This document summarizes sections of a development portfolio, including: 1. A current project involving legacy system modernization and a new user interface. 2. An aerospace section covering aircraft maintenance processes, surveys, calibration, treatments, and NDT applications. 3. Examples of applications developed for fast tracking processes like order intake, material replenishment, and subcontract order processing.

1. Sample Development Portfolio
Current Project
Aerospace Section
Automotive Section
General Section
Legacy System Regeneration Section
Touch Screen Section

2. Current Project
Rationisation and integration of a diverse Range of legacy
business applications.
Migration of btrieve data to SQL RDBMS.
Build new user interface for 22 year old mainframe MRP
system.
Design and development of new business requirements.
Provision of training materials and online help.

3. New User Interface
dll driven user interface. Menu options are derived from the
callable procedures within the application dll’s.

4. Drag and drop user profiles
Home

5. Aerospace
Aircraft Maintenance Checks
EASA Aircraft Assembly and component Surveying
ACR Aircraft Assembly and component Surveying
Touchscreen Applications
Technical Libraries
Application Architecture
Calibration
NDT

6. Aircraft Maintenance Checks
Process:
Receive electronic customer aircraft maintenance work pack
Import MPD Tasks
Tasks are checked with the database Access/Inspection and Maintenance times.
Tasks are sorted into aircraft sections.
Barcode Labels are printed for tasks and job card database records are created.
Master Documents are Bar-coded and held in Technical Services Department until the aircraft
arrives.
Master Documents are issued when the aircraft arrives.
Non-routine cards are created when required.
Material issues are requested, allocated, and issued against the database job card records.
Labour times are recorded against the database job card.
Cost analysis and budget variance available on demand

7. Aircraft Maintenance Checks Import MPDs
Home

8. Aircraft Maintenance Checks Database Check
Home

9. Aircraft Maintenance Checks by aircraft section
Home

10. Aircraft Maintenance Checks non-routine job cards
Non-routine cards are always pegged to an original access/inspection job card
Home

11. Aircraft Maintenance Checks SFDC
Configurable SFDC system
….
Clock On and Clock Off
Book-on single/multiple jobs
Book-on non-productive codes.
Automatically books off
previous job(s) when booking
on to next job(s).
Automatically books-off jobs
when clocking off.
Break allowances.
Time apportionment
Auto book on non-productive
codes for specific staff.
Home

12. Aircraft Maintenance Checks materials allocation

13. Aircraft Maintenance Checks allocations

14. Aircraft Maintenance Checks materials issue

15. Aircraft Maintenance Checks Job Card Closure

16. Aircraft Maintenance Checks booked hours analysis

17. Aircraft Maintenance Checks material cost analysis

18. Aircraft Maintenance Checks material cost analysis
Home

19. Aircraft Maintenance Checks budget variance analysis
Home

20. EASA Survey Frame
User Access Control (Surveyor, Foreman, Inspector, …)
Contract Review
Survey Template (Minor, Major, Fixed, …)
Surveys (AOG, Initial, Report, Detailed, …)
Supplementary Surveys
Purchase Order Requisition (inclusive clauses)
Treatments Control
Kit Lists
Concessions and Permits
RDO Requests
Form 1 Generation
Destruction Certificates
Cost Breakdown

21. EASA Survey Screens
Colour coded survey status

22. EASA Survey Screens
Hot keys exist for repetitive Fault and Rectification narrative.
EIP (edit-in-place) data entry

23. EASA Survey Process Overview

24. ACR Survey Frame
User Access Control (Surveyor, Foreman, Inspector, …)
Contract Review
Survey Template (Minor, Major, Fixed, …)
Surveys (AOG, Initial, Report, Detailed, …)
Supplementary Surveys
Purchase Order Requisition (inclusive clauses)
Treatments Control
Kit Lists
Concessions and Permits
RDO Requests
Form 1 Generation
Destruction Certificates
Cost Breakdown
MOD Status and Asset Reports

25. ACR Survey Screens
Colour coded survey status

26. ACR Survey Screens
Hot keys exist for repetitive Fault and Rectification narrative.
EIP (edit-in-place) data entry

27. Calibration
Calibration:
Sites
Locations
Methods
Frequency
Status Codes
Equipment
Documents
Records
Schedules

28. Company Equipment Calibration Record

29. Company Equipment Calibration Record
Company Equipment Calibration and printed Schedule

30. Operator Calibration Records

31. Operator Calibration Records
Operator Calibration and printed Schedule

32. CCPI Calibration Schedule
CCPI Calibration maintenance

33. CCPI Calibration Schedule
CCPI Calibration maintenance and printed Schedule

34. Fast Track Consignment Stock Replenishment
This browse displays all of the consignment stock parts. Items with stock levels
below the minimum stock level are highlighted in red, and have suggested re-order
quantities. PO are raised and emailed to the suppliers from this single screen.

35. Fast Track MRP Planning
Mass update of MRP planning parameters based on a BOM
explosion of one or more assemblies

36. Fast Track Aerospace Treatments Goods In
The original goods in
process involved
entering data into
multiple screens. That
process was replaced
with a single interface
that gave the operator
full visibility of the
input process.
The regeneration of this
order entry process
increased order
throughput by more than
100%

37. Fast Track Order Intake
Specific customers would email sales orders in xls format.

38. Fast Track Order Intake
The xls files are validated, and sales orders are created on the MRP system, thus
reducing sales order input time.

39. Fast Track Sub-contract Order Processing
This single screen
entry system replaced
a 7 page purchase
order entry process
and hand written
Certificate of
Conformity.
When the goods are
returned a single
screen is used to book
the parts back into
WIP.

40. Fast Track Job Shortages & Update
Enquiry by Job Number displays all purchase orders with outstanding
balances. Updated by purchasing department, providing visibility to all
engineers working on the aircraft.

41. Fast Track Job Shortages & Update
Report capability if required

42. IG-NDT-1 Technique Illustration Application
Select the appropriate images folder, activate the Generate
pdf file, assign a pdf filename. Click on the OK button.

43. IG-NDT-1 Technique Illustration Application
Select the required image, click on the Change
button.

44. IG-NDT-1 Technique Illustration Application
Select the required image, click on the Change
button, and enter the required text for the image.

45. IG-NDT-1 Technique Illustration Application
Print the finished report, both hardcopy and pdf

46. Aircraft component Ident
One time set up per
component. Full database
validation and ability to
print/reprint multiple
chemietch labels.

47. Reject Control (Internal & External)
Application to
track the status of
customer rejects.
UAC for Goods
Receipt,
Production
Planners, and
Inspection.
Full QA and
customer reporting.

48. Customer Order Progress Sheets
The manual update of the customer order progress spread sheet used to take the progress
chasers 3 to 4 days to complete. The progress chaser would interrogate the MRP database
and re-key the data into the spread sheet.
Inbound customer xls file
outbound update customer xls file
The above process received the xls spread sheet, updated the progress information by reading
the ERP Oracle database, and email the updated xls spread sheet back to the customer in less
than 10 minutes.

49. Fast Track Despatch Certificate of Conformance
This screen was developed to replace a six screen process. The
process was driven from the entry of the Works Order Number
and Despatch Qty. The background process updated the database
and printed the Despatch Documentation.

50. Application Architecture
373 business processes, 3383 procedures
Home

51. Automotive
Kanban Tickets

52. Kanban Tickets
This Kanban ticket process was regenerated from a
legacy system and enhanced to use an extended colour range and
incorporate component images for the product tickets and move
tickets. Images were dynamically scaled to prevent distortion.

53. EDI Trading Partner Set Up Verification
Utility to verify the set up parameters for Supplier Releasing
and Customer Releasing for EDI transactions.
Home

54. Stocktaking Software
Cellar Management
Licensed Trade Stocktaking

55. Cellar Management
Full cellar management, stock receipts, issues, stock depreciation, value analysis.
Features EIP (edit-in-place) to reduce browse form cyclic data entry.

56. Cellar Management
Stock movements table, stock receipts, issues, stock depreciation, value analysis.
Full cellar management, features EIP (edit-in-place) to reduce browse form cyclic data entry.

57. Licensed Trade Stocktaking
Home

58. General
Apply4Jobz
Active Statistical Process Control
DPM
GPRS GSM 24/7 Alerts
JetForms to XML Conversion

59. EAN 128 Barcode Labels
Application identifiers define data fields in the the symbol. The software
includes a label designer for printing EAN128 barcode labels.

60. EAN 128 Barcode Labels
The software includes a label designer for printing EAN128 barcode
labels derived from application identifiers.

61. Apply4Jobz
If you are looking for a new job or just want a
change then Apply4Jobz will enable you to
organise your job finding process with the
greatest of ease. Apply4Jobz will keep track
of each job application from start to end,
will build your network contacts, and produce
your CVs.
Multi-lingual job application software supporting
eight languages.

62. Apply4Jobz
The customisable dashboard keeps your
progress visible at start up.

63. Active Statistical Process Control
QA application statistically monitors the production of four production lines.
Out of tolerance is displayed in red. The 21” displays on the lines can be
seen from the QA cabin.

64. Active Statistical Process Control
The std deviation for 3000+ items is calculated in Less than 1
second as a graph.

65. DPM
David’s Project Manager, control multiple projects.

66. DPM
Drill down stages, to view cost, and resources.

67. DPM
Full range of reports inclusive tree maps, burnup, burndown maps.

68. GPRS GSM 24/7 Alerts
Add on tool for management of mission critical
networks. SMS messages are sent to network
administrators when there are critical incidents or
failures of :-
Routers
Servers
Database

69. Incident Logging & Help Desk System
Developed to log software and hardware incidents. Resource would be
assigned to each incident. Customers are updated by email/SMS at key
stages in the incident resolution.

70. AEM
AEM is a server side service that monitors application
folders and environments. Any change to files with
named file extensions are emailed to the designated
controller/developer.
The changes are then investigated and remedial action
taken.
This application works well in an Agile/SCRUM
development environment where there are frequent
releases.

71. JetForms to XML Conversion
Windows service that monitors the JetForms folder

72. JetForms to XML Conversion
Windows service that monitors the JetForms folder, converts the jetforms data to XML

73. JetForms to XML Conversion
Windows service that monitors the JetForms folder, converts the jetforms data to XML and outputs a
file to a FormScape project folder, and archives the jetforms file.
Home

74. Legacy System Regeneration
Group Operations Archive
Technical Library
Specifications Library

75. Group Operational Archive
Facilitates:
Full Item, Lot, and Batch Traceability
Labour and Material Cost Retrieval
Process and Operation Narrative
Purchase Order History
Tooling History
Drawing and Tool Cross Reference

76. Group Operations Archive
Legacy system data migration and regeneration. Small subset
of the original application screens and reports regenerated but
with enhanced functionality.

77. Technical Library
Location of aerospace technical literature current and legacy

78. Specifications Library
Location of aerospace specifications current and legacy
Home

79. Touch Screen
Photopass Security System
Shop Floor Data Collection

80. Photopass Security System
Touchscreen Photopass Security System installed at all hangars. Photopass Id Cards are
scanned, validated, and the displayed image is compared to the card holder. Images are
dynamically scaled to prevent distortion. HR control permanent staff and weekend warriors.
This development took four days the driving force being President Obama’s arrival at
London Stansted Airport for the G20 summit meeting. DFT and BAA approved.

81. Shop Floor Data Collection
Configurable SFDC system
….
Clock On and Clock Off
Book-on single/multiple jobs
Book-on non-productive codes.
Automatically books off
previous job(s) when booking
on to next job(s).
Automatically books-off jobs
when clocking off.
Break allowances.
Time apportionment
Auto book on non-productive
codes for specific staff.
Home

82. Sample Development Portfolio
Thank you for taking an interest in my
Project and Development Portfolio.
Home
