Enterprise-wide deployments require an architecture that scales horizontally and can work in a geographically distributed environment. The Denodo Platform can scale for a single instance used for departmental projects all the way to enterprise-wide distributed clusters. This webinar will explain how the Denodo Platform can scale to handle the most demanding requirements and will provide examples of some actual deployment configurations. More information and FREE registrations to this webinar: http://goo.gl/ma3U5h To learn more click to this link: http://go.denodo.com/a2a Join the conversation at #Architect2Architect Agenda: Deployment Configurations HA and Clustering Geographically Distributed Configurations Development Configurations

1. Five In-depth Technology and Architecture Sessions
on Data Virtualization
Session 3: Scalability

2. Today’s Speaker
■ Jesus Barrasa
Senior Solutions Architect, Denodo

3. Architect-to-Architect Series
■ Series of five webinars over 3 months
■ Deeper look into Denodo Platform
■ Architectural Overview
■ Performance
■ Scalability (today’s session)
■ Data Discovery and Governance
■ Security

4. Denodo Express
■ Denodo Express
■ Free to Download
■ Fully functioning Data Virtualization Platform
■ Single user, supports common data sources
■ Many of the same capabilities of Denodo
Platform
■ Performance, Data Discovery, Governance,
internal Security, Publishing, …

5. Scalability – Architecture Modules

6. Scalability – HA and Clustering
■ Denodo Cache
■ The Denodo Platform incorporates an advanced
cache system to improve performance
■ For data materialization it makes use of an
external JDBC database (physical or in-memory)
■ Denodo High-Availability
■ Set of features provided by the Denodo Platform
to support High Availability and Load Balancing
■ Denodo Cluster Management
■ Tool for monitoring and managing a cluster of
Denodo servers

7. Scalability – HA and Clustering
■ Singleton
■ High Availability Architecture
■ Active-Passive
■ Active-Active
■ Vertical Scalability
■ VM Support
■ Metadata Sharing
■ Horizontal Scalability
■ Clustering
■ Shared Cache or Individual Cache

8. • A single Data Virtualization server instance
…
Data sources
LDAP Auth
Cache Database
Client Application
ESB/BPM/Portal…
Singleton

9. …
Data sources
LDAP Auth
Cache Database
Client Application
ESB/BPM/Portal…
HA – Active-Passive
Load Balancer

10. HA – Active-Passive
■ All queries sent to Active server
■ Passive server running, but not handling
requests
■ Both servers ‘pinged’ by Load Balancer with
appliance health check or using ping script
■ When Load Balancer detects Active server
failure
■ Requests redirected to Passive server
■ Passive server becomes ‘Active’
■ When former Active server restored
■ Load Balancer determines new roles…

11. …
Data sources
LDAP Auth
Cache Database
Client Application
ESB/BPM/Portal…
HA – Active-Active
Load Balancer

12. HA – Active-Active
■ Load Balancer distributes queries between
both servers
■ Both servers running and handling requests
■ Both servers ‘pinged’ by Load Balancer with
appliance health check or using ping script
■ When Load Balancer detects server failure
■ All requests redirected to other server
■ When ‘failed’ server restored
■ Added back to load balancing pool
■ Starts receiving queries

13. Vertical Scaling
■ Java limitations inhibit vertical scaling for singletons
■ Virtualization
■ Run Denodo Platform instances in VM
■ VMWare, Hyper-V, Xen, …
■ Very common scenario
■ Multiple Instances
■ Install multiple instances of Denodo Platform
■ Run multiple instances of Denodo Platform from a single
Denodo Platform installation
■ Share metadata and cache

14. Vertical Scaling (Cont’d)
Cache DatabaseMetadata
Master
Slave-1
Slave-2
Slave-3

15. Vertical Scaling (Cont’d)
■ First started instance is ‘master’
■ All others are ‘slaves’
■ Only ‘master’ instance can modify metadata
■ Slaves read metadata at startup time
■ Pros
■ Only one copy of metadata
■ Cons
■ Port configurations need modifying
■ SPoF

16. Horizontal Scaling – Clustering
Load Balancer
…
Datasources
Virtual Server
VDP Cluster: 192.168.0.10:9999
Web Container Cluster: 192.168.0.10:9090
VDP Cluster:
• Denodo1:9999
• Denodo2:9999
• Denodo3:9999
• Denodo4:9999
• Denodo5:9999
Web Cont. Cluster:
• Denodo1:9090
• Denodo2:9090
• Denodo3:9090
• Denodo4:9090
• Denodo5:9090

17. Clustering – Shared Cache
Load Balancer
Virtual Server
VDP Cluster: 192.168.0.10:9999
Web Container Cluster: 192.168.0.10:9090
VDP Cluster:
• Denodo1:9999
• Denodo2:9999
• Denodo3:9999
• Denodo4:9999
• Denodo5:9999
Web Cont. Cluster:
• Denodo1:9090
• Denodo2:9090
• Denodo3:9090
• Denodo4:9090
• Denodo5:9090
Cache Database

18. Clustering – Separate Caches
Load Balancer
Virtual Server
VDP Cluster: 192.168.0.10:9999
Web Container Cluster: 192.168.0.10:9090
VDP Cluster:
• Denodo1:9999
• Denodo2:9999
• Denodo3:9999
• Denodo4:9999
• Denodo5:9999
Web Cont. Cluster:
• Denodo1:9090
• Denodo2:9090
• Denodo3:9090
• Denodo4:9090
• Denodo5:9090
Cache Database
Cache Database
Cache Database
Cache Database
Cache Database

19. Clustering - Caches
■ Shared Cache
■ Any server can populate cache
■ All servers can access cached data
■ Increased ‘hit ratio’
■ Cache can become performance bottleneck
■ Separate Caches
■ Each server has its own cache
■ Avoids potential performance bottleneck
■ Access only data it has cached
■ Removes SPoF

20. Distributed Environments
■ Local caches help to achieve performance goals when
servers are in geographically dispersed locations
New York City
Omaha
San Francisco
Houston

21. Distributed Environments (Cont’d)
■ A remote Denodo server can be viewed as a
data source to another server
■ Promotes multi-layered architecture
■ Queries can be delegated to remote servers
to reduce network data movement
■ Same query delegation mechanism as talked
about in last session

22. Distributed Environments (Cont’d)
■ Remote query delegation…
Local Data Sources
Cache Cache
Local Data Sources
New York City HoustonClient
10 M
rows
5 M
rows
JOIN Result:
20,000 rows
JOIN Result:
2,500 rows
2 M
rows

23. Distributed Environments (Cont’d)
■ Shared views…
Local Data Sources
Cache Cache
Local Data Sources
New York City HoustonClient
10 M
rows
5 M
rows
JOIN Result:
20,000 rows
JOIN Result:
2,500 rows
2 M
rows
New York City Houston

24. Disaster Recovery
■ Business Continuity policies usually require
that critical IT systems are backed up to a
DR center
■ Denodo supports scripted synchronization of
metadata with DR systems
■ Using Export and Import tools
■ Sync up can be scheduled (time-based) or on
an event (promotion to production)

25. Scalability - Summary
■ Denodo Platform scales from single
instance to geographically distributed
system
■ Grow system without reconfiguring
■ Supports HA configurations
■ Active-Passive, Active-Active
■ Vertical scalability options
■ Support for DR site synchronization

26. Q&A

27. Data Virtualization – Next Steps
Move forward at your own pace
 Download Denodo Express –
The fastest way to Data Virtualization
 Denodo Community: Documents, Videos, Tutorials, and more.
 Attend Architect-to-Architect Series
 Performance
 Scalability
Move forward with one of our Data
Virtualization experts
 Phone: (+1) 877-556-2531 (NA)
 Phone: (+44) (0)20 7869 8053 (EMEA)
 Email: info@denodo.com | www.denodo.com
 Data Discovery and Governance
 Security

28. Five In-depth Technology and Architecture Sessions
on Data Virtualization
Thank You!
Next Session
Session 4
Denodo Platform: Data Discovery
and Governance
