1. Data Market: Developer Exercises
Aitor Magán (UPM)
amagan@fi.upm.es
@AitorMagan

2. Outline
2
• DM-DEV-1: Deploy a Virtual Machine
• DM-DEV-2: Install CKAN
• DM-DEV-3: Install CKAN OAuth2 Plugin
• DM-DEV-4: Install CKAN Private Datasets
Plugin
• DM-DEV-5: Install Wstore
• DM-DEV-6: Install CKAN Store Publisher
Plugin

3. DM-DEV-1. Deploy a Virtual Machine
• Prerequisites
– A FIWARE Lab account
• Steps
– Select Ubuntu 12.04 Server x86_64
– Create a different Security Group
• Ports:
– 8080: It will be used for CKAN
– 8282: It will be used for the Store
• Hints:
– Do not forget creating a key pair
– Assign a public IP address to your machine
Easy

4. DM-DEV-2. Install CKAN
• Prerequisites
– A FIWARE Lab account
– A virtual machine
• Steps:
– Follow this instructions:
http://docs.ckan.org/en/latest/maintaining/installing/ins
tall-from-package.html
– Install the version 2.2
– DataStore and FileStore are required (not optional) in
this case
– Install also the Data Pusher extension
– Disable NGINX startup:
• sudo update-rc.d -f nginx disable
– Check that CKAN is running on YOUR_IP:8080
Medium

5. DM-DEV-3. Install CKAN OAuth2 Plugin
• Prerequisites
– A FIWARE Lab account
– DM-DEV-2
• Steps:
– Follow these instructions:
https://github.com/conwetlab/ckanext-oauth2/wiki/Activating-
and-Installing
• Hint:
– You need to create an application in the Account Portal
– Make OAuth2 works on HTTP
• Edit /etc/apache2/envvars
• Add export OAUTHLIB_INSECURE_TRANSPORT=True
– Activate virtualenv:
• . /usr/lib/ckan/default/bin/activate
Easy

6. DM-DEV-4. Install CKAN Private Datasets Plugin
• Prerequisites
– A FIWARE Lab account
– DM-DEV-2
• Steps:
– Follow these instructions:
https://github.com/conwetlab/ckanext-oauth2
• Hint:
– Use the FIWARE Notification Parser
– Do not secure the notification callback
– Install directory:
• /usr/lib/ckan/default/src/ckan/ckanext
Easy

7. DM-DEV-5. Install Wstore (1)
• Prerequisites
– A FIWARE Lab account
– DM-DEV-1
• Steps:
– Download the file from
https://forge.fiware.org/frs/download.php/1596/APPS-
Store-WStore-4.1.0.zip
– Follow the instructions form:
https://github.com/conwetlab/wstore
– Check that the Store is running in YOUR_IP:8282
– Add a Repo
• Administration > Repositories > Add
– Name: DevelopersWeek
– URL: http://130.206.85.51:8080/Repository-RI-3.2.2/v1
Medium

8. DM-DEV-5. Install Wstore (2)
• Hints
– You should use the port 8282. ¡BE CAREFUL!
• /etc/apache2/ports.conf needs to be modified to include the port
• This is only because you’re installing the two platforms in the
same machine
– You should register another application in the IdM
– Read the instructions carefully
– IdM end point: https://account.lab.fiware.org
Medium

9. DM-DEV-6. Install CKAN Store Publisher Plugin
• Prerequisites
– A FIWARE Lab account
– DM-DEV-2
• Steps:
– Follow these instructions:
https://github.com/conwetlab/ckanext-storepublisher
• Hint:
– Store URL: YOUR_IP:8282
– Repository: DevelopersWeek
• Or the name you chose when the Repository was added in th
– Install directory:
• /usr/lib/ckan/default/src/ckan/ckanext
Easy

10. Thanks!Thanks!
