A design method for PID controllers based on internal model control (IMC) principles, direct synthesis method (DS), stability analysis (SA) method for pure integrating process with time delay is proposed. Analytical expressions for PID controllers are derived for several common types of process models, including first order and second-order plus time delay models and an integrator plus time delay model. Here in this paper, a simple controller design rule and tuning procedure for unstable processes with delay time is discussed. Simulation examples are included to show the effectiveness of the proposed method
DESIGN OF PID CONTROLLERS INTEGRATOR SYSTEM WITH TIME DELAY AND DOUBLE INTEGR...ijics
In this paper first we investigate optimal PID control of a double integrating plus delay process and compare with the SIMC rules. What makes the double integrating process special is that derivative action is actually necessary for stabilization. In control, there is generally a trade-off between performance and
robustness, so there does not exist a single optimal controller. However, for a given robustness level (here defined in terms of the Ms-value) we can find the optimal controller which minimizes the performance J (here defined as the integrated absolute error (IAE)-value for disturbances). Interestingly, the SIMC PID controller is almost identical to the optimal pid controller. This can be seen by comparing the paretooptimal
curve for J as a function of Ms, with the curve found by varying the SIMC tuning parameter Tc.
Second, design of Proportional Integral and Derivative (PID) controllers based on internal model control (IMC) principles, direct synthesis method (DS), stability analysis (SA) method for pure integrating process with time delay is proposed. The performances of the proposed controllers are compared with the
controllers designed by recently reported methods. The robustness of the proposed controllers for the uncertainty in model parameters is evaluated considering one parameter at a time using Kharitonov’s theorem. The proposed controllers are applied to various transfer function models and to non linear model of isothermal continuous copolymerization of styrene-acrylonitrile in CSTR. An experimental set up of tank
with the outlet connected to a pump is considered for implementation of the PID controllers designed by
the three proposed methods to show the effectiveness of the methods.
Disturbance Rejection with a Highly Oscillating Second-Order Process, Part I...Scientific Review SR
This research paper aims at investigating disturbance rejection associated with a highly oscillating
second-order process. The PD-PI controller having three parameters are tuned to provide efficient rejection of a
step input disturbance input. Controller tuning based on using MATLAB control and optimization toolboxes.
Using the suggested tuning technique, it is possible to reduce the maximum time response of the closed loop
control system to as low as 0.0095 and obtain time response to the disturbance input having zero settling time.
The effect of the proportional gain of the PD-PI controller on the control system dynamics is investigated for a
gain ≤ 100. The performance of the control system during disturbance rejection using the PD -PI controller is
compared with that using a second-order compensator. The PD-PI controller is superior in dealing with the
disturbance rejection associated with the highly oscillating second-order process
Tuning of PID controllers for integrating systems using direct synthesis methodISA Interchange
A PID controller is designed for various forms of integrating systems with time delay using direct synthesis method. The method is based on comparing the characteristic equation of the integrating system and PID controller with a filter with the desired characteristic equation. The desired characteristic equation comprises of multiple poles which are placed at the same desired location. The tuning parameter is adjusted so as to achieve the desired robustness. Tuning rules in terms of process parameters are given for various forms of integrating systems. The tuning parameter can be selected for the desired robustness by specifying Ms value. The proposed controller design method is applied to various transfer function models and to the nonlinear model equations of jacketed CSTR to show its effectiveness and applicability.
Optimised control using Proportional-Integral-Derivative controller tuned usi...IJECEIAES
Time delays are generally unavoidable in the designing frameworks for mechanical and electrical systems and so on. In both continuous and discrete schemes, the existence of delay creates undesirable impacts on the underthought which forces exacting constraints on attainable execution. The presence of delay confounds the design structure procedure also. It makes continuous systems boundless dimensional and also extends the readings in discrete systems fundamentally. As the Proportional-IntegralDerivative (PID) controller based on internal model control is essential and strong to address the vulnerabilities and aggravations of the model. But for an real industry process, they are less susceptible to noise than the PID controller.It results in just one tuning parameter which is the time constant of the closed-loop system λ, the internal model control filter factor. It additionally gives a decent answer for the procedure with huge time delays. The design of the PID controller based on the internal model control, with approximation of time delay using Pade’ and Taylor’s series is depicted in this paper. The first order filter used in the design provides good set-point tracking along with disturbance rejection.
DESIGN OF PID CONTROLLERS INTEGRATOR SYSTEM WITH TIME DELAY AND DOUBLE INTEGR...ijics
In this paper first we investigate optimal PID control of a double integrating plus delay process and compare with the SIMC rules. What makes the double integrating process special is that derivative action is actually necessary for stabilization. In control, there is generally a trade-off between performance and
robustness, so there does not exist a single optimal controller. However, for a given robustness level (here defined in terms of the Ms-value) we can find the optimal controller which minimizes the performance J (here defined as the integrated absolute error (IAE)-value for disturbances). Interestingly, the SIMC PID controller is almost identical to the optimal pid controller. This can be seen by comparing the paretooptimal
curve for J as a function of Ms, with the curve found by varying the SIMC tuning parameter Tc.
Second, design of Proportional Integral and Derivative (PID) controllers based on internal model control (IMC) principles, direct synthesis method (DS), stability analysis (SA) method for pure integrating process with time delay is proposed. The performances of the proposed controllers are compared with the
controllers designed by recently reported methods. The robustness of the proposed controllers for the uncertainty in model parameters is evaluated considering one parameter at a time using Kharitonov’s theorem. The proposed controllers are applied to various transfer function models and to non linear model of isothermal continuous copolymerization of styrene-acrylonitrile in CSTR. An experimental set up of tank
with the outlet connected to a pump is considered for implementation of the PID controllers designed by
the three proposed methods to show the effectiveness of the methods.
Disturbance Rejection with a Highly Oscillating Second-Order Process, Part I...Scientific Review SR
This research paper aims at investigating disturbance rejection associated with a highly oscillating
second-order process. The PD-PI controller having three parameters are tuned to provide efficient rejection of a
step input disturbance input. Controller tuning based on using MATLAB control and optimization toolboxes.
Using the suggested tuning technique, it is possible to reduce the maximum time response of the closed loop
control system to as low as 0.0095 and obtain time response to the disturbance input having zero settling time.
The effect of the proportional gain of the PD-PI controller on the control system dynamics is investigated for a
gain ≤ 100. The performance of the control system during disturbance rejection using the PD -PI controller is
compared with that using a second-order compensator. The PD-PI controller is superior in dealing with the
disturbance rejection associated with the highly oscillating second-order process
Tuning of PID controllers for integrating systems using direct synthesis methodISA Interchange
A PID controller is designed for various forms of integrating systems with time delay using direct synthesis method. The method is based on comparing the characteristic equation of the integrating system and PID controller with a filter with the desired characteristic equation. The desired characteristic equation comprises of multiple poles which are placed at the same desired location. The tuning parameter is adjusted so as to achieve the desired robustness. Tuning rules in terms of process parameters are given for various forms of integrating systems. The tuning parameter can be selected for the desired robustness by specifying Ms value. The proposed controller design method is applied to various transfer function models and to the nonlinear model equations of jacketed CSTR to show its effectiveness and applicability.
Optimised control using Proportional-Integral-Derivative controller tuned usi...IJECEIAES
Time delays are generally unavoidable in the designing frameworks for mechanical and electrical systems and so on. In both continuous and discrete schemes, the existence of delay creates undesirable impacts on the underthought which forces exacting constraints on attainable execution. The presence of delay confounds the design structure procedure also. It makes continuous systems boundless dimensional and also extends the readings in discrete systems fundamentally. As the Proportional-IntegralDerivative (PID) controller based on internal model control is essential and strong to address the vulnerabilities and aggravations of the model. But for an real industry process, they are less susceptible to noise than the PID controller.It results in just one tuning parameter which is the time constant of the closed-loop system λ, the internal model control filter factor. It additionally gives a decent answer for the procedure with huge time delays. The design of the PID controller based on the internal model control, with approximation of time delay using Pade’ and Taylor’s series is depicted in this paper. The first order filter used in the design provides good set-point tracking along with disturbance rejection.
FRACTIONAL ORDER PID CONTROLLER TUNING BASED ON IMC IJITCA Journal
In this work, a class of fractional order controller (FOPID) is tuned based on internal model control
(IMC). This tuning rule has been obtained without any approximation of time delay. Moreover to show
usefulness of fractional order controller in comparison with classical integer order controllers, an
industrial PID controller tuned in a similar way, is compared with FOPID and then robust stability of both
controllers is investigated. Robust stability analysis has been done to find maximum delayed time
uncertainty interval which results in a stable closed loop control system. For a typical system, robust
stability has been done to find maximum time constant uncertainty interval of system. Two clarify the
proposed control system design procedure, three examples have been given.
Experimental evaluation of control performance of MPC as a regulatory controllerISA Interchange
Proportional integral derivative (PID) control is widely practiced as the base layer controller in the industry due to its robustness and design simplicity. However, a supervisory control layer over the base layer, namely a model predictive controller (MPC), is becoming increasingly popular with the advent of computer process control. The use of a supervisory layer has led to different control structures. In this study, we perform an objective investigation of several commonly used control structures such as “Cascaded PI controller,” “DMC cascaded to PI” and “Direct DMC.” Performance of these control structures are compared on a pilot-scale continuous stirred tank heater (CSTH) system. We used dynamic matrix control (DMC) algorithm as a representative of MPC. In the DMC cascaded to PI structure, the flow-loops are regulated by the PI controller. On top of that a DMC manipulates the set-points of the flow-loops to control the temperature and the level of water in the tank. The “Direct DMC” structure, as its name suggests, uses DMC to manipulate the valves directly. Performance of all control structures were evaluated based on the integrated squared error (ISE) values. In this empirical study, the “Direct DMC” structure showed a promise to act as regulatory controller. The selection of control frequency is critical for this structure. The effect of control frequency on controller performance of the “Direct DMC” structure was also studied.
Modified smith predictor based cascade control of unstable time delay processesISA Interchange
An improved cascade control structure with a modified Smith predictor is proposed for controlling open-loop unstable time delay processes. The proposed structure has three controllers of which one is meant for servo response and the other two are for regulatory responses. An analytical design method is derived for the two disturbance rejection controllers by proposing the desired closed-loop complementary sensitivity functions. These two closed-loop controllers are considered in the form of proportional–integral-derivative (PID) controller cascaded with a second order lead/lag filter. The direct synthesis method is used to design the setpoint tracking controller. By virtue of the enhanced structure, the proposed control scheme decouples the servo response from the regulatory response in case of nominal systems i.e., the setpoint tracking controller and the disturbance rejection controller can be tuned independently. Internal stability of the proposed cascade structure is analyzed. Kharitonov’s theorem is used for the robustness analysis. The disturbance rejection capability of the proposed scheme is superior as compared to existing methods. Examples are also included to illustrate the simplicity and usefulness of the proposed method.
On the fragility of fractional-order PID controllers for FOPDT processesISA Interchange
This paper analyzes the fragility issue of fractional-order proportional-integral-derivative controllers applied to integer first-order plus-dead-time processes. In particular, the effects of the variations of the controller parameters on the achieved control system robustness and performance are investigated. Results show that this kind of controllers is more fragile with respect to the standard proportional-integral-derivative controllers and therefore a significant attention should be paid by the user in their tuning.
The problem of controlling an unstable delayed double integrating process with fractional delay using a
feed forward first-order lag-lead compensator is studied. The effect of time delay of the process in a range between
0.1 and 0.9 seconds is considered. The compensator is tuned using MATLAB optimization toolbox with five forms
of the objective function in terms of the error between the step time response of the closed-loop control system and
the response steady-state value. Using the proposed compensator with the fractional delayed double integrating
process indicates the robustness of the compensator in the time delay range used with superior time-based
specifications compared with other technique based on PID controller.
Keywords — Delayed double integrating process with fractional delay, Feed forward lag-lead first-order
compensator, compensator tuning, MATLAB optimization toolbox, Control system performance.
Tuning of IMC-based PID controllers for integrating systems with time delayISA Interchange
Design of Proportional Integral and Derivative (PID) controllers based on IMC principles for various types of integrating systems with time delay is proposed. PID parameters are given in terms of process model parameters and a tuning parameter. The tuning parameter is IMC filter time constant. In the present work, the IMC filter (Q) is chosen in such a manner that the order of the denominator of IMC controller is one less than the order of the numerator. The IMC filter time constant (λ) is tuned in such a way that a good compromise is made between performance and robustness for both servo and regulatory problems. To improve servo response of the controller a set point filter is designed such that the closed loop response is similar to that of first order plus time delay system. The proposed controller design method is applied to various transfer function models and to the non-linear model equations of jacketed CSTR to demonstrate its applicability and effectiveness. The performance of the proposed controller is compared with the recently reported methods in terms of IAE and ITAE. The smooth functioning of the controller is determined in terms of total variation and compared with recently reported methods. Simulation studies are carried out on various integrating systems with time delay to show the effectiveness and superiority of the proposed controllers.
Design of a model reference adaptive PID control algorithm for a tank system IJECEIAES
This paper describes the design of an adaptive controller based on model reference adaptive PID control (MRAPIDC) to stabilize a two-tank process when large variations of parameters and external disturbances affect the closed-loop system. To achieve that, an innovative structure of the adaptive PID controller is defined, an additional PI is designed to make sure that the reference model produces stable output signals and three adaptive gains are included to guarantee stability and robustness of the closed-loop system. Then, the performance of the model reference adaptive PID controller on the behaviour of the closed-loop system is compared to a PI controller designed on MATLAB when both closed-loop systems are under various conditions. The results demonstrate that the MRAPIDC performs significantly better than the conventional PI controller.
Closed-loop step response for tuning PID fractional-order filter controllersISA Interchange
Analytical methods are usually applied for tuning fractional controllers. The present paper proposes an empirical method for tuning a new type of fractional controller known as PID-Fractional-Order-Filter (FOF-PID). Indeed, the setpoint overshoot method, initially introduced by Shamsuzzoha and Skogestad, has been adapted for tuning FOF-PID controller. Based on simulations for a range of first order with time delay processes, correlations have been derived to obtain PID-FOF controller parameters similar to those obtained by the Internal Model Control (IMC) tuning rule. The setpoint overshoot method requires only one closed-loop step response experiment using a proportional controller (P-controller). To highlight the potential of this method, simulation results have been compared with those obtained with the IMC method as well as other pertinent techniques. Various case studies have also been considered. The comparison has revealed that the proposed tuning method performs as good as the IMC. Moreover, it might offer a number of advantages over the IMC tuning rule. For instance, the parameters of the frac- tional controller are directly obtained from the setpoint closed-loop response data without the need of any model of the plant to be controlled.
Comparison Analysis of Model Predictive Controller with Classical PID Control...ijeei-iaes
pH control plays a important role in any chemical plant and process industries. For the past four decades the classical PID controller has been occupied by the industries. Due to the faster computing technology in the industry demands a tighter advanced control strategy. To fulfill the needs and requirements Model Predictive Control (MPC) is the best among all the advanced control algorithms available in the present scenario. The study and analysis has been done for First Order plus Delay Time (FOPDT) model controlled by Proportional Integral Derivative (PID) and MPC using the Matlab software. This paper explores the capability of the MPC strategy, analyze and compare the control effects with conventional control strategy in pH control. A comparison results between the PID and MPC is plotted using the software. The results clearly show that MPC provide better performance than the classical controller.
Distributed Control System Applied in Temperatur Control by Coordinating Mult...TELKOMNIKA JOURNAL
In Distributed Control System (DCS), multitasking management has been important issues
continuously researched and developed. In this paper, DCS was applied in global temperature control
system by coordinating three Local Control Units (LCUs). To design LCU’s controller parameters, both
analytical and experimental method were employed. In analytical method, the plants were firstly identified
to get their transfer functions which were then used to derive control parameters based on desired
response qualities. The experimental method (Ziegler-Nichols) was also applied due to practicable reason
in real industrial plant (less mathematical analysis). To manage set-points distributed to all LCUs, master
controller was subsequently designed based on zone of both error and set-point of global temperature
controller. Confirmation experiments showed that when using control parameters from analytical method,
the global temperature response could successfully follow the distributed set-points with 0% overshoot,
193.92 second rise time, and 266.88 second settling time. While using control parameters from
experimental method, it could also follow the distributed set-points with presence of overshoot (16.9%), but
has less rise time and settling time (111.36 and 138.72 second). In this research, the overshoot could be
successfully decreased from 16.9 to 9.39 % by changing master control rule. This proposed method can
be potentially applied in real industrial plant due to its simplicity in master control algorithm and presence
of PID controller which has been generally included in today industrial equipments.
A novel auto-tuning method for fractional order PID controllersISA Interchange
Fractional order PID controllers benefit from an increasing amount of interest from the research community due to their proven advantages. The classical tuning approach for these controllers is based on specifying a certain gain crossover frequency, a phase margin and a robustness to gain variations. To tune the fractional order controllers, the modulus, phase and phase slope of the process at the imposed gain crossover frequency are required. Usually these values are obtained from a mathematical model of the process, e.g. a transfer function. In the absence of such model, an auto-tuning method that is able to estimate these values is a valuable alternative. Auto-tuning methods are among the least discussed design methods for fractional order PID controllers. This paper proposes a novel approach for the auto-tuning of fractional order controllers. The method is based on a simple experiment that is able to determine the modulus, phase and phase slope of the process required in the computation of the controller parameters. The proposed design technique is simple and efficient in ensuring the robustness of the closed loop system. Several simulation examples are presented, including the control of processes exhibiting integer and fractional order dynamics.
DESIGN OF PID CONTROLLERS INTEGRATOR SYSTEM WITH TIME DELAY AND DOUBLE INTEGR...ijcisjournal
In this paper first we investigate optimal PID control of a double integrating plus delay process and compare with the SIMC rules. What makes the double integrating process special is that derivative action is actually necessary for stabilization. In control, there is generally a trade-off between performance and robustness, so there does not exist a single optimal controller. However, for a given robustness level (here defined in terms of the Ms-value) we can find the optimal controller which minimizes the performance J (here defined as the integrated absolute error (IAE)-value for disturbances). Interestingly, the SIMC PID controller is almost identical to the optimal pid controller. This can be seen by comparing the paretooptimal curve for J as a function of Ms, with the curve found by varying the SIMC tuning parameter Tc. Second, design of Proportional Integral and Derivative (PID) controllers based on internal model control (IMC) principles, direct synthesis method (DS), stability analysis (SA) method for pure integrating process with time delay is proposed. The performances of the proposed controllers are compared with the
controllers designed by recently reported methods. The robustness of the proposed controllers for the uncertainty in model parameters is evaluated considering one parameter at a time using Kharitonov’s theorem. The proposed controllers are applied to various transfer function models and to non linear model of isothermal continuous copolymerization of styrene-acrylonitrile in CSTR. An experimental set up of tank with the outlet connected to a pump is considered for implementation of the PID controllers designed by the three proposed methods to show the effectiveness of the methods.
A simple nonlinear PD controller for integrating processesISA Interchange
Many industrial processes are found to be integrating in nature, for which widely used Ziegler–Nichols tuned PID controllers usually fail to provide satisfactory performance due to excessive overshoot with large settling time. Although, IMC (Internal Model Control) based PID controllers are capable to reduce the overshoot, but little improvement is found in the load disturbance response. Here, we propose an auto-tuning proportional-derivative controller (APD) where a nonlinear gain updating factor α continuously adjusts the proportional and derivative gains to achieve an overall improved performance during set point change as well as load disturbance. The value of α is obtained by a simple relation based on the instantaneous values of normalized error (eN) and change of error (ΔeN) of the controlled variable. Performance of the proposed nonlinear PD controller (APD) is tested and compared with other PD and PID tuning rules for pure integrating plus delay (IPD) and first-order integrating plus delay (FOIPD) processes. Effectiveness of the proposed scheme is verified on a laboratory scale servo position control system.
Design of a new PID controller using predictive functional control optimizati...ISA Interchange
An improved proportional integral derivative (PID) controller based on predictive functional control (PFC) is proposed and tested on the chamber pressure in an industrial coke furnace. The proposed design is motivated by the fact that PID controllers for industrial processes with time delay may not achieve the desired control performance because of the unavoidable model/plant mismatches, while model predictive control (MPC) is suitable for such situations. In this paper, PID control and PFC algorithm are combined to form a new PID controller that has the basic characteristic of PFC algorithm and at the same time, the simple structure of traditional PID controller. The proposed controller was tested in terms of set-point tracking and disturbance rejection, where the obtained results showed that the proposed controller had the better ensemble performance compared with traditional PID controllers.
COMPARATIVE ANALYSIS OF CONVENTIONAL PID CONTROLLER AND FUZZY CONTROLLER WIT...IJITCA Journal
All the real systems exhibits non-linear nature,conventional controllers are not always able to provide good and accurate results. Fuzzy Logic Control is used to obtain better response. A model for simulation is designed and all the assumptions are made before the development of the model. An attempt has been made to analyze the efficiency of a fuzzy controller over a conventional PID controller for a three tank level control system using fuzzification & defuzzification methods and their responses are compared. Analysis is done through computer simulation using Matlab/Simulink toolbox. This study shows that the application of Fuzzy Logic Controller (FLC) gives the best response with triangular membership function and centroid defuzzification method.
FRACTIONAL ORDER PID CONTROLLER TUNING BASED ON IMC IJITCA Journal
In this work, a class of fractional order controller (FOPID) is tuned based on internal model control
(IMC). This tuning rule has been obtained without any approximation of time delay. Moreover to show
usefulness of fractional order controller in comparison with classical integer order controllers, an
industrial PID controller tuned in a similar way, is compared with FOPID and then robust stability of both
controllers is investigated. Robust stability analysis has been done to find maximum delayed time
uncertainty interval which results in a stable closed loop control system. For a typical system, robust
stability has been done to find maximum time constant uncertainty interval of system. Two clarify the
proposed control system design procedure, three examples have been given.
Experimental evaluation of control performance of MPC as a regulatory controllerISA Interchange
Proportional integral derivative (PID) control is widely practiced as the base layer controller in the industry due to its robustness and design simplicity. However, a supervisory control layer over the base layer, namely a model predictive controller (MPC), is becoming increasingly popular with the advent of computer process control. The use of a supervisory layer has led to different control structures. In this study, we perform an objective investigation of several commonly used control structures such as “Cascaded PI controller,” “DMC cascaded to PI” and “Direct DMC.” Performance of these control structures are compared on a pilot-scale continuous stirred tank heater (CSTH) system. We used dynamic matrix control (DMC) algorithm as a representative of MPC. In the DMC cascaded to PI structure, the flow-loops are regulated by the PI controller. On top of that a DMC manipulates the set-points of the flow-loops to control the temperature and the level of water in the tank. The “Direct DMC” structure, as its name suggests, uses DMC to manipulate the valves directly. Performance of all control structures were evaluated based on the integrated squared error (ISE) values. In this empirical study, the “Direct DMC” structure showed a promise to act as regulatory controller. The selection of control frequency is critical for this structure. The effect of control frequency on controller performance of the “Direct DMC” structure was also studied.
Modified smith predictor based cascade control of unstable time delay processesISA Interchange
An improved cascade control structure with a modified Smith predictor is proposed for controlling open-loop unstable time delay processes. The proposed structure has three controllers of which one is meant for servo response and the other two are for regulatory responses. An analytical design method is derived for the two disturbance rejection controllers by proposing the desired closed-loop complementary sensitivity functions. These two closed-loop controllers are considered in the form of proportional–integral-derivative (PID) controller cascaded with a second order lead/lag filter. The direct synthesis method is used to design the setpoint tracking controller. By virtue of the enhanced structure, the proposed control scheme decouples the servo response from the regulatory response in case of nominal systems i.e., the setpoint tracking controller and the disturbance rejection controller can be tuned independently. Internal stability of the proposed cascade structure is analyzed. Kharitonov’s theorem is used for the robustness analysis. The disturbance rejection capability of the proposed scheme is superior as compared to existing methods. Examples are also included to illustrate the simplicity and usefulness of the proposed method.
On the fragility of fractional-order PID controllers for FOPDT processesISA Interchange
This paper analyzes the fragility issue of fractional-order proportional-integral-derivative controllers applied to integer first-order plus-dead-time processes. In particular, the effects of the variations of the controller parameters on the achieved control system robustness and performance are investigated. Results show that this kind of controllers is more fragile with respect to the standard proportional-integral-derivative controllers and therefore a significant attention should be paid by the user in their tuning.
The problem of controlling an unstable delayed double integrating process with fractional delay using a
feed forward first-order lag-lead compensator is studied. The effect of time delay of the process in a range between
0.1 and 0.9 seconds is considered. The compensator is tuned using MATLAB optimization toolbox with five forms
of the objective function in terms of the error between the step time response of the closed-loop control system and
the response steady-state value. Using the proposed compensator with the fractional delayed double integrating
process indicates the robustness of the compensator in the time delay range used with superior time-based
specifications compared with other technique based on PID controller.
Keywords — Delayed double integrating process with fractional delay, Feed forward lag-lead first-order
compensator, compensator tuning, MATLAB optimization toolbox, Control system performance.
Tuning of IMC-based PID controllers for integrating systems with time delayISA Interchange
Design of Proportional Integral and Derivative (PID) controllers based on IMC principles for various types of integrating systems with time delay is proposed. PID parameters are given in terms of process model parameters and a tuning parameter. The tuning parameter is IMC filter time constant. In the present work, the IMC filter (Q) is chosen in such a manner that the order of the denominator of IMC controller is one less than the order of the numerator. The IMC filter time constant (λ) is tuned in such a way that a good compromise is made between performance and robustness for both servo and regulatory problems. To improve servo response of the controller a set point filter is designed such that the closed loop response is similar to that of first order plus time delay system. The proposed controller design method is applied to various transfer function models and to the non-linear model equations of jacketed CSTR to demonstrate its applicability and effectiveness. The performance of the proposed controller is compared with the recently reported methods in terms of IAE and ITAE. The smooth functioning of the controller is determined in terms of total variation and compared with recently reported methods. Simulation studies are carried out on various integrating systems with time delay to show the effectiveness and superiority of the proposed controllers.
Design of a model reference adaptive PID control algorithm for a tank system IJECEIAES
This paper describes the design of an adaptive controller based on model reference adaptive PID control (MRAPIDC) to stabilize a two-tank process when large variations of parameters and external disturbances affect the closed-loop system. To achieve that, an innovative structure of the adaptive PID controller is defined, an additional PI is designed to make sure that the reference model produces stable output signals and three adaptive gains are included to guarantee stability and robustness of the closed-loop system. Then, the performance of the model reference adaptive PID controller on the behaviour of the closed-loop system is compared to a PI controller designed on MATLAB when both closed-loop systems are under various conditions. The results demonstrate that the MRAPIDC performs significantly better than the conventional PI controller.
Closed-loop step response for tuning PID fractional-order filter controllersISA Interchange
Analytical methods are usually applied for tuning fractional controllers. The present paper proposes an empirical method for tuning a new type of fractional controller known as PID-Fractional-Order-Filter (FOF-PID). Indeed, the setpoint overshoot method, initially introduced by Shamsuzzoha and Skogestad, has been adapted for tuning FOF-PID controller. Based on simulations for a range of first order with time delay processes, correlations have been derived to obtain PID-FOF controller parameters similar to those obtained by the Internal Model Control (IMC) tuning rule. The setpoint overshoot method requires only one closed-loop step response experiment using a proportional controller (P-controller). To highlight the potential of this method, simulation results have been compared with those obtained with the IMC method as well as other pertinent techniques. Various case studies have also been considered. The comparison has revealed that the proposed tuning method performs as good as the IMC. Moreover, it might offer a number of advantages over the IMC tuning rule. For instance, the parameters of the frac- tional controller are directly obtained from the setpoint closed-loop response data without the need of any model of the plant to be controlled.
Comparison Analysis of Model Predictive Controller with Classical PID Control...ijeei-iaes
pH control plays a important role in any chemical plant and process industries. For the past four decades the classical PID controller has been occupied by the industries. Due to the faster computing technology in the industry demands a tighter advanced control strategy. To fulfill the needs and requirements Model Predictive Control (MPC) is the best among all the advanced control algorithms available in the present scenario. The study and analysis has been done for First Order plus Delay Time (FOPDT) model controlled by Proportional Integral Derivative (PID) and MPC using the Matlab software. This paper explores the capability of the MPC strategy, analyze and compare the control effects with conventional control strategy in pH control. A comparison results between the PID and MPC is plotted using the software. The results clearly show that MPC provide better performance than the classical controller.
Distributed Control System Applied in Temperatur Control by Coordinating Mult...TELKOMNIKA JOURNAL
In Distributed Control System (DCS), multitasking management has been important issues
continuously researched and developed. In this paper, DCS was applied in global temperature control
system by coordinating three Local Control Units (LCUs). To design LCU’s controller parameters, both
analytical and experimental method were employed. In analytical method, the plants were firstly identified
to get their transfer functions which were then used to derive control parameters based on desired
response qualities. The experimental method (Ziegler-Nichols) was also applied due to practicable reason
in real industrial plant (less mathematical analysis). To manage set-points distributed to all LCUs, master
controller was subsequently designed based on zone of both error and set-point of global temperature
controller. Confirmation experiments showed that when using control parameters from analytical method,
the global temperature response could successfully follow the distributed set-points with 0% overshoot,
193.92 second rise time, and 266.88 second settling time. While using control parameters from
experimental method, it could also follow the distributed set-points with presence of overshoot (16.9%), but
has less rise time and settling time (111.36 and 138.72 second). In this research, the overshoot could be
successfully decreased from 16.9 to 9.39 % by changing master control rule. This proposed method can
be potentially applied in real industrial plant due to its simplicity in master control algorithm and presence
of PID controller which has been generally included in today industrial equipments.
A novel auto-tuning method for fractional order PID controllersISA Interchange
Fractional order PID controllers benefit from an increasing amount of interest from the research community due to their proven advantages. The classical tuning approach for these controllers is based on specifying a certain gain crossover frequency, a phase margin and a robustness to gain variations. To tune the fractional order controllers, the modulus, phase and phase slope of the process at the imposed gain crossover frequency are required. Usually these values are obtained from a mathematical model of the process, e.g. a transfer function. In the absence of such model, an auto-tuning method that is able to estimate these values is a valuable alternative. Auto-tuning methods are among the least discussed design methods for fractional order PID controllers. This paper proposes a novel approach for the auto-tuning of fractional order controllers. The method is based on a simple experiment that is able to determine the modulus, phase and phase slope of the process required in the computation of the controller parameters. The proposed design technique is simple and efficient in ensuring the robustness of the closed loop system. Several simulation examples are presented, including the control of processes exhibiting integer and fractional order dynamics.
DESIGN OF PID CONTROLLERS INTEGRATOR SYSTEM WITH TIME DELAY AND DOUBLE INTEGR...ijcisjournal
In this paper first we investigate optimal PID control of a double integrating plus delay process and compare with the SIMC rules. What makes the double integrating process special is that derivative action is actually necessary for stabilization. In control, there is generally a trade-off between performance and robustness, so there does not exist a single optimal controller. However, for a given robustness level (here defined in terms of the Ms-value) we can find the optimal controller which minimizes the performance J (here defined as the integrated absolute error (IAE)-value for disturbances). Interestingly, the SIMC PID controller is almost identical to the optimal pid controller. This can be seen by comparing the paretooptimal curve for J as a function of Ms, with the curve found by varying the SIMC tuning parameter Tc. Second, design of Proportional Integral and Derivative (PID) controllers based on internal model control (IMC) principles, direct synthesis method (DS), stability analysis (SA) method for pure integrating process with time delay is proposed. The performances of the proposed controllers are compared with the
controllers designed by recently reported methods. The robustness of the proposed controllers for the uncertainty in model parameters is evaluated considering one parameter at a time using Kharitonov’s theorem. The proposed controllers are applied to various transfer function models and to non linear model of isothermal continuous copolymerization of styrene-acrylonitrile in CSTR. An experimental set up of tank with the outlet connected to a pump is considered for implementation of the PID controllers designed by the three proposed methods to show the effectiveness of the methods.
A simple nonlinear PD controller for integrating processesISA Interchange
Many industrial processes are found to be integrating in nature, for which widely used Ziegler–Nichols tuned PID controllers usually fail to provide satisfactory performance due to excessive overshoot with large settling time. Although, IMC (Internal Model Control) based PID controllers are capable to reduce the overshoot, but little improvement is found in the load disturbance response. Here, we propose an auto-tuning proportional-derivative controller (APD) where a nonlinear gain updating factor α continuously adjusts the proportional and derivative gains to achieve an overall improved performance during set point change as well as load disturbance. The value of α is obtained by a simple relation based on the instantaneous values of normalized error (eN) and change of error (ΔeN) of the controlled variable. Performance of the proposed nonlinear PD controller (APD) is tested and compared with other PD and PID tuning rules for pure integrating plus delay (IPD) and first-order integrating plus delay (FOIPD) processes. Effectiveness of the proposed scheme is verified on a laboratory scale servo position control system.
Design of a new PID controller using predictive functional control optimizati...ISA Interchange
An improved proportional integral derivative (PID) controller based on predictive functional control (PFC) is proposed and tested on the chamber pressure in an industrial coke furnace. The proposed design is motivated by the fact that PID controllers for industrial processes with time delay may not achieve the desired control performance because of the unavoidable model/plant mismatches, while model predictive control (MPC) is suitable for such situations. In this paper, PID control and PFC algorithm are combined to form a new PID controller that has the basic characteristic of PFC algorithm and at the same time, the simple structure of traditional PID controller. The proposed controller was tested in terms of set-point tracking and disturbance rejection, where the obtained results showed that the proposed controller had the better ensemble performance compared with traditional PID controllers.
COMPARATIVE ANALYSIS OF CONVENTIONAL PID CONTROLLER AND FUZZY CONTROLLER WIT...IJITCA Journal
All the real systems exhibits non-linear nature,conventional controllers are not always able to provide good and accurate results. Fuzzy Logic Control is used to obtain better response. A model for simulation is designed and all the assumptions are made before the development of the model. An attempt has been made to analyze the efficiency of a fuzzy controller over a conventional PID controller for a three tank level control system using fuzzification & defuzzification methods and their responses are compared. Analysis is done through computer simulation using Matlab/Simulink toolbox. This study shows that the application of Fuzzy Logic Controller (FLC) gives the best response with triangular membership function and centroid defuzzification method.
Robustness enhancement study of augmented positive identification controller ...IAESIJAI
The dissolved oxygen concentration in the wastewater treatment process
(WWTP) must remain in a specific range while the factory operates. The
augmented positive identification (PID) controller with a nonlinear element
(sigmoid function) is proposed to assure stability and reduce uncertainties in
the wastewater direct reuse/recycling model. The nonlinear controller gains
(PID controller with sigmoid function) for uncertain wastewater treatment
processes are tuned using the particle swarm optimization (PSO) technique.
The proposed robust method for controlling wastewater treatment processes
has good robustness during model mismatching, reduces treatment time
compared to traditional positive identification (PID) controllers tuned by
PSO, is easy to apply, and has good performance, according to simulation
results.
International Journal of Engineering Research and Applications (IJERA) is an open access online peer reviewed international journal that publishes research and review articles in the fields of Computer Science, Neural Networks, Electrical Engineering, Software Engineering, Information Technology, Mechanical Engineering, Chemical Engineering, Plastic Engineering, Food Technology, Textile Engineering, Nano Technology & science, Power Electronics, Electronics & Communication Engineering, Computational mathematics, Image processing, Civil Engineering, Structural Engineering, Environmental Engineering, VLSI Testing & Low Power VLSI Design etc.
Enhanced self-regulation nonlinear PID for industrial pneumatic actuatorIJECEIAES
The present article describes the improvement of Self-regulation Nonlinear PID (SN-PID) controller. A new function is introduced to improve the system performance in terms of transient without affecting the steady state performance. It is used to optimize the nonlinear function available on this controller. The signal error is reprocessed through this function, and the result is used to tune the nonlinear function of the controller. Furthermore, the presence of the dead zone on the proportional valve is solved using Dead Zone Compensator (DZC). Simulations and experiments were carried out on the pneumatic positioning system. Comparisons between the existing methods were examined and successfully demonstrated.
Hybrid controller design using gain scheduling approach for compressor systemsIJECEIAES
The automatic control system plays a crucial role in industries for controlling the process operations. The automatic control system provides a safe and proper controlling mechanism to avoid environmental and quality problems. The control system controls pressure flow, mass flow, speed control, and other process metrics and solves robustness and stability issues. In this manuscript, The Hybrid controller approach like proportional integral (PI) and proportional derivative (PD) based fuzzy logic controller (FLC) using with and without gain scheduling approach is modeled for the compressor to improve the robustness and error response control mechanism. The PI/PD-based FLC system includes step input function, the PI/PD controller, FLC with a closed-loop mechanism, and gain scheduler. The error signals and control response outputs are analyzed in detail for PI/PD-based FLC’s and compared with conventional PD/PID controllers. The PD-based FLC with the Gain scheduling approach consumes less overshoot time of 74% than the PD-based FLC without gain scheduling approach. The PD-based FLC with the gain scheduling approach produces less error response in terms of 7.9% in integral time absolute error (ITAE), 7.4% in integral absolute error (IAE), and 16% in integral square error (ISE) than PD based FLC without gain scheduling approach.
International Journal of Engineering and Science Invention (IJESI) is an international journal intended for professionals and researchers in all fields of computer science and electronics. IJESI publishes research articles and reviews within the whole field Engineering Science and Technology, new teaching methods, assessment, validation and the impact of new technologies and it will continue to provide information on the latest trends and developments in this ever-expanding subject. The publications of papers are selected through double peer reviewed to ensure originality, relevance, and readability. The articles published in our journal can be accessed online.
Fuzzy gain scheduling control apply to an RC Hovercraft IJECEIAES
The Fuzzy Gain Scheduling (FGS) methodology for tuning the ProportionalIntegral-Derivative (PID) traditional controller parameters by scheduling controlled gains in different phases, is a simple and effective application both in industries and real-time complex models while assuring the high achievements over pass decades, is proposed in this article. The Fuzzy logic rules of the triangular membership functions are exploited on-line to verify the Gain Scheduling of the Proportional-Integral-Derivative controller gains in different stages because it can minimize the tracking control error and utilize the Integral of Time Absolute Error (ITAE) minima criterion of the controller design process. For that reason, the controller design could tune the system model in the whole operation time to display the efficiency in tracking error. It is then implemented in a novel Remote Controlled (RC) Hovercraft motion models to demonstrate better control performance in comparison with the PID conventional controller.
A fuzzy model based adaptive pid controller design for nonlinear and uncertai...ISA Interchange
We develop a novel adaptive tuning method for classical proportional–integral–derivative (PID)
controller to control nonlinear processes to adjust PID gains, a problem which is very difficult to
overcome in the classical PID controllers. By incorporating classical PID control, which is well-known in
industry, to the control of nonlinear processes, we introduce a method which can readily be used by the
industry. In this method, controller design does not require a first principal model of the process which is
usually very difficult to obtain. Instead, it depends on a fuzzy process model which is constructed from
the measured input–output data of the process. A soft limiter is used to impose industrial limits on the
control input. The performance of the system is successfully tested on the bioreactor, a highly nonlinear
process involving instabilities. Several tests showed the method's success in tracking, robustness to noise,
and adaptation properties. We as well compared our system's performance to those of a plant with
altered parameters with measurement noise, and obtained less ringing and better tracking. To conclude,
we present a novel adaptive control method that is built upon the well-known PID architecture that
successfully controls highly nonlinear industrial processes, even under conditions such as strong
parameter variations, noise, and instabilities
New Method for Tuning PID Controllers Using a Symmetric Send-On-Delta Samplin...ISA Interchange
In this paper we present a new method for tuning PI controllers with symmetric send-on-delta (SSOD) sampling strategy. First we analyze the conditions that produce oscillations in event based systems considering SSOD sampling strategy. The Describing Function is the tool used to address the problem. Once the conditions for oscillations are established, a new robustness to oscillation performance measure is introduced which entails with the concept of phase margin, one of the most traditional measures of relative stability in closed-loop control systems. Therefore, the application of the proposed robustness measure is easy and intuitive. The method is tested by both simulations and experiments. Additionally, a Java application has been developed to aid in the design according to the results presented in the paper.
IMC Based Fractional Order Controller for Three Interacting Tank ProcessTELKOMNIKA JOURNAL
In model based control, performance of the controlled plant considerably depends on the
accuracy of real plant being modelled. In present work, an attempt has been made to design Internal
Model Control (IMC), for three interacting tank process for liquid level control. To avoid complexities in
controller design, the third order three interacting tank process is modelled to First Order Plus Dead Time
(FOPDT) model. Exploiting the admirable features of Fractional Calculus, the higher order model is also
modelled to Fractional Order First Order Plus Dead Time (FO-FOPDT) model, which further reduces the
modelling error. Moving to control section, different IMC schemes have been proposed based on the order
of filter. Various simulations have been performed to show the greatness of Fractional order modelled
system & fractional order filters over conventional integer order modelled system & integer order filters
respectively. Both for parameters estimation of reduced order model and filter tuning, Genetic Algorithm
(GA) is being applied.
Performance Based Comparison Between Various Z-N Tuninng PID And Fuzzy Logic ...ijsc
The objective of this paper is to compare the time specification performance between conventional
controller and Fuzzy Logic controller in position control system of a DC motor. The scope of this research
is to apply direct control technique in position control system. Two types of controller namely PID and
fuzzy logic PID controller will be used to control the output response. This paper was written to reflect on
the work done on the implementation of a fuzzy logic PID controller. The fuzzy controller was used to
control the position of a motor which can be considered for a general basis in any project design
containing logic control. Motor parameters were taken from a datasheet with respect to a real motor and a
simulated model was developed using Matlab Simulink Toolbox. The fuzzy control was also designed using
the Fuzzy Control Toolbox provided within Matlab, with each rule consisting of fuzzy sets conditioned to
provide appropriate response times with regards to the limitations of our chosen motor. The Fuzzy
Inference Engine chosen for our control was the Mamdani Minimum Inference engine. The results of the
control provided response times suitable for our application.
Similar to Controller Tuning for Integrator Plus Delay Processes. (20)
Saudi Arabia stands as a titan in the global energy landscape, renowned for its abundant oil and gas resources. It's the largest exporter of petroleum and holds some of the world's most significant reserves. Let's delve into the top 10 oil and gas projects shaping Saudi Arabia's energy future in 2024.
Explore the innovative world of trenchless pipe repair with our comprehensive guide, "The Benefits and Techniques of Trenchless Pipe Repair." This document delves into the modern methods of repairing underground pipes without the need for extensive excavation, highlighting the numerous advantages and the latest techniques used in the industry.
Learn about the cost savings, reduced environmental impact, and minimal disruption associated with trenchless technology. Discover detailed explanations of popular techniques such as pipe bursting, cured-in-place pipe (CIPP) lining, and directional drilling. Understand how these methods can be applied to various types of infrastructure, from residential plumbing to large-scale municipal systems.
Ideal for homeowners, contractors, engineers, and anyone interested in modern plumbing solutions, this guide provides valuable insights into why trenchless pipe repair is becoming the preferred choice for pipe rehabilitation. Stay informed about the latest advancements and best practices in the field.
About
Indigenized remote control interface card suitable for MAFI system CCR equipment. Compatible for IDM8000 CCR. Backplane mounted serial and TCP/Ethernet communication module for CCR remote access. IDM 8000 CCR remote control on serial and TCP protocol.
• Remote control: Parallel or serial interface.
• Compatible with MAFI CCR system.
• Compatible with IDM8000 CCR.
• Compatible with Backplane mount serial communication.
• Compatible with commercial and Defence aviation CCR system.
• Remote control system for accessing CCR and allied system over serial or TCP.
• Indigenized local Support/presence in India.
• Easy in configuration using DIP switches.
Technical Specifications
Indigenized remote control interface card suitable for MAFI system CCR equipment. Compatible for IDM8000 CCR. Backplane mounted serial and TCP/Ethernet communication module for CCR remote access. IDM 8000 CCR remote control on serial and TCP protocol.
Key Features
Indigenized remote control interface card suitable for MAFI system CCR equipment. Compatible for IDM8000 CCR. Backplane mounted serial and TCP/Ethernet communication module for CCR remote access. IDM 8000 CCR remote control on serial and TCP protocol.
• Remote control: Parallel or serial interface
• Compatible with MAFI CCR system
• Copatiable with IDM8000 CCR
• Compatible with Backplane mount serial communication.
• Compatible with commercial and Defence aviation CCR system.
• Remote control system for accessing CCR and allied system over serial or TCP.
• Indigenized local Support/presence in India.
Application
• Remote control: Parallel or serial interface.
• Compatible with MAFI CCR system.
• Compatible with IDM8000 CCR.
• Compatible with Backplane mount serial communication.
• Compatible with commercial and Defence aviation CCR system.
• Remote control system for accessing CCR and allied system over serial or TCP.
• Indigenized local Support/presence in India.
• Easy in configuration using DIP switches.
Hierarchical Digital Twin of a Naval Power SystemKerry Sado
A hierarchical digital twin of a Naval DC power system has been developed and experimentally verified. Similar to other state-of-the-art digital twins, this technology creates a digital replica of the physical system executed in real-time or faster, which can modify hardware controls. However, its advantage stems from distributing computational efforts by utilizing a hierarchical structure composed of lower-level digital twin blocks and a higher-level system digital twin. Each digital twin block is associated with a physical subsystem of the hardware and communicates with a singular system digital twin, which creates a system-level response. By extracting information from each level of the hierarchy, power system controls of the hardware were reconfigured autonomously. This hierarchical digital twin development offers several advantages over other digital twins, particularly in the field of naval power systems. The hierarchical structure allows for greater computational efficiency and scalability while the ability to autonomously reconfigure hardware controls offers increased flexibility and responsiveness. The hierarchical decomposition and models utilized were well aligned with the physical twin, as indicated by the maximum deviations between the developed digital twin hierarchy and the hardware.
Welcome to WIPAC Monthly the magazine brought to you by the LinkedIn Group Water Industry Process Automation & Control.
In this month's edition, along with this month's industry news to celebrate the 13 years since the group was created we have articles including
A case study of the used of Advanced Process Control at the Wastewater Treatment works at Lleida in Spain
A look back on an article on smart wastewater networks in order to see how the industry has measured up in the interim around the adoption of Digital Transformation in the Water Industry.
Water Industry Process Automation and Control Monthly - May 2024.pdf
Controller Tuning for Integrator Plus Delay Processes.
1. The International Journal Of Engineering And Science (IJES)
|| Volume || 6 || Issue || 3 || Pages || PP 10-13 || 2017 ||
ISSN (e): 2319 – 1813 ISSN (p): 2319 – 1805
DOI: 10.9790/1813-0603021013 www.theijes.com Page 10
Controller Tuning for Integrator Plus Delay Processes.
B. S. Patil1
, Dr. L. M. Waghmare2
, Dr. M. D. Uplane3
1
Instrumentation Department, AISSMS’S Polytechnic, Near RTO office, Kennedy Road, Pune-01.
2
Director, Shri Guru Gobind Singhji, Institute of Engineering & Technology,Vishnupuri, Nanded.
3
sHOD, Professor, Instrumentation Science Department, Savitribai Phule Pune University, Pune.
--------------------------------------------------------ABSTRACT-----------------------------------------------------------
A design method for PID controllers based on internal model control (IMC) principles, direct synthesis method
(DS), stability analysis (SA) method for pure integrating process with time delay is proposed. Analytical
expressions for PID controllers are derived for several common types of process models, including first order
and second-order plus time delay models and an integrator plus time delay model. Here in this paper, a simple
controller design rule and tuning procedure for unstable processes with delay time is discussed. Simulation
examples are included to show the effectiveness of the proposed method.
Keywords: PID controller, tuning, unstable processes, internal model control (IMC), direct synthesis method
(DS), stability analysis (SA).
-------------------------------------------------------------------------------------------------------------------------------------
Date of Submission: 02 March 2017 Date of Accepted: 28 March 2017
--------------------------------------------------------------------------------------------------------------------------------------
I. INTRODUCTION
The ubiquitous PID controller has continued to be the most extensively used process control technique for many
decades. Although advanced manage techniques such as model predictive control can provide major
improvement, a PID controller that is correctly planned and tune has proved to be suitable for the vast majority
of industrial control loops. The enormous writing on PID controllers includes a wide variety of design and tuning
methods based on dissimilar performance criteria. A simple IMC-PID controller design technique is given by [9]
on the basis of the IMC principle for integrating processes with time delay. The process is mainly listening
carefully on the trouble rejection, which causes the overshoot in the set point reply, and a Two Degree Of
Freedom (2DOF) control organization is used to eliminate this overshoot. PID controller is designed using
Maclaurin series expansion. The controller is tuned for robustness by specifying the peak of maximum
sensitivity.
The design methods for PID controller are classically based on a time-domain or frequency-domain performance
criterion. However, the relationships between the dynamic performance of the closed-loop system and this
presentation index are not straightforward. In the direct synthesis (DS) approach 13-15 however, the manager
design is based on a desired closed-loop transfer function. Then, the controller is calculated systematically so
that the closed-loop set-point response matches the desired response. The obvious advantage of the direct
synthesis approach is that performance requirements are built-in directly through specification of the closed-loop
transfer function. One way to specify the closed-loop transfer function is to choose the closed-loop poles. This
pole situation method 4, 13 can be interpreted as a special type of direct synthesis.
The SIMC method for PID manager alteration (Skogestad, 2003) has already establish wide industrial usage.
The SIMC rules are logically resulting, and from a first or second order process we can simply find the pi and
PID controller setting, respectively. Even though the rule was originally derived largely with ease in mind, recent
studies have establish that the resulting setting are very close to optimal (Grimholt and Skogestad, 2012, 2013).
For the twice integrating process, the SIMC rule gives the pid setting for the serial form.
II. LITERATURE SURVEY
1.1 Identification and Tuning of Integrating Processes with Dead time and Inverse Response.
Author- William L. Luyben.
The classical example of an integrating method with inverse reply is level control of a boiler steam drum. The
“boiler swell” difficulty can lead to a transfer function between the drum level and boiler feed water flow rate
that contains a clean integrator and a positive zero, in addition to some dead time and lags. a procedure for
identify the transfer-function parameters for this type of structure from step response data. A proportional
integral controller tuning process is also presented. Because the process contains an integrator and the
proportional-integral controller also contains an integrator, manager tuning is somewhat complex.
2. Controller Tuning for Integrator Plus Delay Processes.
DOI: 10.9790/1813-0603021013 www.theijes.com Page 11
1.2 PI/PID Controller Design Based on Direct Synthesis and Disturbance Rejection
Author- Dan Chen and Dale E. Seborg.
A design method for PID controller based on the straight synthesis approach and condition of the desired closed-
loop transfer function for disturbances is proposed. Analytical expressions for PID controllers are resulting for
several common types of process models, including first order and second-order plus time delay models and an
integrator plus point time delay model. Although the controllers are designed for trouble rejection, the set-point
responses are regularly satisfactory and can be tuned separately via a set-point weighting factor.
1.3 PID Controllers Tuning for Improved Performance of Unstable Processes.
Author- G. M. Malwatkar, P. T. Bhosale, S. D. Nikam, L. M. Waghmare.
The design procedures for unbalanced processes involve compensation of unbalanced zeros or poles. In most of
the cases PID controllers are used to control the stable processes, however less common for unbalanced
processes. In this paper, a simple controller design rule and tuning procedure for unstable process with delay
time is discussed. The method is developed based on a -3 dB, gain intersect and phase crossover frequencies
with Pade estimate for the time delay. Simulation examples are included to show the efficiency of the proposed
method.
1.4 Performance Enhancement in Disturbance Rejection by PID Controller in Series with Low Pass Filter.
Author- Sneha S. Patil, Gajanan M. Malwatkar, Jayant V. Kulkarni.
It is based on the direct synthesis approach. Analytical expressions for the PID manager are derived for a
common type of process model. Although the controller is designed for trouble rejection, the set point response
is satisfactory and can be improved by adjusting a single set point weighing factor b. Three simulation examples
show that the proposed design method results in extremely good control for process models. IAE (Internal
absolute error) of the planned method is have smaller value than DS-d controller.
1.5 Design of PID Controllers for Improved Performance of Higher Order Systems.
Author- L. M. Waghmare G. M. Malwatkar.
Frequency reply based design method of PID controller is proposed for higher order (HO)/-plus delay point in
time (HOPDT) systems. The HO/-PDT models are converted into real and unreal part at a incidence where a
criteria similar to amplitude and phase margin is utilized to get the constraints on the parameter of the
controllers. To discard sound and load disturbances, the constraint given by sensitivity and complementary
sensitivity function are also considered. The proposed method has larger features for systems with high order,
time delays and monotonic or oscillatory responses.
1.6 Design of Centralized PI/PID Controller: Interaction Measure Approach.
Author- G. M. Malwatkar, A. A. Khandekar, V. G. Asutkar and L. M. Waghmare.
Control system design involves input/output (IO) range, that is, decisions on the number, the place, and the type
of actuators and sensors. The choice of inputs and outputs affects the presentation, complexity, and cost of the
control system. In most of the multivariable systems controllers are planned by decomposing multi-loop systems
into a number of corresponding single loops and design of a manager for each loop is performed. The success of
controller depends on the input output pairing as it decides the structure of the controller. In this paper design
rules and tuning system of the controller for multivariable process with delay point in time are discussed without
decomposing multivariable system.
III. SYSTEM METHODS
1.7 Direct Synthesis Method Based on Set point Responses:
In the direct synthesis approach [5], an analytical expression is derived for the process model and desired closed-
loop transfer function. Consider a feedback control system in Fig.1.
Fig.1. Feedback control system
3. Controller Tuning for Integrator Plus Delay Processes.
DOI: 10.9790/1813-0603021013 www.theijes.com Page 12
Assume that Gp(s) is a model of the process. The closed-loop transfer function for set point changes is
derived as:
……………1
Rearranging the terms,
……….. 2
Let the desired closed-loop transfer function for set point change is specified as (y/r)d , and assume that process
model Gp(s) is available. Replacing the unknown (y/r) and Gp(s) by (y/r)d and Gp(s). Respectively [1] gives.
………3
Because the individuality of (y/r)d have a direct impact on the resulting controller (y/r)d be supposed to be chosen
so that the closed-loop presentation is suitable and the resulting controller is actually realizable.
1.8 IMC design method:
Lee et al. extended the IMC design approach for two degree of freedom controllers to improve disturbance
performance. Their controller is a combination of two controllers, a standard IMC controller for set-point
changes and a second IMC type of controller designed to shape the disturbance response. Their control system
also includes a set-point filter that is specified as the inverse of the IMC controller for disturbances. This design
provide a set-point reply that is equal to that for the standard IMC controller.This novel control scheme can
provide improved dynamic performance over standard IMC controllers, but the design procedure is more
complicated and might result in unstable controllers.
Fig.2. Feedback control strategies. (a) Classical feedback control. (b) Internal model control.
1.9 Robust stability test using Kharitonov’s theorem:
A control system is supposed to be robust, if the blocked loop system is stable even when the model parameter
of the actual method are dissimilar than that used for the controller design. The robust stability of a linear time-
invariant control system contain a plant which has some transfer function coefficients subject to perturbation.
The set of transfer function generated by varying these coefficients in arranged ranges correspond to a box in
parameter space is referred to as an interval plant. To compare the strength of the different controller design
methods, the stability region in each of the model parameters for which the manager is stable is to be calculated.
The stability of such system is a problem in the theory of robust control with structured perturbations.
Kharitonov’s theorem (Kharitonov’s, 1978) that deals with the stability of an interval polynomial could be
suitably global to deal with this problem.
Kharitonov‟s theorem is used to determine the stability of an uncertain system by major four bounding
polynomials and applying Routh - Hurwitz examination to each of them. It gives a necessary and enough
4. Controller Tuning for Integrator Plus Delay Processes.
DOI: 10.9790/1813-0603021013 www.theijes.com Page 13
condition for all polynomials in a given family to be Hurwitz stable (Callier and Desoer, 1991) In this, the family
of polynomials considered is obtain by allowing each of the polynomial coefficients to vary separately within an
interval. It shows that stability of this family of polynomials can be determined by looking at the stability of four
specially constructed vertex polynomial.
1.9.1 Theorem 1. (Kharitonov 1978a)
1.9.2 Algorithm:
For each of the four Kharitonov polynomial
1. Form the Hurwitz matrix.
2. Perform modified gaussian elimination r closed row reduction to get.
3. Examine the diagonal elements for sign change.
4. If there is a sign change in the diagonal elements, the polynomial is not Hurwitz stable.
5. If all the four set of polynomials are Hurwitz stable, the system is proved for its robust stability. H n H
6. If any one set of polynomial is not Hurwitz the system is not robustly stable.
IV. CONCLUSION
Three methods of designing PID controllers for pure integrating system with time delay are proposed based on
IMC method, stability analysis method and direct synthesis method. The performance of the proposed controllers
is better than the recently reported methods. Stability region for various model parameters considering
uncertainty in one parameter at a time is obtained using theorem and compared with that of the literature
reported methods. The stability region for all the model parameters is comparable with that of the literature
reported methods. The advantage of these methods is that the controller is PID and simple conventional
feedback control structure is used.
ACKNOWLEDGEMENT
I would prefer to give thanks the researchers likewise publishers for creating their resources available.
Additionally, I appreciative to commentator for their vital recommendations moreover I am conjointly grateful to
reviewer for their valuable suggestions and also thank the college authorities for providing the required
infrastructure and support.
REFERENCES
[1]. Chien, L. and Fruehauf, P. S. 1990. Consider IMC tuning to improve performance. Chem Eng Progr, 10: 33-41.
[2]. Fuentes, C. and Luyben, W. L. 1983. Control of high purity distillation columns. Ind Eng Chem Process Des Dev, 22: 362.
[3]. Srividya, R. and Chidambaram, M. 1997.On line controller tuning for integrator plus delay processes. Process Contr Qual, 9: 59-
66.
[4]. Astrom, K. J., and Haggland, T. 1995. “PID controllers: Theory, Design and Tuning”, Instr Soc. America, North Carolina.
[5]. Yu, C. C. 1999. “Auto Tuning of PID controllers”, Springer-Verlag, Berlin
[6]. Ziegler, J. G. and Nichols, N. B. 1942. Optimum settings for automatic controllers. Trans ASME, 64: 759-765.
[7]. Tyreus, B.D. and Luyben, W.L. 1992. Tuning PI controllers for integrator/ dead-time processes. Ind Eng Chem Res, 31: 2625.
[8]. Chidambaram, M. 1994. Design of PI controller for integrator/dead-time processes. Hungar J Ind Chem, 22: 37.
[9]. Poulin, E. and Pomerleau, A. 1999. PI settings for integrating processes based on ultimate cycle information. IEEE Trans Contr
Syst Tech, 7: 509.
[10]. Luyben, W. L. 1996. Design of Proportional Integral and Derivative controllers for integrating dead-time processes. Ind Eng Chem
Res, 35: 3480.
[11]. Wang, L. and Cluette, W.R. 1997. Tuning PID controllers for integrating processes. IEE Proc Contr Theor Appl, 144: 385.
[12]. Kookos, I. K., Lygros, A. I., and Arvanitis, K. G. 1999. On-line PI controller tuning for integrator / dead time processes. Eur J
Contr, 5: 19.
[13]. Wang, Y.G. and Cai, W.J. 2002. Advanced proportional integral derivative tuning for integrating and unstable processes with gain
and phase margin specifications. Ind Eng Chem Res, 41: 2910-2914.
[14]. Visioli, A. 2001. Optimal tuning of PID controllers for integral and unstable processes. IEE Proc Contr Theor Appl, 148: 180.
[15]. Zhang, W., Xu, X., and Sun, Y. 1999. Quantitative performance design for integrating processes with time delay. Automatica, 35:
719-723.
