This document discusses the process and methods of laying fiber optic cables, both underground and aerial. It describes different underground cable laying techniques like direct burial, using underground conduits, and drilling. The conduit laying process involves making an entrance pit, pivot hole, reaming to enlarge the hole, and inserting casing pipe using drilling fluid. Common conduit drilling machines and their specifications are also listed. Finally, it provides details on air compressors used to power pneumatic cable laying tools, including models, pressures, capacities, and engine specifications.

2. WHEN WE TALK ABOUT CABLE LAYING, IT’S THE
FIBER CABLE WE ARE CONSIDERING
PROCESS OF CABLE LAYING
 DIRECT BURRIAL
 UNDERGROUND CONDUIT

 AERIAL
 INTRABUILDING

3. PROCESS OF LAYING UNDERGROUND CONDUIT
 Receiving hole at entrance pit.
 First stage is pivot hole.
 Second stage is (reaming) enlarge the hole.
 Product or the casing pipe in the enlarged hole by
way of drill stem.
 Drilling is done with viscous fluid known as drilling
fluid, which is a mixture of bentonite or polymer.

4.  Reclaimer ( machine), which removes drilling
cutting and maintains the proper viscosity of
the fluid.
 Drilling fluids are used to remove the
clogging.
 Clogging bore creates back pressure on the
cutting head, slowing production.

5.  Walk- Over Locating System:
 Wire Line Locating System:
 Gyro Based Locating System:

6.  DITCH WITCH
 VERMEER INDIA
 CBRTOBNT
 CHINESE PLAYERS

7.  GMP
 PRAYAG TECNOLOGIES
 ADISHWAR TELE- NETWORKS
 CHINESE PLAYERS

8.  STATIONARY REEL METHOD
 MOVING REEL METHOD

10.  PISTON TYPE
 LAMINAR FLOW TYPE
 MECHANICAL PUSHING ( Cable Jet Type )
 AIR TIGHT DUCT.

11.  Free Air Delivery : 350 CFM
 Nominal Working Pressure : 10.5 Bar

13.  XAHS 186 CU

14.  Model : XAHS 186 CU
 Nominal Effective working Pressure: 12 Bar
 Free Air Delivery: 385 CFM
 Noise level : 71 dB
 Engine Make: Cummins India Ltd.
 Type: 6BT5.9C
 Number of Cylinders: 6
 Bore: 102 mm
 Stroke : 120mm
 HP : 143
 Net Weight Dry: 1739 KG
 Net Weight Wet: 1940 KG

15.  ELGI 400- 175
Specifications:
Free Air Delivery : 400 CFM
Nominal Effective Working Pressure: 12 Bar
Engine: Cummins 6BTA 5.9 C
Power : 169 HP
 Doosan CLP 400
Specifications:
Free Air Delivery : 400 CFM
Nominal Effective Working Pressure: 12 Bar
Engine : Cummins 6BTA 5.9 C
Power : 169 HP

16. Salient Features of Compressor
 Highly efficient screw compressor element.
 Step less regulation system for the quick
response to compressed air needs
 No heat zones anywhere around the body
work.
 Unique cooling air outlet & engine exhaust
routing.
 Heavy Duty parking brakes (Part of the
system) & Adjustable Tow bar.
 Ergonomics applied in achieving minimal
lifting Effort

17. Salient Features of Engine
 Cummins Engine Model (6BT5.9C) popularly
used in construction equipment.
 Low power to the weight ration.
 Highly efficient in fuel economy compared to low
speed automotive engine used now in industrial
application.
 The diesel engine is light in weight, high speed
liquid cooled and environmental friendly

18. HDD SOLICITATION

19.  VIDEO SLIDE ,,, REMOVED BECAUSE OF SPACE
CONSTRAINT..
