1. Getting Started with Azure SQL
DatabasePittsburg TechFest
June 2, 2018

2. chadgreen@chadgreen.co
m
chadgreen.com
@ChadGreen
ChadwickEGreen
Chad Green, Data & Solutions
Architect
ProgressiveHealth

3. Database as a Service (DaaS)
Cloud computing service model that provides
users with some form of access to a database
without the need for setting up physical
hardware, installing software

4. Options to Bring Your Database to the
Cloud

5. Getting Started with Azure SQL
Database
Microsoft’s Data Platform
page
05
• Four basic options for hosting SQL Server
• SQL Server on physical machines
• SQL Server in on-premise virtualized machines
• SQL Server in Azure Virtual Machine
• Azure SQL Database

6. Getting Started with Azure SQL
Database
Microsoft’s Data Platform
page
06

7. Getting Started with Azure SQL
Database
Why Azure SQL Database
page
07
Less expensive than on-premise/hosted
Less database-related downtime
Five-year ROI
Increase in IT staff efficiencies
Total five-year average discounted business
benefits per Azure SQL Database
Payback period
53.2
%
46.7
%
98.0
%
18.7k
406% 8.6
Months

8. Getting Started with Azure SQL
Database
page
08
Azure SQL
Database
New cloud-designed applications that
have time constraints in development
and marketing
Teams that need built-in high
availability, disaster recovery, and
upgrade for the database
Teams that do not want to manage the
underlying operating system and
configuration settings
Databases of up to 4-TB
SQL Server on Azure
VMsExisting applications that require fast
migration to the cloud with minimal
change
Teams that can configure and mange
high availability, disaster recovery, and
patching for SQL Server
You need a customized environment
with full administrative rights
SQL Server instances with up to 64-TB
of storage
Azure SQL Database versus SQL Server on Azure Virtual
Machines

9. Getting Started with Azure SQL
Database
page
09
Azure SQL
Database
New cloud-designed applications that
have time constraints in development
and marketing
Teams that need built-in high
availability, disaster recovery, and
upgrade for the database
Teams that do not want to manage the
underlying operating system and
configuration settings
Databases of up to 4-TB
SQL Server on Azure
VMsExisting applications that require fast
migration to the cloud with minimal
change
Teams that can configure and mange
high availability, disaster recovery, and
patching for SQL Server
You need a customized environment
with full administrative rights
SQL Server instances with up to 64-TB
of storage
Azure SQL Database versus SQL Server on Azure Virtual
Machines

10. Getting Started with Azure SQL
Database
page
010
Azure SQL
Database
• DaaS hosted in Azure cloud
that falls into SaaS and
PaaS
• Develop directory on the
service using built-in
features and functionality
• Pay-as-you-go
• Options to scale up or out
SQL Server on Azure
VMs
• IaaS
• Built on standardized
hardware that is owned,
hosted, and maintained by
Microsoft
• Pay-as-you-go or bring your
own license
• Full administrative rights
Azure SQL Database versus SQL Server on Azure Virtual
Machines

11. Getting Started with Azure SQL
Database
SQL Server Features Not
Supported
page
011
• Change Data Capture
• Common Language Runtime
• Cross-database queries (Elastic queries yes)
• Cross-database transactions
• Database mail
• Database mirroring
• Data Quality Services
• Database snapshots
• Most DBCC statements supported
• Most DDL statements supported
• Only Database DDL Triggers
• Distributed partition views
• Distributed transactions (Elastic transactions
yes)
• Most DML triggers supported
• Most DMVs supported
• Event notifications
• Some extended events
• Extended stored procedures
• Filestream
• Most functions supported
• Master Data Services
• Minimal logging in bulk import
• Modifying system data
• OPENDATASOURCE
• OPENQUERY
• OPENROWSET
• Polybase
• Policy-based management
• Resource governor
• RESTORE statements
• Sematic search
• Service Broker
• Server configuration settings
• SQL Server Agent
• SQL Server Analysis Services (SSAS)
• SQL Server Auditing
• SQL Server Profiler
• SQL Sever Reporting Services (SSRS)
• Only some system stored procedures supported
• Only some system catalog views supported
• Trace flags

12. What is Azure SQL
Database

13. Getting Started with SQL Azure
Database
What is SQL Azure
Database
page
013
Azure SQL Database is a
cloud-based relational
database service, built on the
Microsoft SQL Server engine
designed to deliver
predictable performance and
scalability, with virtually no
downtime and near-zero
administration.
SQL Server with out the administration
headaches!

14. Scalable Performance and
Pools

15. Getting Started with Azure SQL
Database
Scalable Performance and Pools
page
015
• Adjust performance and scale without downtime

16. Getting Started with Azure SQL
Database
Scalable Performance and Pools
page
016
• Elastic Pools to maximize resource utilization

17. Getting Started with Azure SQL
Database
Scalable Performance and Pools
page
017
• Blend single databases with pooled databases

18. Getting Started with Azure SQL
Database
Scalable Performance and Pools
page
018
• Extensive monitoring and alerting capabilities

19. Built-In
Intelligence

20. Getting Started with Azure SQL
Database
Built-In Intelligence
page
020
• Automatic performance monitoring and tuning
• Automatic Index Management
• Automatic Plan Correction

21. Getting Started with Azure SQL
Database
Built-In Intelligence
page
021
• Automatic performance monitoring and tuning
• Automatic Index Management
• Automatic Plan Correction
• Adaptive Query Processing

22. Getting Started with Azure SQL
Database
Built-In Intelligence
page
022
• Automatic performance monitoring and tuning
• Automatic Index Management
• Automatic Plan Correction
• Adaptive Query Processing
• Intelligent Threat Detection

23. Advanced Security and
Compliance

24. Getting Started with Azure SQL
Database
Advanced Security and
Compliance
page
024
• Auditing for compliance and security

25. Getting Started with Azure SQL
Database
Advanced Security and
Compliance
page
025
• Auditing for compliance and security
• Data encryption at rest

26. Getting Started with Azure SQL
Database
Advanced Security and
Compliance
page
026
• Auditing for compliance and security
• Data encryption at rest
• Data encryption in motion

27. Getting Started with Azure SQL
Database
Advanced Security and
Compliance
page
027
• Auditing for compliance and security
• Data encryption at rest
• Data encryption in motion
• Dynamic data masking

28. Getting Started with Azure SQL
Database
Advanced Security and
Compliance
page
028
• Auditing for compliance and security
• Data encryption at rest
• Data encryption in motion
• Dynamic data masking
• Row-level security (RLS)

29. Getting Started with Azure SQL
Database
Advanced Security and
Compliance
page
029
• Auditing for compliance and security
• Data encryption at rest
• Data encryption in motion
• Dynamic data masking
• Row-level security (RLS)
• Azure Active Directory integration and multi-factor
authentication

30. Getting Started with Azure SQL
Database
Advanced Security and
Compliance
page
030
• Auditing for compliance and security
• Data encryption at rest
• Data encryption in motion
• Dynamic data masking
• Row-level security (RLS)
• Azure Active Directory integration and multi-factor
authentication
• Compliance certification

31. Getting Started with Azure SQL
Database
Microsoft Azure Compliance
Offerings
page
031

32. Pricing Models

33. Getting Started with Azure SQL
Database
page
033
DT
U
• Based upon bundled
measure of compute,
storage, and IO resources
• Performance levels
expressed in terms of
Database Transaction Units
(DTUs) and elastic Database
Transaction Units (eDTUs)
• Best for customers who want
simple, pre-configured
resource options
vCor
e
• Allows Independently scale
compute and storage – up to
80 vCores, 4-Tb of data
storage, and 200,000 IOPS
• Allows you to use Azure
Hybrid Benefit for SQL
Server to gain cost savings
• Best for customers who
value flexibility, control, and
transparency
Azure SQL Database Pricing Models
(Black Box) (Transparent
Box)

34. Getting Started with Azure SQL
Database
What are Database Transaction Units
(DTUs)
page
034

35. Getting Started with Azure SQL
Database
What are Database Transaction Units
(DTUs)
page
035

36. Getting Started with Azure SQL
Database
What are elastic Database Transaction Units
(eDTUs)
page
036

37. Getting Started with Azure SQL
Database
How can I determine the number of DTUs needed by my
workload
page
037
• DTU Calculator – dtucalculator.azurewebsites.net
• SQL Database Query Performance Insight
• sys.dm_db_resource_stats
• sys.resource_stats

38. Getting Started with Azure SQL
Database
More details about vCore-based purchasing model
page
038
• Represents the logical CPU offered with an option to choose
between generations of hardware
• Flexibility, control, transparency of individual resource
consumption, and straightforward way to translate on-
premises workload requirements to the cloud
• Allows you to scale compute, memory, and storage
• Pay for
• Compute (service tier + number of vCores + generation of hardware)
• Type and amount of data and log storage
• Number of IOs
• Backup storage (RA-GRS)

39. Demos

40. Getting Started with Azure SQL
Database
Demos
page
040
• Create an Azure SQL Database
• Add records to the database
• Use Azure SQL Query
• Dynamic Data Masking
• Geo-Replication
• Apply Performance Recommendations
• Enable Automatic Tuning

41. Create an Azure SQL
Database

42. Getting Started with Azure SQL
Database
Create an Azure SQL Database
page
042

43. Getting Started with Azure SQL
Database
Create an Azure SQL Database
page
043

44. Getting Started with Azure SQL
Database
Create an Azure SQL Database
page
044

45. Getting Started with Azure SQL
Database
Create an Azure SQL Database
page
045

46. Getting Started with Azure SQL
Database
Create an Azure SQL Database
page
046

47. Getting Started with Azure SQL
Database
Create an Azure SQL Database
page
047

48. Getting Started with Azure SQL
Database
Create an Azure SQL Database
page
048

49. Getting Started with Azure SQL
Database
Create an Azure SQL Database
page
049

50. Add records to the
database

51. Getting Started with Azure SQL
Database
Add Records to the Database
page
051

52. Getting Started with Azure SQL
Database
Add Records to the Database
page
052

53. Getting Started with Azure SQL
Database
Add Records to the Database
page
053

54. Getting Started with Azure SQL
Database
Add Records to the Database
page
054

55. Getting Started with Azure SQL
Database
Add Records to the Database
page
055

56. Getting Started with Azure SQL
Database
Add Records to the Database
page
056

57. Getting Started with Azure SQL
Database
Add Records to the Database
page
057

58. Getting Started with Azure SQL
Database
Add Records to the Database
page
058

59. Getting Started with Azure SQL
Database
Add Records to the Database
page
059

60. Use Azure SQL Query

61. Getting Started with Azure SQL
Database
Use Azure SQL Query
page
061

62. Getting Started with Azure SQL
Database
Use Azure SQL Query
page
062

63. Getting Started with Azure SQL
Database
Use Azure SQL Query
page
063

64. Getting Started with Azure SQL
Database
Use Azure SQL Query
page
064

65. Getting Started with Azure SQL
Database
Use Azure SQL Query
page
065

66. Dynamic Data Masking

67. Getting Started with Azure SQL
Database
Dynamic Data Masking
page
067

68. Getting Started with Azure SQL
Database
Dynamic Data Masking
page
068

69. Getting Started with Azure SQL
Database
Dynamic Data Masking
page
069

70. Getting Started with Azure SQL
Database
Dynamic Data Masking
page
070

71. Getting Started with Azure SQL
Database
Dynamic Data Masking
page
071

72. Geo-Replication

73. Getting Started with Azure SQL
Database
Geo-Replication
page
073

74. Getting Started with Azure SQL
Database
Geo-Replication
page
074

75. Getting Started with Azure SQL
Database
Geo-Replication
page
075

76. Getting Started with Azure SQL
Database
Geo-Replication
page
076

77. Getting Started with Azure SQL
Database
Geo-Replication
page
077

78. Getting Started with Azure SQL
Database
Geo-Replication
page
078

79. Getting Started with Azure SQL
Database
Geo-Replication
page
079

80. Getting Started with Azure SQL
Database
Geo-Replication
page
080

81. Getting Started with Azure SQL
Database
Geo-Replication
page
081

82. Getting Started with Azure SQL
Database
Geo-Replication
page
082

83. Getting Started with Azure SQL
Database
Geo-Replication
page
083

84. Getting Started with Azure SQL
Database
Geo-Replication
page
084

85. Getting Started with Azure SQL
Database
Geo-Replication
page
085

86. Getting Started with Azure SQL
Database
Geo-Replication
page
086

87. chadgreen@chadgreen.com
chadgreen.com
@ChadGreen
ChadwickEGreen
bit.ly/PTFSQLD

88. thank you.
