The document provides updates on construction progress and upcoming work at the Cedarvale and Forest Hill stations on the Eglinton Crosstown LRT project. Major concrete pours will continue throughout 2020 and 2021 at all station areas. Geotechnical monitoring will occur on Eglinton Avenue between Winnett Avenue and Allen Road through early 2021. Pedestrian tunnel construction will be underway around Eglinton West station through 2021. The document also outlines upcoming traffic configuration changes and concrete pours at the Forest Hill station secondary entrance in October 2020.

1. September 30, 2020
Eglinton Crosstown-LRT
Cedarvale – Forest Hill CLC

2. Cedarvale Station

3. CEDARVALE STATION UPDATE
3
CEDARVALE –FOREST HILL CLC
Activity Location Approx. Date & Duration
Deep Excavation & Tieback Installation Station’s Main Entrance Complete!
Major Concrete Pours Throughout all station areas
Underway throughout 2020 into 2021
Starting as early as 5:00 a.m. ranging from 12-18
hours
Geotechnical Monitoring
Eastbound curb lane of Eglinton Ave between
Winnett Ave and Allen Rd N
Through early 2021
Tuesdays between 11:00 a.m. – 2:00 p.m.
Pedestrian Tunnel Construction Area surrounding Eglinton West Station
Underway through 2021
Monday – Saturday; 6:00 a.m. – 2:00 a.m.
Eglinton West Station Support of
Excavation and Underpinning Works
Eglinton West Station
Underway through 2020
Monday – Saturday; 6:00 a.m. – 5:00 p.m.
Eglinton West Station Bus Loop Closure
for Roof Construction
Eglinton West Station Underway – Fall 2020
Temporary Traffic Deck Removal, Roof
Construction, and Permanent Utility
Installation
Eglinton Avenue West March 29, 2020 – early 2021

4. CURRENT TRAFFIC CONFIGURATION
4
Through Fall 2020
CEDARVALE –FOREST HILL CLC

5. CONSTRUCTION PROGRESS PHOTOS
5
CEDARVALE –FOREST HILL CLC
CONCRETE POUR FOR LAST
MAIN STATION INVERT SLAB
REMOVAL OF TEMPORARY SUPPORT BEAMS
UNDERNEATH THE TTC STATION BOX

6. Forest Hill Station

7. FOREST HILL STATION UPDATE
7
Activity Location Approx. Date & Duration
Deep Excavation
Beneath the station roof from the Main
Entrance
Complete
Main Entrance Construction
Excavation, installation of struts, lagging
and tie-backs
Northeast corner of Bathurst St and
Eglinton Ave
Underway through 2020
Secondary Entrance Construction
Formwork, rebar, conduit installation
and beam excavation
North side of Eglinton Ave, west of
Bathurst St
Underway through fall 2020
Station Box Construction
Waterproofing, shotcrete application
and duct bank construction
Beneath Eglinton Ave Underway through 2020
Concrete Pours Secondary Entrance
Periodically through fall 2020
Upcoming pours:
• October 5, 2020
Traffic Configuration Change Secondary Entrance
Monday October 5, 2020
*date subject to change

8. CURRENT TRAFFIC CONFIGURATION
8
Until October 5, 2020

9. UPCOMING TRAFFIC CONFIGURATION
9
October 5, 2020 – February 2021

10. CONSTRUCTION PROGRESS PHOTOS
10
REBAR INSTALLATION
SECONDARY ENTRANCE
WALL CONSTRUCTION
