© 2017 Arm Limited
Arm Architecture HPC Workshop
Linaro, HiSilicon, Huawei
HPC Network
Stack on Arm
Pavel Shamis/Pasha, Principal Research
Engineer
© 2017 Arm Limited
Arm Architecture HPC Workshop
Linaro, HiSilicon, Huawei
HPC Network
Stack on Arm
Pavel Shamis/Pasha, Principal Research
Engineer
© 2017 Arm Limited
Arm Architecture HPC Workshop
Linaro, HiSilicon, Huawei
Let’s talk about
MPI
Pavel Shamis/Pasha, Principal Research
Engineer
© 2017 Arm Limited
Let’s talk about
RDMA…
© 2017 Arm Limited5
VERBs API on Arm
• Besides bug fixes not much work was required
• Mellanox OFED 2.4 and above supports Arm
• Linux Kernel 4.5.0 and above (maybe even earlier)
• Linux Distribution Support – on going process
• OFED – no official ARMv8 support
© 2017 Arm Limited6
OpenUCX v1.3.0
• https://github.com/openucx/ucx/releases/tag/v1.3.0
WWW.OPENUCX.ORG
https://github.com/openucx/ucx
UC-T (Hardware Transports) - Low Level API
RMA, Atomic, Tag-matching, Send/Recv, Active Message
Transport for InfiniBand VERBs
driver
RC UD XRC DCT
Transport for intra-node host memory communication
SYSV POSIX KNEM CMA XPMEM
Transport for
Accelerator Memory
communucation
GPU
Transport for
Gemini/Aries
drivers
GNI
UC-S
(Services)
Common utilities
UC-P (Protocols) - High Level API
Transport selection, cross-transrport multi-rail, fragmentation, operations not supported by hardware
Message Passing API Domain:
tag matching, randevouze
PGAS API Domain:
RMAs, Atomics
Task Based API Domain:
Active Messages
I/O API Domain:
Stream
Utilities
Data
stractures
Hardware
MPICH, Open-MPI, etc.
OpenSHMEM, UPC, CAF, X10,
Chapel, etc.
Parsec, OCR, Legions, etc. Burst buffer, ADIOS, etc.
Applications
UCX
Memory
Management
OFA Verbs Driver Cray Driver OS Kernel Cuda
© 2017 Arm Limited7
UCX Features
• Support for InfiniBand and RoCE: RC, UD, DC
• InfiniBand: Hardware tag-matching, extended AMOs, etc.
• Support for GPU Devices/Memory – AMD ROCM, Nvidia CUDA
• Support for TCP (Beta)
• Java bindings (Beta)
• Support for Accelerated Verbs – 40% speedup on Arm compared to vanilla Verbs
• Support for UGNI API for Aries and Gemini (Thanks to ORNL and LANL!)
• Support for Shared Memory: KNEM, CMA, XPMEM, Posix, SySV
• Support for x86, ARMv8, Power
• Efficient memory polling – 36% increase in efficiency on Arm
• UCX interface is integrated with MPICH, OpenMPI, OSHMEM, ORNL-SHMEM, OSSS-SHMEM,
etc.
© 2017 Arm Limited
Let’s talk about MPI…
© 2017 Arm Limited9
Message Passing Interface - MPI
De-facto standard developed by HPC community - https://www.mpi-forum.org/
Excellent overview of MPI by Jeff Squyres - https://www.slideshare.net/jsquyres/the-
message-passing-interface-mpi-in-laymans-terms
Node 1 Node 2
© 2017 Arm Limited10
Programing models
MPICH 3.3b – works on ARMv8
Open MPI 3.x – works on ARMv8
MVAPICH 2.3b – works on ARMv8
OSHMEM – work on ARMv8
© 2017 Arm Limited11
HPE Comanche (Apollo 70) with Cavium Thunder X2 SINGLE core,
Mellanox ConnextX-4 100Gb/s (EDR) - Bandwidth
0
2000
4000
6000
8000
10000
12000
1
2
4
8
16
32
64
128
256
512
1024
2048
4096
8192
16384
32768
65536
131072
262144
524288
1048576
2097152
4194304
MB/s
Message Size
MPI Bandwidth
Higherisbetter
© 2017 Arm Limited12
0
1
2
3
4
5
6
7
8
9
0 1 2 4 8 16 32 64 128 256 512 1024 2048 4096 8192
Micro-Second
Message Size
MPI Latency
HPE Comanche (Apollo 70) with Cavium Thunder X2, Mellanox
ConnectX-4 100Gb/s (EDR) – Latency/Ping Pong
Lowerisbetter
© 2017 Arm Limited13
HPE Comanche (Apollo 70) with Cavium Thunder X2, Mellanox
ConnectX-4 100Gb/s (EDR) – MPI Message Rate (28 cores)
0
10
20
30
40
50
60
70
80
90
1
2
4
8
16
32
64
128
256
512
1024
2048
4096
8192
16384
32768
65536
131072
262144
524288
1048576
2097152
4194304
MessagePerSecond
Millions
Message Size
MPI Message Rate
Higherisbetter
© 2017 Arm Limited14
Lets talk about scale…
© 2017 Arm Limited15
MPI is HUGE!
• MPI Language bindings and compiler wrappers – C, Fortran
• MPI runtimes – PMI, PMI-2, ORTE, PMIX, etc.
• MPI Network layer – supports every possible and impossible exotic network device
Open MPI
MVAPICH
Over 1,200,000 code lines !
© 2017 Arm Limited16
Let’s talk about testing …
Thanks to Howard Pritchard (LANL) and Hari Subramoni (MVAPICH) for
providing this information
Open MPI - 150,000 (aggregated) nightly tests !
MVAPICH – 18,000 Core hours (750 days) per-
commit
© 2017 Arm Limited17
Open MPI testing
CPU arch: CPU types: x86_64 , ARMv8, PPC64le
Compilers: clang37, clang38, gcc (multiple versions, 32/64bit), ibm xlc , absoft 18.0,
armclang (18.3)
Distros: AWS linux 17.03, CentOS, CrayCLE, etc
Thanks to Howard Pritchard (LANL) for providing this information
Arch x Compiler x OS x Interconnect x MPI configurations
© 2017 Arm Limited18
How YOU can help ?
• Providing hardware and software
• Running CI for MPI projects (Jenkins, etc.)
• Running distributed/scale regression (MTT, etc)
• Been active member of the community (mail lists, github, etc)
• https://www.open-mpi.org
• https://www.mpich.org
• http://mvapich.cse.ohio-state.edu
• Answer user questions, fix bugs, etc
• Contribute new features and optimizations !
• Participate in MPI forum - https://www.mpi-forum.org
© 2017 Arm Limited19
HPCAC - http://hpcadvisorycouncil.com/
2020 © 2017 Arm Limited
The Arm trademarks featured in this presentation are registered trademarks or
trademarks of Arm Limited (or its subsidiaries) in the US and/or elsewhere. All rights
reserved. All other marks featured may be trademarks of their respective owners.
www.arm.com/company/policies/trademarks
2121
Thank You!
Danke!
Merci!
!
!
Gracias!
Kiitos!
감사합니다
ध"यवाद
© 2017 Arm Limited
