Oracle Cloud Infrastructure

Copyright © 2018, Oracle and/or its affiliates. All rights reserved. |Copyright © 2018, Oracle and/or its affiliates. All rights reserved. |
Cloud for Enterprise
Patrik Plachy
Principal Sales Consultant
Libor Havelka
Digitec

Copyright © 2018, Oracle and/or its affiliates. All rights reserved. |
Safe Harbor Statement
The following is intended to outline our general product direction. It is intended for
information purposes only, and may not be incorporated into any contract. It is not a
commitment to deliver any material, code, or functionality, and should not be relied upon
in making purchasing decisions. The development, release, and timing of any features or
functionality described for Oracle’s products remains at the sole discretion of Oracle.

ASHBURN, VAPHOENIX
FRANKFURT
Oracle Cloud Infrastructure Region Footprint
SYDNEY
CHICAGO
TORONTO
SAO PAULO
TOKYOSEOUL
ZURICH
OSAKA
LONDON
Commercial
Government
Planned Commercial
Planned Government
MUMBAI
SAUDI ARABIA

Complete cloud infrastructure services
STORAGE
NVMe, Block, File, Object, Archive
Predictable IOPS Block
Storage for up to 98% less,
storage for whole lifecycle
COMPUTE
Bare metal/VM, CPUs/GPUs
Up to 64 CPU cores, 8
GPUs, 768 GB RAM, 51 TB
local NVMe SSD, 5M IOPS,
AMD and Intel processors
AUTONOMOUS DATABASE
Transactions, Data Warehouse
Fast provisioning.
Automatic tuning,
patching, securing.
99.995% availability.
NETWORKING
VCN, LBaaS, FastConnect, VPN
Isolated networks with
reserved IPs, security lists,
firewalls, lowest cost
private connectivity
CONTAINERS
Containers and Kubernetes
Fully managed, certified
Kubernetes service with
Docker containers
EDGE
DNS, WAF, DDoS, Email
Global DNS, application
protection, bot
management, DDoS
protection, email delivery
CLOUD AT CUSTOMER
Exadata, Big Data
Subscription-priced
Big Data and Exadata
managed by Oracle
RAVELLO
Migrate VMware or KVM
Move VM environments,
retaining existing
networking, to the cloud
DATA MOVEMENT
Storage appliance, Data Transfer
Software NAS gateway,
data ingest service
SECURITY
IAM, Audit, KMS, CASB
Integrated security
services to protect data
and to control and
monitor access
GOVERNANCE
Compartments, Tagging
Logical separation and
tagging of resources for
simplified management
DATABASE
Bare metal, VMs, Exadata
Millions of TPS; Full RAC
and Active Data Guard
support

ENTERPRISE WEB &
APPLICATION SERVERS
ENTERPRISE APPLICATION
SERVERS, HADOOP
ORACLE DATABASE,
SPARK, CONTAINERS
HPC, AI/ML,
3D RENDERING
Fast and scalable Bare Metal, VM, and GPU compute
VM Standard
1-24 OCPUs,
15-320 GB RAM
Up to 1 PB Block
$0.0638 core hr
VM
Dense IO
8-24 OCPUs,
120-320 GB RAM,
6.4-25.6TB NVMe
Up to 1 PB Block
$0.0638 core hr
VM GPU Standard
1 P100 GPU,
12 OCPUs,
104 GB RAM
Up to 1 PB Block
$1.275 GPU hr
v2
1-4 V100 GPUs,
6-24 OCPUs
104-360 GB RAM
Up to 1 PB Block
NVLINK
$2.25 GPU hr
VM E2
Standard
1-24 OCPUs,
8-192 GB RAM
Up to 1 PB Block
$0.03 core hr
DNA SEQUENCING, CFD,
CRASH SIMULATIONS
Bare Metal
Dense IO
52 OCPUs,
768 GB RAM,
51.2 TB NVMe
Up to 1 PB Block
$ 0.1275 core hr
Bare Metal
GPU Standard
2 P100 GPUs,
28 OCPUs, 192 GB RAM
Up to 1 PB Block
$1.275 GPU hr
v2
8 V100 GPUs,
52 OCPUs, 768 GB RAM
Up to 1 PB Block
NVLINK
$2.25 GPU hr
Bare Metal
Standard
52 OCPUs,
768 GB RAM
Up to 1 PB Block
$0.0638 core hr
Bare Metal E2
Standard
64 OCPUs,
512 GB RAM
Up to 1 PB Block
$0.03 core hr
Bare Metal HPC
Dense IO
36 OCPUs (3.7 GHz),
384 GB RAM
Up to 1 PB Block
RDMA
$ 0.075 core hr
PREVIEW

Clustered RDMA Network1.5 µs latency, 100Gb/s
X X
CPU Servers GPU Servers* Block Storage*Exadata*
Cloud-first network for ultra low latency and high bandwidth
New: Oracle Cloud Infrastructure Cluster Networking
For high performance workloads (HPC, Database, Big Data, AI) including the hardest product
development workloads like CFD, Crash Simulations, Reservoir Modelling, DNA Sequencing
*Planned

New: Oracle Cloud Compute Instances based on AMD EPYC
• The first public cloud with AMD EPYC-based bare metal instances
• The best price-per-core available in the public cloud
• EBS, JDE, PeopleSoft, and Siebel certified to run on AMD EPYC
$0.03
per core hour
Bare Metal
Virtual Machines
64 cores
512 GB RAM
2X25 Gbps Network
2.5X Better
Price/ Performance

ANALYTICS, OLTP, HPC,
CONTAINERS, KUBERNETES
ENTERPRISE APPLICATIONS, DATABASES,
GPU, CONTAINERS, APPLICATION LIFECYCLE
HADOOP, RICH MEDIA,
LOGS, BACKUP, ARCHIVE
WORKLOADS
• Local NVMe SSD storage
– VMs and Bare Metal compute with
up to 51 TB local storage, backed
by performance SLA
• Block Storage
– Network NVMe SSD block storage
with 60 IOPS/GB; Max 25K IOPS,
320 MB/s per volume; backed by
performance SLA
• File Storage
– Low cost network NVMe SSD file
storage with 150 MB/s per TB
• Object and Archive Storage
– Limitless object storage with S3
and HDFS compatibility
– No cost software storage gateway
and data transfer services
Consistently fast storage performance across workloads
VM
Dense IO
6.4-25.6 TB
NVMe SSD
1.8M IOPS
Bare metal
Dense IO
51 TB
NVMe SSD
5M IOPS
Object & Archive
Storage
Limitless capacity
Native & S3 APIs, HDFS,
encryption
10TB max object size
$0.0255 GB/mo
$0.0026 GB/mo
Block Storage
Up to 32 TB volumes
Up to 1 PB/host
Snapshots, scheduled
backups, clones,
grouped clones,
encryption
$0.0425 GB/mo
File Storage
Scales to
exabytes
NFS, NLM,
snapshots,
encryption
$0.0425 GB/mo
Storage
Gateway
NFS, at rest and
inflight encryption,
configurable cache
Data Transfer
Service
HDD or 150TB
appliance,
encryption

Copyright © 2018, Oracle and/or its affiliates. All rights reserved. |Copyright © 2018, Oracle and/or its affiliates. All rights reserved. |
Demo a solution
cloud.oracle.com/jumpstart
Start a trial
cloud.oracle.com/tryit
Work with your partner
or one of ours

The Latest Technologies Enable a Modern Cloud Infrastructure
Technology Benefit
Availability domains and
Fault domains
Enterprise-level resiliency
No oversubscription,
flat non-blocking architecture
Low latency between resources, predictable performance,
eliminates “noisy neighbor issues”
Off-box IO virtualization
Better security through management isolation, better
performance through IO management offload from server CPU
NVMe SSD storage everywhere
Millions of IOPS for workloads that need them
Array of compute instance and
processor options
High core count, core frequency, and low cost options with AMD
EPYC and Intel Xeon options. HPC clusters and NVIDIA GPUs.

• Regions serve different
geographies, and provide
widely dispersed Disaster
Recovery capabilities
• Oracle’s Backbone Network
and Peering capabilities
provide for connectivity
between regions
• Availability Domains
provide a foundation for
High Availability within a
region, and contain
multiple fault domains
Regions

• 3 Options for HA:
– Multi-Region
– Multi-Availability Domain
– Multi Fault Domain
• High Availability for
traditional and cloud-
native applications
Inside a Region – High Availability Building Blocks

• Non-oversubscribed network
• Flat network speeds traffic by
reducing the switches
between any two hosts
• High speed interconnects:
2 x 25Gbps bandwidth
• Predictable, low latency
< 100μs expected one-way
latency between hosts in an
AD, <500μs between ADs
• The only cloud network
performance SLA
Fast and predictable physical network infrastructure

• Layer-3 virtual networks
• Bare metal available
through the same portal
and APIs as VMs
• Exadata and Real
Application Clusters
(RAC) options available
for database
performance and
reliability
Comprehensive Virtual Network with off-box IO Virtualization

• Millions of read and write
IOPS
• Best DB service for Oracle
• Only cloud performance &
manageability SLA
• Broad compute options
including bare metal, VM,
GPU, containers
• Edge services, including
industry-leading DNS
Services

• Compartments
• Identity federation
• Tags – including
structured tags
• Universal credits –
consistent discounts
across all IaaS & PaaS
Governance

• Deep Virtual Cloud Network
(VCN) control:
– Subnets, route rules, firewalls,
VCN peering, load balancing, DNS
– Console or API-driven
• Secure, reliable connectivity
– IPSec VPN
– FastConnect dedicated
connectivity with global providers
• Low latency underlying
physical network
– 25 Gbps with <100 µs one-way
latency within an AD
– <500 µs one-way latency between
Availability Domains
– Oracle-managed backbone
between regions
High fidelity virtual networks and connectivity
ORACLE CLOUD REGION
Provisioned
bandwidth
Load Balancing
AVAILABILITY
DOMAIN-1
VIRTUAL CLOUD NETWORK
Subnet-A Subnet-n
AVAILABILITY
DOMAIN-2
Subnet-B Subnet-n1
AVAILABILITY
DOMAIN-3
Subnet-C Subnet-n2
VPN
FastConnectCustomer
Datacenter
End customers
DNS
OTHER ORACLE
CLOUD REGIONS
Backbone

AVAILABILITY
DATABASESTORAGECAPACITY
ENTERPRISE APPS
& DEV/TEST
ENTERPRISE
APPLICATIONS
ENTERPRISE APPS
Local HA with massive
capacity and seconds of SLA
ENTERPRISE APPS
Local HA with
seconds of SLA
WORKLOADS
• Database shapes based on high
performance X7 server platform
– VMs, Bare Metal, or Exadata
– Up to 368 Intel Xeon cores per
instance
– Up to 424 TB of usable SSD
storage per Exadata instance
– Up to 40 TB network NVMe SSD
block storage per VM instance
– Up to dual 25 GbE network
interfaces per instance
• BYOL or License-included
– Oracle DB 11.2, 12.1, 12.2, 18c
– Standard, Enterprise,
High Performance, Extreme
Performance Editions
Highest DB performance on VM, Bare Metal or Exadata
Oracle Exadata
0-368 OCPUs
106-424 TB usable HC
disk storage
Extreme Performance
Edition
Oracle DB on
X7 Bare Metal
2-52 OCPUs
768 GB RAM
Up to 16 TB usable
local NVMe storage
Oracle DB
on Virtual
Machines
1-24 OCPUs
15-320 GB RAM
Up to 40 TB usable
remote storage
Oracle RAC on
Virtual Machines
4-48 OCPUs
60-640 GB RAM
Up to 40 TB usable
remote storage
Extreme Performance
Edition

• Cloud Native
– Standard Docker and Kubernetes
– Registry Integration
– Integrated with virtual cloud
networking and storage
• Developer Friendly
– Streamlined workflow
– Full REST API
– Built in cluster add-ons
– Open standards
• Enterprise Ready
– Simplified Cluster Operations
– Full Bare Metal Performance and
Highly Available IaaS
– Team Based Access Controls
– Autonomous Clusters
Container Engine for Kubernetes and Registry
Customer ManagedOracle Managed
OCI Container Engine
for Kubernetes
Cluster Management
Container Engine
Dashboard
Oracle Cloud Infrastructure
OCI Registry
In-flight and at rest
data encryption
VM based Clusters and Nodes
Bare Metal Clusters and Nodes
Customer’s OCI
Account/Tenancy
HA - 3 Masters/etcd
across 3 ADs

• Bare metal
• Private off-box virtual
networking
• Exadata
• All data encrypted at rest
• Encrypted global
backbone
• Key Management Service
• Security Lists
• Private Subnets
• Load Balancer
• IPSec VPN + FastConnect
• South/North routing –
custom middlebox
• Web Application Firewall (WAF)
• DDoS Protection
• Strong compliance
• Audit logs
• Cloud Access Security
Broker (CASB)
Cloud infrastructure trusted by enterprise customers
Data encryption
end-to-end
Network
protection
Verifiable
security
Deeper customer
isolation

Core and Edge Create a Complete Cloud
Users
[Customers, Partners,
Employees, Things] IT
[DevOps, Administrators,
Architects]
Expectation
[High quality experience]
Identity
Compute Block Storage
Database Networking
Object Storage
Edge
Name
Resolution
Distributed
Content
Traffic
Steering
Internet
Monitoring
Availability
Performance
Security
Control
Edge
Networking
Edge
Security
Core+
End-to-End SLA
No Single Point of
Failure
Common Console
Across Functionality
Email
Delivery

• Comprehensive: Broadest, Easy
to Use, PaaS & IaaS
– Everything you need to build cloud and
mobile apps for your customers and
employees, extend SaaS apps
• Integrated: Identity,
Infrastructure, Management
– To secure, operate and manage hybrid
cloud environments
• Choice: Standards-Based, Public
or Private Cloud
– Hybrid Cloud Choice - giving you
complete control when it comes to
deployment – Control over how to
leverage Oracle Cloud Platform services
and what mix of on prem and public
cloud best fits your needs
Cloud Platform: Integrate, Analyze, Build, Manage
DATA MANAGEMENT
• Database
• Big Data
• Autonomous Data
Warehouse
• Autonomous NoSQL
• MySQL
• Database Backup
• Data Hub
• Event Hub
SYSTEMS MANAGEMENT
• IT Analytics
• Log Analytics
• App Performance
Monitoring
IDENTITY AND SECURITY
• Identity
• Security Monitoring and Analytics
• Configuration and Compliance
CONTENT AND EXPERIENCE
• Autonomous Content and Experience
• WebCenter Portal
APPLICATION DEVELOPMENT
• Java
• Application Container
• Mobile and Chatbots
• AI Platform
• API Catalog
• Visual Builder
• Developer
• Blockchain
• Autonomous Visual
Builder Cloud
• Messaging
ENTERPRISE INTEGRATION
• Integration
• SOA
• Managed File Transfer
• Autonomous
Integration Cloud
• Internet of Things
• Process
• API Platform
• Self-Service
Integration
DATA INTEGRATION
• Autonomous Data
Integration Platform
BUSINESS ANALYTICS
• Data Visualization
• Autonomous Analytics
Cloud
• Infrastructure
Monitoring
• Orchestration
• Business Intelligence
• Essbase
• CASB
• GoldenGate

• Public cloud feature set
– Infrastructure services: storage,
compute and network
– Platform services: database,
development, integration
– Software application services*
• Public cloud financial model
– Subscription pricing, or pay-as-
you-consume platform and
software services
– All operations and support
services included in the service fee
• Public cloud operational model
– Delivered and managed as a
service by Oracle, with same
operational and support model as
public Oracle Cloud
Cloud at Customer: Public cloud in your data center
Oracle Cloud at
Customer
Exadata Cloud at
Customer
SaaS Cloud at
Customer
Same Cloud,
Your Choice of
Location
Comprehensively
Managed by Oracle
On-Premises Data Center
Public Cloud
Big Data Cloud at
Customer
SaaS
PaaS
IaaS

• Applications move to the
cloud “as-is,” without
requiring changes of any kind
to the VMs, networking or
storage
• Ravello makes the underlying
public cloud look and feel like
a data center
• Rapid provisioning lets
enterprises deploy apps
quickly
• Oracle Cloud provides bare
metal compute performance
and advanced networking
Ravello Service: Easily move VMware/KVM apps to Cloud
VM
VM
VM
VM
VM
PRODUCTION APPLICATION
ENVIRONMENT EXACT REPLICA IN
THE PUBLIC CLOUD
VM
VM
VM
VM
VM

Oracle Cloud Infrastructure

More Related Content

What's hot

Similar to Oracle Cloud Infrastructure

More from MarketingArrowECS_CZ

Recently uploaded

Oracle Cloud Infrastructure
