The Oracle Database Appliance is a highly available, plug-and-play hardware and software solution designed for small and medium businesses as well as departmental systems. It simplifies deployment and management with automated features and offers scalability based on a pay-as-you-grow model, accommodating databases of up to 4TB. The system is optimized for performance, reliability, and ease of use, with support for a wide range of applications.

1. © 2011 Oracle Corporation

2. Oracle Database Appliance
Simple. Reliable. Affordable.
© 2011 Oracle Corporation

3. World’s Most Popular Database
• Database Share
• Database for Data Warehouses
• Database for Enterprise Applications
© 2011 Oracle Corporation

4. Oracle Database Appliance
Highly Available Database System in a Single Box
• Simple
– Complete, plug-and-go hardware and software
– Easy to implement, manage and maintain
• Reliable
– Highly available database cluster configured in minutes
– Advanced management features and single vendor support
• Affordable
– Capacity on pay-as-you-grow basis
– Consolidation platform for small databases
© 2011 Oracle Corporation

5. Oracle Database Appliance
Ideal for SMBs and Departmental Systems
• Simple to implement
• Designed and priced to scale
• Performance improves as you scale
• Highest levels of serviceability
• Highest availability for this class of machine
© 2011 Oracle Corporation

6. When to Use the Oracle Database Appliance
Ideal for SMBs and Departmental Systems
• Database(s) up to a maximum of 4 TB of data
• Fast, efficient replacement of aging servers
• Higher availability for application databases
• Migrate and consolidate databases
© 2011 Oracle Corporation

7. Easy to Deploy, Manage, and Maintain
Reduced Installation and Administration Effort
Installation
Expertise
Optimization
Expertise
Network
Administration Savings
Time
Cost
Storage
Administration
System
Administration
Database Oracle Appliance
Administration Manager
Oracle Database
Build Your Own Appliance
© 2011 Oracle Corporation

8. Easy to Install
Rapidly Deploy a Database Cluster
• Plug in the power
• Plug in the network
• Wizard-driven install
© 2011 Oracle Corporation

9. Easy to Manage
Appliance Manager Software
• Self-managing database features pre-configured
– Automatic Storage Management, Automatic Memory Management
• Automatic detection and correction of many failure conditions
• Fast problem diagnosis
– Automated Service Request filing
– Relevant logs gathered and packaged for Oracle support
• One-button patching for entire stack
• Single point of contact for all support issues
© 2011 Oracle Corporation

10. Appliance Manager Software
© 2011 Oracle Corporation

11. Highly Reliable Software
• Oracle Database 11g Enterprise Edition
– Automatic Storage Management
• Oracle Real Application Clusters
– Oracle Clusterware
• Oracle Linux
• Oracle Appliance Manager software
– Phones home automatically to file Service Requests
© 2011 Oracle Corporation

12. Fully Redundant Hardware
• 2 x dual-socket Oracle Linux servers
– 24 Intel Xeon processor X5675 cores
– 192 GB main memory
• 12 TB raw disk storage
• 292 GB solid state storage
• Built-in redundancy
– Server, storage, network, power and cooling
© 2011 Oracle Corporation

13. Three Tiers of Availability
Single Instance Active – Passive Active – Active
• Good Availability • Better Availability • Best Availability
• Oracle Database 11g • Oracle Database 11g • Oracle Database 11g
Enterprise Edition Enterprise Edition Enterprise Edition
• Oracle Real • Oracle Real
Application Clusters Application Clusters
One Node • Mutual failover and
• Can have mutual loadbalancing
failover
© 2011 Oracle Corporation

14. ‘Pay-as-you-Grow’ Database Licensing
• Purchase single hardware configuration
• Start with minimum of 2 processor core licenses
• Scale to maximum of 24 processor core licenses
• No hardware upgrades required
• License database software just for the cores you use
© 2011 Oracle Corporation

15. Low Entry Cost to High Availability
HP Oracle Database Appliance
• 24 processor cores • 24 processor cores
• Manual configuration & installation • One-button configuration & installation
• Multiple-vendor support contracts • Single-vendor support contract
• Minimum 24 processor core licenses • Minimum 2 processor core licenses
© 2011 Oracle Corporation

16. TCO Analysis – 3 year savings

17. Engineered Systems for Oracle Database
Oracle Database
Appliance Full Rack
Half Rack
Quarter Rack Oracle Exadata
Database Machine
© 2011 Oracle Corporation

18. “We ran 9 of our most complex processes on the Oracle Database
Appliance, and executed them in a fraction of the time it takes on
our existing platforms. The multi-core head room enables us to do
much more, with much less equipment, in much less time!
That’s truly great bang for the buck!”
Jason Scinocca
Chief Technology Officer, CallSource Inc.
© 2011 Oracle Corporation

19. “The Oracle Database Appliance was up and running in 20% of the
time it takes us to roll out a typical 2 node RAC. We didn’t have to
spend time on engineering the drives, o/s packages, or patching.
When Oracle says one button install – they’re right!”
Rhos B. Dyke
Executive Vice President, Cloud Creek Systems, Inc
© 2011 Oracle Corporation

20. Wide Range of Oracle & ISV Applications
Horizontal
Finance
Healthcare
Manufacturing
Telcos
Retail
Government
© 2011 Oracle Corporation

21. For More Information visit
www.oracle.com/goto/databaseappliance
© 2011 Oracle Corporation

22. Oracle Database Appliance
Simple. Reliable. Affordable.
