1. Docker Remote API &
docker-py
Eric Ahn
2016/07

2. $ docker-machine create -d virtualbox default
$ docker-machine env default
$ docker-machine ls default
$ curl https://192.168.99.100:2376/images/json
—cert $DOCKER_CERT_PATH/cert.pem
—key $DOCKER_CERT_PATH/key.pem
—cacert $DOCKER_CERT_PATH/ca.pem
curl: (58) SSL: Can't load the certificate "/Users/EricAhn/.docker/machine/
machines/default/cert.pem" and its private key: OSStatus -25299
password?

3. $ cd ~/.docker/machine/machines/default
$ openssl pkcs12 -export
> -inkey key.pem
> -in cert.pem
> -CAfile ca.pem
> -name client-side
> -out cert.p12
> -password pass:mypass
$ curl https://192.168.99.100:2376/images/json
—cert $DOCKER_CERT_PATH/cert.p12
—pass mypass
—key $DOCKER_CERT_PATH/key.pem
—cacert $DOCKER_CERT_PATH/ca.pem
[{"Id":"sha256:0d409d33b27e47423b049f7f863faa08655a8c901749c2b25b93ca6
7d01a470d","ParentId":"","RepoTags":["nginx:latest"],"RepoDigests":null,"Created":
1464804059,"Size":182786784,"VirtualSize":182786784,"Labels":{}}]
Generate cert.p12
with password
List images :
“nginx:latest”
Result

4. $ curl -X POST https://192.168.99.100:2376/images/create?fromImage=nginx:latest
—cert $DOCKER_CERT_PATH/cert.p12
—pass mypass
—key $DOCKER_CERT_PATH/key.pem
—cacert $DOCKER_CERT_PATH/ca.pem
{"status":"Pulling from library/nginx","id":"latest"}
{"status":"Digest:
sha256:0fe6413f3e30fcc5920bc8fa769280975b10b1c26721de956e1428b9e2f29d04"}
{"status":"Status: Image is up to date for nginx:latest"}
$ docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
nginx latest 0d409d33b27e 7 weeks ago 182.8 MB
Download “nginx:latest” image
Result
Check using command line

5. $ curl -v -X POST -H "Content-Type: application/json" -d '
{ "Image": "nginx"
}' https://192.168.99.100:2376/containers/create
--cert $DOCKER_CERT_PATH/cert.p12
--pass mypass
--key $DOCKER_CERT_PATH/key.pem
--cacert $DOCKER_CERT_PATH/ca.pem
{"Id":"8c6e0e97330c08461cdfc179a524ad56c2b0c3a2ba95fc5909a999d
75eb44b37","Warnings":null}
Create container
Result a message

6. $ curl -X POST -H "Content-Type: application/json"
> -d '{ "PortBindings": {"80/tcp": [{ "HostPort": "80"}]} }'
> https://192.168.99.100:2376/containers/8c6e0e97330c/start
> --cert $DOCKER_CERT_PATH/cert.p12
> --pass mypass
> --key $DOCKER_CERT_PATH/key.pem
> --cacert $DOCKER_CERT_PATH/ca.pem
{"message":"starting container with HostConfig was deprecated
since v1.10 and removed in v1.12"}
Set a specific HostConfig
Result : Failed with
HostConfig

7. $ curl -v https://192.168.99.100:2376/containers/json?all=1
--cert $DOCKER_CERT_PATH/cert.p12
--pass mypass
--key $DOCKER_CERT_PATH/key.pem
--cacert $DOCKER_CERT_PATH/ca.pem
[{"Id":"4ee9a6f6b24715266ae8037fd069e2439d67c0198ee8f96b531682d61363f527","Na
mes":["/
hello"],"Image":"nginx:latest","ImageID":"sha256:0d409d33b27e47423b049f7f863faa08655
a8c901749c2b25b93ca67d01a470d","Command":"nginx -g 'daemon off;'","Created":
1469639718,"Ports":[{"PrivatePort":443,"Type":"tcp"},{"IP":"0.0.0.0","PrivatePort":
80,"PublicPort":80,"Type":"tcp"}],"Labels":{},"State":"running","Status":"Up 14
minutes","HostConfig":{"NetworkMode":"default"},"NetworkSettings":{"Networks":{"bridge":
{"IPAMConfig":null,"Links":null,"Aliases":null,"NetworkID":"f22986e826e252df0d0f06011158
9f0a732993c6636ba47e549911ccaf8f8ed8","EndpointID":"41513d5005aa2777561b6c0c
d3f3f6ae44fa7d6d47d261734391e206cdade7b6","Gateway":"172.17.0.1","IPAddress":"17
2.17.0.2","IPPrefixLen":16,"IPv6Gateway":"","GlobalIPv6Address":"","GlobalIPv6PrefixLen":
0,"MacAddress":"02:42:ac:11:00:02"}}},"Mounts":[]}]
List all containers
Result ( json )

8. $ curl -X POST -H "Content-Type: application/json"
https://192.168.99.100:2376/containers/8c6e0e97330c/start
--cert $DOCKER_CERT_PATH/cert.p12
--pass mypass
--key $DOCKER_CERT_PATH/key.pem
--cacert $DOCKER_CERT_PATH/ca.pem
$ docker ps -a
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
8c6e0e97330c nginx "nginx -g 'daemon off" 2 minutes ago Up 1 seconds 80/tcp, 443/tcp goofy_ardinghelli
Start a container
Running status

9. $ cd ~/_Python
$ sudo easy_install pip
$ sudo pip install virtualenv
$ virtualenv foobar
$ source foobar/bin/activate
(foobar) $ pip install docker-py
Collecting docker-py
Downloading docker_py-1.9.0-py2.py3-none-any.whl (42kB)
Collecting requests>=2.5.2 (from docker-py)
Downloading requests-2.10.0-py2.py3-none-any.whl (506kB)
100% | | 512kB 938kB/s
Collecting six>=1.4.0 (from docker-py)
Downloading six-1.10.0-py2.py3-none-any.whl
Collecting websocket-client>=0.32.0 (from docker-py)
Downloading websocket_client-0.37.0.tar.gz (194kB)
100% | | 194kB 1.4MB/s
Collecting backports.ssl-match-hostname>=3.5; python_version < "3.5" (from docker-py)
Downloading backports.ssl_match_hostname-3.5.0.1.tar.gz
Building wheels for collected packages: websocket-client, backports.ssl-match-hostname
Running setup.py bdist_wheel for websocket-client ... done
Stored in directory: /Users/EricAhn/Library/Caches/pip/wheels/e4/20/12/48d6732b88733a0a8f98ee1a5b2f59b64b27011d5c34c4f98c
…..
Install python and virtualenv

10. (foobar) $ vi docker-run.py
import docker
tls_config = docker.tls.TLSConfig(
client_cert=('/Users/EricAhn/.docker/machine/machines/default/cert.pem',
'/Users/EricAhn/.docker/machine/machines/default/key.pem'),
verify='/Users/EricAhn/.docker/machine/machines/default/ca.pem'
)
client = docker.Client(base_url='tcp://192.168.99.100:2376', tls=tls_config)
client.containers()
container_id = client.create_container(
image='nginx:latest',
ports=[80],
name='hello'
)
client.start(
container_id,
port_bindings={80: ('0.0.0.0', 80)}
)
$ python docker-run.py
$ docker ps -a
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
4ee9a6f6b247 nginx:latest "nginx -g 'daemon off" 2 seconds ago Up 1 seconds 0.0.0.0:80->80/tcp, 443/tcp hello
Python code
Run code and check
