The final phd dissertation of Dr. Corrado Groth. The synergy between advanced mesh morphing and adjoint sensitivity for reshaping shapes according to multi physics performances. Aeronautical and automotive examples, experimentally verified, provide a quantitative evaluation of benefits.
Updating a CAE model (FEM or CFD) to the experimental acquired shape is a key step in the Quality Assessment Process. A workflow based on RBF mesh morphing is proposed and demonstrated on a research case: the wind tunnel test article of the European FP7 project RIBES.
