Palomar Technologies is a leading provider of precision assembly equipment and contract manufacturing services headquartered in Carlsbad, CA. They have over 30,000 square feet of factory and laboratory space to support microelectronic assembly. Their mission is to help customers overcome assembly challenges in a cost-effective manner. Palomar offers a variety of bonding and assembly equipment, as well as process development and contract assembly services out of class 1,000-10,000 cleanrooms.

1. David Rasmussen
General Manager Assembly Services
Palomar Technologies, Inc.
Apr 2015
Palomar Technologies
Assembly Services Overview

2. Headquartered in Carlsbad, CA USA
www.palomartechnologies.com 2© Palomar Technologies, Inc.
30,000 sq feet of factory and laboratory space

3. Mission
Enable our customers to overcome their microelectronic
assembly challenges in a cost-effective manner
www.palomartechnologies.com 3© Palomar Technologies, Inc.
A Strategic Partner
• Leading supplier of precision assembly equipment and
contract assembly services
• Strong global position with direct sales and services with
facilities in the U.S., Asia and Europe
• Expert process solutions provider
 Palomar Technologies differentiates with ability to develop and
deliver robust, integrated, high-precision process solutions

4. Strong Technology Roots
• Former subsidiary of Hughes Aircraft
• Established leader in micro/opto electronic
packaging systems for advanced commercial,
industrial and defense applications
• Thousands of systems installed worldwide and
serviced directly by Palomar
• Excellence in Quality Standards ISO 9001:2008,
Mil Standard 883, JEDEC, and ITAR Compliance
• Decades of process expertise, since the 1970s
www.palomartechnologies.com 4© Palomar Technologies, Inc.

5. www.palomartechnologies.com 5© Palomar Technologies, Inc.
53%
18%
12%
11%
6%
Company Breakdown of Direct Service and
Support Worldwide
Engineering (Applications,
Systems)
Service: North/South
American Support (based in
Carlsbad, CA)
Assembly Services
(Process Development,
Contract Manufacturing)
Service: APAC Support
(based in Singapore)
Service: EMEA Support
(based in Erlangen,
Germany)

6. Markets: Complex Hybrids
• OPTOELECTRONICS / PHOTONICS
LEDs, Lasers, Sensors, Printheads,
TOSA/ROSA, Lens Attach, Passive
Alignment, MEMS, Active Optical Cables
• BIO-MEDICAL Implantable Devices
(Pacemakers, Hearing Aids), Blood
Oxygen Analyzers, Genomics, MEMS • AEROSPACE AND
DEFENSE Avionics, Flight Hardware,
Missile Guidance, MEMS
• AUTOMOTIVE
Pressure Sensors, Accelerometers,
Gyroscopes, MEMS
• RF / WIRELESS
Multi-Channel Communications,
Wireless Base Stations
www.palomartechnologies.com 6© Palomar Technologies, Inc.

7. Palomar Value Proposition
• High Reliability
• Precision
• Accuracy
• Repeatability
• Decades of Process
Expertise
• Design and
Manufacturing
• Deep Access
• Large Work Area
• Flexibility
• Customization
www.palomartechnologies.com 7© Palomar Technologies, Inc.

8. Manual Bonders
Pull Testers; Die Sorterswww.palomartechnologies.com 8© Palomar Technologies, Inc.
Tools for Micro-Electronic Assembly
Dispensers
High-Rel
Wedge & Wire
BondersHigh-Accuracy
Die Bonders
Turn-key
assembly
solutions
Fully
integrated
precision
production
lines

9. Precision. Reliability. Consistency.
www.palomartechnologies.com 9© Palomar Technologies, Inc.
8000 WIRE BONDER
3800 DIE BONDER
Fully Automated Micro/Opto-
Electronic Manufacturing Equipment
6500 DIE BONDER

10. .
www.palomartechnologies.com 10© Palomar Technologies, Inc.
Class 10,000 cleanroom

11. Process Development and
Contract Assembly Services
• Decades of process expertise
• Ultra-high accuracy die attach and
wire bonding
• Process development and
prototyping
• Test and measurement
• Advanced packaging services
• Supply chain management
• Over 250m2 class 1,000 –10,000
clean rooms
• Computerized paperless lab data
collection and analysis
• High-reliability applications
www.palomartechnologies.com 11© Palomar Technologies, Inc.© 2011 Palomar Technologies, Inc.

12. Benefits of Assembly Services
• Intellectual property protection
• Rapid prototype-to-volume assembly without using valuable
engineering resources too quickly
• Ability to quickly react to needed changes
• Improved communication
• Access to product in all stages of assembly
• High-quality processes and applications
• Ability to perform consistent complex applications and processes
www.palomartechnologies.com 12© Palomar Technologies, Inc.

13. Clients of Assembly Services
• BAE Aerospace
• Cisco Systems – 100G optical communications
assemblies
• Corning - Thunderbolt™ Optical Cables
• Honeywell
• Seagate
• Many more
www.palomartechnologies.com 13© Palomar Technologies, Inc.

14. Connect with Us!
• Blog: www.palomartechnologies.com/blog
• Twitter: twitter.com/PalomarTech (@PalomarTech)
• YouTube: youtube.com/user/palomartechnologies
• LinkedIn: linkedin.com/company/palomar-technologies/
• Google+: gplus.to/PalomarTechnologies
• Visit our website: www.palomartechnologies.com to
download technical papers and eBooks; watch videos and
webcasts
www.palomartechnologies.com 14© Palomar Technologies, Inc.

15. Corporate Headquarters: +1-760-931-3600
APAC: +65-6686-3096
EMEA: +49-9131-48009-30
Palomar Technologies
For more information visit
www.palomartechnologies.com
© Palomar Technologies, Inc. www.palomartechnologies.com 15
