A Building Management System (BMS) centralizes and simplifies controlling, monitoring, and managing building services like heating, air conditioning, ventilation and more to achieve a safe, comfortable environment and energy savings. A BMS uses field devices, controllers and a central workstation to control equipment like air handlers, chillers and pumps. It provides features like user-friendly interfaces, alarm management, reporting, data logging, scheduling and remote connectivity. BMS benefits include improved indoor environment, maintenance savings, energy savings, consolidated facility control and improved management reporting.
2. 2 File Number
What is BMS?
- A micro-processor based system which centralizes and simplifies…
controlling
monitoring
operation and…
management
…of heating, air-conditioning, ventilation & other building services to
achieve…
» safe and comfortable working environment
» energy saving & efficient operation
» at reduced time & cost
3. 3 File Number
BMS provides…
Comfortable & safe environment
for your building
by controlling…..
Air Handling Units
Fan Coil Units
Chillers
Pumps
Boilers
VFD’s
and many more…..
4. 4 File Number
Components of BMS
- Centralized WorkStation Computer
With powerful user-friendly software.
Used for everyday building operation.
- Field devices
Temperature, Humidity, Pressure sensors
Valves, Actuators
- DDC Controllers
Micro-processor based
Pre-configured / Freely programmable
Controls the HVAC equipment of the building
5. 5 File Number
LOG-IN
BMS Features….
• Man / Machine Interface
- interact with the connected
technical building equipment.
- user friendly
- for operators…
- engineers….
- and building managers
• System Security
- To prevent unauthorized use
- Password protection
- Operator specific access
- Operator log summary
6. 6 File Number
BMS Features….
• User-friendly data presentation
- co-ordination of the flow of
information through the system by
implementing customized graphics.
- floor plans of the building
- graphical representation of the
equipment.
• Alarm Management
- the presentation in the sequence of
importance and time of..
potentially dangerous situations
process value deviations
- guiding the operator to take
appropriate action through..
audible and visual indications
Email, SMS
- alarm summary
Time, date, priority and description
7. 7 File Number
BMS Features….
• Reporting
- present customized subsets of
data
- actual or historical state
- export as a word or excel
document or..
- to a printer.
• Data Logging
- The automatic gathering and
storage of data from the field
equipment for later analysis and
reporting
- Dynamically or historical
- Customized charts and graphs
- Tabular reports
8. 8 File Number
BMS Features….
• Time Scheduling
- time-based start/stop of the
equipment
- saves energy cost and efficient
operation
- effective for lighting, occupancy
control
- can be as daily, weekly, for holidays
or events
• Event recording
- automatic logging of…
operator activities and commands
processes related to connected
devices
workstations and printers.
9. 9 File Number
BMS Features….
• Remote connectivity
- provide remote access to
the system with full
functionality through..
local area network
dial-up
internet via web browser
10. 10 File Number
BMS Benefits….
• Improved indoor environment
quality
- Comfortable living and working
environment – domestic or
commercial
- Better temperature and humidity
control
- Good air quality
• Faster response to ..
- occupant needs
- end-user complaints
- trouble conditions
11. 11 File Number
BMS Benefits….
• Maintenance Savings.
- efficient control gives less wear and
strain of mechanical equipment.
- provides longer life
- runtime monitoring alerts timely
maintenance of equipment
- avoids expensive failures
• Energy Savings
- eliminates unnecessary system
operation.
- accurate energy usage information
- helps you to take steps to reduce
energy consumption like…
Optimum-Start
Night-Purging
Time-Scheduling
12. 12 File Number
BMS Benefits….
Consolidated facility control…
- One point centralized operation
- Simpler operation
- Reduces time and resources
• Reduced operator training
- on-screen instructions
- user-friendly graphic displays
- simpler operation programmed for
routine and repetitive operation
13. 13 File Number
BMS Benefits….
• Improved management reporting
- Provides valuable real-time data
- Creates reports, charts…
- Critical information immediately sent
to printers, emailed
- or sent via SMS
• Timely and effective control
- alerts your employees when your
facility is not operating correctly
- reduce troubleshooting and down
time.
- Remote access connectivity without
site visits.
14. 14 File Number
BMS Benefits….
• Performance Benchmarking
- Facilitates the overall system
performance measurement
- Comparison with set benchmarks
15. 15 File Number
Almost all applications in building automation are based on a
common functionality
I/O functions
(field devices)
Processing
functions
Management
functions
Operator
functions PagingHelpOperation
Set point rangeCalculation
y = f(x)
Closed loop ctrl.
Recording Supervision
Networking
Alarming
Operat.hours
0 0 0 9 7 8 h
Backup power
control
CountingCharacteristics
Measuring
J
Time programTechn. alarm
MaintenanceEngineering
Interlocks
Peak dem. limit
kWh
s
0 0 2 9 7 3 8
Safety alarm
Data analyses
Man. operation
Positioning
M
Reporting
+ -
Signaling Switching
M
Documentation
