The document summarizes two approaches to implementing foveated imaging in CMOS image sensors: (1) A pyramidal architecture with multiple rings of pixels having different integration times, allowing for dynamic range enhancement. (2) A universal multiresolution sensor using a 3T pixel design that allows pixels to be grouped and averaged, enabling adaptive resolution. Both designs aim to mimic the human retina and improve efficiency over traditional sensors. The pyramidal and multiresolution sensors were fabricated in 0.18um CMOS technology and are being tested for applications like video conferencing and industrial inspection.
