Lesson 9- NodeMCU with Arduino UNO (UART)
•
0 likes•1,144 views
Lesson 9- NodeMCU with Arduino UNO (UART) Course Contents: 1- What is NodeMCU. 2- NodeMCU Instillation in Arduino IDE. 3- Simple Projects with NodeMCU (Sensors & Actuators) 4- NodeMCU with Communication protocols. 5- Connection NodeMCU with Wi-Fi. 6- Use NodeMCU as Clients & Server. 7- Different Platform uses with IOT application.
![NodeMCU Course
Serial Communication between NodeMCU and Arduino[Esp8266 -
12E]](https://image.slidesharecdn.com/nodemcucourse-lesson9-uart-210329125316/85/Lesson-9-NodeMCU-with-Arduino-UNO-UART-1-320.jpg)
![Serial Communication between
NodeMCU and Arduino[Esp8266 -12E]
Eng.
Elaf
A.Saeed
• Embedded Systems should be connected with each other to transfer data
between them. Because all operations can’t be performed on a single
system.
• For example, Arduino has 6 analog pins but NodeMCU has only one
analog pin. So two are more microcontrollers or microprocessors can be
combined to form a required embedded system.
• The connection can be established through any of the following
protocols.
SPI
I2C
Recommended
More Related Content
What's hot
What's hot (20)
Similar to Lesson 9- NodeMCU with Arduino UNO (UART)
Similar to Lesson 9- NodeMCU with Arduino UNO (UART) (20)
More from Elaf A.Saeed
More from Elaf A.Saeed (20)
Recently uploaded
Recently uploaded (20)
Lesson 9- NodeMCU with Arduino UNO (UART)
- 1. NodeMCU Course Serial Communication between NodeMCU and Arduino[Esp8266 - 12E]
- 2. Serial Communication between NodeMCU and Arduino[Esp8266 -12E] Eng. Elaf A.Saeed • Embedded Systems should be connected with each other to transfer data between them. Because all operations can’t be performed on a single system. • For example, Arduino has 6 analog pins but NodeMCU has only one analog pin. So two are more microcontrollers or microprocessors can be combined to form a required embedded system. • The connection can be established through any of the following protocols. SPI I2C UART
- 3. Serial Communication between NodeMCU and Arduino[Esp8266 -12E] Eng. Elaf A.Saeed Serial Communication: • Serial communication is a communication process wherein data transfer occurs by transmitting data one bit at a time in sequential order over a computer bus or a communication channel. • It is the most widely used approach to transfer information between data processing equipment and peripherals. Binary One represents a logic HIGH or 5 Volts, and zero represents a logic LOW or 0 Volts, used for communicating between the Arduino board and a computer or other devices.
- 4. Serial Communication between NodeMCU and Arduino[Esp8266 -12E] Eng. Elaf A.Saeed
- 5. Serial Communication between NodeMCU and Arduino[Esp8266 -12E] Eng. Elaf A.Saeed • All Arduino boards have at least one serial port which is also known as a UART or USART. It communicates on digital pins 0 (RX) and 1 (TX) as well as with the computer via USB. Serial communication on pins TX/RX uses TTL logic levels (5V or 3.3V depending on the board).
- 6. Serial Communication between NodeMCU and Arduino[Esp8266 -12E] Eng. Elaf A.Saeed • To establish serial communication between two devices, the devices should be connected as shown below. • . Because the data sent from the device 1 should be received in the device 2 and vice versa.
- 7. Serial Communication between NodeMCU and Arduino[Esp8266 -12E] Eng. Elaf A.Saeed
- 8. Components Eng. Elaf A.Saeed • NodeMCU • Cable • Arduino UNO
