The GA-1000 is an all-in-one gaming board with features designed for entry-level gaming applications. It has an onboard VIA Nano or Eden processor, dual VGA output, networking, storage options and gaming I/O. Security features include an onboard security engine and optional crypto memory. Main applications include video slot machines, fruit machines, and amusement game machines.

1. GA-1000
all-in-one Gaming Board
NEW
Onboard VIA® NANO/Eden™ ULV Processor with Dual VGA, NVRAM, ccTalk and Gaming I/O Golden Finger
USB 3&4 ■ Key features:
KB/Mouse USB 5&6
USB 1&2 Design dedicated for entry level
Industrial Motherboard
COM 1&2 VGA DVI LAN1 DDR II DIMM Gaming/Amusement applications
Onboard VIA® Eden™ ULV 500MHz/1GHz fan-less
or Nano 1.6GHz processor
VIA® UniChromePro & MPEG-2 acceleration for
CCTALK 182
2D/multimedia applications
Battery Dual VGA display supported
72-pin One DDRII DIMM, 400/533MHz
golden finger
CPU FSB 400/533/800MHz
COM Express Module
NVRAM 32/128/512 KB; and onboard 256MB
NANDrive optional up to 4GB
Onboard Crypto Memory for custom individual
HDD security
Power Customized BIOS and tailor made FPGA functions
SATA 1&2 JAMMA 56-pin and Fruit Machine 20-pin + 72-pin
IDE
golden finger interface
Applications: fruit machines, amusement machines,
ETX CPU Module
slave unit of multi-player system, etc.
20-pin NANDrive JAMMA interface
golden finger CF Scoket
3.5 inch Embedded Board
■ System ■ Security
CPU VIA® Nano 1.6GHz, 800MHz FSB Security Processor built-in security engine support AES, RNG
VIA® Eden™ ULV 500MHz, 400MHz FSB, w/ fan-less heat sink and Security Hash
VIA® Eden™ ULV 1GHz, 400MHz FSB, w/ fan-less heat sink Crypto Memory for individual security
Other processor on request TPM 1.2 on LPC
BIOS AMI® via LPC 4Mb Flash ROM FPGA
Chipset North Bridge: VIA® CN700;
- Support VIA® V4 bus 400/533/800 MHz FSB
■ Gaming
South Bridge: VIA® VT8237R+ Boot ROM Optional 2MB Flash ROM onboard
5.25 inch Embedded Board
System Memory DDRII 400/533 DIMM, up to 1GB NVRAM Battery backup 32KB/128KB/512KB CMOS SRAM
Watchdog Timer Programmable watchdog timer, time-out value up to 255 sec Optional change to battery-less FRAM
Timers 4x Programmable timer with timeout interrupt
■ Display Intrusion Detection Optional module with
Graphic Chipset Integrated UniChrome™ Pro graphics - 6x Intrusion detection inputs
MPEG2 video decoding - Logs date/time of last 32 events
Share memory size from 8MB and up to 64MB - Events include door status, system resets/brownouts
Video Interface Primary – VGA; support CRT resolution in 1600 X I2C Pin header
1200 (UXGA) Gaming I/O FPGA controlled photo-coupler isolated inputs and
Secondly – VGA 350mA open-collector driver outputs through
Support independent dual display resolution up to
Gaming System
- 20-pin + 72-pin fruit machine golden finger
1024 X 768 - 56-pin JAMMA standard golden finger
■ Audio ■ I/O Connectors
Audio Chipset AC 97 I/O Connectors 2 x RS-232 D-SUB 9
Power Amplify Onboard 6W x2 Stereo Power Amplifier 2 x ccTalk pin header
Audio Interface 2x amplified speaker out through golden finger 2 x USB 2.0
Accessories
■ Networking 4 x USB 2.0 pin header
1 x PS2 KB/MS pin header
LAN 1x RJ45 for 10/100Base-TX Ethernet
■ Power Supply
■ Storage
Power input Through JAMMA and fruit machine golden finger
Solid State Disk One CF type II slot
Power consumption Max: DC+12V/3A, DC+5V/4A required only for
Onboard 256MB NANDrive for Microsoft Windows CE the board
6.0; optional expend to 4GB Power for Gaming I/O and peripherals excluded
Hard Disk Drive One 44-pin PATA connector for DOM (PATA or CF
jumper selectable)
Two SATA connectors
24 AEWIN Technologies www.aewin.com.tw

2. ■ Software ■ Ordering Information
all-in-one Gaming Board
Operating System Microsoft Windows CE 6.0 license included in Standard
the onboard NANDrive GA-1000A VIA® NANO 1.6GHz with Dual VGA, 10/100LAN, PATA x1, SATA x 2, TPM
Microsoft Windows XPe or Linux on request 1.2, Crypto memory, NVRAM 512KB, RS-232 *2, ccTalk *2, USB 2+4 ports,
PS2 KB/MS pin header
API Gaming I/O API and sample code for
- Microsoft Windows CE 6.0 included GA-1000B VIA® Eden™ ULV 1.0G with single VGA, 10/100LAN, PATA x1, SATA x 1,
- Microsoft Windows XPe or Linux on request Crypto memory, NVRAM 128KB, RS-232 *2, ccTalk *2, USB 2+4 ports,
PS2 KB/MS pin header
■ Mechanical and Environment GA-1000C VIA® Eden™ ULV 500MHz with single VGA, NVRAM 32KB, USB 0+2 ports
Environmental Operating Temperature: 0~60 ºC
■ Optional
Industrial Motherboard
Storage Temperature: -20~80 ºC
Humidity: 10~95% non-condensing R-135A Gaming I/O testing board
Approval FCC/CE Class A 46L-JAM001-00 Cable harness for Gaming I/O testing board
RoHS, WEEE 46L-IUSB03-00 USB cable 2 x 5 2mm / RoHS
Dimension Mini-ITX, 170 x 200mm (11.6” L x 8.7” W) 46L-I00IDE-00 IDE cable (2mm) 45cm / RoHS
46L-SATA00-00 S-ATA cable
■ Optional
46L-IPS200-00 KB/MS cable 15cm/ RoHS
Optional List 1. Intrusion detection module
* Note All specifications are subject to change without prior notice
2. I2C module pin header
COM Express Module
3. 2MB bootable Flash ROM
4. Battery-less FRAM
5. Microsoft Windows XPe license with API and
sample code
■ Applications
Main Application Video slot machine
Fruit machine
Video lottery terminal
ETX CPU Module
Amusement game machine
Slave unit of roulette machine
3.5 inch Embedded Board
5.25 inch Embedded Board
Gaming System
Accessories
www.aewin.com.tw AEWIN Technologies 25
