Exploiting dynamic analysis for architectural smell detection: a preliminary study
- 5. Many tools leverage static analysis to detect architectural smells. Exploiting dynamic analysis for architectural smell detection: a preliminary study 5 Tool Supported Languages Detected Architectural Smells AI Reviewer C, C++ Cyclic Dependency, Hub-Like Dependency, Cyclic Hierarchy, God Component, Ambiguous Interface, Unutilized Abstraction ARCADE Java Cyclic Dependency, Hub-Like Dependency, Implicit Cross-module Dependency Arcan Java Cyclic Dependency, Hub-Like Dependency, Unstable Dependency, Scattered Functionality, God Component, Implicit Cross-module Dependency, Architecture Violation Designite C# Cyclic Dependency, Hub-Like Dependency, Unstable Dependency, Cyclic Hierarchy, Scattered Functionality, God Component, Multipath Hierarchy, Ambiguous Interface, Unutilized Abstraction, many others Hotspot Detector Java Cyclic Dependency, Unstable Dependency, Cyclic Hierarchy, Abstraction without Decoupling, Implicit Cross-module Dependency Massey Architecture Explorer Java Cyclic Dependency, Cyclic Hierarchy, Abstraction without Decoupling, Multipath Hierarchy Sonargraph Java, C#, C, C++ Cyclic Dependency, Architecture Violation STAN Java Cyclic Dependency Structure 101 Java, C#, C, C++, many other Cyclic Dependency, Architecture Violation
- 6. Hub-Like Dependency (HLD) a.k.a. Hub-like Modularization and Link Overload. What does it? It occurs when an abstraction or a concrete class has (out-going and in-going) dependencies with many ot her abstractions or concrete classes. It violates Modularity and Healthy Dependency Structure. How to detect it? The dependencies can be computed using several metri cs (e.g., Fan-In and Fan-Out for in-going and out-going dependencies). It requires selecting a threshold. The detection results largely vary across tools. Exploiting dynamic analysis for architectural smell detection: a preliminary study 6 Most Wanted #1: Hub-Like Dependency
- 7. Exploiting dynamic analysis for architectural smell detection: a preliminary study 7 Cyclic Dependency (CD) a.k.a. Tangle, Cross-Module Cycle, Cross-Package Cycle, Cycle of classes, and Cyclically-dependent Modularization. What does it? It arises when several architectural components depend on each ot her directly or indirectly. It violates Modularity and Healthy Dependency Structure. How to detect it? Most tools detect this smell only at the class level, then analyze it at the package level by generalizing the dependency graph obtained at the class level. Most Wanted #2: Cyclic Dependency
- 9. Exploiting dynamic analysis for architectural smell detection: a preliminary study We conjecture that integrating dynamic analysis could enhance the detection precision of previous approaches. 8 RQ1. To what extent does the usage of dynamic analysis improve the detection of the Hub-Like Dependency smell performed through static analysis?
- 10. Exploiting dynamic analysis for architectural smell detection: a preliminary study We conjecture that integrating dynamic analysis could enhance the detection precision of previous approaches. 8 RQ1. To what extent does the usage of dynamic analysis improve the detection of the Hub-Like Dependency smell performed through static analysis? RQ2. To what extent does the usage of dynamic analysis improve the detection of the Cyclic Dependency smell performed through static analysis?
- 11. Exploiting dynamic analysis for architectural smell detection: a preliminary study We conjecture that integrating dynamic analysis could enhance the detection precision of previous approaches. 8 RQ1. To what extent does the usage of dynamic analysis improve the detection of the Hub-Like Dependency smell performed through static analysis? RQ2. To what extent does the usage of dynamic analysis improve the detection of the Cyclic Dependency smell performed through static analysis?
- 12. Exploiting dynamic analysis for architectural smell detection: a preliminary study We conjecture that integrating dynamic analysis could enhance the detection precision of previous approaches. 9 H1. The data from the dynamic analysis should improve precision by reducing the number of false positives due to the removal of not resolved dependencies. H2. The data from the dynamic analysis could decrease recall if the code coverage is low. RQ1. To what extent does the usage of dynamic analysis improve the detection of the Hub-Like Dependency smell performed through static analysis? RQ2. To what extent does the usage of dynamic analysis improve the detection of the Cyclic Dependency smell performed through static analysis?
- 13. Exploiting dynamic analysis for architectural smell detection: a preliminary study ARCAN: ARChitecture ANalyzer - https://essere.disco.unimib.it/wiki/arcan/ 10 Java File Parsing Dependency Graph Generation via Static Analysis Detection of Architectural Smells Printing of the Results Metric Computation
- 14. Exploiting dynamic analysis for architectural smell detection: a preliminary study ARCAN: ARChitecture ANalyzer - https://essere.disco.unimib.it/wiki/arcan/ 11 Java File Parsing Dependency Graph Generation via Static Analysis Detection of Architectural Smells Printing of the Results Extraction of Execution Traces via Dynamic Analysis Graph Integration and Metric Computation Java Call Tracer
- 15. Exploiting dynamic analysis for architectural smell detection: a preliminary study ARCAN: ARChitecture ANalyzer - https://essere.disco.unimib.it/wiki/arcan/ Detection Strategy for Hub-Like Dependency 12 Hub-Like Dependency (HLD) a.k.a. Hub-like Modularization and Link Overload. What does it? It occurs when an abstraction or a concrete class has (out-going and in-going) dependencies with many ot her abstractions or concrete classes. It violates Modularity and Healthy Dependency Structure. How to detect it? The dependencies can be computed using several metri cs (e.g., Fan-In and Fan-Out for in-going and out-going dependencies). It requires selecting a threshold. The detection results largely vary across tools. Metric Collection Threshold Derivation via Static Analysis: the median number of in-going and out- going dependencies for each class. Threshold Re fi nement: the maximum values of the two sets of thresholds. If the “static” threshold equals zero, the re fi ned threshold is set to zero to decrease the number of false positives. Threshold Derivation via Dynamic Analysis: the median number of in-going and out- going dependencies for each class. Architectural Smell Detection: evaluation of all components against the thresholds. The classes whose metric values are higher than the thresholds are marked as smelly.
- 16. Exploiting dynamic analysis for architectural smell detection: a preliminary study ARCAN: ARChitecture ANalyzer - https://essere.disco.unimib.it/wiki/arcan/ Detection Strategy for Cyclic Dependency 13 The dependency graph is enriched through execution traces. A Depth-First Search (DFS) algorithm is executed on the obtained graph. Cyclic Dependency (CD) a.k.a. Tangle, Cross-Module Cycle, Cross-Package Cycle, Cycle of classes, and Cyclically-dependent Modularization. What does it? It arises when several architectural components depend on each ot her directly or indirectly. It violates Modularity and Healthy Dependency Structure. How to detect it? Most tools detect this smell only at the class level, then analyze it at the package level by generalizing the dependency graph obtained at the class level.
- 17. Exploiting dynamic analysis for architectural smell detection: a preliminary study More about the Experimental Design 14 Project Version # Classes LOC % Coverage JGraphT 0.8.1 38 11,931 73.8 JFreeChart 1.5.0 652 92,938 71.7 Apache Sling 1.6.17 83 10,312 65.8 Spring PetClinic 4.2.6 42 10,343 83.1 Lecousin.net 0.8.4 73 6,115 87.2 SimpleMathBackEnd 0.0.1 17 671 89.0 Zxing 3.4.1 499 43,623 98.0 Oryx 1.0.1 431 20,173 100.0 Ambari 1.2.3 711 70,621 100.0 HandleBar 4.2.0 391 24,770 78.0 The fi rst two authors of the paper validated each instance of detected smell into True Positives and False Positives. The validation was conducted in isolation to avoid bias. We executed Arcan featuring (i) only static analysis and (ii) both static and dynamic analysis to detect Hub-Like Dependencies and Cyclic Dependencies.
- 18. Exploiting dynamic analysis for architectural smell detection: a preliminary study Results for Hub-Like Dependency 15 Project Static Analysis (precision) Static and Dynamic Analysis (precision) # Matches JFreeChart 2 (1.00) 14 (0.92) 2 (14%) Apache Sling 3 (1.00) 5 (0.80) 3 (60%) Spring PetClinic 0 (-) 1 (0.00) - Lecousin.net 1 (1.00) 1 (1.00) 1 (100%) HandleBar 2 (1.00) 7 (1.00) 1 (14%)
- 19. Exploiting dynamic analysis for architectural smell detection: a preliminary study Results for Hub-Like Dependency 16 Project Static Analysis (precision) Static and Dynamic Analysis (precision) # Matches JFreeChart 2 (1.00) 14 (0.92) 2 (14%) Apache Sling 3 (1.00) 5 (0.80) 3 (60%) Spring PetClinic 0 (-) 1 (0.00) - Lecousin.net 1 (1.00) 1 (1.00) 1 (100%) HandleBar 2 (1.00) 7 (1.00) 1 (14%) The tests were not complete enough.
- 20. Exploiting dynamic analysis for architectural smell detection: a preliminary study Results for Hub-Like Dependency 17 A Façade was detected as a Hub-Like Dependency. The tests were not complete enough. Project Static Analysis (precision) Static and Dynamic Analysis (precision) # Matches JFreeChart 2 (1.00) 14 (0.92) 2 (14%) Apache Sling 3 (1.00) 5 (0.80) 3 (60%) Spring PetClinic 0 (-) 1 (0.00) - Lecousin.net 1 (1.00) 1 (1.00) 1 (100%) HandleBar 2 (1.00) 7 (1.00) 1 (14%)
- 21. Exploiting dynamic analysis for architectural smell detection: a preliminary study Results for Hub-Like Dependency 18 A GUI Listener was detected as a Hub-Like Dependency. Project Static Analysis (precision) Static and Dynamic Analysis (precision) # Matches JFreeChart 2 (1.00) 14 (0.92) 2 (14%) Apache Sling 3 (1.00) 5 (0.80) 3 (60%) Spring PetClinic 0 (-) 1 (0.00) - Lecousin.net 1 (1.00) 1 (1.00) 1 (100%) HandleBar 2 (1.00) 7 (1.00) 1 (14%) A Façade was detected as a Hub-Like Dependency. The tests were not complete enough.
- 22. Exploiting dynamic analysis for architectural smell detection: a preliminary study Results for Hub-Like Dependency 18 A GUI Listener was detected as a Hub-Like Dependency. Project Static Analysis (precision) Static and Dynamic Analysis (precision) # Matches JFreeChart 2 (1.00) 14 (0.92) 2 (14%) Apache Sling 3 (1.00) 5 (0.80) 3 (60%) Spring PetClinic 0 (-) 1 (0.00) - Lecousin.net 1 (1.00) 1 (1.00) 1 (100%) HandleBar 2 (1.00) 7 (1.00) 1 (14%) A Façade was detected as a Hub-Like Dependency. The tests were not complete enough. Reminder 1. Utility classes may be naturally born Hub-Like Dependencies.
- 23. Exploiting dynamic analysis for architectural smell detection: a preliminary study Results for Hub-Like Dependency 18 A GUI Listener was detected as a Hub-Like Dependency. Project Static Analysis (precision) Static and Dynamic Analysis (precision) # Matches JFreeChart 2 (1.00) 14 (0.92) 2 (14%) Apache Sling 3 (1.00) 5 (0.80) 3 (60%) Spring PetClinic 0 (-) 1 (0.00) - Lecousin.net 1 (1.00) 1 (1.00) 1 (100%) HandleBar 2 (1.00) 7 (1.00) 1 (14%) A Façade was detected as a Hub-Like Dependency. The tests were not complete enough. Reminder 1. Utility classes may be naturally born Hub-Like Dependencies. Reminder 2. Some Architectural Smells are related to design patterns.
- 24. Exploiting dynamic analysis for architectural smell detection: a preliminary study Results for Cyclic Dependency 19 Project Static Analysis (precision) Static and Dynamic Analysis (precision) # Matches JFreeChart 12 (0.90) 8 (1.00) 6 (75%) JGraphT 21(0.00) 29 (0.00) 11 (34%) Apache Sling 19 (0.24) 0 (-) -
- 25. Exploiting dynamic analysis for architectural smell detection: a preliminary study Results for Cyclic Dependency 20 Project Static Analysis (precision) Static and Dynamic Analysis (precision) # Matches JFreeChart 12 (0.90) 8 (1.00) 6 (75%) JGraphT 21(0.00) 29 (0.00) 11 (34%) Apache Sling 19 (0.24) 0 (-) - Dynamic Analysis allowed Arcan to increase its precision.
- 26. Exploiting dynamic analysis for architectural smell detection: a preliminary study Results for Cyclic Dependency 20 Project Static Analysis (precision) Static and Dynamic Analysis (precision) # Matches JFreeChart 12 (0.90) 8 (1.00) 6 (75%) JGraphT 21(0.00) 29 (0.00) 11 (34%) Apache Sling 19 (0.24) 0 (-) - Reminder 3. All false positives concern a class and its inner and anonymous classes. Such dependencies must be fi ltered out when detecting Cyclic Dependencies. Dynamic Analysis allowed Arcan to increase its precision.
- 28. Exploiting dynamic analysis for architectural smell detection: a preliminary study Limitations and Future Work 21 We considered only two architectural smells. What about other architectural smells affecting other violations?
- 29. Exploiting dynamic analysis for architectural smell detection: a preliminary study Limitations and Future Work 21 An excessive number of tests leads to very long execution traces, which are complex and costly to analyze. What about the automated selection and generation of tests for dynamic analysis? What about using execution traces from production (e.g., in a DevOps lifecycle)? We considered only two architectural smells. What about other architectural smells affecting other violations?
- 30. Exploiting dynamic analysis for architectural smell detection: a preliminary study Limitations and Future Work 21 An excessive number of tests leads to very long execution traces, which are complex and costly to analyze. What about the automated selection and generation of tests for dynamic analysis? What about using execution traces from production (e.g., in a DevOps lifecycle)? We considered only two architectural smells. What about other architectural smells affecting other violations? We relied on Java Call Tracer. What about a dedicated monitoring component?
