This document discusses how to build measurement systems using an object-oriented approach in LabVIEW. It presents an example of building a thermometry system using objects to represent instruments, measurements, and controls. Measurements are factored into processes that reference instrument objects. This allows different measurements to reuse instruments. The example illustrates creating subclasses for specific measurement types. It shows how measurement systems can be naturally factored into classes representing physical instruments, virtual measurements, and controls that work together.
