- The document proposes corrections to errors in use case modeling, defining a use case as a sequence of messages between a system and actor, similar to a BPMN conversation.
- It suggests use cases should be modeled externally to the system as hexagons or conversation elements, rather than internally as ovals. Actor should be an external entity rather than role.
- A use case can also be modeled as an association class in a class diagram, showing its relationship between an actor class and the system class.
[1] A view that a UseCase (UC) is a "dialog" between the System under Consideration (SuC) and an Actor (for a specific UC) brings focus to what "messages need to be exchanged between the SuC and Actor to reach UC Goal".
[2] Agreeing on and specifying UC Goal is related to business or application. UC Goal would be the right first step of UC description.
[3] There are many "means" of generating "messages from SuC", through various internal activities within the SuC. They need not be (I would even say should not be) specified in UC Description.
[4] The concept of UseCase is profound and useful because it is a "dialog" but NOT a process. This distinction is not defined and clarified which is why, I think, the full benefits of UC modeling are not widely realized.
[5] This view of UC (as per 1, 2 & 3) clearly separates the "internal processes" of the SuC from UC. The "internal processes" can be hypothesized and evolved separately using UML Sequence Diagrams. All the business / user needs can be specified with sufficient precision and rigor through the “messages” of UC dialog. There are no external dependencies, though constraints may exist and have to be taken care of.
I have REVISED & uploaded the PPT with TWO Sections, Section 2 First.
[6] I would like to study applications and demonstrate how the "dialog" view of UseCase would simplify & clarify UseCase description for the business user as well as system developer without sacrificing precision and usefulness.
02 FEB 14
Multiple Actors DO interact with the SuC, which is why the SuC exists in the first place, but NO TWO of them can do so through a single UseCase. There can be NO Second Actor in a UseCase.
Each interaction, more appropriately the dialog, can only have two members actively involved in the dialog.
First is the SuC and the second is the associated Actor.
The nature of UseCase and its implications were well discussed in
http://www.slideshare.net/putchavn/usecase-case-is-a-dialog-not-a-process
http://www.slideshare.net/putchavn/use-casesingle-session
http://www.slideshare.net/putchavn/one-use-case-one-actor
Yet there are discussions and justifications for associating multiple actors with the same UseCase.
UseCase is a DIALOG involving only one SuC and One Actor per Session. There is NO scope for another actor to take part in that dialog. Here is an example ATM Cash withdrawal. It needs THREE separate UCs.
This is explained using Process Maps to show the separation and how to separate.
This should end the confusion and persistent misunderstanding and misrepresentation.
Harmonizing use cases, dialogs or conversations, process maps, usecase diagra...Putcha Narasimham
UseCase concept is unique and profound concept to represent the needs of businesses and users from their view point. Based on UseCase and Actor identification, the System to be Developed can be specified and evolved systematically. This summary updates and integrates many proposals made earlier. It logically integrates all the concepts of the title.
[1] A view that a UseCase (UC) is a "dialog" between the System under Consideration (SuC) and an Actor (for a specific UC) brings focus to what "messages need to be exchanged between the SuC and Actor to reach UC Goal".
[2] Agreeing on and specifying UC Goal is related to business or application. UC Goal would be the right first step of UC description.
[3] There are many "means" of generating "messages from SuC", through various internal activities within the SuC. They need not be (I would even say should not be) specified in UC Description.
[4] The concept of UseCase is profound and useful because it is a "dialog" but NOT a process. This distinction is not defined and clarified which is why, I think, the full benefits of UC modeling are not widely realized.
[5] This view of UC (as per 1, 2 & 3) clearly separates the "internal processes" of the SuC from UC. The "internal processes" can be hypothesized and evolved separately using UML Sequence Diagrams. All the business / user needs can be specified with sufficient precision and rigor through the “messages” of UC dialog. There are no external dependencies, though constraints may exist and have to be taken care of.
I have REVISED & uploaded the PPT with TWO Sections, Section 2 First.
[6] I would like to study applications and demonstrate how the "dialog" view of UseCase would simplify & clarify UseCase description for the business user as well as system developer without sacrificing precision and usefulness.
02 FEB 14
Multiple Actors DO interact with the SuC, which is why the SuC exists in the first place, but NO TWO of them can do so through a single UseCase. There can be NO Second Actor in a UseCase.
Each interaction, more appropriately the dialog, can only have two members actively involved in the dialog.
First is the SuC and the second is the associated Actor.
The nature of UseCase and its implications were well discussed in
http://www.slideshare.net/putchavn/usecase-case-is-a-dialog-not-a-process
http://www.slideshare.net/putchavn/use-casesingle-session
http://www.slideshare.net/putchavn/one-use-case-one-actor
Yet there are discussions and justifications for associating multiple actors with the same UseCase.
UseCase is a DIALOG involving only one SuC and One Actor per Session. There is NO scope for another actor to take part in that dialog. Here is an example ATM Cash withdrawal. It needs THREE separate UCs.
This is explained using Process Maps to show the separation and how to separate.
This should end the confusion and persistent misunderstanding and misrepresentation.
Harmonizing use cases, dialogs or conversations, process maps, usecase diagra...Putcha Narasimham
UseCase concept is unique and profound concept to represent the needs of businesses and users from their view point. Based on UseCase and Actor identification, the System to be Developed can be specified and evolved systematically. This summary updates and integrates many proposals made earlier. It logically integrates all the concepts of the title.
UML stands for Unified Modelling Language.
UML is a standard language for specifying, visualizing, constructing, and documenting a system in which software represents the most significant part.
UML is different from the other common programming languages like C++, Java, COBOL etc.
UML is a pictorial language used to make software blue prints.
UML can serve as a central notation for software development process. Using UML helps project teams communicate, explore potential designs, and validate the architectural designs of software.
UML diagrams are made using notation of things and relationships.
The building blocks of UML can be defined as:
Things
Relationships
Diagrams
Things: Things are the most important building blocks of UML. Things can be:
Structural
Behavioral
Grouping
Annotational
The Structural things define the static part of the model. They represent physical and conceptual elements. Following are the brief descriptions of the structural things.
Class: Class represents set of objects having similar responsibilities.
Interface: Interface defines a set of operations which specify the responsibility of a class.
Collaboration: Collaboration defines interaction between elements.
Use case: Use case represents a set of actions performed by a system for a specific goal.
Component: Component describes physical part of a system.
Node: A node can be defined as a physical element that exists at run time.
A behavioral thing consists of the dynamic parts of UML models. Following are the behavioral things:
Interaction: Interaction is defined as a behavior that consists of a group of messages exchanged among elements to accomplish a specific task.
State machine: State machine is useful when the state of an object in its life cycle is important. It defines the sequence of states an object goes through in response to events. Events are external factors responsible for state change.
