PoP Process Capabilities
Memo
PoP is package-on-package assembly that consists of two or more fine- O.5mm pitch
pitch ball grid arrays (BGAs) stacked one on top another. In a two-piece as- OMAP Processor FtKlU Fw
P"rlll
sembly, the bottom package is usually a high-density logic device, while the
O.4mm pitch
top package is a high-capacity memory device. Both devices may contain
more than one die. PCB
Source: T1 Package-on-Package (PoP) structure
ONYX29 PoP Assembly Process
ONYX29 PoP Assembly Process
Challenge
Package & PCBwarp, variation in solder balls height may lead to open connections
Solution
Bake and dry box process control for PoPand PCB.Developing ball-dipping method
using solder paste for PoPassembly and rework
OSI Electronics Manufacturing Capabilities
OSI Electronics is a Lead-Free qualified factory that can manufacture the PCBAs in both
lead-free and leaded processes.
We have the advanced equipment and manufacturing process capabilities on the following:
• PoP assembly and rework using advanced SMT robotic station.
• Screen printer with 2D paste inspection
• Advanced SMT pick-a-place machines that are capable of placing 01005 & OAmm pitch uBGA
• 10- Zone Lead-Free approved convection reflow ovens
• Wave soldering & Thru-Hole connector rework
