1. The document describes the design and simulation of a wireless local area network (WLAN) for an administrative office using the OPNET network simulator. The network consists of 3 subnets connected by a router to an internet service provider.
2. Key performance parameters of the network like delay, throughput, and packet drop were analyzed under normal traffic conditions and with a 50% increase in traffic. Delay and load increased while throughput decreased with higher traffic loads.
3. The simulations showed that increased network traffic led to longer delays, higher loads on access points, and reduced throughput across the three office subnets.
