1. IP6TABLES IN LINUX
Mandeep Singh
M.Tech (IS)
1

2. TABLE OF CONTENTS
• What is firewall
• What is iptables
• Installing ip6tables
• ip6tables Configuration
• Apache Server Installation and Configuration.
• Blocking Inbound IP services
• Blocking Outbound IP services
• Blocking all traffic
• Prevent DoS attack
• Conclusion
• References
2

3. What is a Firewall?
• Hardware, software, or a combination of both
• prevent unauthorized accessing of private network.
• Protects the resources from users of other networks.
3

4. Continue..
• Linux Firewall Programs:
Ipfwadm : Linux kernel 2.0.34
Ipchains : Linux kernel 2.2.
iptables : Linux kernel 2.4. & above
4

5. What is IPTABLES?
Modified firewall package in linux OS.
Earlier known as ipchains.
Other improvements are:
improved speed and reliability.
Stateful packet inspection.
Filter packets based on TCP header and MAC address.
Better network address translation.
Rate limiting feature blocks DoS attacks.
5

6. Installing ip6tables
•In most Linux installs ip6tables by default.
•Procedure to verify installation of ip6tables in Redhat.
Open terminal and type the following command:
[root@localhost ~]#sudo info ip6tables
For the installation of IP6TABLES:
[root@localhost ~]#apt-get install ip6tables
6

7. 7
 To stop
[root@localhost ~]# sudo service ufw stop
ufw stop/waiting
 To start
[root@localhost ~]# sudo service ufw start
ufw start/running
Start/Stop ip6tables services

8. IP6TABLES Command Switch Operations
IP table command
switch
Description
-t <table> Table is of three types: filter, nat,
mangle. By default filter table is
selected.
-j <target> Packet matches current rule, jump to
specified chain.
-A Append Rule to the End of chain.
-F Delete all rules in selected table.
-p <protocol-type> Match protocol, icmp, tcp, udp, all.

9. Continue
-s <ip- address> Match source ip- address.
-d <ip- address> Match destination ip- address.
-i <interface- name> Match “input” where packet enters.
-o <interface-name> Match “output” on which packet exits.

10. Targets And Jumps
• Firewall rule inspects IP packet and identifies it as the
target.
• After target identification, the packet needs to jump over
it.
By default, ip6tables allows four targets:
 ACCEPT
 REJECT
 DROP
 LOG
11

11. Check the ip6tables rules list:

12. Allowing Established Sessions:
We can allow established sessions to receive traffic:
[root@localhost ~]# sudo ip6tables -A INPUT -m conntrack
--ctstate ESTABLISHED,RELATED -j ACCEPT
[root@localhost ~]# sudo ip6tables -A INPUT -m state
--state ESTABLISHED,RELATED -j ACCEPT

13. Continue..

14. Allowing Incoming Traffic on Specific Ports
Define default SSh port no. for ip6tables to allow all TCP
traffic to come to that port.
sudo ip6tables -A INPUT -p tcp --dport ssh -j ACCEPT
The above link explains:
1.append this rule to the input chain (-A INPUT) to look at incoming
traffic
2. check to see if it is TCP (-p tcp).
3.check if the input goes to the SSH port (--dport ssh).
4. if so, accept the input (-j ACCEPT).

15. Continue..

16. sudo ip6tables -A INPUT -p tcp --dport 80 -j ACCEPT
Allow all incoming web traffic:

17. INSTALL APACHE2 SERVER
To install apache, open terminal and run these
commands:
#sudo apt-get update
#sudo apt-get install apache2

18. Configuration of Apache2 server for IPv6

19. Ping to IPv6

20. Blocking an Inbound IP Service
Initially we on Ubuntu and run server at http//[::1]/

21. Continue..
• To drop any fragments going to 0:0:0:0::1
[root@localhost ~]#ip6tables -I INPUT -s 0:0:0:0::1 -j DROP

22. Continue..

23. Blocking an Outbound IP Service
• Make the LAN connection & check connectivity

24. Continue..

25. Continue..
• Rule to block the outbound service:

26. Continue..

27. Blocking Traffic
Once a decision is made to accept a packet, no more rules affect
it.
Rules allowing ssh and web traffic come first,
Rule to block all traffic comes next, thus maximum traffic
can be accepted.
At the end, rule is defined to block the traffic.

28. Continue..

29. Saving IP6TABLES
Save your firewall rules to a file
#sudo sh -c "ip6tables-save > /etc/ip6tables.rules"

30. Continue..

31. Prevent DoS Attack:
To prevent the DoS attack on webserver
# ip6tables -A INPUT -p tcp --dport 80 -m limit --limit 25/minute
--limit-burst 100 -j ACCEPT
m limit: to limit IP6TABLES extension
limit 25/minute: maximum of 25 connections per minute.
limit-burst 100: the limit/minute will be enforced only after
limit-burst level is reached.
32

32. Conclusion
Different services can be maintained i.e. firewall, routing,
natting, logging
To Block some types of DoS attacks with the help of rules
implementation.
33

33. References
[1]. https://help.ubuntu.com/community/IptablesHowTo
[2]. https://www.frozentux.net/iptables-tutorial/iptables-tutorial.html
[3]. http://www.netfilter.org/documentation/HOWTO/packet-filtering-
HOWTO.html
[4]. http://www.netfilter.org/documentation/
[5]. http://linux.die.net/man/8/ip6tables
[6]. https://www.hscripts.com/tutorials/linux-services/ip6tables.html
