1. Communication in Android
by Yuriy Voznyak, Software Engineer
eleks.com
You can view the presentation on http://eleksdev.blogspot.com
1

2. Agenda
● Networking in Android
● Useful Networking
Libraries
● Bluetooth
● NFC
2

3. Connecting to the Network
We are going to learn how to implement a simple application that connects to the
network. It explains some of the best practices you should follow in creating even
the simplest network-connected app.
Note that to perform the network operations described in this lecture, your
application manifest must include the following permissions:
<uses-permission android:name="android.permission.INTERNET"/>
<uses-permission android:name="android.permission.ACCESS_NETWORK_STATE"/>
Most network-connected Android apps use HTTP to send and receive data. The
Android platform includes the HttpURLConnection client, which supports HTTPS,
streaming uploads and downloads, configurable timeouts, IPv6, and connection
pooling.
3

4. Check the Network Connection
Before your app attempts to connect to the network, it should check to see whether a
network connection is available using getActiveNetworkInfo() and isConnected().
Remember, the device may be out of range of a network, or the user may have disabled
both Wi-Fi and mobile data access.
ConnectivityManager connMgr = (ConnectivityManager)
context.getSystemService(Context.CONNECTIVITY_SERVICE);
NetworkInfo networkInfo = connMgr.getActiveNetworkInfo();
if (networkInfo != null && networkInfo.isConnected()) {
// fetch data
} else {
// display error
}
4

5. Network Operations on a Separate Thread
Network operations can involve unpredictable delays. To prevent this from causing a poor user
experience, always perform network operations on a separate thread from the UI. The AsyncTask
class provides one of the simplest ways to fire off a new task from the UI thread.
private class DownloadWebpageTask extends AsyncTask<String, Void, String> {
@Override
protected String doInBackground(String... urls) {
try {
return downloadUrl(urls[0]);
} catch (IOException e) {
return "Unable to retrieve web page. URL may be invalid.";
}
}
@Override
protected void onPostExecute(String result) {
textView.setText(result); // Executes in Main Thread
}
} 5

6. Connect and Download Data
In your thread that performs your network transactions, you can use HttpURLConnection to
perform a GET and download your data. After you call connect(), you can get an InputStream of
the data by calling getInputStream().
private String downloadUrl(String myurl) throws IOException {
InputStream is = null;
int len = 500; // Only display the first 500 characters
try {
URL url = new URL(myurl);
HttpURLConnection connection = (HttpURLConnection) url.openConnection();
connection.setRequestMethod("GET");
connection.setDoInput(true);
connection.connect(); // Starts the query
Log.d(DEBUG_TAG, "The response code is: " + conn.getResponseCode()); // HTTP Response code
is = connection.getInputStream();
return readToString(is, len); // Convert the InputStream into a string; See next slide
} finally {
if (is != null)
is.close(); // Makes sure that the InputStream is close
}
} 6

7. Convert the InputStream to a Data
7
In the example shown above, the InputStream represents the text of a web page. This is how the
example converts the InputStream to a string so that the activity can display it in the UI:
public String readToString(InputStream stream, int len) throws IOException, UnsupportedEncodingException {
Reader reader = null;
reader = new InputStreamReader(stream, "UTF-8");
char[] buffer = new char[len];
reader.read(buffer);
return new String(buffer);
}
An InputStream is a readable source of bytes. Once you get an InputStream, it's common to
decode or convert it into a target data type. For example, if you were downloading image data, you
might decode and display it like this:
InputStream is = null;
… // Get some data
Bitmap bitmap = BitmapFactory.decodeStream(is);
ImageView imageView = (ImageView) findViewById(R.id.image_view);
imageView.setImageBitmap(bitmap);

8. Managing Network Usage
It is important to know how to write applications that have fine-grained control over
their usage of network resources.
If your application performs a lot of network operations, you should provide user
settings that allow users to control your app’s data habits, such as how often your
app syncs data, whether to perform uploads/downloads only when on Wi-Fi,
whether to use data while roaming, and so on. With these controls available to
them, users are much less likely to disable your app’s access to background data
when they approach their limits, because they can instead precisely control how
much data your app uses.
8

9. Check a Device's Network Connection
A device can have various types of network connections. This lesson focuses on using either a
Wi-Fi or a mobile network connection. For the full list of possible network types, see
ConnectivityManager.
Wi-Fi is typically faster. Also, mobile data is often metered, which can get expensive. A common
strategy for apps is to only fetch large data if a Wi-Fi network is available.
Before you perform network operations, it's good practice to check the state of network
connectivity. Among other things, this could prevent your app from inadvertently using the
wrong radio. If a network connection is unavailable, your application should respond gracefully.
9

10. Network Connection Type Example
To check the network connection, you typically use the following classes:
● ConnectivityManager: Answers queries about the state of network connectivity. It also
notifies applications when network connectivity changes.
● NetworkInfo: Describes the status of a network interface of a given type (currently either
Mobile or Wi-Fi).
private static final String DEBUG_TAG = "NetworkStatusExample";
ConnectivityManager connMgr = (ConnectivityManager)
getSystemService(Context.CONNECTIVITY_SERVICE);
NetworkInfo networkInfo = connMgr.getNetworkInfo(ConnectivityManager.TYPE_WIFI);
boolean isWifiConnected = networkInfo.isConnected();
networkInfo = connMgr.getNetworkInfo(ConnectivityManager.TYPE_MOBILE);
boolean isMobileConnected = networkInfo.isConnected();
Log.d(DEBUG_TAG, "Wifi connected: " + isWifiConnected);
Log.d(DEBUG_TAG, "Mobile connected: " + isMobileConnected);
10

11. Efficient Network Access
Using the wireless radio to transfer data is potentially one of your
app's most significant sources of battery drain. To minimize the
battery drain associated with network activity, it's critical that you
understand how your connectivity model will affect the underlying
radio hardware.
It is good approach to minimize your data connections, use
prefetching, and bundle your transfers in order to minimize the
battery drain associated with your data transfers.
11

12. The Radio State Machine
The state machine for a typical 3G network radio consists of three energy states:
● Full power: Used when a connection is active, allowing the device to transfer
data at its highest possible rate.
● Low power: An intermediate state that uses around 50% of the battery power
at the full state.
● Standby: The minimal energy state during which no network connection is
active or required.
12

13. How Apps Impact the Radio States
13
For example, an app that transfers unbundled data for 1 second every 18 seconds will keep the
wireless radio perpetually active, moving it back to high power just as it was about to become idle.
As a result, every minute it will consume battery at the high power state for 18 seconds, and at the
low power state for the remaining 42 seconds.
By comparison, the same app that bundles transfers of 3 seconds of every minute will keep the
radio in the high power state for only 8 seconds, and will keep it in the low power state for only an
additional 12 seconds.

14. Prefetch Data
14
“The single most important measure: transmit as much data
as possible in a single burst and then end the connection.”
AT&T Labs
By front loading your transfers, you reduce the number of radio activations required to
download the data. As a result you not only conserve battery life, but also improve the
latency, lower the required bandwidth, and reduce download times.
Prefetching also provides an improved user experience by minimizing in-app latency
caused by waiting for downloads to complete before performing an action or viewing
data.

15. Android Libs for Effective Networking
15
Just a small amount of them
● Retrofit
● okHttp
● Volley
● RoboSpice

16. Retrofit Advantages
16
A type-safe HTTP client for Android for REST interfaces
From their site: "Retrofit turns your REST API into a Java interface.” It’s an elegant solution for
organizing API calls in a project. The request method and relative URL are added with an annotation,
which makes code clean and simple.
With annotations, you can easily add a request body, manipulate the URL or headers and add query
parameters.
Adding a return type to a method will make it synchronous, while adding a Callback will allow it to
finish asynchronously with success or failure.
Retrofit uses Gson by default, so there is no need for custom parsing. Other converters are supported
as well.

17. Retrofit Example
17
public interface RetrofitInterface {
@GET("/api/user")
User getUser(@Query("user_id") int userId, Callback<User> callback);// asynchronously with a callback
@POST("/api/user/register")
User registerUser(@Body User user);// synchronously
}
RetrofitInterface retrofitInterface = new RestAdapter.Builder()
.setEndpoint(API.API_URL).build().create(RetrofitInterface.class);
// fetch user with id 42
retrofitInterface.getUser(42, new Callback<User>() {
@Override
public void success(User user, Response response) {
}
@Override
public void failure(RetrofitError retrofitError) {
}
});

18. okHttp
18
OkHttp is an modern, fast and efficient Http client which supports HTTP/2 and SPDY and does a lot of
stuff for you. Reading how many things OkHttp does it’s a good way to understand how hard
networking is: Connection pooling, gziping, caching, recovers from network problems, sync and async
calls, redirects, retries … and so on.
OkHttp is a very capable networking tool out of the box, without the need of any REST library (Retrofit,
Volley…) and probably is the library most developers would choose if they could only include one
library in their projects.
OkHttp sits on top of Okio, a library that complements java.io and java.nio to make it much easier to
access, store, and process your data. It provides fast I/O and resizable buffers.
OkHttp depends Okio, but Okio can be used by its own.

19. Volley
19
Volley is a REST client that makes easy common networking tasks. Takes care of requesting, loading,
caching, threading, synchronization and some more stuff. It’s ready to deal with JSON, images,
caching, raw text and allow some customization.
Volley was design for RPC style network operations that populate the UI. Is good for short operations.
Volley by default uses as transport layer the Apache Http stack on Froyo and HttpURLConnection
stack on Gingerbread and above. The reason is there are problems with those http stacks have on
different Android versions.
Volley allow us to easily set up OkHttp as its transport layer.
Volley was developed by Google.

20. Volley Example
20
final TextView mTextView = (TextView) findViewById(R.id.text);
… // Do something important
// Instantiate the RequestQueue.
RequestQueue queue = Volley.newRequestQueue(this);
String url ="http://www.google.com";
// Request a string response from the provided URL.
StringRequest stringRequest = new StringRequest(Request.Method.GET, url,
new Response.Listener<String>() {
@Override
public void onResponse(String response) {
// Display the first 500 characters of the response string.
mTextView.setText("Response is: "+ response.substring(0,500));
}
}, new Response.ErrorListener() {
@Override
public void onErrorResponse(VolleyError error) {
mTextView.setText("That didn't work!");
}
});
queue.add(stringRequest); // Add the request to the RequestQueue.

21. RoboSpice
21
● perform a REST request to a web service (e.g. GitHub API)
● convert JSON results to POJOs (Plain Old Java Object)
● cache them on disk
● let you control cache expiry
● notify you app, on the UI thread, when result is ready.
public class DataListRequest extends SpringAndroidSpiceRequest<DataList> {
private String user;
public DataListRequest (String user) {
super(DataList.class);
this.user = user;
}
@Override
public DataList loadDataFromNetwork() throws Exception {
String url = String.format("https://api.site.com/users/%s/data", user);
return getRestTemplate().getForObject(url, DataList.class);
}
}

22. Relationships
22

23. Bluetooth
23
The Android platform includes support for the Bluetooth network stack, which allows a
device to wirelessly exchange data with other Bluetooth devices. The application
framework provides access to the Bluetooth functionality through the Android Bluetooth
APIs. These APIs let applications wirelessly connect to other Bluetooth devices, enabling
point-to-point and multipoint wireless features.
Using the Bluetooth APIs, an Android application can perform the following:
● Scan for other Bluetooth devices
● Query the local Bluetooth adapter for paired Bluetooth devices
● Establish RFCOMM channels
● Connect to other devices through service discovery
● Transfer data to and from other devices
● Manage multiple connections

24. Bluetooth Permissions
24
In order to use Bluetooth features in your application, you must declare the Bluetooth
permission BLUETOOTH. You need this permission to perform any Bluetooth
communication.
If you want your app to initiate device discovery or manipulate Bluetooth settings, you
must also declare the BLUETOOTH_ADMIN permission. Most applications need this
permission solely for the ability to discover local Bluetooth devices. The other abilities
granted by this permission should not be used, unless the application is a "power
manager" that will modify Bluetooth settings upon user request. If you use
BLUETOOTH_ADMIN permission, then you must also have the BLUETOOTH permission.
<uses-permission android:name="android.permission.BLUETOOTH" />

25. Beginning work with Bluetooth
25
Get the BluetoothAdapter
BluetoothAdapter mBluetoothAdapter = BluetoothAdapter.getDefaultAdapter();
if (mBluetoothAdapter == null) {
// Device does not support Bluetooth
}
Enable Bluetooth if not enabled
if (!mBluetoothAdapter.isEnabled()) {
Intent enableBluetoothIntent= new Intent(BluetoothAdapter.ACTION_REQUEST_ENABLE);
startActivityForResult(enableBluetoothIntent, REQUEST_ENABLE_BT);
}
Optionally, your application can also listen for the ACTION_STATE_CHANGED broadcast Intent, which
the system will broadcast whenever the Bluetooth state has changed. This broadcast contains the
extra fields EXTRA_STATE and EXTRA_PREVIOUS_STATE, containing the new and old Bluetooth
states, respectively. Possible values for these extra fields are STATE_TURNING_ON, STATE_ON,
STATE_TURNING_OFF, and STATE_OFF.

26. Discovery
26
Device discovery is a scanning procedure that
searches the local area for Bluetooth enabled devices
and then requesting some information about each one
(this is sometimes referred to as "discovering,"
"inquiring" or "scanning"). However, a Bluetooth device
within the local area will respond to a discovery
request only if it is currently enabled to be
discoverable. If a device is discoverable, it will respond
to the discovery request by sharing some information,
such as the device name, class, and its unique MAC
address. Using this information, the device performing
discovery can then choose to initiate a connection to
the discovered device.

27. Querying paired devices
27
Before performing device discovery, its worth querying the set of paired devices to see if
the desired device is already known. To do so, call getBondedDevices(). This will return
a Set of BluetoothDevices representing paired devices. For example, you can query all
paired devices and then show the name of each device to the user:
Set<BluetoothDevice> pairedDevices = mBluetoothAdapter.getBondedDevices();
if (pairedDevices.size() > 0) {
// Loop through paired devices
for (BluetoothDevice device : pairedDevices) {
// Just output Name and Address to log
Log.d("Devices Info: ", device.getName() + "n" + device.getAddress());
}
}

28. Connecting to Devices
28
When you want to connect two devices, one must act as a server by holding an open
BluetoothServerSocket. The purpose of the server socket is to listen for incoming
connection requests and when one is accepted, provide a connected BluetoothSocket.
When the BluetoothSocket is acquired from the BluetoothServerSocket, the
BluetoothServerSocket can (and should) be discarded, unless you want to accept
more connections.
● Get a BluetoothServerSocket by calling the
listenUsingRfcommWithServiceRecord(String, UUID).
● Start listening for connection requests by calling accept().
● Unless you want to accept additional connections, call close().
See more, e.g. on https://developer.android.com/guide/topics/connectivity/bluetooth.html

29. Bluetooth Profiles
29
You can implement the interface BluetoothProfile to write your own classes to support a
particular Bluetooth profile. The Android Bluetooth API provides implementations for the
following Bluetooth profiles:
● Headset. The Headset profile provides support for Bluetooth headsets to be used
with mobile phones.
● A2DP. The Advanced Audio Distribution Profile (A2DP) profile defines how high
quality audio can be streamed from one device to another over a Bluetooth
connection.
● Health Device. Android 4.0 (API level 14) introduces support for the Bluetooth
Health Device Profile (HDP). This lets you create applications that use Bluetooth to
communicate with health devices that support Bluetooth, such as heart-rate
monitors, blood meters, thermometers, scales, and so on.

30. Near Field Communication
30
Near Field Communication (NFC) is a set of short-range wireless technologies, typically
requiring a distance of 4cm or less to initiate a connection. NFC allows you to share small
payloads of data between an NFC tag and an Android-powered device, or between two
Android-powered devices.
Tags can range in complexity. Simple tags offer just read and write semantics, sometimes
with one-time-programmable areas to make the card read-only. More complex tags offer
math operations, and have cryptographic hardware to authenticate access to a sector.
The most sophisticated tags contain operating environments, allowing complex
interactions with code executing on the tag. The data stored in the tag can also be
written in a variety of formats, but many of the Android framework APIs are based around
a NFC Forum standard called NDEF (NFC Data Exchange Format).

31. NFC Modes
31
Android-powered devices with NFC simultaneously support three main modes of
operation:
● Reader/writer mode, allowing the NFC device to read and/or write passive NFC tags
and stickers.
● P2P mode, allowing the NFC device to exchange data with other NFC peers; this
operation mode is used by Android Beam.
● Card emulation mode, allowing the NFC device itself to act as an NFC card. The
emulated NFC card can then be accessed by an external NFC reader, such as an
NFC point-of-sale terminal.

32. NFC: is it all?
32
NFC is a technology which is complex enough.
NFC communication performs through Magnetic Field coupling, like RFID.

33. Inspired by Technology.
Driven by Value.
Find us at eleks.com Have a question? Write to eleksinfo@eleks.com
33
