This document discusses the design and implementation of an amplitude modulation (AM) software defined radio transmitter using an FPGA. It begins with an abstract describing the goals of the project. It then provides an overview of the system design, including discussion of the individual components like the microphone, analog to digital converter, digital to analog converter, carrier frequency generator, and antenna. It describes how these components will be implemented on the FPGA, including using behavioral modeling with VHDL. It also discusses designing filters and modulation/demodulation circuits. The overall summary is that this document outlines the goals and high-level system design for creating an AM transmitter using an FPGA that can transmit an audio signal by digitally modulating a carrier frequency.
