. 6
State-of-the art equipment...
1. Canning Processing Line at
Central Interfood factory
2. Hammer Mill
3. Low Pressure Extractor
Sketch of Low Pressure Extractor
www.Muninmax.co.th
1
2
3

7. 7
… get high yield recovery
www.Muninmax.co.th
The pineapple will come to the canning line
for slicing, cutting into cube, filling syrup,
sterilization with Cooker and Cooler and then
labeling for final product.
The fruit is juiced by traditional screw presses
which generate a high proportion of solids in
the juice. The extractors are used in a 2 or 3
stage arrangement.
1. Horizontal High Pressure Extractor
2. Inside Horizontal High Pressure Extractor
Sketch of Horizontal High Pressure Extractor

8. 8
Mixing Tanks
Mixing Tanks Mixing Tanks

9. 9
Tanks and more…
A fully equipped and independently managed
technical department with in-house design and
drawing capacity, allows us to present a unique
range of services to clients:
• Planning and optimizing vessel and
building layout
• Walkway, staircase and platform design
and manufacture
• Product and cooling piping design and
installation
• Turnkey project management

10. 10
State-of-the art equipment...
Evaporator
The juice produced in this way is evaporated to the desired concentration in
multi-effects evaporator. Our company is professional in the manufacturing
and exporting a wide range of Falling Film Evaporator, the best kind of
Evaporator, which we recommend.
• The liquid feed enters at top, get distributed uniformly in tube bundle by a
distributor.
• The feed flows downwards along the tube walls as a film. It receives the heat
from the heating media on the shell side.
• Vapor is formed and the concentrate flows downward along with the vapor.
• Separate the vapor vs. liquid and the concentrated liquid is collected at the
bottom or transferred to the next stage.
• The falling film evaporator can be single effect or multiple effects depending
on your requirement for steam economy
Machines operations, including start-up and shut-down, are controlled by
PC/PLC system.
www.Muninmax.co.th

11. 11
… get high yield recovery
Sterilization
UHT (Ultra High Temperature)
process can extend the shelf
life of the product from a few
days up to several months
with minimum quality loss. The
UHT plants also allow for the
thermal and aseptic treatment
of products with portions or
fibers and particulate. Product
is heated up to high
temperature for a short period
of time to kill micro-organisms
that are present in all product.
The energy recovery achieved
by the heat regeneration
leading to reduce energy
consumption.
Feature
- Energy and water consumption saving.
- Corrugated tubes to promote efficient heat transfer and reduce thermal stresses.
- PLC control automatic system.
- Sanitary construction.
- Low operation cost.
www.Muninmax.co.th

12. 12
www.Muninmax.co.th
State-of-the art equipment...
Aseptic Filler
Machine is designed to provide the highest possible level of sterility and productivity for
filling bulk aseptic bag in box or bag in drum containers. Most aseptic packing of this
kind have been applied to bulk packing for high and low acid food products, including
tomato paste, fruit juice purees, fruit juice concentrates, dairy products and other such
products.
Before the filler is used, it is automatically sterilized. The system is fully automatic,
consisting of hydraulic actuation, a sterilization phase, filling head with clamping device,
filling vale, aseptic chamber and control panel.
The automatic cycle of opening, filling and closing; begins once the bag has been
manually inserted into the filling head. During the filling cycle, the temperature can be
controlled at critical point.
Features
• Machine frame is made of Galvanized
• Filling head is made of AISI 316/AISI 304 Stainless steel
• The parts in contact with product are made of AISI 316 stainless steel.
• Heads for bag with 1” fitment (2” spout feasible under request) with Plug Style and Cap
Style
• Steam sterilization system
• Circular head chamber which is fully-viewable (twin head)
• Integrated processing cycle safety system at critical point such as control temperature,
steam pressure and self - diagnosis with on screen alarms.
• Mass Flow-Meter for measuring the volumetric capacity.
• PLC control automatic system.
• Applicable bag size 20L, 200l, 1000L

13. 13
Pineapple
Washing
Sorting
Peeling
Cylindrical Flesh Juice Material
Damaged
Pineapple
Peel
Trimming
Slicing
Segmentation
Packing in can
Syrup Filling
Seaming
Sterilization
Extraction
Preheating
Deaeration
Single Strength
Juice
Filling
Evaporation
Sterilization
… get high yield recovery
PRODUCTION FLOW DIAGRAM
Concentrate
Sterilization
Storage
Filling
www.Muninmax.co.th

14. 14
Muninmax Co., Ltd
107/1 M5 T. Wangpong, A. Pranburi,
Prachuapkhirikhan, Thailand 77120
Tel: +66 32 65 1939
Fax: +66 32 54 2208
Email: candy@muninmax.co.th
www.Muninmax.co.th
“ONLY IF YOU SUCCEED,
