1. Mule Concepts
Mule Expression Language (MEL)
Basics -V

2. • Payload and Attachments
– To copy the current payload in a flow variable
named originalPayload then restore it :
<set-variable variableName="originalPayload"
value="#[message.payload]" /> <set-payload value="#[originalPayload]"
/>
– To retrieve the message payload in a particular format, using Mule’s
auto-transformation capability, use payloadAs:
<logger message="#[message.payloadAs(java.lang.String)]" />
– To extract all .txt and .xml attachments, use a filtered projection:
<expression-transformer expression="#[($.value in
message.inboundAttachments.entrySet() if $.key ~=
'(.*.txt|.*.xml)')]" />
– To ask for a null payload:
#[payload is NullPayload]
Mule Expression Language (MEL)

3. • Regex Support
– Regular expression helper functions retrieve null, a single value or an
array of values, depending on matches.
– The forms that take a melExpression argument apply the regex to the
result of its evaluation instead of message.payload.
#[regex(regularExpression [, melExpression [, matchFlags]])]
– Example :
• to select all the lines of the payload that begin with To:, From:, or Cc: use:
#[regex('^(To|From|Cc):')]
Mule Expression Language (MEL)

4. • XPath Support
– XPath helper functions return DOM4J nodes.
– By default the XPath expression is evaluated
onmessage.payload unless an xmlElement is specified:
#[xpath3(xPathExpression [, xmlElement])]
– To get the text content of an element or an attribute:
#[xpath3('//title').text]
#[xpath3('//title/@id').value]
Mule Expression Language (MEL)

5. • JSON Processing
– MEL has no direct support for JSON.
– The json-to-object-transformer can turn a JSON payload into a
hierarchy of simple data structures that are easily parsed with MEL.
– For the equivalent of this JSON path expression:
$..[? (@.title=='Moby Dick')].price
The following uses a filtered projection:
<json:json-to-object-transformer returnClass="java.lang.Object" />
<expression-transformer expression='#[($.price in message.payload if
$.title =='Moby Dick')[0]]" />
Mule Expression Language (MEL)

6. • Including DataWeave code
– You can carry out powerful complex data transformations by
including MEL DataWeave Functionsthat use DataWeave Language
code.
– You can include this code via two different functions in MEL: 'dw()' and
'split()'.
– 'dw' simply executes the DataWeave code you pass as an argument
and returns the transformation’s result
– 'split()' executes the code you pass as an argument and returns an
iterator that allows you to process each instance of the output as a
separate message.
dw("myobject:{id:payload.accountid, user:payload.user}")
Mule Expression Language (MEL)

7. • Miscellaneous Operations
– Assign to variable lastname the value of the message
inbound property lastname:
#[lastname = message.inboundProperties.lastname]
– Append a string to the message payload:
#[message.payload + 'mystring']
– Call a static method:
#[java.net.URLEncoder.encode()]
– Create a hash map:
#[new java.util.HashMap()]
Mule Expression Language (MEL)
