Driver Location Intelligence at Scale using Apache Spark, Delta Lake, and MLflow on Databricks
- 1. WIFI SSID:Spark+AISummit | Password: UnifiedDataAnalytics
- 2. Sergio Ballesteros, TomTom Kia Eisinga, TomTom Driver Location Intelligence at Scale using Apache Spark, Delta Lake and MLflow on Databricks #UnifiedDataAnalytics #SparkAISummit
- 3. Ourvision A safe, connected, autonomous world that is free of congestion and emissions.
- 5. Data • Anonymous location (GPS) traces 5
- 7. 7
- 8. Data • Anonymous location (GPS) Traces • Community inputs • User events • Journalistic data • Car sensor data 8
- 9. Dataflow 9 ~150 trillion data points ~80 billion data points per day
- 10. Dataflow 10
- 11. Dataflow 11
- 12. In dash systems are outperformed by smartphones The embedded systemis expected to be up-to-date, with no user interaction. And the most visible component of it is a map. Usecase1:IQMapsanalytics 12
- 13. Driversdonotupdatetheirmaps Today’s solutions provide manual updates, oftenwith a necessity to drive to the dealer. This is way too complex and inefficient. 13
- 14. 14
- 15. OEMsrequire dataefficient solutions While drivers expect up-to-date system, the carmakers are usually concerned about the data cost required for the map management. 15
- 16. 98% OF TRIPS ARE DRIVEN WITHIN150KM RADIUS99.8% OF TRIPS ARE DRIVEN WITHIN1000KM RADIUS 16
- 17. Whenradiusis0km • User drives within 2 regions every week day • Radius of 0 km. • Download and install justhome regions • Cellular data usage kept to a minimum 17
- 18. Whenradiusis150km • User drives within 2 update regions every week day • Radius of 150 km. • Home region: 6 update regions. • Cellular data usage increased 18
- 20. 20
- 21. Realresultsusing0.5Mtrips 21 “This insight has led me to the conclusion that a default radius of 150km is unnecessary, and a small radius of ~10km would already satisfy mostdrivers while keeping cellular data usage low for OEMs.” - Rolf Dorland, PM at TomTom
- 22. Goingonholidays • User goes for his holiday (less frequent updated region) • Once user starts driving, updates for all update regions the route goes through are downloaded and installed. 22
- 24. 24
- 25. Opportunity 25 Past: Rule-based solution Delta Lake pipelines Present: Machine Learning
- 26. Data 26 Original trace data from 1 source 227K device serials Filtering out invalid trips 143K device serials Users with at least 50 trips 3.6K device serials Devices feasible for modelling 2.5K device serials
- 27. Features For each trip, we have the following information: • Where did the trip start? • At what speed were you driving when the trip started? • What was the time of day (morning/afternoon/evening) when the trip started? • Was it rush hour when the trip started? • What day of the week was it? • Was it a weekend day? • What was the season? • Which driver profile do you belong to? Historical information: • Which destination did you go to your last trip? And the one before that? And the one before that? • If it is a, let's say Monday, where did you go to the last Monday you made a trip? (do this for every weekday) To predict: To which destination are you going? What do we use in the end? 27
- 28. Labels • We are given the latitude and longitude of a destination of a trip. • In order to find out which latitude and longitudes belong to the same destination, we apply a clustering algorithm called DBSCAN. • DBSCAN clusters together destinations that are within 500 meters from each other. We should have at least 5 trips to a destination in order to call it a cluster. How do we define where you are going? 28
- 29. 29
- 30. Train,validationandtestsplit Trip ID Date Destination Trip 1 January1 Cluster1 Trip 2 January22 Cluster2 Trip 3 February3 Cluster1 Trip 4 February15 Cluster2 Trip 5 March 2 Cluster1 Trip 6 March 14 Cluster1 Trip 7 March 27 Cluster2 Trip 8 April 4 Cluster1 Trip 9 April 16 Cluster2 Trip 10 May 8 Cluster1 Train & validation dataset Test dataset TIME-SERIES CROSS-VALIDATION Iterativeevaluation of the trips to avoid overfitting Trip ID Date Destination Trip 1 January1 Cluster1 Trip 2 January22 Cluster2 Trip 3 February3 ? Trip ID Date Destination Trip 1 January1 Cluster1 Trip 2 January22 Cluster2 Trip 3 February3 Cluster1 Trip 4 February15 ? Data for 1 driver: Trip ID Date Destination Trip 1 January1 Cluster1 Trip 2 January22 Cluster2 Trip 3 February3 Cluster1 Trip 4 February15 Cluster1 … … … Trip 10 May 8 ? 30
- 32. 32
- 33. Majoritybaseline Distribution of precision on the test set with a majority baseline classifier 33
- 34. Results Distribution of precision on the test set with a tuned classifier 34
- 35. AcceleratingtheFutureofMobility By embracing Apache Spark, Databricks and the Azure cloud 3535
