A presentation given by Joost van Dijk, Developer Advocate, Yubico, at our 2023 Platform Summit, October 17-18, 2023.

1. ©
2022
Yubico
© 2023 Yubico
Joost van Dijk, Yubico
Nordic APIs Platform Summit - October 18, 2023
Future-proofing Authentication With
Passkeys

2. ©
2023
Yubico
● Passkeys and API security
● What is a passkey?
● FIDO and the WebAuthn API
● Device attestation and the FIDO metadata service
● Assurance levels and step-up authentication
Overview

3. ©
2023
Yubico
Protecting the OAuth Flow
User Agent Application AuthZ Server Resource Server
AuthZ Request
AuthZ Code Response
Token Request
API Request
API Response
Token Validation
User AuthN & Consent

4. ©
2023
Yubico
Protecting the OAuth Flow
User Agent Application AuthZ Server Resource Server
AuthZ Request
AuthZ Code Response
Token Request
API Request
API Response
Token Validation
User AuthN & Consent
???
JAR
PAR
PKCE
DPoP
JARM
Non-
Repudiation
Signed
Response
Sender
Constrained
Aaron Parecki
https://www.udemy.com/course/advanced-oauth-security/

5. ©
2023
Yubico
● Passkeys are a more secure alternative to passwords
● More secure, because:
○ passkeys are resistant to phishing
○ passkeys have no secrets that can be leaked from servers
○ passkeys are generated automatically, never reused
○ passkeys can be stored on secure hardware
● Also easier to use:
○ “Sign in with your face, your finger, or your PIN”
○ Optionally, automatically backed up and synced
What is a passkey?

6. ©
2023
Yubico
Demo

7. ©
2023
Yubico
● Roaming Authenticator
also called cross-platform authenticator
example: a USB security key
● Roaming authenticators can use different
transports: USB, NFC, BLE, hybrid
● Platform Authenticator
Built into user’s device
example: a built-in fingerprint sensor
● Note: a single authenticator can store
multiple passkeys!
TouchID
FaceID
Windows
Hello
Passkeys are stored on Authenticators

8. ©
2023
Yubico
Hardware-bound
● Single-device
● Hardware attestation
● Ideal for high assurance use
cases
● FIPS eligible
● Example: passkey stored on a
security key
Synced | Copyable passkeys
● Multi-device
● Backed up and synced across
devices via a cloud provider
● No need to re-enroll a new
device on every account!
● Synced across devices but not
across ecosystems
(Apple iCloud and Google
Password Manager)
Different types of passkeys

10. ©
2023
Yubico
FIDO Public Key authentication
Veri
fi
er
challenge
response = sign(k, challenge)
private key k public key p
response
Client
challenge
response
Authenticator
(Simplified)
result = verify(p, response, challenge)

11. ©
2023
Yubico
Phishing resistance
Veri
fi
er
challenge
response = sign(k, challenge)
private key k public key p
result = verify(p, response, challenge)
response
Client
response
Authenticator
+origin
+origin +origin
(Simplified)
challenge

12. WebAuthn
API
HTTPS
CTAP
User
Veri
fi
cation
CTAP and Webauthn
Platform
API
Roaming
Authenticator
Platform
Authenticator
(Relying Party)

13. ©
2023
Yubico
● navigator.credentials.create()
register new FIDO credential
● navigator.credentials.get()
authenticate using a previously registered credential
Webauthn: JavaScript API
Client-side
JavaScript
Server-side
application
Browser
WebAuthn
API
HTTPS
CTAP
Web Application

14. ©
2023
Yubico
Attestation and Metadata
● Attestation provides verifiable evidence as to the authenticator’s origin
● Based on a hardware attestation key and certificate
● Use FIDO Alliance Metadata Service to determine provenance
● Implement Allow/Deny lists to filter Authenticators
● Typically used in high-assurance (enterprise) use cases
MDS
Attestation
Data
Authenticator
Metadata

15. ©
2023
Yubico
Metadata example
● aaguid
(Authenticator unique ID)
● keyProtection
e.g. secure_element
● transports
e.g. usb
● status
(certification level)

16. ©
2023
Yubico
Assurance Levels
Password OTP Copyable
passkey
Hardware
bound
passkey
High assurance
Low assurance

17. ©
2022
Yubico
● Step up: elevate the authentication
assurance level for sensitive API calls
● Resource servers will return an error
when step up is required
● Levels are expressed using an
Authentication context class reference
claim, for instance:
"acr": "high"
● Use acr_values parameter in
authorization requests to obtain the
required level
● See RFC 9470:
OAuth 2.0 Step Up Authentication
Challenge Protocol
Step-up Authentication
GET /sensitive HTTP/1.1
Host: server.example.com
Authorization: Bearer mF_9.B5f-4.1JqM
GET /authorize?client_id=…&
response_type=code&acr_values=high
AuthZ Server
Resource Server
API Request
API Response
HTTP/1.1 401 Unauthorized
WWW-Authenticate: Bearer
error="insufficient_user_authentication",
acr_values=“high"

18. ©
2023
Yubico
Step-up Authentication
User Agent Application AuthZ Server Resource Server
AuthZ Request
AuthZ Code Response
Token Request
API Request
API Response
User AuthN & Consent
200 OK
Low Assurance
Authentication
GET /protected

19. ©
2023
Yubico
Step-up - Insufficient User Authentication
User Agent Application AuthZ Server Resource Server
AuthZ Request
AuthZ Code Response
Token Request
API Request
API Response
User AuthN & Consent (High Assurance)
API Request
API Response
401 Unauthorized
200 OK
GET /sensitive
GET /sensitive
High Assurance
Authentication
acr_values=high

20. ©
2023
Yubico
Key Take-aways
● Passkeys are a secure and user-friendly alternative to passwords
● Passkeys are phishing-resistant by design
● Don’t let user authentication become the weakest link of API security
● Don’t frustrate users by unnecessarily excluding authenticators
● Device attestation and the FIDO metadata service let you differentiate
between different types of authenticator

21. ©
2023
Yubico
● Demo:
https://passkey.org/
● Passkeys developers site:
https://passkeys.dev/
● FIDO Metadata Explorer:
https://opotonniee.github.io/fido-mds-explorer/
● Passkey Workshop:
https://developers.yubico.com/Passkeys/
● Workshop source code:
https://github.com/YubicoLabs/passkey-workshop
Resources
