1. Mobile & Offline Data Synchronization
in AngularJS
http://bit.ly/zen-ng-pouchdb
Daniel Zen
@zendigital

2. My Background
● Longtime JavaScript programmer
● Former XP Consultant for Google & Pivotal
● Started using AngularJS 2 years ago
● Started AngularJS-NYC Meetup May 2012
● Reformed Zen Digital consultancy 2013
○ Web & mobile application development
○ Focus on using latest technologies & solutions

3. Outline for this talk:
● Requirements for AngularJS data models
● Standard Online Techniques
○ CRUD,RESTful APIs
○ $http, $resource
● Offline issues
● local storage options
● Sample Application walk through
○ Ionic
○ PouchDb

4. Requirements for data models in
AngularJS:

5. Requirements for models in AngularJS:
ABSOLUTELY NOTHING
● AngularJS is model agnostic
● Any variable or object can serve as a model
● No unique ID required
● No built-in persistence model for objects
● ng-model binds javascript variables to UI not
to backend

6. What does this mean for data persistence
● There is no standard, yet
○ See AngularJS 2.0 Data Persistence Design Doc
● Various open source storage options
○ SQL
■ MySQL
■ PostgreSQL
○ NoSQL
■ MongoDB
■ CouchDB

7. Common Persistence Practices
● CRUD - Create, read, update and delete
Each letter in the acronym can map to a standard
SQL statement and HTTP method:
Operation` SQL HTTP
Create INSERT PUT / POST
Read (Retrieve) SELECT GET
Update (Modify) UPDATE PUT / PATCH
Delete (Destroy) DELETE DELETE

8. Typically we employ RESTful APIs
● RESTful APIs - Representational state transfer
The name “Representational State Transfer” is intended to
evoke an image of how a well-designed Web application
behaves: a network of Web pages forms a virtual state machine,
allowing a user to progress through the application by selecting
a link or submitting a short data-entry form, with each action
resulting in a transition to the next state of the application by
transferring a representation of that state to the user. - Roy
Fielding
● HTTP 1.1 based on REST

9. Common REST Practices
Resource POST
create
GET
read
PUT
update
DELETE
delete
/accounts Create a new
account
List accounts Bulk update
accounts
Delete all
accounts
/accounts/123 Error Show account
123
If exists update
account 123
If not error
Delete account
123
/customers Create a new
customer
List customers Bulk update
customers
Delete all
customers
/customers/456 Error Show customer
456
If exists update
customer 456
If not error
Delete
customer 456

10. $http Service
● The AngularJS XmlHttpRequest API follows the
Promise interface ($q service)
○ Returns a promise object with the standard then method
and two http specific methods: success and error.
$http({method: 'GET', url: '/someUrl'}).
success(function(data, status, headers, config) {
// this callback will be called asynchronously
// when the response is available
}).
error(function(data, status, headers, config) {
// called asynchronously if an error occurs
// or server returns response with an error
status.
});

11. $resource - a higher level abstraction
● service in module ngResource
● factory lets you interact with server-side data
● returns resource with methods for CRUD
operations: get, save, query, remove, delete
● operations can be invoked by the following:
● no need to interact with the low level $http
● HTTP GET "class" actions: Resource.action([parameters], [success], [error])
● non-GET "class" actions: Resource.action([parameters], postData, [success], [error])
● non-GET instance actions: instance.$action([parameters], [success], [error])

12. $resource - a higher level abstraction
● You can also access the raw $http promise via
the $promise property on the object returned
● More reference: Angular communication $http & $resource
var User = $resource('/users/:userId',
{userId:'@id'});
User.get({userId:123})
.$promise.then(function(user) {
$scope.user = user;
})

13. But what about offline?
● Web apps no longer dependent on servers
● Solution: richer clients (using AngularJS ;)
● Google Docs is a good example
● For offline first experience:
○ You need to store the data in the front end
○ You need it to sync to the server’s data store.
● In browser databases available:
○ derby.js, Lawnchair, Sench touch
● requirement: online synchronization

14. What have we come to expect
● Email should work offline
○ Local copy of recent emails
○ Can read or delete
○ Can write new emails, and will send when online
● Google Docs keeps pushing threshold
○ In Chrome we can view and edit while offline
○ mobile version now has offline edit capability
● Conflict resolution
○ Intelligently merge documents with multiple edits

15. Connectivity Lifecycle
Failures can happen on: client push, or client pull/ server push
● Communicate or hide connectivity state
○ Chat app
● Enable client-side creation and editing features
○ Todo app
● Disable, modify, or hide features that won’t
work
○ Facebook status, Twitter Tweets
● Notify user about possibly conflicting data
● Conflict resolution tools (merge)

16. How to deal with being offline
● “You are offline”
○ “Unable to connect to the Internet”
○ We need to stop treating offline as an error condition
● Try not to block features completely
○ If you can’t update, show old data (with message)
○ Let user create data locally to be sent later
● Dealing with new incoming data. Options:
○ Show it as the most recent
○ Show it in chronological order

17. So what are local storage storage?
● Roll your own!
○ Use localstorage, indexDb, or WebSql directly
● Open source local storage databases that sync
○ PouchDB (JavaScript database that syncs!)
○ Hoodie (Another JS db that syncs. In preview mode)
○ remotestorage.io (IETF Proposed Standard)
● Proprietary solution?
○ Firebase (AngularFire)
■ Firebase transparently reconnects to server
■ But doesn’t persist to local storage

18. Firebase
● Pros
○ AngularJS library (AngularFire)
○ 3-way binding with $bind
○ Free Developer (Hacker) plan
○ Paid solution with premium support
○ Hosted solution
○ Can deploy static hosted apps
● Cons
○ Proprietary solution
○ Hosted solution (can’t run local or on own servers)
○ No local storage solution

19. PouchDB
● Pros:
○ Open Source
○ Lightweight Cross Browser JavaScript implementation
○ Syncs with open source CouchDB protocol servers
■ PouchDB-Server - a HTTP on top of PouchDB
■ Cloudant - A cluster aware fork of CouchDB
■ Couchbase Sync Gateway
● Cons:
○ No Standard AngularJS library (yet)
■ angular-pouchdb looks promising

20. Sample Application: ionic-pouchdb-todo
● Source code will be available at:
○ http://github.com/danielzen/ionic-pouchdb-todo (soon)
● Uses ionic hybrid mobile app framework
● Pre-requisites:
○ Node
○ CouchDb

21. Resources
● Data Persistence in Angular 2.0
● Designing Offline - Alex Feyerke
● Building offline applications with AngularJS and PouchDB
● Sync multiple AngularJS apps without server via PouchDB
● TodoMVC (AngularJS) + Hood.ie = 60 minutes to awesome
A copy of these slides is available at:
http://bit.ly/zen-ng-pouchdb
