Otto Cycle | Mechanical Engineering
•Download as PPTX, PDF•
4 likes•1,267 views
This document discusses the Otto cycle, which is an idealized thermodynamic cycle that models the processes involved in spark ignition piston engines. It describes the four processes that make up the Otto cycle: intake, compression, combustion/power, and exhaust strokes. The cycle involves isentropic compression, constant volume heat addition, isentropic expansion, and constant volume heat rejection. A formula for the thermal efficiency of an Otto cycle engine is also provided.
